Presentation Transcript


Improving the structure of existing code


refactoring the idea
Refactoring, the idea
  • Make software more supportable
    • Understandable
      • By other programmers and other human readers
    • Maintainable
      • Correcting errors
      • Adapting to new requirements
      • Introducing new qualities.
    • Scalable
      • Scale up in response to growth in demand for its functionality
        • More users
        • More CPU’s


refactoring targets bad smells in code
Refactoring targets“Bad smells in code”
  • Duplicated code
  • Long method
  • Large class
  • Long parameter list
  • Shotgun surgery
    • A simple change spreads over several classes.
  • Feature envy
    • Method uses a lot of methods from other classes
  • Data clumps
    • Same data clumps in many classes
      • Example: first name, last name, address
  • Explaining comments
    • Comments often cover (try to explain) code that is otherwise difficult to read.


categories of refactorings
Categories of refactorings
  • Composing methods
  • Moving features between objects
  • Organizing data
  • Simplifying conditional expression
  • Making method calls simpler
  • Dealing with generalization


some refactoring methods refactorings
Composing methods

Extract method

Introduce explaining variable

Remove assignments to parameters

Moving features between objects

Move method

Move field

Extract class

Inline class

Organizing data

Replace magic number with symbolic constant

Encapsulate field

Encapsulate collection

Simplifying conditional expressions

Remove control flag

Replace conditional with polymorphism

Introduce assertion

Making method calls simpler

Rename method

Remove setting method

Hide method

Replace constructor with factory method

Replace error code with exception

Replace exception with test

Dealing with generalization

Pull up field

Pull up method

Pull up constructor body

Extract subclass

Extract superclass

Extract interface

Replace inheritance with delegation

Some refactoring methods (refactorings)


composing methods
Composing methods
  • Common problems (“smells in code”)
    • Long method
    • Duplicated code
    • Comments to explain hard-to-understand code
  • Refactorings
    • Extract method
      • Turn a code fragment into a method whose name explains the purpose of the method
        • Comment no longer necessary
    • Introduce explaining variable
      • Put the result of an expression in a temporary variable with a name that explains the purpose.
    • Remove assignments to parameters
      • Use a temporary variable


moving features between objects
Moving features between objects
  • Common problems
    • Data class
      • A class with only get and set methods, and nothing else
    • Feature envy
      • A method is more interested in other classes methods than in it own class’ methods.
    • Large class
  • Refactorings
    • Move method
      • Move a method from one class to another
    • Move field
      • Move a field from one class to another
    • Extract class
      • Create a new class and move field + methods to the new class. (Rest of) old class references the newly extracted class.
    • Inline class
      • Move fields + methods to another class.


organizing data
Organizing data
  • Common “smells”
    • Explaining comments
    • Public fields
  • Refactorings
    • Replace magic number with symbolic constant
      • Area = 3.14159265 * r * r; // bad
      • Static final int PI = 3.14159265;
      • Area = PI * r * r; // better
    • Encapsulate field
      • Public fields are bad
      • Use private field + get / set methods
    • Encapsulate collection
      • Methods must generally return read-only views of collections


simplifying conditional expressions
Simplifying conditional expressions
  • Common “smells”
    • Lots of conditions in loops.
  • Refactorings
    • Remove control flag
      • Don’t use a lot of conditions in a loop. Use break or return (or continue)
    • Replace conditional with polymorphism
      • If you have different types of objects from the same class consider making subclasses.
    • Introduce assertion
      • If you have any assumptions about the state of the program, you should make an assertion in the program
        • assert object != null


making method calls simpler
Making method calls simpler
  • Refactorings
    • Rename method
      • If the method name does not reveal the methods purpose, rename the method.
    • Remove setting method
      • If the field is supposed to be read-only, remove the set method.
    • Hide method
      • If the method is not used by other classes, make the method private
    • Replace constructor with factory method IMPORTANT!
      • If you want to do more than simple creation, use a factory method.
      • Example: java.text.DateFormat
    • Replace error code with exception
      • -1 or null might not be appropriate error codes
    • Replace exception with test
      • Give the caller a chance to test the condition of an object before calling the real method.
      • Example: java.util.Iterator


dealing with generalization
Dealing with generalization
  • Refactorings
    • Pull up field
      • Two subclasses have the same field
    • Pull up method
      • Two subclasses have the same method
    • Pull up constructor body
      • Two subclasses have constructors with similar bodies
    • Extract subclass
      • A class has features that are use only in some instances.
      • Create a subclass for that subset of features.
    • Extract superclass
      • Two classes with similar features.
      • Create a superclass with the common features.
    • Extract interface
      • Several clients use the same subset of features of a class.
      • Extract the subset into an interface
    • Replace inheritance with delegation IMPORTANT!
      • Subclass uses only a part of a superclass
        • Example (don’t do this at home): Stack extends Vector
        • Properties extends HashTable
      • Use delegation


unit testing
Unit testing
  • Before you do any refactoring you must have a reliable unit test.
  • Run the test before the refactoring.
  • Run the test after the refactoring
    • To check that nothing bad happened due to the refactoring.


small steps
Small steps
  • Refactoring must be done in small steps.
    • Don’t assume that you can do a lot in one big step.
  • Example: Extract class
    • Create the new (but empty class)
    • Make a link from the old to the new class
    • Use move field (another refactoring) to move fields to the new class
      • Run test after each separate move
    • Use move method (another refactoring) to move methods to the new class.
      • Run test after each separate move
    • Decide whether to expose the new class
      • Should if be public or not?


refactoring is not debugging
Refactoring is not debugging
  • Your program must be working and tested before you start refactoring.
  • If your refactoring reveals a previously unknown bug
    • Stop refactoring
    • Write an new test case that shows the bug
    • Run the new test case
    • Do your debugging
    • Run the test case: Now shows that the bug has gone
    • Go back to refactoring


netbeans assistance
NetBeans assistance
  • NetBeans can help do simple refactorings
    • Rename a class, method, or field
      • Across all files in a project
    • Move class from one package to another
    • Encapsulate field
      • Make the field private
      • Generate get and set methods
    • Change parameters to a method
      • Across al files in a project
    • Extract method
    • And many other refactorings


  • PMD scans Java source code and looks for potential problem (smells) like
    • Possible bugs
    • Dead code
    • Sub-optimal code
    • Overcomplicated expressions
    • Duplicate code
  • PMD suggests simple refactorings
  • PMD is a plugin for NetBeans, and other IDEs


  • RefactorIT is a plug-in to NetBeans
    • And other IDE’s
  • RefactorIT can detect simple smells in your code
    • Use the Auditsfeature
    • Like PMD, but more rules …
  • RefactorIT can assist you in doing several refactorings
    • basically the same as NetBeans
  • Unfortunately RefactorIT only works with NetBeans 5.5



Fowler et al.Refactoring: Improving the Design of Existing Code, Addison Wesley 1999. Chapter 1 Refactoring, a First Example, page 1-52.

  • This is THE book on refactoring

Martin Fowler w Catalog of refactorings

William C. Wake Extreme Programming Explored, Addison Wesley 2002

  • Chapter 2. Refactoring, page 23-43

Maciaszek & LiongPractical Software Engineering, Addison Wesley 2005. Chapter 15 Architectural Refactoring, page 478-508

  • Modern books on software engineering has chapters on refactoring

Joshua KerievskyRefactoring to Patterns, Addison Wesley Professional 2005

The code

Arie van Deursen et al.Refactoring Test Code,

  • Any code can benefit from refactoring, even test code.
