Presentation to the International Ice Charting Working Group VI26 October, 2005

Ice In ECDIS

(Reaching out to our marine users)

C. Douglas O’Brien

Timothy V. Evangelatos


Ice in ecdis overview l.jpg
Ice In ECDIS - Overview

  • ECDIS and its Potential for Safer Navigation

  • Vision for “Ice In ECDIS” and its History

  • Base Standards incorporating Ice Objects

  • Status of Ice Objects/Registry

  • Authority for Ice Objects

  • Conclusions and Recommendations

  • Future Steps


Ecdis and its potential for safer navigation l.jpg
ECDIS and its Potential for Safer Navigation

  • Marine Electronic Highway (MEH)

  • Power of ECDIS lays in integration of databases

  • Delivering INTERNET onboard at low cost is key Organize bridge for real time information

  • Optimize use of smart data in an enhanced “intelligent” marine transportation system for safer navigation, environmental protection and marine transportation efficiency

per Captain John Pace, Ice In ECDIS, June 2000


Enc electronic navigational chart st lawrence river area l.jpg
ENC – Electronic Navigational ChartSt Lawrence River Area

Canadian Hydrographic Service


Enc electronic navigational chart l.jpg

ENC – Electronic Navigational Chart

US National Ocean Service


Slide7 l.jpg

Ice info

CIS

FINAL PRODUCT DELIVERY

Notice to Mariners

CCG

ECDIS updates

Tide info

Currents

CHS

Used with permission from Dr. Ahmed Elrabbany


Ice in ecdis vision l.jpg
Ice In ECDIS Vision

  • In the far northern and southern hemispheres ice is a major factor in safe navigation and the integration of real time or near real-time ice information into ECDIS is an important and natural step.

  • To achieve this vision one primary requirement is the development of an ICE feature data dictionary to work with ECDIS.


Ice in ecdis history l.jpg
Ice In ECDIS - History

After many years of effort an ICE Feature Data Dictionary is now available as a register compatible with IHO and others

  • 1992 – Workshop: S57 Object Catalogue - Ottawa

  • 1995 Workshop: Standards for Ice Information in ECDIS - Ottawa

    • Draft Ice Object Catalogue, Version 1.0

  • 1996 Workshop: ECDIS in Ice Navigation – Hamburg

    • Ice Object Catalogue, Version 2.0

  • 1999 The ECDIS Ice Chart Project, SevenCs AG & Co.

  • 2000 Ice In ECDIS Workshop – St. John’s, NFLD

    • Ice Object Catalogue, Version 3.0

  • 2002 Integration of Sea Ice into ECDIS, University of New Brunswick Project

  • 2004 DGIWG develops structure for Feature Data Dictionary Register (Draft)

  • 2005 IHO Ice Registry (Draft)


Why registers and registries l.jpg
Why Registers and Registries?

… and then leveraging technology -- a means to the ends, not an end 

  • Fundamentally, a register is little more than a managed list which assists in defining and implementing good business practices

    • Objective is to rethink what we currently do,why we do it, and … how we’d rather be doing it

  • Three major business problems

    • Content update/release is slow

      • Cycle time must be in weeks, not months/years

    • There will be more than one “domain” data dictionary

      • E.g., feature data dictionaries DGIWG FADD, & military profiles of FADD

        S57 Feature Object Data Dictionary, ICAO aeronautical features, environmental features, etc.

        • Concepts may come from multiple sources and be managed by different authorities

        • Problem is multi-level; bigger than a “base level” catalogue

      • Consider features and attributes:

        • Need feature data dictionaries for definitions, feature catalogues tobind features and attributes to support product specifications (and/or feature information content specifications)

        • And mappings between different feature catalogues/data product specifications to allow for interworking

Change management model, develop better tools, improve access

Use source referencing and compound registers to “pull them together”

Layered family of registers with “downward” dependencies & “upward” reuse


Registr ies model is iso based l.jpg

ISO/TC 211 conformant

registr(ies)

ISO 19135 Procedures for the Registration of Geographic Information

Content

Information Model

Populated &

Operational Registry

Register

Model

RegisterInformation Model

+

+

Purpose

Content

DGIWG FADD,S-57, ICE, ICAO, AML

DGIWG FDD registry

IHO compound FDDICAO registry

Feature DataDictionaries

ISO 19126

ISO 19126

MGCP Product Spec

DGIWG Products

ECDIS Product Spec

ICAO Product Spec

AML product Specs

MGCP Feature Catalogue DGIWG Feature Catalogue

ECDIS Feature Catalogue

ICAO Feature Catalogue

AML Feature Catalogue

FeatureCatalogs

ISO 19110

ISO 19126

GeoSym

S-52

EMS/HLS

OOB (2525B)

Portrayal

Catalogs

GeoSymS-52EMS

ISO 19117

TBD

Registr(ies) Model is ISO based

* Note: MGCP is the military Multinational Geospatial Co Production project


Registry management l.jpg
Registry Management

A Registry is the system that supports the Register

  • Registry Owner:

    • Primary responsibility for the management, dissemination and intellectual content of the registry

  • Registry User:

    • Any person or organization interested in accessing or influences the content of the register

  • Registry Manager:

    • Responsible for the administration of the registry content. Follows ISO 19135……

IHO will establish a compound register that may contain multiple registers for different domains in one registry. This will include ICE features and attributes.


Standards based geo feature registries l.jpg
Standards-based Geo- feature Registries

AeronauticalFDD Registry

Hydrographic & LittoralFDD Registry

Meteorology & OceanographicFDD Registry

Other OrganizationsFDD Registry

S-57 Register

FAA Register

Register

JMBL Register

ICE Register

Eurocontrol/AIXM Register

AML Register

NOAA Register

ICAO Register

OEF Register

  • ISO 19110, 19135, 19126

  • A single information model

  • A single management mechanism

  • A common cross-community technical realization



Slide18 l.jpg

Ice Coverage Type

- Attributes continued


Roles and responsibilities l.jpg

qualifier

1..*

owner

Executive

1

qualifiedBy

Register Owner

Submitting Organization

delegator

Level

1

1

1

appointer

1..*

submitter

appointedBy

1..*

1..*

delegatedBy

1

Management

decisionAuthority

1

receiver

Control Body

Register Manager

Level

contentManager

1..*

decisionRequester

1..*

1..*

systemManager

1

contentController

1

manager

Registry Manager

1

operator

controlled

1

system

1..*

Deployment

1..*

Level

1..*

managed

Register

Registry

register

usedBy

1..*

content

1..*

1

storedOn

1..*

accessedBy

User Level

1..*

1..*

Register User

user

accessor

Roles and Responsibilities

ETSI

Ice and Hydro

charting

communities

ETSI Designate

ESTI-WG

Registry Management

Same Registry Manager as IHO

ETSI

IHO

Clients


Approval of ice register l.jpg
Approval of ICE Register

  • Content of ICE Register presented to the JCOMM Expert Team on Sea Ice (ETSI

  • Content will be reviewed by the ETSI team. Deadline for comments to be set at the ETSI meeting.

  • Comments on the ICE register prepared by the TSMAD in spring 2004 were primarily editorial or related to integration with S-57 objects and have already been included in the register.

  • ICE Catalogue document V 3 has not been updated yet awaiting review of the register and a single baseline document will be prepared when the register is reviewed by the Ice Committee. (differences are primarily editorial)

  • The draft implementation of the ICE register has been mounted by the UKHO at http://195.217.61.120/.


Conclusions and recommendations l.jpg
Conclusions and Recommendations

  • The technology to produce and view ice objects exists (e.g. CARIS (GIS) and OSL (ECDIS)).

  • The Ice Object and Presentation Specifications exist (e.g. IHO and AML).

  • Promote the Ice Object Registry.

  • Encourage/Help National Ice Services to use/expand the Ice Registry

  • Develop a Demonstration Project

    • Baltic Sea or St. Lawrence River? (Ice already planned to be a minor part of the lower St Lawrence integrated chart project)

    • How to Kick start? (Military and/or Coast Guard support)


For more information l.jpg
For more Information

C. Douglas O’Brien, IDON Technologies Inc.

Timothy V. Evangelatos, Terraqueous Technologies

Acknowledgement:

The authors would like to thank the Canadian Hydrographic Service for their support in preparing this presentation.
