a secure stable reliable and high performance cad workstation environment

A Secure, Stable, Reliable and High Performance CAD Workstation Environment

WB Lim

Seagate Technology International

wb.lim@seagate.com

reasons for change
Reasons for Change

MCAD tool migration

Migration from existing NX-Ideas5 to NX6 is planned

NX6 certified hardware

*NX6 is no longer supported on existing Unix platform

Network and software/hardware performance issues

Existing installation faced performance and network bottleneck

Users want familiar Microsoft Windows environment with better hardware performance

Accessibility

Quick access to workstation anytime and anywhere requirements

Physical and data security

Management concerns over access control and data security

2

existing infrastructure layout
Existing Infrastructure - Layout

LAN

LAN

User Workspace

Common Shared Workstations

Existing Workstations Layout

Data Center Services

Control environment with UPS protection

Sun Application Servers – NIS domain, NSF shared, user /home

Network Storage – SAN, NAS

Backup server and Tape Library

Cluttered User Workspace

Desktop PC and CAD Workstation

Tedious to maintain

No physical access control

3

existing infrastructure limitations
Existing Infrastructure - Limitations

Without centralized and environmental control

CAD workstations are not resided in centralized Data Center

CAD workstations scattered around user’s desktop occupying lot of useful workspace

CAD workstations are away from shared network resources

No UPS protection

Access control and Security

CAD workstations are shared with no physical access control

Administration

Tedious administration and maintenance

Difficult to provide users’ data backup and recovery

Uncontrollable and unpredictable downtime

4

existing software tools
Existing Software Tools

NX-Ideas5

NX5

Teamcenter Engineering client

ANSYS

FLUENT

Mentor Expedition PCB

Mentor DxDesigner

Mentor HyperLynx

5

existing software tools upgrade process
Existing Software Tools - Upgrade Process

On UNIX client workstation

Customized upgrade is simply extracting the tar-zipped file overwriting the previous installation

Can be repeated on all UNIX client workstations

On Microsoft Windows client workstation

Standard Microsoft installation steps

Challenges

Same steps need to be repeated on every client workstation

Might be done by users

Prone to mistakes and errors

6

users preferences
Users - Preferences
  • A familiar Microsoft Windows personal workstation with complete installation of NX-Ideas5 locally
  • Workstation with powerful 2D/3D graphics and video capability
  • Multi-display with simultaneous multi-workstation access
  • Able to collaborate real-time securely
  • Access to workstation remotely without much degrade in system performance and response
  • 24x7 operation - uninterrupted services with high availability
management expectations
Management - Expectations
  • Easy transition and cost control
    • Reuse existing Microsoft Windows-based PCs and Laptops
    • Spend less money on workstation upgrade and lower the total cost of ownership
  • Data security
    • Keep classified information securely in data center
    • Provide better risk protection to engineering intellectual property
  • Disaster Recovery and Business Continuity requirements
    • Efficient data backup
    • Quick disaster recovery
    • High availability - quick fail-over capability
    • Remote access - work-from-home or work remotely
it requirements
IT - Requirements

Consolidation, Centralization & Optimization – A lean CAD workstations infrastructure

Simplifies IT administration and management

Maximizes system performance with scalability

Improves IT efficiency

Improves uptime and response time

Enhances data security

Speed up of deployment and serviceability

Simplifies disaster recovery & improves business continuity

Reduces total IT cost

IT resource and capital – administration and maintenance

Energy

9

new infrastructure layout
New Infrastructure - Layout

HP Blade Enclosure

Array of HP Blade Workstations

RGS Sender

Network Storage

LAN

User’s Desktop PC

RGS Receiver

HP Thin Client

RGS Receiver

Laptop/Notebook

RGS Receiver

HP Thin Client

Dual Display

RGS Receiver

HP Chubby Client

4 Screens Display

RGS Receiver

New Workstations Layout

10

new infrastructure promises
New Infrastructure - Promises

To meet all Users, Management and IT requirements

Availability and Accessibility – access anytime and anywhere from

PC Desktop

Laptop

Thin client

Data security

Disaster Recovery & Business Continuity

IT Optimization with Consolidation and Centralization

TCO & ROI

Lowering IT administrative overhead

Increasing user satisfaction and productivity

11

new setup primary components and services
New Setup - Primary Components and Services

HP Blade Enclosure

HP Blade Workstation

HP RGS – Remote Graphics Software v5.0

HP RDP – Rapid Deployment Pack

HP SAM – Session Allocation Manager v2.2

Windows ADS – Active Directory Service

Microsoft WSUS – Windows Server Update Services 3.0 SP1

McAfee VirusScan Enterprise 8.5.0 with ePO – ePolicy Orchestrator 4.0

12

hp blade enclosure
HP Blade Enclosure

Power and cooling

Energy efficiency with multiple thermal sensors

Consumes less power per workstation than traditional workstation

Smaller footprint per workstation

Redundancy network connectivity

Dedicated data network Gb/s ports

Separate Administrator management port

Embedded SAN connectivity

System management

iLO - Integrated Lights Out management system

HP SIM - System Insight Manager

13

hp blade enclosure vs workstation
HP Blade Enclosure vs. Workstation

C3000 Enclosure

SunBlade Workstation 1000

C3000 Fully Populated with HP Blade Workstations

SunBlade Workstation 21000

HP Blade Enclosure vs Workstation

14

hp blade workstation options
HP Blade Workstation - Options
  • Processor x86-based
    • 2 Dual-Core or 2 Quad-Core Intel® Xeon® processors
  • Memory
    • Up to 32 GB of memory supported by 8 slots of PC2-5300 Fully Buffered DIMMs at 667 MHz.
    • Note: 32-bit OS limits physical memory space to 4GB
  • Graphics Adapter - Multi-display hardware accelerated graphics performance for 2D & 3D
    • NVIDIA Quadro FX560M or NVIDIA Quadro FX1600M up to 4 display support
    • Resolution - Max width 7680 pixels (@7680x1200)
    • Resolution - Max height 7680 pixels (@1200x7680)
hp rgs remote graphics software
HP RGS – Remote Graphics Software

RGS Sender/Receiver 5.0 or higher

Provides fast capture, compression, and transmission of the workstation image over the network to users

Note: will only work on HP Blade Systems

Advantages over Windows Remote Desktop Protocol

Multi-display with simultaneous multi-workstation access

Better performance by taking advantage of Blade workstation hardware and graphics resources

Session recovery

Collaboration

WAN optimization

16

hp sam session allocation manager v2 2
HP SAM – Session Allocation Manager v2.2

Manages the assignment of end user connections to desktop sessions running on Blade workstations

Features and benefits

Single log in – Allow log in once and connected to multiple Blade workstations

Static and dynamic resource assignments with auto-failover

Static resources - pre-defined set of Blade workstations

Dynamic resources - pool of available Blade workstations

Follow-me roaming - re-connect users to their previous remote Blade workstation

Ease of administration

Web interfaces to manage the properties with detailed logging

17

hp sam session allocation manager v2 218
HP SAM – Session Allocation Manager v2.2

HP SAM software components

HP SAM Web Server

Microsoft Windows Web Server - IIS

Microsoft Windows SQL Server 2005 Standard or Enterprise

SAM client running on any access device

PC with Microsoft Windows XP

HP thin client

Microsoft Windows Active Directory Services

Provides user account and resource management

18

hp sam session allocation manager v2 219
HP SAM – Session Allocation Manager v2.2

SAM Web Server with an associated SQL database

Manages connections between Blade workstations and users

When a user requests a connection to a Blade, the SAM Web Server accesses the SQL Server database to determine how to allocate the requested Blade resources to the user

The SQL database stores information such as:

The properties of each Blade resources

The properties of each access clients

Monitor layout ID - number of monitors, layout info as well as resolutions

The properties HP RGS

On a per user basis, a per user group basis, and a per security group basis

19

hp sam session allocation manager v2 220
HP SAM – Session Allocation Manager v2.2

Blade Workstation Pool 1

Blade Workstation Pool 2

Role = Designer

Role = Administrator

Blade Workstation 1

Blade Workstation 2

Blade Workstation 3

Blade Workstation 1

Blade Workstation 2

Blade Workstation 3

RGS or RDP

Client1

Client2

Client3

Client4

User Access Terminal4

User Access Terminal1

User Access Terminal 2

User Access Terminal3

User Robert

User Tom

HP SAM Configuration

20

hp rdp rapid deployment pack
HP RDP – Rapid Deployment Pack

Automated installation and configuration

Fast and scalable patch/change deployment

Monitor, remote control and troubleshoot Blade workstations

Image management - Support unattended image or script based deployments

Capture the fine-tuned NX and Teamcenter Engineering client installation consists of enormous number of special/unique configuration details being optimized based on this centralized Blade workstation hardware

IT administrators do not need to worry about user messing up the pre-configured NX and TcEng installations as each workstation image is being captured and managed by HP RDP

Last known working environment can be retrieved and re-deployed in minutes

21

windows active directory service
Windows Active Directory Service

Users authentication

GPO – Group Policy management

User Profiles management

User roaming profile

User network home space allocation

Home space allocation

22

microsoft wsus windows server update services 3 0 sp1
Microsoft WSUS – Windows Server Update Services 3.0 SP1

To deploy the latest Microsoft product updates or patches to these Blade workstations running Microsoft Windows

To manage should the updates be deployed automatically or in a control manner

Note: Auto update feature on each Blade workstations can be enabled/disabled to receive update from the WSUS server

23

mcafee virusscan enterprise 8 5 0 with mcafee epolicy orchestrator 4 0
McAfee VirusScan Enterprise 8.5.0 with McAfee ePolicy Orchestrator 4.0
  • McAfee VirusScan Enterprise - Anti-virus tool
    • Protects the Blade workstations installation
  • McAee ePolicy Orchestrator – Centralized security policy analysis and enforcement tool
    • Provides IT administrator a centralized and remotely accessible component to analyze security profiles on these Blade workstations
    • Allows IT administrator to enforce the policies locally on each of these Blade workstations
    • Allows IT administrator to deploy updates for McAfee DATs, engines, service packs, patches, etc.
new setup secondary components and services
New setup – Secondary Components and Services

User Access Client

HP Blade Management Tools

Storage, Backup and Recovery

25

user access client
User Access Client

Normal PC

Thin Client – HP t5730 (Windows XP Embedded SP2)

Eliminates hard disk or removable media for increased data security

Single client device at the desk dramatically removes heat and noise from user workspace

26

hp blade management tools
HP Blade Management Tools

HP RDP – Rapid Deployment Pack

HP iLO 2 - Integrated Lights-Out 2

HP Onboard Administrator

HP SIM - System Insight Manager

Single management interface for monitoring health of entire Blade workstations infrastructure

Proactive alert of actual or impending component failure

Automatic event handling policies and script execution

Comprehensive utilities for system data collection and inventory reporting

27

storage backup and recovery
Storage, Backup and Recovery

Tiered storage strategy

SAN and network storages simplify backup and data recovery process

Uses disk and tape when required to meet the Business Continuity and Disaster Recovery requirements

Data deduplication eases storage requirements and enhances retention

Improve performance as it is being back up to disk as staging instead to tapes

Longer retention on disk provides fast recovery without ever going to tape

28

others to consider
Others to Consider

SAM – Session Allocation Manager

Setting up users with Dynamic or Dedicated resources

Users and Roles

Resources

Windows ADS – Active Directory Service

Roaming profiles

Windows AD on Profiles and Group Policy

Book on Active Directory

O'Reilly Media, Inc.; 3rd edition (19 Jan 2006)

By Joe Richards, Robbie Allen & Alistair Lowe-Norris

29

others to consider30
Others to Consider

License management and usage monitoring

SAMsuite/SAMreport -> FLEXnet Manager

http://www.acresso.com/

Data center readiness

Power and cooling consideration

Power distribution management

RDP - Image management strategy

Before and after AD login

Windows clustering requirements

Benefit of Windows cluster for the ANSYS or FLUENT

30

thank you

Thank You

WB Lim

Seagate Technology International

wb.lim@seagate.com

(65) 6417 7710
