  1. SOFT-TRONIK, a.s. ProxySG’s Policy Michal ČervinkaPre-sales SE

  2. Construction - Policy Files • VPM • created via Visual Policy Manager • Local Policy File • manualy created CPL • Central Policy File • global setting managed by BCSI by default • Forwarding Policy File • forwarding rules (for backward compatibility only) Evaluated in THIS order by default …

  3. Construction - Policy Layers • <admin> Admin Authentication Layer • <admin> Admin Access Layer • <dns-proxy> DNS Access Layer • <proxy> SOCKS Authentication Layer • <ssl-intercept> SSL Intercept Layer • <ssl> SSL Access Layer • <proxy> Web Authentication Layer • <proxy> Web Access Layer • <cache> Web Content Layer • <forward> Forwarding Layer Prefered ordering Evaluated sequentialy

  4. Construction – Design of Layers • Separate decisions in separate layers • Start with general, proceed to more specific • Remember the default policy • ALLOW usualy for app acceleration • DENY typical for security GW

  5. Construction - Policy Rules • Rules evaluation • reflects order within the layer • „first match“ model • Design rule • go from specific to general

  6. Integrity – ALLOW vs. OK • ALLOW can reverse a previous denial • OK action available as „empty“ action

  7. Integrity – DENY vs. FORCE DENY • DENY can be overridden by a later ALLOW • FORCE_DENY terminates further policy evaluation • The same for exception vs. force_ exception

  8. Optimization • Try to avoid regular expressions • they are too CPU-intensive

  9. Optimization • Place rules most likely to match at the beginning of the layer • Place like conditions together within the layer • let the compiler optimize

  10. Optimization • Use subnets when possible • or group by „define subnet“ definition

  11. Optimization • Use definitions to minimize the number of rules

  12. Optimization • Select the Appropriate URL Condition

  13. Optimization • Use Layer Guards • to prevent layers from being evaluated unnecessarily

  14. Michal ČervinkaPre-sales SEmichal.cervinka@soft-tronik.czSOFT-TRONIK, a.s.OstravaTvorkovských 5709 00 Ostrava - Mariánské Horytel.: +420 597 488 811 fax: +420 596 622 486PrahaNagano Office and Technology Park,Nagano IIIU nákladového nádraží 10130 00 Praha 3tel: +420 266 109 211 fax: +420 283 840 236www.soft-tronik.cz
