Presentation Transcript

Slide2 l.jpg

Equipment and Software Needed Modbus

  • MLC 9000 BCM with Modbus and appropriate number LCM’s

  • AB SLC 5/03 CPU or higher, Power Supply and Rack

    • 5/03 is smallest CPU to support M0/M1 file transfer

  • ProSoft MCM3150 Modbus Communications Card

  • RSLogix 500 Programming Software for SLC500

  • Programming Cable for SLC500

  • West.RSS Driver File

  • Communication Cable between MLC9000 and MCM3150 Card


Slc500 backplane communications basics l.jpg
SLC500 Backplane Communications Basics Modbus

  • SLC 500 is a modular PLC

    • Racks can be configured with a wide variety of modules

  • PLC CPU receives information from modules in rack via one of two ways

    • I/O Transfer

      • Used with Analog or Digital I/O Modules where small amounts of information are being passed

    • Block Transfer via M0/M1 Files

      • Used for large blocks of data

      • M0/M1 files are local to the module

      • Information must be transferred form M0/M1 files into usable registers

        • Process is known as Block Transfer


Slc500 backplane communications basics4 l.jpg
SLC500 Backplane Communications Basics Modbus

Integer File

Integer File

M0

M1

...

...

...

...

Block Transfer Example


Setting up the prosoft 3150 mcm l.jpg
Setting Up the ProSoft 3150-MCM Modbus

  • Verify Jumpers are in position for RS485 2-Wire (Factory Default)


Setting up communications between pc and slc500 l.jpg
Setting Up Communications between PC and SLC500 Modbus

  • From Start Menu, start RSLinx under Rockwell Software

  • Under Communications, select Configure drivers


Setting up communications between pc and slc5007 l.jpg
Setting Up Communications between PC and SLC500 Modbus

  • From Available Driver Types select 1747-PIC/AIC+ Driver


Setting up communications between pc and slc5008 l.jpg
Setting Up Communications between PC and SLC500 Modbus

  • Set station number to 31, pick open comm. port on PC


Setting up communications between pc and slc5009 l.jpg
Setting Up Communications between PC and SLC500 Modbus

  • Close window then reboot PC to start driver


Loading the driver for the 3150 mcm l.jpg
Loading the Driver for the 3150-MCM Modbus

From Start Menu, load RSLogix 500


Loading the driver for the 3150 mcm11 l.jpg
Loading the Driver for the 3150-MCM Modbus

Select File, then Open and select the directory that West.RSS is stored in.



Loading the driver for the 3150 mcm13 l.jpg
Loading the Driver for the 3150-MCM Modbus

  • From Menu Bar on Left, Double-Click on IO Configuration

  • Verify Configuration for correct number of racks and position of modules


Loading the driver for the 3150 mcm14 l.jpg
Loading the Driver for the 3150-MCM Modbus

  • From Menu on left, under Data Files, double-click on N255 West

  • Adjust N255:110 to the proper number of loops in the system


Loading the driver for the 3150 mcm15 l.jpg
Loading the Driver for the 3150-MCM Modbus

  • N255:111-N255:142 Contain the Modbus Addresses for up to 32 loops

  • Adjust these files to match Modbus Addresses of LCM’s


Loading the driver for the 3150 mcm16 l.jpg
Loading the Driver for the 3150-MCM Modbus

  • To begin download, first go to communications menu and select System Comms


Loading the driver for the 3150 mcm17 l.jpg
Loading the Driver for the 3150-MCM Modbus

  • Select PLC to download program to

  • Select Download


Loading the driver for the 3150 mcm18 l.jpg
Loading the Driver for the 3150-MCM Modbus

  • Select OK to begin download


Loading the driver for the 3150 mcm19 l.jpg
Loading the Driver for the 3150-MCM Modbus

Press Yes to Go Online


Completing communications between 3150 mcm and mlc9000 l.jpg
Completing Communications between 3150-MCM and MLC9000 Modbus

MLC9000 to ProSoft 3150-MCM Cable Pin-out (RS485)

3150-MCM

MLC 9000

9

5 (A)

1

4 (B)

5

3 (GND)

7

8


Diagnostics on 3150 mcm l.jpg
Diagnostics on 3150-MCM Modbus

  • Eight indicator lights on module used as communications diagnostics


Mlc 9000 parameters l.jpg
MLC 9000 Parameters Modbus

  • N250 File used to hold parameters read from MLC 9000 loops 1-16

  • N250:XXX-address of parameter to be accessed

  • Read-Only data, to be used by PLC or HMI for reference

  • File N251 used for loops 17-32


Mlc9000 parameters l.jpg
MLC9000 Parameters Modbus

  • Alarm Words are broken down into sixteen read accessible bits

  • Bits are accessed through address format N250:XXX/XX


Mlc9000 parameters24 l.jpg
MLC9000 Parameters Modbus

  • N254 File used for data to be written to MLC9000

  • N254:XXX-address format used for accessing write data

  • Data has Read/Write capabilities, can be manipulated by PLC or HMI


Mlc9000 parameters25 l.jpg
MLC9000 Parameters Modbus

  • Control Bits are broken down into 16 Read/Write bits

  • Parameters are addressed in N254:XXX/XX format
