  1. BAB 6 PANDANGAN ISOMETRIK

  2. (a) Pandangan Ortografik (b) Pandangan Isometrik (c) Pandangan Oblik (d) Pandangan Perspektif Rajah 6.1 Jenis – jenis pandangan

  3. (a) Rahang Bebas (b) Engkol Putar (c) Fius Kartrij (d) Butiran Kekuda Bumbung Rajah 6.2 Contoh – contoh pandangan Isometrik

  4. HUBUNGKAIT LUKISAN ORTOGRAFIK DENGAN BENTUK OBJEK DALAM TIGA DIMENSI. PANDANGAN ISOMETRIK PANDANGAN ISOMETRIK PELAN PELAN HADAPAN SISI HADAPAN SISI RAJAH 6.3
