kerberos an authentication service for open network systems

KERBEROS:AN AUTHENTICATION SERVICE FOR OPEN NETWORK SYSTEMS

J. G. Steiner, C. Neuman, J. I. Schiller

MIT

authentication servers i
AUTHENTICATION SERVERS (I)
  • Their mission is:

(a) To check identity of all users

(b) To prevent unauthorized accesses

  • Traditional solution is to use a pair(userid, password)
    • Very bad in a LAN environment
    • Too vulnerable to snooping
authentication servers ii
AUTHENTICATION SERVERS (II)
  • Another bad solution is to trust the kernel of sender’s machine:
    • Solution used by rlogin, rsh, rcp
    • Like trusting a foreign passport
    • Only works in well-controlled networks
    • Suffers from domino effect :
      • Gaining full access to one machine gives full access to whole network
cryptography i
CRYPTOGRAPHY (I)

1. Conventional Cryptography

  • Uses same key for coding and encoding
    • Key could be a secret alphabet
  • We now use much more complex schemes and much bigger keys
  • Major problem is key distribution
    • Very hard without a trusted channel
example
Example
  • Assume we have a random stream of bits:

r0 , r1 , r2 , r3 , ...

  • We convert our message into a bit stream:

m0 , m1 , m2 , m3 , ...

  • Encode the message bitwise using XOR:

ci = miri for i = 1, 2, 3 , ...

  • Impossible to break if random bit stream istruly random and never reused
cryptography ii
CRYPTOGRAPHY (II)

2. Public-Key Cryptography

  • Uses two keys:

(a) A public key to encode: KP

(b) A secret key to decode: KS

  • It is not possible to compute KSknowing KP
    • The function KP = f (KS )is said to be hard to invert:
cryptography ii7
CRYPTOGRAPHY (II)
  • We should have
    • { { cleartext }KP }KS = cleartext
    • { { cleartext }KS }KP = cleartext
  • Requires very long keys
  • Cannot pick an arbitrary secret key
  • Much slower than conventional cryptography
example8
Example
  • Assume A knows KP, B and B knows KP, A
    • A can send to B a secret message:

{ text } KP, B

    • A can send to B a message that is signed:

A, { text } KS, A

    • A can send to B a signed secret message:

{ A, { text }KS, A} KP, B

application
Application
  • Can combine conventional cryptography and public-key cryptography
    • A uses public-key cryptography to send to B asigned secret message containing a session key KS
    • A and B use this session key KSto continue their dialogue
kerberos
KERBEROS
  • Authentication server using conventional keys
  • The Kerberos server has
    • The key of each user
    • The key of the ticket granting service (TGS)
  • Authentication is a two-step process
    • Get from kerberos a ticket for the TGS
    • Get from TGS the ticket for a given server
general organization
General Organization

Ticket granting service

TGS

3

4

Kerberos

Server

2

5

6

S

1

WS

K

Client c on workstation WS

general assumptions i
General Assumptions (I)
  • Cannot trust the network:
    • Intruders can listen to all messages and replay them later
  • Can trust the time service
    • No intruder can reset any clock backward by more than a few minutes
general assumptions ii
General Assumptions (II)
  • Client c can trust the workstation WS on which she is logged on:
    • Cannot do encryption without a safe place to encode and decode messages
  • Assumes the workstation is controlled by the client
    • Not true for public workstations
step 1
Step 1
  • Client provides WS with its ID c:

c WS: c

WS sends to Kerberos a request for a ticket for the TGS:

WSK: c, tgs

step 2
Step 2
  • Kerberos sends to WS a ticket Tc,tgs and a random session key Kc,tgs:

KWS: { Kc,tgs, { Tc,tgs }Ktgs}Kc

Both items are encrypted with the client key Kc

Ticket is encrypted with the secret key of the ticket granting service to prevent tampering by client

the ticket i
The ticket (I)
  • Note that the encrypted ticket ticket is encrypted a second time by the client key KC
    • In more recent versions of Kerberos

KWS: { Kc,tgs }Kc, { Tc,tgs}Ktgs

the ticket ii
The ticket (II)
  • Tc,tgs = c, tgs, addr, timestamp, life, Kc,tgs
  • It contains
    • The client's name c
    • The name of the ticket-granting service tgs
    • The IP address of the client addr
    • The current time timestamp
    • A ticket lifetime life
    • The random session key K c,tgs
step 3
Step 3
  • When WS receives Kerberos reply, it prompts the client c for her password and uses it to compute the user key

Kc = fn(password)

and uses Kc to decrypt the message

shared secrets
Shared Secrets

TGS

Ks

Ktgs

Server

Kc

S

WS

K

step 3 continued
Step 3 (continued)
  • WS then sends to the TGS
    • The name of the service s the client wants to utilize
    • The encrypted ticket Tc,tgs
    • An authenticator Ac,tgs encrypted with Kc,tgs

WSTGS: s, { Tc,tgs}Ktgs, { Ac,tgs }Kc,tgs

the authenticator i
The authenticator (I)
  • Any intruder could replay a ticket that has already be submitted to TGS
  • Authenticator contains
    • The client name c
    • Its address addr
    • The current time timestamp

Ac,tgs = c, addr, timestamp

  • Authenticator is encrypted with Kc,tgs
the authenticator ii
The authenticator (II)
  • Authenticator provides proof that WS was able to obtain the session key Kc,tgs by decrypting message number 2 using the right client key KC
  • To detect replays of authenticators, TGS
    • Rejects authenticators that are too old(say, by more than five minutes)
    • Keeps track of all recently received authenticators
step 4
Step 4
  • The TGS replies by sending to the workstation
    • A ticket T cs for the service s
    • A new random session key Kc,s

TGSWS: { Kc,s, { Tc,s}Ks}Kc,tgs

encrypted with the session key Kc,tgs shared by the client and the ticket granting service

step 4 continued
Step 4 (continued)
  • Tc,scontains
    • The user's name c
    • The name of the service s
    • The IP address of the client addr
    • The current time timestamp
    • A new lifetime life
    • A new random session key Kc,s
  • Tc,sis encrypted with the secret key of server s
step 5
Step 5
  • WS then sends to server S
    • the encrypted ticket Tc,s
    • an authenticator Ac,s encrypted with Kc,s

WSS: { Tc,s }Ks, { Ac,s }Kc,s

step 5 continued
Step 5 (continued)
  • Authenticator contains
    • the client name c
    • its address addr
    • the current time timestamp

Ac,s = c, addr, timestamp

  • Authenticator is encrypted with the session key Kc,sshared by client and server
step 6
Step 6
  • If client wanted to authenticate server, the server replies with the authenticator time stamp plus one:

sWS: { timestamp + 1 }Kc,s

encrypted with the session key Kc,s

  • This proves that swas able to obtain the session key Kc,s by decrypting message number 5 using its server key Ks
picking ticket lifetimes
Picking ticket lifetimes
  • There is a trade-off in determining the optimal ticket lifetime:
    • Short ticket lifetimes make the system more secure
      • Less delay between password change and full effect of action
    • Short ticket lifetimes also make the system less convenient for its users.
the kerberos server i
The Kerberos server (I)
  • Most critical part of the system
    • If it is compromised, all user passwords are lost
    • If it is unavailable, nobody will be able to log in
  • A compromised TGS would only force all users to repeat the Kerberos login procedure
the kerberos server ii
The Kerberos server (II)
  • The Kerberos server is normally replicated on several sites:
    • No single point of failure
    • More difficult to maintain key secrecy
  • There is a single primary site and it is the only than can accept key change requests
    • Changing passwords is not a critical task
limitations
LIMITATIONS
  • Must maintain
    • secrecy of keys
    • integrity of time service
  • Client must trust the workstation on which she is logged in
  • Does not protect clients and servers against denial of service attacks
other solutions i
OTHER SOLUTIONS (I)
  • Could use a pair public key/private key
    • private keys cannot be generated from an arbitrary password
    • impossible to memorize
    • must store them somewhere
      • key ring of PGP is encrypted using a strong conventional encryption algorithm
other solutions ii
OTHER SOLUTIONS (II)
  • Could use one-time passwords
    • Use a different password at each log in
    • Passwords can be managed by a smart card
    • User must always carry it with her
    • Some systems also require a password to use the card and disable card after enough unsuccessful trials
      • Must keep card in a rigid container
other solutions iii
OTHER SOLUTIONS (III)
  • SSH-2 uses
    • Diffie-Hellman key exchange
      • Uses public keys and private keys
      • Produces a symmetric session key
    • Strong integrity checking via message authentication codes.
conclusions
CONCLUSIONS
  • Kerberos offers one of the best solutions for authentication in distributed systems
    • Does not require any special equipment
    • Does not significantly alter the user interface
  • Main drawback is that the user must trust the workstation on which she is logged in
    • Works best for personal workstations
