1. Whats New in Neuroanesthesia? Irene P. Osborn, MDAssociate Professor of AnesthesiologyMount Sinai Medical Center
2. 3
3. 4 Goals of Neuroanesthesia To maintain or improve intracranial dynamics
To provide optimal operating conditions
To produce an awake patient forneurologic evaluation
4. Neurosurgical Procedures: Challenges Vasospasm, ICP, neurologic deficit
Ischemia, hyperemia
Painful stimuli (laryngoscopy, intubation, mayfield clamp)
Retractor pressure, temporary clipping
5. 6 Whats New? New procedures
New anesthetic agents/ techniques
New monitors
New thinking
6. 7 What hasnt changed? Intracranial components
Intracranial elastance (compliance) curve
Regulation of cerebral blood flow (CBF) by metabolic and chemical factors
Autoregulation and "coupling" of CBF to metabolic activity
7. 8 The Adult Brain: Blood Flow CBF= 45-54 ml/100gm/min
750 ml/min
CSF=150 ml, entire volume replaced 3-4 times/day
8. 9 Intracranial components Brain tissue- 80%
Blood- 12%
CSF- 8%
9. 10 Intracranial Elastance and Adverse Consequences of Increasing Intracranial Volume Increases in the volume of an intracranial compartment will eventually exhaust compensatory mechanisms (the flat part of the elastance curve). Gradual increases in intracranial volume are better tolerated than acute increases. As the "knee" of the curve is approached, small increments in intracranial volume generate large increases in intracranial pressure (ICP).
Increasing intracranial volume, and therefore eventually increasing ICP, can lead to morbidity through a number of mechanisms:
(1) Because of pressure differentials across brain compartments, brain tissue may herniate transluminally across the falx, through the foramen magnum or across a cranial defect.
(2) Increased brain volume can make surgical exposure extremely difficult, leading to brain herniation through the dural incision and to retractor- induced ischemia.
(3) Because cerebral perfusion pressure is determined by the difference between mean arterial pressure and ICP, intracranial hypertension may lead to underperfusion of cerebral tissue.
Drummond JC, Patel PM. Neurosurgical anesthesia. In: Miller RD, ed. Anesthesia. 5th ed. Philadelphia, Pa: Churchill Livingstone; 2000:1895-1933.
Increases in the volume of an intracranial compartment will eventually exhaust compensatory mechanisms (the flat part of the elastance curve). Gradual increases in intracranial volume are better tolerated than acute increases. As the "knee" of the curve is approached, small increments in intracranial volume generate large increases in intracranial pressure (ICP).
Increasing intracranial volume, and therefore eventually increasing ICP, can lead to morbidity through a number of mechanisms:
(1) Because of pressure differentials across brain compartments, brain tissue may herniate transluminally across the falx, through the foramen magnum or across a cranial defect.
(2) Increased brain volume can make surgical exposure extremely difficult, leading to brain herniation through the dural incision and to retractor- induced ischemia.
(3) Because cerebral perfusion pressure is determined by the difference between mean arterial pressure and ICP, intracranial hypertension may lead to underperfusion of cerebral tissue.
Drummond JC, Patel PM. Neurosurgical anesthesia. In: Miller RD, ed. Anesthesia. 5th ed. Philadelphia, Pa: Churchill Livingstone; 2000:1895-1933.
10. 11 Cerebral blood flow Varies with metabolic activity
15-20ml/100g/min can produce flat EEG
<10ml/100g/min associated with irreversible brain damage
11. Deliberate Hyperventilation CBF is proportional to arterial carbon dioxide tension
Change in CBF of 2ml/100gm/minper 1mmHg PaCO2 change
Lower limit produces vasoconstriction and tissue hypoxia
Effect is mediated by increase in perivascular pH, which lasts about 6 hours
12. Management of hyperventilation
13. 14
14. Cerebral Perfusion Pressure (CPP) = MAP-ICP Normal CPP= 80 mmHgAvoid < 70 mmHg
15. 16 Methods To Acutely DecreaseIntracranial Pressure Head up position
Deliberate hyperventilation
Barbiturates/sedatives
Osmotic/renal tubular diuretics
CSF drainage
16. Drainage of cerebral venous blood Cerebral blood volume vs. body position
17. Perioperative morbiditysupratentorial craniotomy
18. Concepts of anesthesia in neurosurgeryA 2004 survey among neuroanesthesia departments in Germany
19. 20 Anesthetic Techniques Short-acting volatile agents for neurosurgical procedures
Total intravenous anesthesia with remifentanil/propofol
Dexmedetomidine as a component of anesthesia
Use of nitrous oxide (?)
20. 21 Inspired and Alveolar Anesthetic Concentrations The rate of rise of the alveolar concentration (FA) toward the inspired concentration (FI) increases with decreasing solubility (Yasuda et al). The rate of rise for nitrous oxide is augmented by the concentration effect (Eger).
Yasuda N et al. Anesth Analg. 1991;72:316-324.
Eger EI II. Desflurane (SupraneŽ). A Compendium and Reference. Rutherford, NJ: Healthpress Publishing; 1993.
The rate of rise of the alveolar concentration (FA) toward the inspired concentration (FI) increases with decreasing solubility (Yasuda et al). The rate of rise for nitrous oxide is augmented by the concentration effect (Eger).
Yasuda N et al. Anesth Analg. 1991;72:316-324.
Eger EI II. Desflurane (SupraneŽ). A Compendium and Reference. Rutherford, NJ: Healthpress Publishing; 1993.
21. 22 Volatile Anesthetics andCerebral Blood Flow Autoregulation Over a wide range of arterial blood pressures, CBF does not change, due to autoregulation. When pressure is too low, autoregulation cannot cause dilation sufficient to maintain flow.
In normal brain, blood flow is controlled by autoregulatory mechanisms. This is generally assumed to result in stable flow over a range of perfusion pressures from 50 to 150 mm Hg. Volatile anesthetics interfere with autoregulation in a dose-dependent manner. Even at moderate doses, CBF may become largely pressure-dependent.
When autoregulation is impaired (in ischemia, brain trauma, vascular malformations, and brain tumors), increases in blood pressure may directly affect CBF and, presumably, cerebral blood volume and ICP.
Volatile anesthetic agents may produce cerebral vasodilation, leading to increases in CBF and CSF pressure. Therefore, the CBF effects of halothane, isoflurane, and the newer inhalational agents desflurane and sevoflurane may influence important and critical neuroanesthetic parameters.
Drummond JC, Patel PM. Cerebral physiology and the effects of anesthetics and techniques. In: Miller RD, ed. Anesthesia. 5th ed. Philadelphia, Pa: Churchill Livingstone; 2000:695-733.Over a wide range of arterial blood pressures, CBF does not change, due to autoregulation. When pressure is too low, autoregulation cannot cause dilation sufficient to maintain flow.
In normal brain, blood flow is controlled by autoregulatory mechanisms. This is generally assumed to result in stable flow over a range of perfusion pressures from 50 to 150 mm Hg. Volatile anesthetics interfere with autoregulation in a dose-dependent manner. Even at moderate doses, CBF may become largely pressure-dependent.
When autoregulation is impaired (in ischemia, brain trauma, vascular malformations, and brain tumors), increases in blood pressure may directly affect CBF and, presumably, cerebral blood volume and ICP.
Volatile anesthetic agents may produce cerebral vasodilation, leading to increases in CBF and CSF pressure. Therefore, the CBF effects of halothane, isoflurane, and the newer inhalational agents desflurane and sevoflurane may influence important and critical neuroanesthetic parameters.
Drummond JC, Patel PM. Cerebral physiology and the effects of anesthetics and techniques. In: Miller RD, ed. Anesthesia. 5th ed. Philadelphia, Pa: Churchill Livingstone; 2000:695-733.
22. 23 Propofol Advantages:
rapid onset of effect
rapid recovery
decrease CBF,ICP,CMRO2
neurophysiologic monitoring Disadvantages:
potential hypotension
? prolonged action
reliance on I.V. access
Cost
23. 24 Remifentanil for Craniotomy Excellent control of BP and HR with easy titration
Rapid emergence despite durationof case
No increase in CBFor ICP Potential for hypotension in elderly, debilitated
Must be controlled throughout (NIVA?)
No residual analgesia
24. 25 TIVA forNeurosurgical Anesthesia Pts with decreased intracranial compliance
Avoidance of nitrous oxide
Neurophysiologic monitoring
25. Effect of Dexmedetomidine on ICP Animal model
ICP was unchanged despite an increase in systemic blood pressure in rabbits
ICP was decreased in the presence of intracranial hypertension
Zornow MH et al, Anesth Analg 1992
Human study
Dex has no effect on lumbar CSF pressure in patients undergoing transphenoidal pituitary tumor resection
Talke P et al. Anesth Analg 1997
26. 27
27. Scalp Block Supplemental analgesia for craniotomy
Ablation of hemodynamic response to pin fixation
Anesthesia and analgesia for awake craniotomy
Stereotactic biopsy
Postoperative pain relief following craniotomy
28. Effect of ropivacaine skull block on perioperative outcomes in patients with supratentorial brain tumors and comparison with remifantanil: a pilot study Gazoni FM, Pouratian N, NemergutJ Neurosurg 2008 109:44.
29. Skull Block 30 patients received skull block or none
Pts in skull block group did not have a significant increase in HR and MAP during pinning
No difference in blood pressure variability between the groups
No difference in VAS scores postoperatively
30. 31 Neurosurgical Positioning For surgical access
Physiologic phenomena
Potential for injury
31. Effects of head posture on cerebral hemodynamics: its influences on intracranial pressure, cerebral perfusion pressure, and cerebral oxygenation Ng I, Lim J, Wong HBNeurosurgery 2004; 54:593.
32. Head position Positioning is everything!
Avoidance of neck flexion
33. 34 Subarachnoid Hemorrhage:Evolution of Technique 1980s
Late surgery
Restrict fluids
Induced hypotension 1990s
Urgent surgery
Emphasis on cerebral perfusion
Temporary clips
HHH therapy
34. 35 Anesthetic Technique Avoidance of acute hypertension
Provision of intraoperative brain relaxation
Maintenance of perfusion pressure to prevent critical reduction of CBF
Ability to perform precise manipulations of MAP as surgeon attempts to clip or control bleeding
35. 36 Mannitol Osmotic diuretic
Causes reduction of brain water
Onset- 15-20 min
Duration of effectiveness- hrs to days
36. Fluid Management Increased emphasis on cerebral perfusion
Isotonic solutions to maintain hemostasis and replace diuresis
Use of normal saline and hypertonic saline
Packed RBCs for blood replacement
37. 38 Brain Injury & Glucose Hypo-osmolar glucose (D5W)
Increases Cerebral Edema
Increases ICP
Induces Hyperglycemia Which Exacerbates Ischemic Injury
38. 39 Temperature &Cerebral Metabolism Cerebral Metabolism is Decreased 6 7 % Per 1? C Decrease In Temperature.
Fever is Known To Worsen Postoperative Ischemic Outcome
39. 40 IHAST Trial 1000 patients for aneurysm clipping
Randomized to receive normothermia vs. moderate hypothermia (33.3 ş)
Patients warmed by end of surgery
No difference in outcome betweenthe groups
40. Hypothermia and Cerebral Aneurysm surgery IHAST-2
41. 42 How do we protect the brain? Appropriate anesthetics and doses
Avoidance of ischemia (normocarbia)
Avoidance of hyperthermia
Maintainance of cerebral perfusionpressure
Communication (keeping control)with neurosurgeon
42. 43 Aneurysm rupture! Decrease MAP(with a bolus of thiopental or propofol)
Increase oxygen
Open fluids
Apply ipsilateral carotid pressure
43. 44 Radiology Suite vs. OR Location / anatomy of the aneurysm
Age and grade of the patient
Skill of the facility
Luck of the draw
44. 45 Endovascular Coiling Anterior or posterior circulation aneurysm
Medical contraindications to surgery
Advanced age
Pt. preference (unruptured)
45. Anesthesia for aneurysm coiling GA with ETT (possible LMA)
Patient must NOT move
Normocapnia and stable VS
Radial artery line, especially if acute SAH 46
46. More indications for general anesthesia Inducing coma with pentobarbital
Treatment of status epilepticus
Emergency craniotomy
48. 49 Embolization of AVM
49. Emergence from anesthesia Should occur if patient lucid before surgery
Should be smooth with minimal
Couching, straining, hypertension
Facilitate with IV lidocaine, betablockers, propofol if necessary
50. Why isnt he patient waking up? Anesthetic agents
Metabolic state
Temperature
Intraoperative problems
51. Decision time Not breathing
Breathing but comfortable
Fighting, bucking but not responsive to commands
52. Pain in neurosurgical patients:A prospective observational study More painful than anticipated
Anticipated pain independent of operation type or preoperative pain intensity
Preoperative pain promotes postoperative analgetic requirements
ivPCA better than on demand
53. 54 Advantages of Airway Control with ETT Controlled ventilation
decreased ICP
decreased CBF
Prevention of aspiration
Facilitates positioning
54. 55 Awake craniotomy Careful monitoringof drug effects
Response to stimulation
Improved ability to awaken patients
55. 56 Awake Craniotomy Requires: Sufficient depth of anesthesia during openning and closing bone flap
Full consciousness during cortical mapping
Smooth transition between anesthesia and consciousness
Adequate ventilation
Patient immobility and comfort throughout
56. 57 Complications of Awake Craniotomy Hypoventilation
Hypoxemia
Seizures
Nausea
57. Anaesthesia for awakecraniotomy-evolution of atechnique that facilitatesawake neurological testing Sarang A, Dinsmore JBJA 2003; 90:161 58
58. Anesthetic agents for deep brain stimulation Nothing!
Propofol
Remifentanil
Dexmedetomidine
59
59. 60 Trends Out:
Deep hypothermia
Prolonged hyperventilation
Certain anesthetic agents
Hypovolemia
Nitroprusside In:
Short acting agents
Rapid recovery
Emphasis on cerebral perfusion pressure
Appropriate fluid replacement
Nicardipine
60. 61 Conclusions Future of neurosurgery
Goals for neuroanesthesia
Careful understanding and evaluation of patients
Communication and cooperation with neurosurgeons
61. 62 Thank you!
