    1. Graphical Programming Languages Lecture 19: Supporting Material Dr Kathryn Merrick Thursday 21st May, 2009

    2. Overview • Graphical programming languages: • Variables, types, values, operators • Flow of control • Built-in functions • Strengths and limitations

    3. Lego Mindstorms NXT: Programmable Robots Programmable Brick

    4. The NXT Programming Environment The programming window

    5. Built-in Functions ‘Move’ functions connected up like Lego bricks Input parameters set here

    6. Loops Instructions to be repeated will be dragged into here Loop connected up like a Lego brick Exit condition (can behave like a for loop or a while loop)

    7. Selection What to do will be dragged into here Selection connected up like a Lego brick Conditions set here

    8. A Complete Program

    9. Demo 1: Programming a Lego scorpion

    10. Variables Variable brick

    11. Maths Operators Maths operator brick

    12. Boolean Operators Boolean operator brick

    13. Complete Program

    14. Demo 2: Programming a Lego scorpion

    15. Summary • After today’s lecture you should be able to: • Identify the key programming tools we used in MATLAB in the NXT graphical language • Appreciate the strengths and weaknesses of graphical languages
