Friction and Inclined Planes

Friction and Inclined Planes. Friction. Friction – force that opposes motion Caused by microscopic irregularities of a surface The friction force is the force exerted by a surface as an object moves across it or makes an effort to move across it. . Friction. Friction.

belle
Download Presentation

Friction and Inclined Planes

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Friction and Inclined Planes

  2. Friction Friction – force that opposes motion • Caused by microscopic irregularities of a surface • The friction force is the force exerted by a surface as an object moves across it or makes an effort to move across it.

  3. Friction

  4. Friction • Depends on the normal force and the type of surface Ff=mFN • Ff– force of friction (N) • FN – normal force • m – coefficient of friction (1 or less)

  5. Coefficient of Friction • Ratio of the frictional force to the normal force m • The coefficient of friction is a unitless constant that is specific to the material type and usually less than one

  6. Types of Friction • Three types of friction • Static – object at rest • Kinetic – object in motion • Rolling- object on wheels

  7. Friction • Friction depends only on • 1) the nature of the two surfaces in contact • 2) the normal force • It does not depend on the surface area.

  8. Friction and Newton’s First Law • If the coefficient of kinetic friction between a 35-kg crate and the floor is 0.30, what horizontal force is required to move the crate to the right at a constant speed across the floor? • If the object is on a level • surface, then the normal • force = weight force. If the • object is moving at constant • speed, then frictional force = • only force. • Ff = mFNFN= mg • Ff = (0.30)(35)(9.8) FN= (35) (9.8) • Ff = 102.9 N

  9. Friction and Newton’s Second Law • Suppose the same 35 kg crate was not moving at constant speed but accelerating at 0.70 m/s2. Calculate the applied force. • For horizontal forces with friction: Fapp= Fnet + Ff • Fapp = ma + mFN • Fapp = ma + mmg • Fapp= (35) (0.70) + (0.3)(35)(9.8) • Fapp= 24.5 + 102.9 = 127.4 N
