Presentation Transcript
agenda
AGENDA

*Adapter Block diagram

*Circuit refers

*CET products

slide3

Adaptor Application

Transformer

D

Vin AC

85~265V

50~60Hz

+

Line Filter

Rectifier Diode

DC Link Cap

Load

CEP0xN6

Sense FET

PWM

adapter block diagram

AC

Input

Rectifier

PFC

PWM

Transformer

DC

Output

Power

Switch

Linear

Regulator

Synchronous

Rectifier

Adapter- Block diagram
slide6

PFC

被動功因:.利用電感、電容於電源端以便將領先或落後之相位做補償,線路架構上較簡單,但其存在體積大、重量重、輸出易因輸入電壓變動而閃爍不穩定。

主動功因:.一般利用市售之IC來達成功率因素修正功能,其原理乃將PFC.IC電路,至於橋式整流器及負載之間,使其電流隨整流後的電壓波型而做調整,其優點為輸出不因輸入電壓變動而改變,但奇線路架構上路較為複雜。

CEX740N(A), CEX10N4, CEX840N

(400V/10A) (450V/10A) (500V/8A)

slide7

PWM

PWM(Pulse Width Modulation)把變流器的輸出電壓斬波成為脈衝,通過改變脈衝的寬度、數量或者分佈規則,以改變輸出電壓的數值和頻率的控制方法。

CEX01N7,CEX04N7, CEX02N7, CEX09N7A , CEX1165 ,

(700V/0.8A) (700V/4A) (700V/1.9-1.6A) (700V/8A) (600V/10A)

CEX1175

(650V/10A)

CEX01N6 ,

(650V/0.9A)

CEX02N6, CEX02N6A, CEX04N6, CEX09N6, CEX07N8A

(600V /2-1.9A) (650V/1.5-1.3A) (600V/4A) (600V/9A) (800V/6.5A)

slide8

Synchronous Rectifier

CEX6060R, CEX50N06, CEX70N06, CEX6106,

(60V/60A) (60V/50A) (60V/70A)(60V/56A)

CEX9060R, CEX80N75, CEX60N10

(55V/100A) (75V/80A) (100V/57A)

thank you

Rm.1602,Blk A,New Trade Plaza

No.6 Ping St. Shatin.H.K.

Http://www.goldfullsemi.com

TEL:852 -2649 8901FAX:852- 2649 9164

THANK YOU !
