    1. SPNEGO authentication using JGSS Jens Bo Friis M. Sc, Technical University of Denmark M. Cryptology from University of Aarhus Partner in IT Practice A/S Email: jbf@it-practice.dk

    2. SPNEGO support Introduction Protocol SPNEGO token JGSS in J2SDK 1.4 SPNEGO in PortalProtect Client side SPNEGO Conclusion

    3. Introduction SPNEGO (Simple and Protected GSS-API Negotiation Mechanism) Provides a mechanism for extending a Kerberos based single sign-on environment to Web applications Kerberos is used in Windows 2k domains Internet Explorer 5+ supports SPNEGO.

    4. Web server authentication using SPNEGO - overview

    5. Web server authentication using SPNEGO – overview explained Logon towards domain test.net Browser request a protected page at www.test.net www.test.net responds with a HTTP Error 401 Unauthorized and starts the SPNEGO protocol Browser requests a session ticket from the KDC for www.test.net server using server principal name HTTP/www.test.net@test.net The browser resends the request for the protected page including the HTTP Authorization header containing the ticket packaged into a SPNEGO envelope. Web server unpacks the ticket from the SPNEGO envelope and sends the ticket to the KDC for verification. KDC verifies the ticket and returns the user name

    6. SPNEGO protocol details

    7. HTTP Authorization header Negotiate YIIEqwYGKwYBBQUC... Base64 encoded octet string Octet string is ASN.1 encoded blob ASN.1 blob is 0x60 <application specific>, an ObjectIdentifier(1.3.6.1.5.5.2) and a NegTokenInit defined in rfc 2478 1.3.6.1.5.5.2 is the OID for SPNEGO mechanism. NegTokenInit ::= SEQUENCE { mechTypes [0] MechTypeList OPTIONAL, reqFlags [1] ContextFlags OPTIONAL, mechToken [2] OCTET STRING OPTIONAL, mechListMIC [3] OCTET STRING OPTIONAL }

    8. mechToken is the InitialContextToken from rfc 1964. InitialContextToken ::= SEQUENCE { thisMech MechType -- MechType is OBJECT IDENTIFIER -- representing "Kerberos V5" innerContextToken ANY DEFINED BY thisMech } innerContextToken is the binary blob containing the Kerberos V5 KRB_AP_REQ message. innerContextToken is later used when we do the authentication i the JGSS code

    9. JGSS connection to KDC GSSManager manager = GSSManager.getInstance(); GSSName serverName = manager.createName(serverPrincipalName, null); Where serverPrincipalName points to the web servers servicePrincipalName entry in ActiveDirectory – the web servers account which matches the user account with the keytab file. GSSContext context = manager.createContext(serverName, krb5MechanismOid, null, GSSContext.DEFAULT_LIFETIME); Create the context. Use the Kerberos OID. Other implementations using SPNEGO enabled JGSS implementations, specify the SPNEGO OID. byte[] neg_token_targ = context.acceptSecContext(innerContextToken, 0, innerContextToken.length); This calls the KDC to verify the KRB_AP_REQ message received from the browser

    10. JGSS context The GSSContext can afterwards be examined: context.getMutualAuthState() =? True context.isEstablished() =? True userPrincipalName = context.getSrcName(); User principal name is the userid of the user that logged on to the domain. Since the user is authenticated, we can propagate the userid to the security manager of the web server.

    11. PortalProtect SPNEGO support Authenticator plug-in (a servlet) in the Tunnel (reverse proxy) which handles the NEGOTIATE conversation. Nothing but the conversation is handled here. Authentication plug-in to the Session controller. All remaining work is done here: Token decoding ASN.1 decoding JGSS

    12. Client side SPNEGO Normally only the IE browser is capable of doing SSO over SPNEGO Mozilla also supports SPNEGO, but dont support SSO using windows domain login SPNEGO tokens can be generated on client side, using nothing but JDK 1.4 This can be run on Java applets or Java applications. Supports native windows ticket cache and Java ticket cache. Supports Windows XP and Windows 2000 clients. See http://appliedcrypto.com/spnego/spnego_client.html for further details.

    13. Conclusion This demonstrates SPNEGO support using J2SDK 1.4 JGSS implementation only. No need for 3rd party products like Wedgetail. Can be implemented in application server running on top of J2SDK 1.4, like WebLogic 8.1 server from www.bea.com. Tomcat 4.x and 5 from Jakarta.apache.org Using PortalProtect, SPNEGO support can be added to basically ANY application server including older versions of WebLogic and WebSphere 3.5+ Client side tokens can be generated. This adds support for Java applets and Java applications. This means FULL client side single sign-on.

    14. Links http://www.it-practice.dk (PortalProtect) http://www.portalprotect.dk (PortalProtect demo) http://appliedcrypto.com/spnego/qa.html (SPNEGO FAQ) http://appliedcrypto.com/spnego/spnego_client.html (client side SPNEGO)
