  1. ADO.NET 2.0 CaptatorTlf: 8620 4242www.captator.dkHenrik Lykke NielsenSoftwarearkitekt, Microsoft Regional Director for Denmarklykke@captator.dkMobil: 2237 3311

  2. Agenda • Providermodellen • Basis klasser og interfaces • Provider factories, Connectionstrenge • Schema API • DataSet, DataTable, DataView • Indexeringsmekanisme, serialisering • SqlBulkCopy • Asynkrone kald • DataBinding

  3. Web/Win Form Controls VS.NET Class Generator XML Parser Kode Cust OLEDB SQL … ADO.NET arkitekturen VS.NET Designers DataSet .NET Data Provider DataAdapter DataReader Item Command Order Connection <xml>…</xml>

  4. Basis klasser og interfaces i 1.1 Bemærk: Læses som at SqlDataAdapter arver fra DbDataAdapter SqlClient • SqlConnection • IDbConnection • SqlCommand • IDbCommand • SqlDataAdapter • DbDataAdapter • DataAdapter • IDataAdapter • IDbDataAdapter • IDataAdapter • SqlDataReader • IDataReader • IDataRecord OleDb • OleDbConnection • IDbConnection • OleDbCommand • IDbCommand • OleDbDataAdapter • DbDataAdapter • DataAdapter • IDataAdapter • IDbDataAdapter • IDataAdapter • OleDbDataReader • IDataReader • IDataRecord

  5. Basis klasser og interfaces i 2.0 SqlClient • SqlConnection • DbConnection • IDbConnection • ISqlConnection • IDbConnection • SqlCommand • DbCommand • IDbCommand • ISqlCommand • IDbCommand • SqlDataAdapter • DbDataAdapter • DataAdapter • IDataAdapter • IDbDataAdapter • IDataAdapter • SqlDataReader • DbDataReader • IDataReader • IDataRecord • ISqlReader • ISqlRecord • IDataRecord OleDb • OleDbConnection • DbConnection • IDbConnection • OleDbCommand • DbCommand • IDbCommand • OleDbDataAdapter • DbDataAdapter • DataAdapter • IDataAdapter • IDbDataAdapter • IDataAdapter • OleDbDataReader • DbDataReader • IDataReader • IDataRecord DbDataAdapter implementerer nu IDbDataAdapter

  6. Interfaces og basis klasse i 1.1

  7. Interfaces og basis klasser i 2.0 • De abstrakte basis klasser befinder sig i System.Data.Common namespacet

  8. Provider factories • System.Data.Common.DbProviderFactory • En abstrakt klasse der er basisklasse for de konkrete factories: SqlClientFactory, OleDbFactory, ... • Metoder: • CreateConnection As DbConnection • CreateCommand As DbCommand • CreateCommandBuilder, CreateConnectionStringBuilder, CreateDataAdapter, CreateParameter, CreatePermission, CreateDataSourceEnumerator, CanCreateDataSourceEnumerator • De konkrete factories har ingen konstruktører, men i stedet en Instance-metode VB Public ReadOnly SharedInstanceAsSqlClientFactory public readonly staticSqlClientFactory Instance C#

  9. Provider factories • System.Data.Common.DbProviderFactories • Util klasse • Metoder: Public Shared Function GetFactory(ByVal providerInvariantName As String) _As System.Data.Common.DbProviderFactory Public Shared Function GetFactory(ByVal providerRow As System.Data.DataRow) _As System.Data.Common.DbProviderFactory Public Shared Function GetFactoryClasses() As System.Data.DataTable VB public static System.Data.Common.DbProviderFactory GetFactory(string providerInvariantName) public static System.Data.Common.DbProviderFactory GetFactory( System.Data.DataRow providerRow) public static System.Data.DataTable GetFactoryClasses() C#

  10. Provider factories • DbProviderFactories er registreret i machine.config GetFactoryClasses giver en DataTable med ovenstående info <system.data> <DbProviderFactories> <addname="Odbc Data Provider" invariant="System.Data.Odbc" support="BF" description=".Net Framework Data Provider for Odbc" type="System.Data.Odbc.OdbcFactory, System.Data, Version=2.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089" /> <addname="OleDb Data Provider" ... /> <addname="OracleClient Data Provider" ... /> <addname="SqlClient Data Provider" ... /> <addname="SQL Server CE Data Provider" ... /> </DbProviderFactories> </system.data>

  11. ConnectionStrenge • System.Data.Common.DbConnectionStringBuilderer et svagt-typet dictionary Dim factory As System.Data.Common.DbProviderFactory factory = DbProviderFactories.GetFactory("System.Data.SqlClient") Dim connBuilder As System.Data.Common.DbConnectionStringBuilder connBuilder = factory.CreateConnectionStringBuilder() connBuilder.Add("Data Source", "localhost") connBuilder.Add("User Id", "DemoUser") connBuilder.Add("Password", "hemmeligt") VB System.Data.Common.DbProviderFactory factory; factory = DbProviderFactories.GetFactory("System.Data.SqlClient"); System.Data.Common.DbConnectionStringBuilder connBuilder; connBuilder = factory.CreateConnectionStringBuilder(); connBuilder.Add("Data Source", "localhost"); connBuilder.Add("User Id", "DemoUser"); connBuilder.Add("Password", "hemmeligt"); C#

  12. ConnectionStrenge • Nedarves af (mere eller mindre) typestærke klasser • OdbcConnectionStringBuilder • Driver, Dsn • OleDbConnectionStringBuilder • DataSource, FileName, Provider, ... • OracleClientConnectionStringBuilder • DataSource, IntegratedSecurity, LoadBalanceTimeout, MaxPoolSize, MinPoolSize, Password, PersistSecurityInfo, Pooling, Unicode, UserID, ... • SqlConnectionStringBuilder • ApplicationName, AsynchronousProcessing, ConnectTimeout, DataSource, Encrypt, FailOverPartner, InitialCatalog, IntegratedSecurity, LoadBalanceTimeout, MaxPoolSize, MinPoolSize, MultipleActiveResultSets, NetworkLibrary, Password, PersistSecurityInfo, Pooling, Replication, UserID, ...

  13. Enumerering af data sources • GetDataSources på en DbDataSourceEnumerator finder datasources (MS SQL) på nettet • System.Data.Sql.SqlDataSourceEnumerator er den eneste konkrete implementation Dim factory As System.Data.Common.DbProviderFactory factory = DbProviderFactories.GetFactory("System.Data.SqlClient") Dim enumerator As System.Data.Common.DbDataSourceEnumerator enumerator = factory.CreateDataSourceEnumerator() Dim dataSourceTable As System.Data.DataTable = enumerator.GetDataSources() VB System.Data.Common.DbProviderFactory factory; factory = DbProviderFactories.GetFactory("System.Data.SqlClient"); System.Data.Common.DbDataSourceEnumerator enumerator; enumerator = factory.CreateDataSourceEnumerator(); System.Data.DataTable dataSourceTable = enumerator.GetDataSources(); C#

  14. Fælles programmeringsmodel • Lettere for Microsoft (og andre) at udvide providere • Mere ensartet programmeringsmodel • Provider factories løser instansieringsproblemet • Gem providerens InvariantName i f.eks. konfiguationsfil • GetFactory der returnerer den enkelte provider factory instans bruger reflektion – så genbrug den! • Brug af basisklasser giver ikke performance overhead • GetFactoryClasses() god til udvikler/admin tools • ConnectionStringBuilders gør det lettere at lave connectionstrenge – men de enkelte er (desværre) ret forskellige

  15. Schema APIet • API til at få schema-oplysninger om en DataSource • DbConnections GetSchema-metode i tre former Public Function conn.GetSchema() As DataTable Public Function conn.GetSchema(collectionName As String) As DataTable Public Function conn.GetSchema(collectionName As String, _ restrictionValues As String()) As DataTable VB public DataTable conn.GetSchema() public DataTable conn.GetSchema(string collectionName) public DataTable conn.GetSchema(string collectionName, string[] restrictionValues) C#

  16. Schema - MetaDataCollections • Få en liste over metadatacollections • Metadata collections: • MetaDataCollections, DataSourceInformation, DataTypes, Restrictions, Users, Databases, Tables, Columns, Views, ViewColumns, ProcedureParameters, Procedures, ForeignKeys, IndexColumns, Indexes, UserDefinesTypes VB Dim tbl As DataTable = conn.GetSchema() ' eller tbl = conn.GetSchema("MetaDataCollections") DataTable tbl = conn.GetSchema(); // eller DataTable tbl = conn.GetSchema("MetaDataCollections"); C#

  17. Schema - DataSourceInformation • Få informationer om datasourcen • Indeholder én row • Muligvis forskellige felter – ens for MS’s providere • DataSourceProductName, DataSourceProductVersion, IdentifierPattern, ParameterMarkerFormat, ParameterMarkerPattern, ParameterNameMaxLength, ParameterNamePattern, QuotedIdentifierPattern, StatementSeparatorPattern, StringLiteralPattern, SupportedJoinOperators, ... VB Dim tbl As DataTable = conn.GetSchema("DataSourceInformation") DataTable tbl = conn.GetSchema("DataSourceInformation"); C#

  18. Schema - restriktioner • Restriktioner er simple filtre for, hvilke entiteter man ønsker metadata for • Restriktioner angives via værdier i et streng array • Restriktioner er defineret i ”Restrictions”-collectionen • Eksempel på brug af restrictioner • Konkrete informationer varierer mellem providere Dim res AsString(3) res(1) = "Person" res(2) = "Contact" Dim tbl As System.Data.DataTable = conn.GetSchema("Columns", res) VB string[] res = newstring[4]; res[1] = "Person"; res[2] = "Contact"; System.Data.DataTable tbl = conn.GetSchema("Columns", res); C#

  19. DataSet, DataTable - performance • Ny indexeringsmekanisme giver markant forbedret performance ved for eksempel Fill og Merge public System.Data.DataTable CreateDataTable(int numberOfRows) { System.Random rnd = new System.Random(); System.Data.DataTable tbl = new System.Data.DataTable(); tbl.Columns.Add("Id", typeof(System.Guid)); tbl.Columns["Id"].Unique = true; tbl.Columns.Add("RandomValue", typeof(int)); for (int n = 0; n < numberOfRows; n++) { System.Data.DataRow row = tbl.NewRow(); row["Id"] = System.Guid.NewGuid(); row["RandomValue"] = rnd.Next(); tbl.Rows.Add(row); } return tbl; } C#

  20. DataSet, DataTable - performance • Resultater

  21. Dataset, DataTable - serialisering • DataSets og DataTables serialiserer sig selv som XML uanset man bruger en BinaryFormatter • Kan nu fortælle, at der skal serialiseres binært • RemotingFormat-propertyen kan sættes til • System.Data.SerializationFormat.Xml (default) • System.Data.SerializationFormat.Binary

  22. Dataset, DataTable - serialisering tbl.RemotingFormat = System.Data.SerializationFormat.Binary Dim formatter AsNew BinaryFormatter() Dim st AsNew FileStream(fileName, FileMode.Create) formatter.Serialize(st, tbl) st.Close() • Eksempel med 100.000 simple rows skrevet til fil • XML-format: 16.813 KB – 19.851 KB • Binært format: 835 KB – 3.374 KB VB tbl.RemotingFormat = System.Data.SerializationFormat.Binary; BinaryFormatter formatter = newBinaryFormatter(); FileStream st = newFileStream(fileName, FileMode.Create); formatter.Serialize(st, tbl); st.Close(); C#

  23. DataTable - XML • XML understøttelse som for DataSets:ReadXml, ReadXmlSchemaWriteXml, WriteXmlSchema

  24. DataSet, DataTable, DataReader • Populér DataTable/DataSet ud fra DataReader • Generer DataReader ud fra DataTable/DataSet • Hvis CreateDataReader kaldes på et DataSet med flere tabeller vil DataReaderen indeholde multiple resultset 'Tag fat i en database … Dim dr As System.Data.SqlClient.SqlDataReader = cmd.ExecuteReader() Dim tbl As New System.Data.DataTable() tbl.Load(dr) VB //Tag fat i en database … System.Data.SqlClient.SqlDataReader dr = cmd.ExecuteReader(); System.Data.DataTable tbl = new System.Data.DataTable(); tbl.Load(dr); C# VB Dim tbl As System.Data.DataTable = LavEnDataTable() Dim dr As System.Data.DataTableReader = tbl.CreateDataReader() System.Data.DataTable tbl = LavEnDataTable(); System.Data.DataTableReader dr = tbl.CreateDataReader(); C#

  25. DataTable, DataView • Generer en DataTable ud fra et DataView Dim tbl As System.Data.DataTable = LavEnDataTable() Dim view As New System.Data.DataView(tbl) view.Sort = "FirstName ASC, LastName DESC" view.RowFilter = "FirstName>'C'" Dim columnNames AsString() = { "FirstName", "LastName" } Dim tblFiltered As System.Data.DataTabletblFiltered = view.ToTable("MinFiltreredeTabel", False, columnNames) VB System.Data.DataTable tbl = LavEnDataTable(); System.Data.DataView view = new System.Data.DataView(tbl); view.Sort = "FirstName ASC, LastName DESC"; view.RowFilter = "FirstName>'C'"; string[] columnNames = { "FirstName", "LastName" }; System.Data.DataTable tblFiltered;tblFiltered = view.ToTable("MinFiltreredeTabel", false, columnNames); C#

  26. Connection statistik - SqlClient • StatisticsEnabled, RetrieveStatistics conn.StatisticsEnabled = true; System.Collections.Hashtable statistics = (System.Collections.Hashtable)_conn.RetrieveStatistics(); txtStatistics.Text = ""; foreach (string key in statistics.Keys) { txtStatistics.Text += key.PadRight(20, ' ') + "= " + statistics[key].ToString() + "\r\n"; } C# NetworkServerTime = 50 BytesReceived = 20989728 UnpreparedExecs = 12 SumResultSets = 12 SelectCount = 12 PreparedExecs = 0 ConnectionTime = 113202 ExecutionTime = 3194 Prepares = 0 BuffersSent = 12 SelectRows = 239664 ServerRoundtrips = 12 CursorOpens = 0 Transactions = 0 BytesSent = 1968 BuffersReceived = 2628 IduRows = 0 IduCount = 0

  27. Multiple Active ResultSets (MARS) • SQL Server 2005 feature • Man kan nu have flere resultsets åbne på samme tid– flere DataReadere om en connection (hver sin command) SqlClient.SqlConnection conn = new SqlClient.SqlConnection(connString); conn.Open(); SqlClient.SqlCommand cmd1 = new SqlClient.SqlCommand(sql1, conn); SqlClient.SqlDataReader rd1 = cmd1.ExecuteReader(); rd1.Read(); rd1.Read(); rd1.Read(); rd1.Read(); rd1.Read(); rd1.Read(); SqlClient.SqlCommand cmd2 = new SqlClient.SqlCommand(sql2, conn); SqlClient.SqlDataReader rd2 = cmd2.ExecuteReader(); rd2.Read(); rd1.Read(); rd2.Read(); rd2.Close(); rd1.Close(); conn.Close(); C# Op til 9 poolede commands per connection

  28. UpdateBatchSize og SqlBulkCopy • DbDataAdapter.UpdateBatchSize property påvirker DbDataAdapter.Update • System.Data.SqlClient.SqlBulkCopy påvirker performance • 100.000 rows i en DataTable • DbDataAdapter.Update tog 70 sekunder (BatchSize=100) • SqlBulkCopy.WriteToServer tog 3 sekunder System.Data.DataTable tbl = CreateDataTable(100000); System.Data.SqlClient.SqlBulkCopy bulk = new System.Data.SqlClient.SqlBulkCopy(connString); bulk.DestinationTableName = "RandomTable"; bulk.WriteToServer(tbl); bulk.Close(); C#

  29. Asynkrone kald • Asynkrone kommandoer i ADO.NET 1.1 og ADO.NET 2.0 • I 1.1 er det muligt at lave asynkrone kald ved at bruge ThreadPool eller asynkrone delegates – en baggrundstråd blokeres • Asynkrone kommandoer i 2.0 blokerer ingen baggrundstråde • Brugen af asynkrone kommandoer til ADO.NET (SqlClient) • I scenarier hvor det er vigtigt ikke at blokere tråde (fx. Web apps) • Designet som resten af de asynkrone arkitekturer i .NET • Xxx => BeginXxx med input-parms og EndXxx med output-parms og retur-værdi

  30. Asynkrone kald • Opsætning • ”Asynchronous Processing=true” eller ”async=true” i Connectionstring • Brug forskellige connections til synkrone og asynkrone connections (af hensyn til performance) • Der findes 4 måder at afslutte et asynkront kald på: • Callback – angiv metode der skal kaldes når arbejde udført • Synkroniseringsobjekt – koordinering af asynkrone kald via WaitHandle • Polling – check på IAsyncResults property IsCompleted • Kald EndXxx som vil blokere indtil det asynkrone kald er færdigt • Vær opmærksom på: • Kald EndXxx, når et asynkront kald er færdigt (for at undgå ressource-leaks) • Der kan kastes exceptions ved både BeginXxx og EndXxx

  31. DataBinding • System.Windows.Forms.BindingSource fungerer • som en datakilde for kontroller • som en mekanisme for opdatering af data • som et datalager (datasource) i sig selv • Kan bindes til forskellige datasources • Simple objekter (benytter properties) • Lister såsom ArrayList • Komplekse datakilder såsom DataTables

  32. DataBinding • Sæt BindingSources DataSource-property til datakilden • DataSource kan også sættes til en System.Type • Informationen videregives til kontroller der bindes Dim binding As System.Windows.Forms.BindingSource binding = New System.Windows.Forms.BindingSource() grdPerson.DataSource = binding Dim p As Person p = New Person("Mr", "Anders", "And", "a.and@andeby.com") binding.Add(p) p = New Person("Ms", "Andersine", "And", "a2.and@andeby.com") binding.Add(p) p = New Person("Mr", "Mikkel", "Mus", "m.mus@andeby.com") binding.Add(p) VB

  33. DataBinding • Events såsom: • AddingNew, CurrentItemChanged, PositionChanged • ListChanged(ListChangedType: Added, Changed, Removed, Moved, ...) • Properties såsom: • Current, Filter, Position, Sort, ListCount • Metoder såsom: • Move*, Add, Clear, Remove, RemoveFIlter, RemoveSort • ResetBindings-metoden fortæller kontrollerne, at data har ændret sig

  34. DataBinding- BindingNavigator • En video kontrol der kan bruges til navigering og redigering • Sæt BindingNavigator-komponentens BindingSource-property til et BindingSource objekt • ToolStripButtons kan let tilføjes og fjernes

  35. Spørgsmål www.captator.dknyheder, artikler, information, ...
