outline
Outline
  • Our internal requirements
  • The challenges of 99.9% uptime
  • Our architecture
  • How we setup SharePlex
  • How we configured SharePlex
  • CRS Integration
  • Useful commands
  • Final Thoughts
service level agreement
Service Level Agreement
  • Must maintain 99.9% availability
  • Maximum allowed outage of 43.8 minutes/month
  • Not allowed to combine monthly allocations
  • Financial penalties will be paid for overages
  • Zero scheduled downtime allowed

This product is Highly visible to Executive team, so it is in our best interest to proactively meet the requirements of the Service Level Agreement.

the challenge
The Challenge
  • Upgrade Oracle – upgrade inactive silo, failover
  • Patch Oracle – patch inactive silo, failover
  • Quarterly software releases – inactive silo, failover
  • Hardware failure/updates - failover to inactive silo
  • Software failure – failover to inactive silo
  • User error – use flashback table/database
  • Disaster recovery – storage replication to NJ site
  • OS Patches/upgrades

… all with near zero downtime!

architecture
Architecture

UT - Silo A - RAC Cluster

UT - Silo B - RAC Cluster

inst_a1

Logical Replication

inst_a2

inst_b1

inst_b2

Bi-directional

Block Level

Storage Replication

Block Level

Storage Replication

NJ - Silo A - RAC Cluster

NJ - Silo B - RAC Cluster

Logical Replication

inst_a1

inst_a2

inst_b1

inst_b2

research
Research
  • RAC
    • Upgrading with no downtime is questionable
    • Does not facilitate our quarterly releases methodology
  • Data Guard
    • Upgrading with no downtime is questionable
    • Target site is down (or read-only) when propagating changes
    • Active data guard is additional cost
    • Switchover takes minutes+ to complete
  • Golden Gate
    • Ability to compare/repair data is an add-on (expensive)
    • Could not justify the cost of the product missing functionality
  • SharePlex
    • Seemed to satisfy all our requirements
decision
Decision

During our discovery effort it was determined that SharePlex was the best solution for the following reasons:

  • Intuitive setup and configuration
  • Cost effective compared to other solutions
  • Detects when table get out of sync
  • Includes the ability to compare and repair tables
  • Allows bi-directional replication
setup
Setup

In the source environment:

Create the required tablespaces

CREATE TABLESPACE SPLEXDAT DATAFILE SIZE 50MAUTOEXTEND ON NEXT 100M MAXSIZE 5G LOGGING EXTENT MANAGEMENT LOCAL AUTOALLOCATE BLOCKSIZE 8K SEGMENT SPACE MANAGEMENT AUTO FLASHBACK ON;CREATE TABLESPACE SPLEXIDX DATAFILE SIZE 50M AUTOEXTEND ON NEXT 100M MAXSIZE 5G LOGGING EXTENT MANAGEMENT LOCAL AUTOALLOCATE BLOCKSIZE 8K SEGMENT SPACE MANAGEMENT AUTO FLASHBACK ON;

setup continued
Setup - Continued

Obtain new IP addresses in the same network as the SCAN interface IP addresses (for each cluster):

Utah:

Silo A: 192.168.1.10

Silo B: 192.168.1.20

New Jersey:

Silo A: 192.168.2.10

Silo B: 192.168.2.20

setup continued1
Setup - Continued

Obtain DNS entries for the new IP addresses:

Utah:

192.168.1.10 - inst_a-splex-vip.xactware.com

192.168.1.20 - inst_b-splex-vip.xactware.com

New Jersey:

192.168.2.10 - njinst_a-splex-vip.xactware.com

192.168.2.20 - njinst_b-splex-vip.xactware.com

setup continued2
Setup - Continued

Create the CRS VIP to allow SharePlex to failover between RAC nodes:

Utah Silo A (only on one of the nodes)

as root:

${CRS_HOME}/bin/appvipcfg create -network=1 -ip=192.168.1.10

-vipname=shareplex.vip -user=oracle -group=dba

as oracle:

crsctl start resource shareplex.vip

Utah Silo B (only on one of the nodes):

as root:

${CRS_HOME}/bin/appvipcfg create -network=1 -ip=192.168.1.20

-vipname=shareplex.vip -user=oracle -group=dba

as oracle:

crsctl start resource shareplex.vip

setup continued3
Setup - Continued

Add SharePlex environment variables to .bashrc.*

Utah Silo A:

SP_SYS_HOST_NAME="inst_a-splex-vip.xactware.com" ; export SP_SYS_HOST_NAMESP_INSTALL_DIR="/u02/app/quest"; export SP_INSTALL_DIRSP_SYS_VARDIR="${SP_INSTALL_DIR}/vardir" ; export SP_SYS_VARDIRSP_SYS_PRODDIR="${SP_INSTALL_DIR}/sp" ; export SP_SYS_PRODDIRSP_OCT_ASM_SID="+ASM1" ; export SP_OCT_ASM_SID - (different for each host in the cluster)

Utah Silo B:

SP_SYS_HOST_NAME="inst_b-splex-vip.xactware.com" ; export SP_SYS_HOST_NAMESP_INSTALL_DIR="/u02/app/quest"; export SP_INSTALL_DIRSP_SYS_VARDIR="${SP_INSTALL_DIR}/vardir" ; export SP_SYS_VARDIRSP_SYS_PRODDIR="${SP_INSTALL_DIR}/sp" ; export SP_SYS_PRODDIRSP_OCT_ASM_SID="+ASM1" ; export SP_OCT_ASM_SID - (different for each host in the cluster)

setup continued4
Setup - Continued

Create Silo A TNS Entries:

Utah Silo A – Node 1:INST_A_SP =  (DESCRIPTION =    (ADDRESS = (PROTOCOL = TCP)(HOST = utdb01a)(PORT = 1521))    (ADDRESS = (PROTOCOL = TCP)(HOST = utdb02a)(PORT = 1521))    (CONNECT_DATA =      (SERVER = DEDICATED)      (SERVICE_NAME = inst_a)(INSTANCE_NAME = inst_a1)    )  )

Utah Silo A – Node 2:

INST_A_SP =  (DESCRIPTION =    (ADDRESS = (PROTOCOL = TCP)(HOST = utdb01a)(PORT = 1521))    (ADDRESS = (PROTOCOL = TCP)(HOST = utdb02a)(PORT = 1521))    (CONNECT_DATA =      (SERVER = DEDICATED)      (SERVICE_NAME = inst_a)(INSTANCE_NAME = inst_a2)    )  )

setup continued5
Setup - Continued

Create Silo B TNS Entries:

Utah Silo B – Node 1:INST_B_SP =  (DESCRIPTION =    (ADDRESS = (PROTOCOL = TCP)(HOST = utdb01b)(PORT = 1521))    (ADDRESS = (PROTOCOL = TCP)(HOST = utdb02b)(PORT = 1521))    (CONNECT_DATA =      (SERVER = DEDICATED)      (SERVICE_NAME = inst_b)(INSTANCE_NAME = inst_b1)    )  )

Utah Silo B – Node 2:

INST_B_SP =  (DESCRIPTION =    (ADDRESS = (PROTOCOL = TCP)(HOST = utdb01b)(PORT = 1521))    (ADDRESS = (PROTOCOL = TCP)(HOST = utdb02b)(PORT = 1521))    (CONNECT_DATA =      (SERVER = DEDICATED)      (SERVICE_NAME = inst_b)(INSTANCE_NAME = inst_b2)    )  )

setup continued6
Setup - Continued

Create the required oratab entries:

For Silo A (all nodes):inst_a:/u01/app/oracle/product/11.2.0/dbhome_1:Ninst_a_sp:/u01/app/oracle/product/11.2.0/dbhome_1:N

For Silo B (all nodes):inst_b:/u01/app/oracle/product/11.2.0/dbhome_1:N

inst_b_sp:/u01/app/oracle/product/11.2.0/dbhome_1:N

Make sure the entries look like this:

inst_b_sp:/u01/app/oracle/product/11.2.0/dbhome_1:N

Not this:

inst_b_sp:/u01/app/oracle/product/11.2.0/dbhome_1:N # Line added by agent

setup continued7
Setup - Continued

Create and mount an NFS share for each RAC cluster. This mount point will contain the SharePlex installation and replication configuration files.

You must use the following mount options:

rw,hard,proto=tcp,rsize=32768,wsize=32768,intr,timeo=600,retrans=2,vers=3,llock,suid

See:

https://support.software.dell.com/shareplex-for-oracle/kb/30450

setup continued8
Setup - Continued

Install SharePlex (on one node of each cluster):

cd /dba/software/quest/splex

tar -xf ./SharePlex-8.0.1-b40-oracle110-sun-11-sparc-m64.tar

./SharePlex-8.0.1-b40-oracle110-sun-11-sparc-m64.tpm

Please enter the product directory location? /u02/app/quest/sp(/u02 is the NFS mount created earlier)Please enter the variable data directory location? /u02/app/quest/vardirPlease specify the SharePlex Admin group (select a number):1. [oinstall]2. dba? 1

Please enter the ORACLE_SID that corresponds to this installation? [inst_a1] inst_a(Needs to be the RAC TNS entry)

Please enter the ORACLE_HOME directory that corresponds to this ORACLE_SID? /u01/app/oracle/product/11.2.0/dbhome_1Please enter the TCP/IP port number for SharePlex communications? [2100] <enter>Proceed with installation? [yes]  <enter>Do you have a valid SharePlex for Oracle v. 8.0.1 license? [yes] <enter>Please enter the License key? SORRYCANTSHARETHISWITHYOUPEOPLEPlease enter the customer name associated with this license key? XACTWARE INC

setup continued9
Setup - Continued

Configure SharePlex on Silo A ONLY (one node):

cd /u02/app/quest/sp/bin./ora_setupEnter the Oracle SID for which SharePlex should be installed [inst_a1] :inst_a_sp(this is the new sp TNS alias)Enter a DBA user name : <sysdba user>Enter password for the DBA account, which will not echo : <password>@inst_a_spWould you like to create a new SharePlex user ? [y] : yEnter username for new user [SPLEX/SPLEX] : splexEnter password for new user : splexpwd@inst_a_spRe-enter password for new user : splexpwd@inst_a_spDo you want to enable replication of tables with TDE? [n] :<enter>Enter the default tablespace for use by SharePlex [USERS] : SPLEXDAT (The data tablespace created earlier)Enter the temporary tablespace for use by SharePlex [TEMP] :  <enter>Enter the index tablespace for use by SharePlex [ ] : SPLEXIDX (The index tablespace created earlier)Oracle ASM detected. Enable SharePlex ASM support? [y] : <enter>

setup continued10
Setup - Continued

For RAC configurations add License for other nodes

Run the following on the Silo A host to be added:

/u02/app/quest/sp/util/splex_uname|grep “Host ID”

  Host ID            = 2230858275

On the host where the SharePlex VIP is running:

/u02/app/quest/sp/install/splex_add_key

3) Add license key for alternate host        Enter option: 3

        Adding license for machine ID : 2230858275 (Host ID from splex_uname above)

        2) Enter license key manually       Enter option: 2

        Enter Key: SORRYCANTSHARETHISWITHYOUPEOPLE        Enter Customer Name: XACTWARE INC The SharePlex license has been successfully added for host 2230858275.

  q) Quit License Utility

        Enter option: q

setup continued11
Setup – Continued

Verify the paramdb file on Silo A:

cd /u02/app/quest/vardir

view paramdb

SP_COP_TPORT 2100

SP_COP_UPORT 2100

SP_OCT_TDE_SHARED_SECRET "" # SPO TDE Shared Secret

SP_OCT_ASM_SUPPORT "1" # ASM support on or off

SP_ORD_LOGIN_O.inst_a_SP "77bff9a39a0c2bb430c6c013e35ba8617cc4521279ff"

SP_ORD_OWNER_O.inst_a_SP "SPLEX"

SP_SYS_LIC_2230925271 "SORRYCANTSHARETHISWITHYOUPEOPLE:XACTWARE INC"

SP_SYS_LIC_2231029195 "SORRYCANTSHARETHISWITHYOUPEOPLE:XACTWARE INC"

SP_SHS_SHMSIZE "33554432" # Statistics shared-memory Size

SP_OCT_USE_DST "0" # If 1, factor in DST when computing REDOLOG_ENSURE

SP_OCT_REPLICATE_SEQUENCES 0

SP_OCT_REPLICATE_DDL 0

SP_OCT_AUTOADD_ENABLE 0

SP_DEQ_THREADS "1" # Number of compare threads to run

Make sure the following entry does not exist:SP_OCT_ASM_SID="+ASM1"

setup continued12
Setup – Continued

Verify the paramdb file on Silo B:

cd /u02/app/quest/vardir

view paramdb

SP_COP_TPORT 2100

SP_COP_UPORT 2100

SP_OCT_TDE_SHARED_SECRET "" # SPO TDE Shared Secret

SP_OCT_ASM_SUPPORT "1" # ASM support on or off

SP_ORD_LOGIN_O.inst_b_SP "77bff9a39a0c2bb430c6e89c013ba8617cc4511279ff"

SP_ORD_OWNER_O.inst_b_SP "SPLEX"

SP_SYS_LIC_2231091337 "SORRYCANTSHARETHISWITHYOUPEOPLE:XACTWARE INC"

SP_SYS_LIC_2231027673 "SORRYCANTSHARETHISWITHYOUPEOPLE:XACTWARE INC"

SP_SHS_SHMSIZE "33554432" # Statistics shared-memory Size

SP_OCT_USE_DST "0" # If 1, factor in DST when computing REDOLOG_ENSURE

SP_OCT_REPLICATE_DDL 0

SP_OCT_AUTOADD_ENABLE 0

SP_DEQ_THREADS "1" # Number of compare threads to run

Make sure the following entry does not exist:SP_OCT_ASM_SID="+ASM1"

setup continued13
Setup – Continued

SharePlex Configuration Settings:

SP_OCT_USE_DST

Note: If 1, factor in DST when computing REDOLOG_ENSURE (default 1)

SP_OCT_REPLICATE_SEQUENCES

Note: If 1, replicate sequences (default 1)

SP_OCT_REPLICATE_DDL

Note: If 1, replicate alter/truncate statements (default 1)

SP_OCT_AUTOADD_ENABLE

Note: If 1, auto add new tables that match wildcard configuration (default 1)

SP_DEQ_THREADS

Note: This defines the number of compare threads to run (dynamic)

See:

http://documents.software.dell.com/DOC136923

configuration
Configuration

Create the Silo A SharePlex configuration file:

cd /u02/app/quest/vardir/config

vi schema_name_all

datasource:o.inst_a_SP

#source tables target tables routing map

expand schema_name.% schema_name.% inst_b-splex-vip@o.inst_b_SP

Note: This will replicate the schema_name schema from silo a to silo b.

configuration continued
Configuration - Continued

Create the Silo B SharePlex configuration file:

cd /u02/app/quest/vardir/config

vi schema_name_all

datasource:o.inst_b_SP

#source tables target tables routing map

expand schema_name.% schema_name.% inst_b-splex-vip@o.inst_a_SP

Note: This will replicate the schema_name schema from silo b to silo a.

configuration continued1
Configuration - Continued

Start SharePlex:

On silo A and silo B (on the host with SP VIP):

sp_cop &

Stop Target Post:

On silo B ONLY (on the host with SP VIP):

sp_ctrl

stop post

Activate Config:

On theSilo A (on the host with the SP VIP):

sp_ctrl

activate configschema_name_all

Note: the “activate config” begins tracking changes to the schema schema_name.

configuration continued2
Configuration - Continued

Verify Process State:

On both silo A and silo B

sp_ctrl

status

Brief Status for inst_a-splex-vip

Process State PID Running   Since     --------------- ------------------------------  -------- --------------------Cop Running 4207 01-Nov-13 17:10:24  Cmd & Ctrl Running 4272 01-Nov-13 17:12:55  Capture Running 5236 01-Nov-13 17:15:41  Read Running 5310 01-Nov-13 17:15:46  Post Stopped by user 5336 01-Nov-13 17:15:51

Note: On silo B the status of post should be “Stopped by user”

configuration continued3
Configuration - Continued

The next step is to duplicate the Silo A database to the Silo B database. It does not matter which method you use to get the source copied to the target (impdp, rman, etc.) as long as you have a consistent SCN to pass to SharePlex.

When using rman make sure to record the following from the duplication log file:

scn322033901803

setup1
Setup

Configure SharePlex on Silo B ONLY (Do NOT create a new SP user):

cd /u02/app/quest/sp/bin./ora_setupEnter the Oracle SID for which SharePlex should be installed [inst_a1] :inst_b_sp(this is the new sp TNS alias)Enter a DBA user name : <sysdba user>Enter password for the DBA account, which will not echo : <password>@inst_b_spWould you like to create a new SharePlex user ? [y] : n

Enter username of an existing user : splexEnter password for splex : splexpwd@inst_b_spDo you want to enable replication of tables with TDE? [n] :<enter>Enter the default tablespace for use by SharePlex [USERS] : SPLEXDAT (The data tablespace created earlier)Enter the temporary tablespace for use by SharePlex [TEMP] :  <enter>Enter the index tablespace for use by SharePlex [ ] : SPLEXIDX (The index tablespace created earlier)Oracle ASM detected. Enable SharePlex ASM support? [y] : <enter>

setup continued14
Setup - Continued

For RAC configurations add License for other nodes

Run the following on the Silo B host to be added:

/u02/app/quest/sp/util/splex_uname|grep “Host ID”

  Host ID            = 2231027673

On the host where the SharePlex VIP is running:

/u02/app/quest/sp/install/splex_add_key

3) Add license key for alternate host        Enter option: 3

        Adding license for machine ID : 2231027673 (Host ID from splex_uname above)

        2) Enter license key manually       Enter option: 2

        Enter Key: SORRYCANTSHARETHISWITHYOUPEOPLE        Enter Customer Name: XACTWARE INC The SharePlex license has been successfully added for host 2231027673.

  q) Quit License Utility

        Enter option: q

setup continued15
Setup – Continued

Verify the paramdb file on Silo B:

cd /u02/app/quest/vardir

view paramdb

SP_COP_TPORT 2100

SP_COP_UPORT 2100

SP_OCT_TDE_SHARED_SECRET "" # SPO TDE Shared Secret

SP_OCT_ASM_SUPPORT "1" # ASM support on or off

SP_ORD_LOGIN_O.inst_b_SP "77bff9a39a0c2bbeab430c6e89c013e35ba8617cc4511279ff"

SP_ORD_OWNER_O.inst_b_SP "SPLEX"

SP_SYS_LIC_2231091337 "SORRYCANTSHARETHISWITHYOUPEOPLE:XACTWARE INC"

SP_SYS_LIC_2231027673 "SORRYCANTSHARETHISWITHYOUPEOPLE:XACTWARE INC"

SP_SHS_SHMSIZE "33554432" # Statistics shared-memory Size

SP_OCT_USE_DST "0" # If 1, factor in DST when computing REDOLOG_ENSURE

SP_OCT_REPLICATE_DDL 0

SP_OCT_AUTOADD_ENABLE 0

SP_DEQ_THREADS "1" # Number of compare threads to run

Make sure the following entry does not exist:SP_OCT_ASM_SID="+ASM1"

setup continued16
Setup - Continued

Lookup Datasource Name (Silo B):

Queues Statistics for inst_b-splex-vip

Name: inst_a-splex-vip (o.INST_A_SP-o.INST_B_SP) (Post queue)

Number of messages: 1029659 (Age 24 min; Size 485 mb)

Backlog (messages): 0 (Age 0 min))

Reconcile Queues:

On Silo B - issue the reconcile command.

sp_ctrl

reconcile queue queuename for datasource-datadestscnscn_number

Example:

reconcile queue inst_a-splex-vipfor o.INST_A_SP-o.INST_B_SPscn 322033901804

If this Process hangs it is likely related to no activity on the source. Log into the source database and create at least one transaction, then force a log switch.

NOTE:  This will not apply transactions yet...

setup continued17
Setup - Continued

Cleanup Target Tables:

Run the cleanup.sql script to truncate all of the SharePlex internal tables.

Only run this on Silo B:

cd /u02/app/quest/sp/bin

sqlplussplex/<pass>@inst_b_sp

@cleanup.sql

setup continued18
Setup - Continued

Modify Triggers:

On Silo B (or both silos if you are bi-directional), disable triggers on the replicated tables, or run the sp_add_trigger.sql utility script so that the triggers ignore the SharePlexuser. This will prevent circular replication.

cd /u02/app/quest/sp/util

sqlplus “/as sysdba”

@sp_add_trigger.sql

Enter SharePlex username --> splex

Verify all the triggers in the replicated schema have the following:

WHEN (

USER != 'SPLEX'

)

setup continued19
Setup - Continued

Before moving on with the next steps, make sure that there are no replicated tables with constraints that are “on delete cascade”. This will cause issues with replication and must be disabled.

ALTER TABLE table_name ADD

CONSTRAINT constraint_name

FOREIGN KEY (column)

REFERENCES table_name (column_name)

ON DELETE CASCADE

ENABLE

VALIDATE

NOTE: If you are planning on bi-directional replication, neither silo can have this set.

setup continued20
Setup - Continued

Sequences:

If you are planning on active-active in your configuration then you have 2 options for sequences.

(1) - Alter one cluster to odd and the other to even and increment by 2.

Example: select sequence.nextval from dual; (until odd or even), then

alter sequence sequence_name increment by 2;

(2) - Use sequence ranges for each silo in the cluster.

The recommended method is to use odd/even to avoid conflicts.

Determine the best method for your setup and make the sequence changes before moving on with the next step.

setup continued21
Setup - Continued

Start SharePlex Post Process:On silo B, start the Post process.

sp_ctrl

start post

NOTE: Silo B will now post the changes from the beginning of the duplicate database until current. May take some time to catch up.

Monitor Queue Status:

On Silo A and Silo B:

sp_ctrl

qstatus

crs configuration
CRS Configuration

Create Start / Stop Script:

logfile="/u02/app/quest/scripts/log/spctl.log" ; export logfile

sp_env="/export/home/oracle/.bashrc.inst_b" ; export sp_env

sp_start_cmd='/u02/app/quest/sp/bin/sp_cop-uinst_b&'

spctrl='/u02/app/quest/sp/bin/sp_ctrl'

case "$1" in

'start')

echo "Starting Shareplex" | tee -a ${logfile}

su - oracle <<EOF

source ${sp_env}

set|grep "SP_" >> ${logfile}

${sp_start_cmd} >> ${logfile}

sleep 30

exit

EOF

echo | tee -a ${logfile}

;;

'stop')

echo "Stopping Shareplex" | tee -a ${logfile}

su - oracle <<EOF

source ${sp_env}

set|grep "SP_" >> ${logfile}

crs configuration1
CRS Configuration

echo "shutdown" | ${spctrl} | tee -a ${logfile}

exit

EOF

echo | tee -a ${logfile}

;;

‘check')

echo "Checking Shareplex" | tee -a ${logfile}

sp_check=$(ps -ef|grep "sp_cop"|grep -v grep|wc -l)

if [ ${sp_check} -gt 0 ] ; then

echo "Shareplex is running" | tee -a ${logfile}

echo | tee -a ${logfile}

exit 0

else

echo "Shareplex is not running " | tee -a ${logfile}

echo | tee -a ${logfile}

exit 1

fi

;;

'clean')

echo "Cleaning Shareplex" | tee -a ${logfile}

;;

esac

crs configuration2
CRS Configuration

Create the CRS Resource:On Silo A and Silo B (as root):

${CRS_HOME}/bin/crsctl add resource shareplex -type cluster_resource -attr "AGENT_FILENAME="%"CRS_HOME"%"/bin/scriptagent, ACTION_SCRIPT=/u02/app/quest/scripts/spctl.sh, DESCRIPTION=, DEGREE=1, ENABLED=1, AUTO_START=always, START_TIMEOUT=0, UPTIME_THRESHOLD=1h, CHECK_INTERVAL=10, STOP_TIMEOUT=0, SCRIPT_TIMEOUT=60, RESTART_ATTEMPTS=2, OFFLINE_CHECK_INTERVAL=0, START_DEPENDENCIES=hard(shareplex.vip) pullup(shareplex.vip), STOP_DEPENDENCIES=hard(intermediate: shareplex.vip),CARDINALITY=1, FAILURE_INTERVAL=0, FAILURE_THRESHOLD=0, SERVER_POOLS=*, PLACEMENT=balanced, LOAD=1, ACTIVE_PLACEMENT=1”

Set CRS Resource Permissions:

On Silo A and Silo B (as root):

${CRS_HOME}/bin/crs_setpermshareplex -u user:oracle:r-x

administration
Administration

Useful CRS Commands:

Start:

${CRS_HOME}/bin/crsctl start resource shareplex

VIP will start automatically

# ${CRS_HOME}/bin/crsctl start resource shareplex.vip

Stop:

${CRS_HOME}/bin/crsctl stop resource shareplex

${CRS_HOME}/bin/crsctl stop resource shareplex.vip

Relocate:

${CRS_HOME}/bin/crsctl relocate resource shareplex -s <existing node> -n <new node> -f

administration continued
Administration - Continued

sp_ctrl commands:

status – checks the status of shareplex processes

qstatus – shows the current status of the shareplex queues

shutdown – shutdown the shareplexsp_cop process

showlogreverse – shows the event_log in reverse order

show post detail – show a detail view of the post process

show capture detail – show a detail view of the capture process

show sync – shows if there are known out of sync tables

compare – compares a table or wildcard list of tables

repair – repairs a table or wildcard list of tables

comparestatus – shows the current status of a compare process

repairstatus – shows the current status of a repair process

administration continued1
Administration - Continued

Compare/RepairTable:

sp_ctrl > comparesp_demo.test

IDTablename Status Time Total Rows %Comp Total Time------ ------------------------------------ ---------- ---------- ---------- ----- ----------1      ”SP_DEMO"."TEST"                Out SyncN/A        2 100 0:07

sp_ctrl > repairsp_demo.test

ID     Tablename Status Time Total Rows %Comp Total Time------ ------------------------------------ ---------- ---------- ---------- ----- ----------1      ”SP_DEMO"."TEST"                Repaired N/A          0 100 0:07

NOTE: After running compare and finding “out of sync” it will not show in “show sync”

administration continued2
Administration - Continued

Adding an object to existing configuration:

  • Create the object on the source (and target if not using DDL replication).
  • sp_ctrl > activate configschema_name_all

NOTE: Do not deactivate configuration as you will lose transactions and be forced to re-synchronize the source and target environments.

final thoughts
Final Thoughts

We are pleased with the overall value of the SharePlex product. The cost is reasonable for the functionality it provides, and we are satisfied with the stability and performance as well. If you combine that with the ease of setup and administration it becomes clear that SharePlex is a good fit for Xactware.
