Presentation Transcript
olga zoidi anastasios tefas member ieee ioannis pitas fellow ieee

Visual Object Tracking Based on Local Steering Kernels and Color HistogramsIEEE TRANSACTIONS ON CIRCUITS AND SYSTEMS FOR VIDEO TECHNOLOGYVOL. 23, NO.5, MAY 2013

Olga Zoidi, AnastasiosTefas, Member, IEEE Ioannis Pitas, Fellow, IEEE

overview
Overview

Introduction

Proposed method

Experiment Result

Conclusion

overview1
Overview

Introduction

  • Visual tracking
  • Object representation
  • Object position prediction

Proposed method

Experiment Result

Conclusion

visual tracking
Visual Tracking

Visual tracking is difficult to accomplish as some reason

  • Illumination conditions
  • Object may be nonrigid or articulated
  • Occluded
  • Rapid and complicated movements
overview2
Overview

Introduction

  • Visual tracking
  • Object representation
  • Object position prediction

Proposed method

Experiment Result

Conclusion

object representation
Object Representation

Model-based

Appearance-based

Contour-based

Feature-based

Hybrid

object representation model based
Object Representation : Model-Based

Exploit a priori information about the object shape and create model [7].

Deal with the problem of object tracking under illumination variations, viewing angle, and partial occlusion.

Heavy cost.

[7]D.Roller, etc, “Model-based object tracking in monocular image sequences of road traffic scenes” Int. J. Comput. Vision, vol. 10, pp. 257-281, Mar.1993.

object representation appearance based
Object Representation : Appearance-Based

Use the visual information for the object projection on the image plane, i.e., color, texture, and shape.

Deal with simple object transformation.

Sensitive to illumination changes.

object representation contour based
Object Representation : Contour-Based

By employing shape matching or contour-evolution techniques [9]. Contour can be represented by active models, such as snakes or B-splines [10].

Deal with rigid and nonrigid objects.

Incorporate with occlusion detection and estimation techniques.

[9] A. Yilmaz, X.Li, and M. Shah, “Contour-based object tracking with occlusion handling in video acquired using mobile cameras”, IEEE Trans. Pattern Anal. Mach. Intell., vol. 26, no. 11, pp. 1531-1536, Nov. 2004

[10] Y.Wang and O. Lee, “Active mesh – a feature seeking and tracking image sequence representation scheme”, IEEE Trans, Image Process, vol.3, no. 5, pp. 610-624, Sep. 1994

object representation feature based
Object Representation : Feature-Based

By tracking a set of feature points and these features are then grouped.

Problem is the correct distinction between the target object and background features.

overview3
Overview

Introduction

  • Visual tracking
  • Object representation
  • Object position prediction

Proposed method

Experiment Result

Conclusion

object position prediction
Object Position Prediction

The position of the object in the following frame is usually predicted using a linear Kalmanfilter. [32]

[32] G. Welch and G. Bishop, “An introduction to the Kalman filter,” Univ. North Carolina, Chapel Hill, NC, Tech. Rep. TR95041, 2000.

overview4
Overview

Introduction

Proposed method

Experiment Result

Conclusion

proposed method
Proposed Method

Some tips of object tracking algorithm

  • Using color histogram (CH) to handle severe change in the object view.
  • Using decomposing target into fragments, which are tracked separately, to handle partial occlusion.
  • Using local steering kernel (LSK) object texture descriptor to represent the region of interest (ROI).

Proposed tracking approach is an appearance based method using both CHs and LSK descriptor.

proposed method1
Proposed Method

First, search image regions in video frame that have high color similarity to the object CH, and get candidate regions.

Next, LSK descriptors of both the target object and candidate search regions are extracted.

Discard the image regions with small CH similarity to the object CH, the new position of the object is selected as the image region, whose LSK representation has the maximum similarity to the one of the target object.

As tracking evolves, target object appearance changes and being a stack containing different instances. Stack is updated with the representation of the most recent detected object.

lsk object tracing framework
LSK Object Tracing Framework

Steps

  • Initialization of the object ROI in the first video frame. Initialization can be done manually.
  • Use CH information for color similarity search in the current search region. CH information can lead to background subtraction and reduction of the number of the candidate.
  • Representation of both the object and search region with LSK features.
  • Decision on the object ROI in the new frame, based on the similarities between candidate and: a) ROI in the previous frame, and b) top object instance in the stack.
  • Update the object instance in the stack.
  • Prediction of the object position in the following video frame and initialization of an object search region.
overview5
Overview

Introduction

Proposed method

  • Color Similarity
  • Object Texture Description
  • Object Localization and Model Update
  • Search Region Extraction in The Next Frame

Experiment Result

Conclusion

color similarity
Color Similarity

After object position prediction and search region selection, the search region of size R1*R2 is divided into candidate ROI which size is Q1*Q2.

Parameter d determines a uniform sampling of the candidate object ROIs every d pixels in the search region.

  • At frame t, the Bt% of the search region patches with the minimal histogram similarity to the object histogram are considered to belong to the background.
  • Cosine similarity :
  • Normalized form S =
color similarity1
Color Similarity

Three color channels’ S of all patches comprise a matrix MCH.

The distribution of MCH takes values and sets a threshold in deciding whether the patch is a valid candidate ROI.

Finally, the binary matrix BCH, whose entry is set to 1 if entry of MCH is ≧threshold and 0, otherwise. BCH will be used in tracking in Object Location section.

Setting , and as the mean, maximal, and minimal values of entries, respectively.

overview6
Overview

Introduction

Proposed method

  • Color Similarity
  • Object Texture Description
  • Object Localization and Model Update
  • Search Region Extraction in The Next Frame

Experiment Result

Conclusion

object texture description
Object Texture Description

Introduction of LSK descriptors

  • LSKs are descriptors of the image salient features.
  • They were proven to be robust in small scale and orientation changes and deformations.
  • Result in successful tracking of slowly deformable objects.

LSKs descriptors are a nonlinear combination of weighted spatial distances between a pixel p of an image of size N1*N2 and its surrounding M*M pixels (pi). (M is equal to 3 pixels in this paper)

The distance K is measured using a weighted Euclidean distance, which uses as weights the covariance matrix Ci of the image gradients.

object texture description1
Object Texture Description

In order to get Ci matrix in Ki(p), get gradient vectors gi and formed matrix GiM^2*2. Where .

And Ci can be calculated via the singular value decomposition (SVD) of Gi.

, and

object texture description2
Object Texture Description

For each neighboring pixel , ,extract K(p) and normalize into , where is the L1-norm.

Above concepts are applied. First converted ROI and search region from RGB to La*b* color space and the LSKs are computed for each channel separately through steps above.

The final representation of ROI is obtained by applying PCA [26].

Finally, the search region is divided into patches and the LSK similarity matrix, which will be used in next section, is estimated (like color similarity) by applying the cosine similarity measure.

[26] H. Seo and P. Milanfar, “Training-free, generic object detection using locally adaptive regression kernels,” IEEE Trans. Pattern Anal. Mach. Intell., vol. 32, no. 9, pp. 1688–1704, Sep. 2010.

overview7
Overview

Introduction

Proposed method

  • Color Similarity
  • Object Texture Description
  • Object Localization and Model Update
  • Search Region Extraction in The Next Frame

Experiment Result

Conclusion

object localization and model update
Object Localization and Model Update

Object localization in the search region is performed by taking into account CH and LSK similarity of patch to the 1ROI in the previous frame and the 2object instance in the stack.

First, divide the search region into overlapping patches of size equal to the detected object. And for each patch, we extract CH and LSK features.

Then, for each patch, we construct three cosine similarity matrices

  • LSK similarity. Between this patch and the detected object in the previous frame.
  • LSK similarity. Between this patch and the last updated object instance.
  • CH similarity. Between this patch and the last updated object instance.
object localization and model update1
Object Localization and Model Update

The new ROI is decided with the final decision matrix, which is computed by . (* denotes the element-wise matrix multiplication and λ usually takes the value 0.5)

The new candidate object position is at the patch with the maximal value maxi,j(Mij).

  • We compare Mij with previous frame’s maximal value Mij’. If the values drops under a threshold, it indicates a possible change in the object appearance.

Other 4 decision matrix of rotation and scaling are calculated. The final decision for the new object is the one which corresponds to the maximal value of five decision matrices.

  • The newly localized object is stored in a stack, which size is constant.
overview8
Overview

Introduction

Proposed method

  • Color Similarity
  • Object Texture Description
  • Object Localization and Model Update
  • Search Region Extraction in The Next Frame

Experiment Result

Conclusion

search region extraction in the next frame
Search Region Extraction in The Next Frame
  • The position of the object in the following frame is predicted using a linear Kalman filter.

The object motion state , and the new state is given by . denotes the process noise, with probability distribution.

After get , we can then get to compute the equation :

Where is a covariance matrix with stochastic model. And this model is adjusted through equations below.

Among the equation above, is the predicted position of a search region’s center.

overview9
Overview

Introduction

Proposed method

Experiment Result

Conclusion

experiment result
Experiment Result

Quantitative evaluationcomparison is performed through the frame detection accuracy (FDA) measure.

FDA calculates the overlap area between the ground truth object and the detected object D at a given frame t.

experiment result1
Experiment Result

The performance of proposed tracker is compared with two other trackers, PF tracker and FT tracker.

Test case:

experiment result3
Experiment Result
  • Test Case1 : test for variation of object scale
experiment result4
Experiment Result
  • Test Case2 : test for variation of object scale
experiment result5
Experiment Result
  • Test Case3 : test for variation of object rotation
experiment result6
Experiment Result
  • Test Case4 : test for variation of partial occlusion
experiment result7
Experiment Result
  • Test Case5 : test for variation of partial occlusion; the man walks behind the woman
experiment result8
Experiment Result
  • Test Case6 : test for strong change in illumination
experiment result9
Experiment Result
  • Test Case7 : test for human activity (orientation of glass)
experiment result10
Experiment Result
  • Test Case8 : test for human activity (hands are articulated objects)
experiment result11
Experiment Result
  • Test Case9 : test for human activity
experiment result12
Experiment Result
  • Test Case10 : test for face tracking
overview10
Overview

Introduction

Proposed method

Experiment Result

Conclusion

conclusion
Conclusion

The tracker extracted a representation of the target object based on LSK and CH at frame and tried to find its location in the frame .

Proposed method is effective in object tracking under severe changes in appearance, affine transformations, and partial occlusion.

The method cannot handle the case of full occlusion. (The tracker continues tracking another object in the background)

Kalman filter cannot follow sudden changes in the object direction or speed. (Although a larger search region may solve the issue, but it would result in rapid decrease of speed)
