Presentation Transcript
overview
Overview
  • What is the National ITS Architecture?
  • User Services
  • Logical Architecture
  • Physical Architecture
  • Market Packages
  • Developing a Regional ITS Architecture
  • Information Sources
what is the national its architecture4
What is the National ITS Architecture?
  • Provides a structured approach for planning, defining, and integrating intelligent transportation systems that meet national and regional needs
  • Defines:
    • Types of systems to be deployed
    • Functionality of the systems
    • Information exchanged between the systems
the national its architecture is a tool
The National ITS Architecture Is a “Tool”
  • Framework
    • Identifies ITS components and interconnections
  • Vocabulary
    • Uses specific terms for clear communications
  • Guidance
    • For development of ITS project
    • For early identification of integration opportunities
    • For compliance with ITS Standards
    • For customized development of a Regional ITS Architecture
national its architecture is a living document
National ITS Architecture is a “Living Document”

Continuing evolution of the architecture over 13 years

User

Services

Phase I & II

Development

1993

1993-6

Architecture

Published

Transportation Security Update Version 5.0

HRI

Update

ADUS

Update

Ver 3.0

MCO Update Ver 4.0

Version2.0

1996

1997

1998

1999

2002

2003

Current Version: 5.1.1

federal regulations
Federal Regulations
  • FHWA Rule and FTA Policy
  • Regions deploying ITS projects shall use the National ITS Architecture to develop a Regional ITS Architecture
  • All ITS projects shall subsequently adhere to the Regional ITS Architecture and ITS Standards
  • Applies to all ITS projects that are funded in whole or in part with the Highway Trust Fund (including Mass Transit Account)
entry points into the architecture
Entry Points Into the Architecture

Source: National ITS Architecture – Version 5

what is a user service
What is a User Service?
  • Defines What ITS Should Do From the User's Perspective
  • Represents a Broad Range of Users
  • Allows Project Definition to Begin
    • By Establishing the High Level Services
    • To Address Identified Problems and Needs
user services bundles
User Services Bundles
  • Travel and Traffic Management
  • Public Transportation Management
  • Electronic Payment
  • Commercial Vehicle Operations
  • Emergency Management
  • Advanced Vehicle Safety Systems
  • Information Management
  • Maintenance and Construction Operations
travel and traffic management
Travel and Traffic Management
  • 1.1 Pre-trip Travel Information
  • 1.2 En-route Driver Information
  • 1.3 Route Guidance
  • 1.4 Ride Matching And Reservation
  • 1.5 Traveler Services Information
  • 1.6 Traffic Control
  • 1.7 Incident Management
  • 1.8 Travel Demand Management
  • 1.9 Emissions Testing And Mitigation
  • 1.10 Highway Rail Intersection
transit and e payment
Transit and E-Payment

2.0 Public Transportation Management

  • 2.1 Public Transportation Management
  • 2.2 En-route Transit Information
  • 2.3 Personalized Public Transit
  • 2.4 Public Travel Security

3.0 Electronic Payment

  • 3.1 Electronic Payment Services
logical architecture15
Logical Architecture
  • Defines the Processes (the Activities and Functions) That Are Required to Provide the Required User Services
  • Many Different Processes Must Work Together and Share Information to Provide a User Service
  • Can Be Implemented Via Software, Hardware, or Firmware
  • Independent of Technologies and Implementations
  • More of Systems Development Approach
data flow diagram
Data Flow Diagram
  • Show the Functions That Are Required for ITS and the Information That Moves Between These Functions
    • Circles Represent the Processes or Functions
    • Arrows Represent the Data Flows
    • Parallel Lines Represent Data Stores
    • Rectangles Represent the Terminators (not shown)
manage its data flow diagram

Travel & Traffic Management

Emergency Management

Electronic Payment

Public Transportation Management

Commercial Vehicle Operations

Information Management

M&C Ops

Advanced Vehicle Safety Systems

Manage ITS Data Flow Diagram

Source: Version 5 National ITS Architecture

manage traffic user services
Manage Traffic – User Services
  • 1.1 Pre Trip Travel Information
  • 1.2 En-Route Driver Information
  • 1.5 Traveler Services Information
  • 1.6 Traffic Control
  • 1.7 Incident Management
  • 1.8 Travel Demand Management
  • 1.9 Emission Testing and Mitigation
  • 1.10 Highway Rail Intersections
  • 3.1 Electronic Payment Services
  • 5.3 Disaster Response and Evacuation
  • 7.1 Archived Data Function
  • 8.1 Maintenance and Construction Operations
breakdown of manage traffic
Breakdown of Manage Traffic

1.1 Provide Traffic Surveillance

1.2 Provide Device Control

1.3 Manage Incidents

1.4 Manage Travel Demand

1.5 Manage Emissions

1.6 Manage Highway Rail Intersections

1 2 provide device control
1.2 Provide Device Control

1.2.1 Select Strategy

1.2.2 Determine Road and Freeway State

1.2.3 Determine Ramp State

1.2.4 Output Control Data

1.2.5 Manage Parking Lot State

1.2.6 Maintain Static Data for TMC

1.2.7 Provide Roadside Control Facilities

1.2.8 Collect and Process Indicator Fault Data

process specification
Process Specification
  • Provides an Overview of the Process
  • Set of Functional Requirements
  • Complete Set of Inputs and Outputs
    • Data Dictionary
1 2 7 1 process indicator output data for roads
1.2.7.1-Process Indicator Output Data for Roads
  • Implement the indicator output data
  • Provide control at intersections or pedestrian crossings
  • Provide the interface for data for units that manage multimodal crossings or highway-rail intersections
  • Monitor the status of the indicator equipment and provide fault status
  • Includes list of Data Inputs and Outputs
physical architecture26
Physical Architecture
  • Forms a high-level structure around the processes and data flows in the Logical Architecture
  • Defines the Physical Entities and Their Connections
  • Relates to Solutions as Implemented
subsystems
Subsystems
  • Individual physical systems that comprise the overall ITS program
  • Four Types
    • Center
    • Field
    • Vehicle
    • Traveler
national its architecture subsystems
National ITS Architecture Subsystems

Source: Version 5 National ITS Architecture

key terms
Key Terms
  • Equipment Packages: The building blocks of subsystems.
    • Examples: “Onboard Transit Signal Priority”, “Roadway Basic Surveillance”
  • Architecture Flows: Data exchanged between ITS subsystems.
    • Examples: “signal control data”, “traffic images”
  • Market Packages:
    • Links needs to appropriate solutions provided by ITS applications
    • Define the components (equipment packages and subsystems) and interfaces (architecture flows) needed to implement a particular solution
market package service areas
MARKET PACKAGES

Advanced Traveler Information Systems

Advanced Traffic Management Systems

Advanced Public Transportation Systems

Emergency Management

Maintenance and Construction Management

Archived Data Management

Commercial Vehicle Operations

Advanced Vehicle Safety Systems

USER SERVICES

Travel and Traffic Management

Public Transportation Management

Electronic Payment

Emergency Management

Maintenance and Construction Operations

Information Management

Commercial Vehicle Operations

Advanced Vehicle Safety Systems

Market Package Service Areas
market package example
Market Package Example

Architecture Flow

Subsystem

Equipment Package

Source: Version 5 National ITS Architecture

market package example32

APTS7

Multi

-

modal Coordination

Market Package Example

Source: Version 5 National ITS Architecture

consolidated view of the architecture
Consolidated View of the Architecture

Source: City of Seattle ITS Master Plan (IBI Group)

what is a regional its architecture
What is a Regional ITS Architecture?
  • Framework for implementing and integrating ITS with a region
  • Planning tool for identifying gaps in existing and planned ITS deployments versus transportation needs
  • Involves working with agencies to document partnerships, roles, and responsibilities.
developing a regional its architecture
Developing a Regional ITS Architecture

Source:

Regional ITS Architecture Guidance: Developing, Using and Maintaining an ITS Architecture For Your Region (October 2001)

puget sound regional its architecture project
Puget Sound Regional ITS Architecture Project
  • Conduct Stakeholder Outreach Efforts
  • Compile Regional ITS Inventory
  • Develop Regional ITS Architecture
  • Incorporate ITS into Regional Planning Process
  • Provide Guidance on Federal ITS Requirements
puget sound regional its architecture40
Puget Sound Regional ITS Architecture
  • Framework for Planning and Coordinating How ITS Projects Are Implemented in the Central Puget Sound Region
  • Provides Guidance and Resource for Local ITS Project Development
  • Addresses Both Technical and Intuitional Coordination
  • Based on National ITS Architecture but Tailored to Address Specific Regional Needs
stakeholder involvement
Stakeholder Involvement
  • Project Oversight – Regional ITS Advisory Panel
  • Local, County, and State Traffic Managers
  • Regional Transit Agencies Technology Managers
  • Freight Community
  • Emergency Management Coordinators
  • Private Sector Traveler Information Providers
  • FHWA and FTA
  • Federal Land Agencies
regional its architecture elements
Regional ITS Architecture Elements
  • Description Of The Region
  • Identification Of Stakeholders
  • Operational Concept
  • Required Agreements
  • System Functional Requirements
  • Interface Requirements And Information Exchanges
  • Identification Of ITS Technical Standards
  • Sequence Of Projects Required For Implementation
operational concept development
Operational Concept Development

Operational Concept Defines:

  • Institutional Relationships Among Organizations
  • Roles And Responsibilities
  • Information Exchange
agreements between organizations
Agreements Between Organizations
  • Documents Current Status of ITS Agreements
  • Identifies Needed Agreements as New Projects are Deployed
  • Provides Guidance on Elements of New Agreement
technical framework
Technical Framework

Provides Guidance For Defining

  • System Functional Requirements
  • Interface Requirements
  • Information Exchanges
  • Based on Market Packages
its technical standards
ITS Technical Standards
  • ITS Technical Standards
    • Allows systems to “talk to each other”
    • Removes dependency on one vendor
    • FHWA will tie funding to use of standards
  • Identifies Key Regional ITS Technical Standards
  • Provides Guidance on Use of Standards
why develop a regional its architecture
Why Develop a Regional ITS Architecture?
  • Saves Time and Money During Project Development
  • Guides Coordination Among Individual Projects
  • Sets Direction for Improving Efficiency of Transportation System
  • Provides Framework for Sharing Information Among Agencies and General Public
  • Reduces Cost of Implementation
  • Conformance With the Federal ITS Requirements Is Required to Receive Federal Highway Trust Funds
trubo architecture
Trubo Architecture
  • Tool for Development & Maintenance
  • Provides Database
  • Maps Relationships
information sources
Information Sources
  • National ITS Architecture:
    • http://www.iteris.com/itsarch/
  • US DOT ITS Program:
    • http://www.its.dot.gov/index.htm
  • ITS Standards:
    • http://www.standards.its.dot.gov/default.asp
  • ITS Benefits and Costs
    • http://www.benefitcost.its.dot.gov/
  • ITS America
    • http://www.itsa.org/
  • ITS Washington
    • http://depts.washington.edu/itswa/
does any one use this
Does Any One Use This?
  • SR 167 HOT Lanes Project Example
contact information
Contact Information

Bart Cima, PE

Director

IBI Group

206-521-9091

bcima@ibigroup.com
