dickson k w chiu phd smieee deitel et al java web services for experienced programmers

Web Services Programming

Java Web Services Programming

Dickson K.W. Chiu

PhD, SMIEEE

Deitel et al., Java Web Services for Experienced Programmers

java web services development pack jwsdp
Java Web Services DevelopmentPack (JWSDP)
  • Now integrated into J2EE 1.4
  • Provides a convenient all-in-one package
  • Geared for developers
  • Contains
    • JAXP (Java API for XML Processing)
    • JAX-RPC (Java API for XML-based RPC)
    • SAAJ (SOAP with Attachments API for Java)
    • JAXR (Java API for XML Registries)
    • JAXM (Java API for XML Messaging)
  • See: http://java.sun.com/webservices/

Dickson Chiu 2005

jax rpc and jaxm
JAX-RPC and JAXM
  • Both based on SOAP with Attachments
  • For web service programming
  • Sun recommends JAX-RPC – easier to program
  • SAAJ / JAXM
    • Interoperability (e.g. calling other clients)
    • Non-blocking option

Dickson Chiu 2005

jax rpc
JAX-RPC
  • Java™ API for XML-based RPC
  • RPC requests and responses represented using SOAP
  • Both Web service endpoints and clients use JAX-RPC
  • Services are described using WSDL
  • Key technology for Web Services in the upcoming J2EE 1.4 platform

Dickson Chiu 2005

remote procedure call rpc
Remote Procedure Call (RPC)

RPC, COM, CORBA, RMI:

  • Synchronous communication - calling process blocks until there is a response
  • Tightly coupled - client must find recipients and know method arguments
  • Non persistent

Dickson Chiu 2005

jax rpc design goal
JAX-RPC Design Goal
  • Easy to use programming model
    • Defining a service
    • Using a service
  • Hides all the plumbing – complexity of SOAP messaging
  • SOAP and WSDL-based interoperability
    • Interoperate with any SOAP compliant peers
  • Extensibility and Modularity
    • Support future versions of XML specification, i.e., XMLP (SOAP 1.2 and beyond)
  • Message handler architecture

Dickson Chiu 2005

what happen during an rpc
What happen during an RPC?
  • To call a remote procedure, the HelloClient program invokes a method on a stub, a local object that represents the remote service.
  • The stub invokes routines in the JAX-RPC runtime system.
  • The runtime system converts the remote method call into a SOAP message and then transmits the message as an HTTP request.
  • When the server receives the HTTP request, the JAX-RPC runtime system extracts the SOAP message from the request and translates it into a method call.
  • The JAX-RPC runtime system invokes the method on the tie object.
  • The tie object invokes the method on the implementation of the HelloWorld service.
  • The runtime system on the server converts the method's response into a SOAP message and then transmits the message back to the client as an HTTP response.
  • On the client, the JAX-RPC runtime system extracts the SOAP message from the HTTP response and then translates it into a method response for the HelloClient program.

Dickson Chiu 2005

service description and wsdl
Service Description and WSDL

JAX-RPC describes a Web Service as a collection

of remote interfaces and methods

  • JAX-RPC service endpoint mapped to WSDL service description
  • WSDL enables export of a JAX-RPC service endpoint across heterogeneous environments
  • JAX-RPC specifies the standard WSDL<-> Java mapping:
    • Mapping between service endpoint interface and WSDL definitions
    • Binding to specific protocol and transport
    • XML <-> Java data types

Tools are used to convert between WSDL documents and sets of Java remote interfaces

WSDL describes a Web Service as a

collection of ports and operations

Dickson Chiu 2005

wsdl mapping
WSDL Mapping
  • wsdl:portType mapped into a Java Interface (Service Definition Interface) that extends java.rmi.Remote
  • wsdl:operation mapped into a method of the Service definition interface
  • wsdl:message's are mapped into parameters of the method
  • wsdl:type's of wsdl:message's are mapped into the types of the parameters

Dickson Chiu 2005

wsdl mapping example
WSDL Mapping Example

<!------------------- WSDL Document ------------------------------------->

<message name=”GetLastTradePriceInput”>

<part name=”tickerSymbol” type=”xsd:string”/>

</message>

<message name=”GetLastTradePriceOutput”?

<part name=”result” type=”xsd:float”/>

</message>

<portType name=”StockQuoteProvider”>

<operation name=”GetLastTradePrice” parameterOrder=”tickerSymbol”>

<input message=”tns:GetLastTradePriceInput”/>

<output message=”tns:GetLastTradePriceOutput”/>

</operation>

</portType>

public interface StockQuoteProvider extends java.rmi.Remote {

float getLastTradePrice(String tickerSymbol)

throws java.rmi.RemoteException;

}

Dickson Chiu 2005

supported java type
Supported Java Type

See J2EE tutorial

  • Note: all objects are passed by copy
  • Java primitive types
  • String, Date, Calendar, BigInteger, BigDecimal
  • Multi-dimensional Java arrays
  • JAX-RPC value type – classes you’ve written for your applications, based on the above
  • JavaBean Components – also based on the above

Dickson Chiu 2005

developing a jax rpc web service
Developing a JAX-RPC Web Service
  • Define service endpoint
  • Implement Service endpoint
  • Compile code and generate WSDL
  • Packaging WAR and deploy

Dickson Chiu 2005

0 setting the port
0. Setting the Port

If you do not use the default port 8080, edit:

  • <INSTALL>/j2eetutorial14/examples/common/build.properties
  • <INSTALL>/j2eetutorial14/examples/jaxrpc/staticstub/config-wsdl.xml
  • <INSTALL>/j2eetutorial14/examples/jaxrpc/dynamicproxy/config-wsdl.xml
  • <INSTALL>/j2eetutorial14/examples/jaxrpc/appclient/config-wsdl.xml
  • <INSTALL>/j2eetutorial14/examples/jaxrpc/webclient/config-wsdl.xml
  • <INSTALL>/j2eetutorial14/examples/jaxrpc/webclient/web/response.jsp
  • <INSTALL>/j2eetutorial14/examples/security/basicauthclient/SecureHello.wsdl
  • <INSTALL>/j2eetutorial14/examples/security/mutualauthclient/SecureHello.wsdl

Dickson Chiu 2005

1 service endpoint definition
1. Service Endpoint Definition
  • Specified in Service Definition Interface
    • Could be generated from WSDL document using a tool or
    • Could be written in Java programming language directly
  • No assumption about type of client that would use this service definition interface

package hello;

import java.rmi.Remote;

import java.rmi.RemoteException;

public interface HelloIF extends Remote {

public String sayHello(String s) throws RemoteException;

}

Dickson Chiu 2005

2 service implementation
2. Service Implementation
  • Service implementation class is an ordinary Java class
  • Invocation done inside the servlet container
    • JAX-RPC defines Servlet-based Endpoint model
    • Other endpoint models (e.g., stateless session beans) will be defined in J2EE 1.4 / EJB 2.1
  • Optional ServiceLifecycle interface for initialization and destruction callbacks

package hello;

public class HelloImpl implements HelloIF {

public String message = new String("Hello ");

public String sayHello(String s) {

return new String(message + s);

}

}

  • package hello;
  • import java.rmi.Remote;
  • import java.rmi.RemoteException;
  • public interface HelloIF extends Remote {
  • public String sayHello(String s)
  • throws RemoteException;
  • }

Dickson Chiu 2005

3 compiling wsdl generation
3. Compiling / WSDL generation
  • Use the ant tool simplifies the job
  • Compile HelloIF.java and HelloImpl.java, go to the <INSTALL>/j2eetutorial14/examples/jaxrpc/helloservice/ directory and type the following: ant build
    • compile-service: compiles HelloIF.java and HelloImpl.java, writing the class files to the build subdirectory
    • generate-wsdl: runs wscompile, creating MyHelloService.wsdl and mapping.xml
  • Customize wsdl generation with config-interface.xml

<?xml version="1.0" encoding="UTF-8"?>

<configuration xmlns="http://java.sun.com/xml/ns/jax-rpc/ri/config">

<service name="MyHelloService" targetNamespace="urn:Foo"

typeNamespace="urn:Foo" packageName="helloservice">

<interface name="helloservice.HelloIF"/>

</service>

</configuration>

Dickson Chiu 2005

4 packaging the war file i
4. Packaging the WAR file (i)
  • Use Deploytool to create a standalone WAR module

Dickson Chiu 2005

4 packaging the war file ii
4. Packaging the WAR file (ii)
  • Use Deploytool to create a standalone WAR module

Dickson Chiu 2005

4 packaging the war file iii
4. Packaging the WAR file (iii)
  • Enter context root
  • Add alias “hello”
  • Update the endpoint address to hello (see previous slide)
  • Save and Deploy

Dickson Chiu 2005

4 another way to deploy the war file
4’. Another way to deploy the WAR file
  • To create the WAR file that contains the service code:
    • asant create-war
  • Set your admin port, username, and password in <INSTALL>/j2eetutorial14/examples/common/build.properties.
  • To deploy the WAR file:
    • asant deploy-war
  • Note this may create different

naming

Dickson Chiu 2005

jax rpc clients
JAX-RPC Clients
  • Independent of how an XML based RPC service (service endpoint) is implemented on the server side
  • Generates a Java based client side representation for a service from WSDL document
  • Not tied to a specific XML based protocol, transport or any JAX-RPC implementation specific mechanism
  • Can use either J2SE or J2EE
  • 3 programming modes:
    • Static stub-based – least dynamic, easiest to program - you know everything about the services and pre-generate the stub
    • Dynamic proxy - call location dynamic (URL/service/name), information about the service by looking up WSDL document at run time (but signature of method fixed)
    • Dynamic invocation interface (DII) – everything dynamic, but more tedious and more time to set up a call

Dickson Chiu 2005

wsdl generated
WSDL Generated

<?xml version="1.0" encoding="UTF-8"?>

<definitions name="MyHelloService" targetNamespace="urn:Foo" xmlns:tns="urn:Foo" xmlns="http://schemas.xmlsoap.org/wsdl/" xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:soap="http://schemas.xmlsoap.org/wsdl/soap/">

<types/>

<message name="HelloIF_sayHello">

<part name="String_1" type="xsd:string"/></message>

<message name="HelloIF_sayHelloResponse">

<part name="result" type="xsd:string"/></message>

<portType name="HelloIF">

<operation name="sayHello" parameterOrder="String_1">

<input message="tns:HelloIF_sayHello"/>

<output message="tns:HelloIF_sayHelloResponse"/></operation></portType>

<binding name="HelloIFBinding" type="tns:HelloIF">

<soap:binding transport="http://schemas.xmlsoap.org/soap/http" style="rpc"/>

<operation name="sayHello">

<soap:operation soapAction=""/>

<input>

<soap:body encodingStyle="http://schemas.xmlsoap.org/soap/encoding/" use="encoded" namespace="urn:Foo"/></input>

<output>

<soap:body encodingStyle="http://schemas.xmlsoap.org/soap/encoding/" use="encoded" namespace="urn:Foo"/></output></operation></binding>

<service name="MyHelloService">

<port name="HelloIFPort" binding="tns:HelloIFBinding">

<soap:address location="REPLACE_WITH_ACTUAL_URL"/></port></service></definitions>

Dickson Chiu 2005

wsdl mapping binding port service
WSDL Mapping - binding, port, service
  • wsdl:service is mapped into an implementation of javax.xml.rpc.Service interface
  • JAX-RPC runtime provides the implementation
  • A javax.xml.rpc.Service class acts as a factory of either
    • Instance of a generated stub class
    • Dynamic proxy for a service port
    • Instance of the object javax.xml.rpc.Call for the dynamic invocation of a remote operation on a service port

Dickson Chiu 2005

static stub client code
Static Stub - Client Code

package staticstub;

import javax.xml.rpc.Stub;

public class HelloClient {

private String endpointAddress;

public static void main(String[] args) {

System.out.println("Endpoint address = " + args[0]);

try {

Stub stub = (Stub) (new MyHelloService_Impl().getHelloIFPort());

stub._setProperty(javax.xml.rpc.Stub.ENDPOINT_ADDRESS_PROPERTY, args[0]);

HelloIF hello = (HelloIF) stub;

System.out.println(hello.sayHello("Duke!"));

} catch (Exception ex) {

ex.printStackTrace();

}

}

}

// output – “Hello Duke!”

Generated by wscompile before writing this program (i.e., static and implementation-specific)

Dickson Chiu 2005

static stub build and run
Static Stub – build and run
  • To automate the rest of the steps, go to the <INSTALL>/j2eetutorial14/examples/jaxrpc/staticstub/ directory and type the following: asant build
    • generate-stubs: wscompile -gen:client -d build -classpath build config-wsdl.xml

<configuration xmlns="http://java.sun.com/xml/ns/jax-rpc/ri/config">

<wsdl location="http://localhost:8080/hello-jaxrpc/hello?WSDL“

packageName="staticstub"/>

</configuration>

    • compile-client: compiles src/HelloClient.java and writes the class file to the build subdirectory.
    • package-client: packages the files created by the generate-stubs and compile-client tasks into the dist/client.jar file.
  • Run the client - asant run

Dickson Chiu 2005

dynamic proxy based client
Dynamic Proxy-based Client
  • Client calls a remote procedure through a dynamic proxy
  • Client gets information about the service by looking up its WSDL document at runtime - call location (URL/service/name)
  • But the signature (parameters and their types) of the method is fixed
  • The Service class that is created during runtime
  • Similar usage of asant
  • However, only the service endpoint interface class of the sample target is used but not the generated stub

Dickson Chiu 2005

example dynamic proxy based client
package dynamicproxy;

import java.net.URL;

import javax.xml.rpc.Service;

import javax.xml.rpc.JAXRPCException;

import javax.xml.namespace.QName;

import javax.xml.rpc.ServiceFactory;

import dynamicproxy.HelloIF;

public class HelloClient {

public static void main(String[] args) {

try {

String UrlString = args[0] + "?WSDL";

String nameSpaceUri = "urn:Foo";

String serviceName = "MyHelloService";

String portName = "HelloIFPort";

System.out.println("UrlString = " + UrlString);

URL helloWsdlUrl = new URL(UrlString);

ServiceFactory serviceFactory = ServiceFactory.newInstance();

Service helloService =

serviceFactory.createService(helloWsdlUrl,

new QName(nameSpaceUri, serviceName));

dynamicproxy.HelloIF myProxy =

(dynamicproxy.HelloIF) helloService.getPort

(new QName(nameSpaceUri,portName),

dynamicproxy.HelloIF.class);

System.out.println(myProxy.sayHello(“Buzz”));

} catch (Exception ex) {

ex.printStackTrace();

}

}

}

Example Dynamic Proxy-based Client

Dickson Chiu 2005

dynamic invocation interface dii client
Dynamic Invocation Interface (DII) Client
  • Dynamic invocation of an operation on the target service endpoint
  • Enables broker model
  • Client finds (through search criteria) from a UDDI directory and invokes a service during runtime through a broker
    • Note: the code in the following example does not show the lookup and simply hardcode the services in strings
  • Used when service definition interface is not known until runtime
  • Set all operation and parameters during runtime
  • From the Service object create Call object first
  • Similar usage of asant

Dickson Chiu 2005

dii client example
package dii;

import javax.xml.rpc.Call;

import javax.xml.rpc.Service;

import javax.xml.rpc.JAXRPCException;

import javax.xml.namespace.QName;

import javax.xml.rpc.ServiceFactory;

import javax.xml.rpc.ParameterMode;

public class HelloClient {

private static String qnameService = "MyHelloService";

private static String qnamePort = "HelloIF";

private static String BODY_NAMESPACE_VALUE = "urn:Foo";

private static String ENCODING_STYLE_PROPERTY =

"javax.xml.rpc.encodingstyle.namespace.uri";

private static String NS_XSD = "http://www.w3.org/2001/XMLSchema";

private static String URI_ENCODING =

"http://schemas.xmlsoap.org/soap/encoding/";

public static void main(String[] args) {

System.out.println("Endpoint address = " + args[0]);

try {

ServiceFactory factory = ServiceFactory.newInstance();

Service service = factory.createService(new QName(qnameService));

QName port = new QName(qnamePort);

Call call = service.createCall(port);

call.setTargetEndpointAddress(args[0]);

call.setProperty(Call.SOAPACTION_USE_PROPERTY, newBoolean(true));

call.setProperty(Call.SOAPACTION_URI_PROPERTY, "");

call.setProperty(ENCODING_STYLE_PROPERTY, URI_ENCODING);

QName QNAME_TYPE_STRING = new QName(NS_XSD, "string");

call.setReturnType(QNAME_TYPE_STRING);

call.setOperationName(new QName(BODY_NAMESPACE_VALUE, "sayHello"));

call.addParameter(“String_1”, QNAME_TYPE_STRING,

ParameterMode.IN);

String[] params = { "Murph!" };

String result = (String) call.invoke(params);

System.out.println(result);

} catch (Exception ex) {

ex.printStackTrace();

} }}

DII Client Example

Dickson Chiu 2005

slide32
JAXM
  • Java API for XML Messaging
  • Java support for sending and receiving SOAP XML document oriented messages
  • Two JAXM API Programming Models
    • Point-to-point model – simpler
    • JAXM Provider-based" (like a "messaging server") model - supports Asynchronous messaging
  • Design Goals
    • Build on SOAP with Attachments
    • Add support to plug higher-level messaging protocols (e.g., ebXML)
    • Design for easy porting of applications from one container to another – specifically from web containers to that of J2EE
    • Don’t attempt to build a full-fledged messaging API (e.g., JMS)

Dickson Chiu 2005

jaxm point to point model
JAXM Point-to-Point Model
  • Synchronous Request-response interaction
  • Calling process blocks until there is a response
  • Connection established directly to the ultimate recipient
    • No persistence
    • can be difficult to scale

Dickson Chiu 2005

jaxm provider model
JAXM Provider Model
  • Asynchronous (or Synchronous you choose)
  • Sender is not blocked, Receiver does not have to be available
  • Reliable - Message can be stored and forwarded (routed) until it can be delivered
  • JAXM Provider works behind the scene

Dickson Chiu 2005

jaxm provider
JAXM Provider
  • Offers message routing and reliable messaging as all messages go through it
  • Assign message identifiers and keeping track of messages
  • JAXM client makes JAXM method calls, and the provider (working with container) makes everything happen
  • JAXM providers are responsible for producing an error message and sending it to the offending JAXM client when receiving a malformed message
  • Responsibility of JAXM application to consume error messages and take corrective actions

Dickson Chiu 2005

jaxm client
Not using JAXM provider

Just a standalone J2SE application

Point to point operation

Establishes a connection directly with the service (using a URL)

Synchronous only

Request/response interaction

Using JAXM provider

Maintains a connection with JAXM provider, and all messages go through the provider

JAXM client deployed in a web or EJB container

MessageDrivenBean

JAXMServlet

Send and receive messages synchronously or asynchronously

JAXM client

Dickson Chiu 2005

jaxm vs jms
Differences

JAXM provider could be lightweight while JMS provider is usually heavyweight

JAXM supports standalone mode while JMS does not

JAXM client is interoperable over any SOAP compatible client while JMS client is interoperable only with other JMS client over the same messaging system

Delivery endpoint model is different

Similarities

Both supports Messaging Provider model

Reliable, secure message delivery

Routing

Both supports asynchronous message delivery

JAXM vs. JMS

Dickson Chiu 2005

using saaj api to call a web service
Using SAAJ API to call a Web Service
  • Steps
    • Create SOAP message
    • Populate SOAP message
    • Add attachments (optional)
    • Initialize SOAP connection
    • Send SOAP message
    • Analyze response message
  • Code based on J2EE tutorial p.398 request.java
  • Library files required:

H:/Sun/Appserver/lib/j2ee.jar;H:/Sun/Appserver/lib/saaj-impl.jar;H:\Sun\AppServer\lib\endorsed\xercesImpl.jar;H:\Sun\AppServer\lib\endorsed\dom.jar;.

  • Example based on URL:
    • http://www.mindreef.net/tide/scopeit/start.do?referer=xmethods&url=http://services.xmethods.net/soap/urn:xmethods-delayed-quotes.wsdl

Dickson Chiu 2005

saaj example code
import javax.xml.soap.*;

import java.util.*;

import java.net.URL;

public class Request {

public static void main(String[] args) {

try {

SOAPConnectionFactory soapConnectionFactory = SOAPConnectionFactory.newInstance();

SOAPConnection connection = soapConnectionFactory.createConnection();

SOAPFactory soapFactory = SOAPFactory.newInstance();

MessageFactory factory = MessageFactory.newInstance();

SOAPMessage message = factory.createMessage();

SOAPHeader header = message.getSOAPHeader();

SOAPBody body = message.getSOAPBody();

header.detachNode();

SAAJ Example Code

Dickson Chiu 2005

saaj example code 2
Name bodyName = soapFactory.createName( "getQuote", "m",

"urn:xmethods-delayed-quotes");

SOAPBodyElement bodyElement = body.addBodyElement(bodyName);

Name name = soapFactory.createName("symbol");

SOAPElement symbol = bodyElement.addChildElement(name);

symbol.addTextNode(args[0]);

URL endpoint = new URL("http://64.124.140.30:9090/soap");

SOAPMessage response = connection.call(message, endpoint);

connection.close();

response.writeTo(System.out);

} catch (Exception ex) {

ex.printStackTrace();

}

}

}

<SOAP-ENV:Envelope xmlns:SOAP-ENV=

"http://schemas.xmlsoap.org/soap/envelope/">

<SOAP-ENV:Body>

<m:getQuote xmlns:m=" urn:xmethods-delayed-quotes">

<symbol>XXXX</symbol>

</m:getQuote>

</SOAP-ENV:Body>

</SOAP-ENV:Envelope>

SAAJ Example Code (2)

Dickson Chiu 2005

saaj result message
SAAJ Result Message

<soap:Envelope

soap:encodingStyle="http://schemas.xmlsoap.org/soap/encoding/"

xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:soapenc="http://schemas.xmlsoap.org/soap/encoding/">

<soap:Body>

<n:getQuoteResponse xmlns:n="urn:xmethods-delayed-quotes">

<Result xsi:type="xsd:float">4.15</Result>

</n:getQuoteResponse>

</soap:Body>

</soap:Envelope>

Dickson Chiu 2005

adding attachment with saaj
Adding Attachment with SAAJ

// We're using a HTTP image repository here

// to get the data for an image

URL url = new URL ("http://images.wombats.com/w.jpg");

// Create a JAF DataHandler with this URL

DataHandler dh = new DataHandler(url);

// Create and Add an AttachmentPart

message.addAttachmentPart(

message.createAttachmentPart(dh));

Dickson Chiu 2005

summary calling web services in java
Summary – Calling Web Services in Java
  • Use JAX-RPC
    • Static Stub – you know everything about the services and pre-generate the stub
    • Dynamic Proxy – call location dynamic (URL/service/name), information about the service by looking up WSDL document at run time (but signature of method fixed)
    • DII – everything lookup at run time, i.e., call and parameters prepared at runtime
  • Send SOAP messages with SAAJ
    • for most flexibility
    • target is not RPC

Dickson Chiu 2005
