Presentation Transcript
object space ewa surface splatting a hardware accelerated approach to high quality point rendering

CMU

Object Space EWA Surface Splatting: A Hardware Accelerated Approach to High Quality Point Rendering

Liu Ren

Hanspeter Pfister

Matthias Zwicker

motivation
Motivation
  • Point-based graphics needs high quality texture filtering
  • High quality point rendering lacks hardware support
  • GPU performance outpaces CPU

[Wolfman Geforce 4 demo]

Pure Hardware Accelerated + High Quality?

Yes!

related work
Related Work

Object Space EWA Splatting EG 02

point based surface representation

Surface Element (Surfel)

normal

y

surfel tangent plane

z

x

  • No connectivity
  • No texture maps, no normal maps, etc

2D reconstruction filter

Point-based Surface Representation
surfel rendering splatting

warp

screen space

object space

surfel reconstruction filter

y

x

aliasing

warped reconstruction filter

y

z

x

Surfel Rendering: Splatting
surfel rendering screen space ewa filtering

warp

screen space

object space

warped reconstructionfilter

screen space resampling filter

low-pass filter

Surfel Rendering: Screen Space EWA Filtering

reconstruction filter

  • Elliptical Weighted Average (EWA) filtering
  • EWA Splat = low-pass filter warped reconstruction filter
  • Screen space EWA splatting not supported by graphics hardware.
surfel rendering object space ewa filtering

warp

screen space

object space

warped

low-pass filter

reconstruction

filter

tangent spaceresampling filter

low-pass filter

Surfel Rendering: Object Space EWA Filtering
  • Tangent space resampling filter = warped low-pass filter reconstruction filter
  • View dependent filter
hardware accelerated point based rendering

normal

surfel tangent plane

Textured polygons

Tangent space resampling filters

Texture mapping

EWA splats in frame buffer

Additive alpha

blending

Warped surface

texture reconstruction

Hardware Accelerated Point-based Rendering
challenges

Correct visibility in hardware

?

  • No holes, hidden surface splats removal
  • Lack of A-buffer support

?

EWA resampling filter

  • View dependent
  • Texture or polygon not fixed
Challenges
two pass algorithm overview

1. Visibility splatting

  • Disable frame buffer updates
  • Render opaque quad for each surfel
  • Generate depth image with a small offset

2. Resampling filter splatting

  • Disable Z-buffer updates
  • Render textured polygons with additive alpha blending
Two Pass Algorithm Overview
first pass visibility splatting schemes

surface

surface

occlusion artifacts

depth image

depth image

QSplat

z

z

camera space

camera space

Object Space EWA

First Pass: Visibility Splatting Schemes
second pass handle view dependent ewa resampling filter

elliptical gaussian (tangent space resampling filter)

texture (unit gaussian)

(0,1)

(1,1)

match

(0,0)

(1,0)

texturemapping

surfel polygon with unknown geometry

tangent space quad with known geometry

vertex computation

textured quad

Second Pass: Handle View Dependent EWA Resampling filter
normalization issues

Per-pixel normalization:

  • Read back data from frame buffer
  • Post-processing scheme
  • Bad for hardware acceleration

Per-surfel normalization:

  • Pre-compute the surfel normalization weight
  • Pre-processing scheme
  • Good for hardware acceleration

without normalization

with normalization

no artifacts

varying brightness

Normalization Issues
demo checkerboard on geforce 4 ti 4600

Splatting No Filtering

V.S.

Object Space EWA Filtering

Object Space EWA / Points

V.S.

Anisotropic Texture Filtering + Accuview /Triangle Mesh

Demo: Checkerboard on Geforce 4 Ti 4600

:

conclusion
Conclusion
  • New object space formulation of EWA surface splatting
  • Completely hardware accelerated approach with negligible CPU involvement
  • Benefits from GPU performance improvements
future work
Future Work
  • Semitransparent point models
  • View dependent BRDF shading
  • Animated point models
  • Optimization with upcoming hardware features
acknowledgments

CMU

Acknowledgments

Jessica Hodgins, Paul Heckbert

Micheal Doggett, Evan Hart, Jeff Royle

Henry Moreton

Jennifer Pfister, Wei Li, Wei Chen

Http://www.cs.cmu.edu/~liuren/research.htm
