finding security vulnerabilities in java applications with static analysis usenix security 2005

Finding Security Vulnerabilities in Java Applications with Static AnalysisUSENIX Security 2005

Authors: V. Benjamin Livshits and Monica S. Lam

Presented in UIUC CS527 (Fall ’07) by Matt Stockton

introduction motivation
Introduction / Motivation
  • Many web applications create, delete, update, and display sensitive information that has financial value to hackers
  • Many of these web applications are vulnerable to attacks (Imperva Application Defense Center Study)
  • Attacks on web applications are expensive to deal with after the fact (litigation, lost proprietary information, lost customer information, etc.)
  • The most commons means of discovering web application vulnerabilities before application deployment is also expensive.

How can we solve this dilemma?

static analysis overview
Static Analysis Overview

Definition: the analysis of computer software that is performed without actually executing programs built from that software - wikipedia

Many static analysis tools exist for analyzing C/C++ code. These look for buffer overflows, string format vulnerabilities, etc.

Java language safety features prevent direct memory access so static analysis is not as necessary…or is it?

Even with automatic memory management, Java applications are still exploitable , although the vector of attack is quite different. The paper presents a technique for identifying these attack vectors by using static analysis techniques.

unchecked user input
Unchecked User Input
  • Unchecked user input is the source of most web application vulnerabilities
  • Many ways to send data to a web application. Web programmers make assumptions on what data can be sent and how this data will be formatted. When assumptions are wrong, there is opportunity for attack.
  • Attackers must fulfill two goals to exploit unchecked input vulnerabilities:
    • Inject malicious data into a web applications
    • Manipulate web applications using the malicious data
injecting malicious data
Injecting Malicious Data

Parameter Tampering – Enter maliciously formed data into HTML forms

URL Tampering – Directly edit the URL string (usually modifying an HTTP GET request after form submissions)

Hidden Field Manipulation – Web sites sometimes use hidden forms for persistence. An attacker can manually change the values

HTTP Header Manipulation – Free tools allow you to intercept browser requests, and change HTTP headers.

Cookie Poisoning – Manually modify web site cookies stored on a computer

Non-Web Input Sources – Modify command-line parameters sent to web application management scripts.

manipulating apps with unchecked data
Manipulating apps with unchecked data

SQL Injections – Use input to generate SQL queries that will leak information from the database, or perform a malicious insert, update, or deletion. Example: Username:

Cross-Site Scripting – User-controlled content that the web application displays without filtering at all (e.g. load a javascript library, send cookie information to another domain)

HTTP Response Splitting – User-controlled content that the web application uses in the HTTP response header. Web application could send multiple responses, could corrupt proxy cache

Path Traversal – Crafted user input allows user to read / write / update files that shouldn’t be accessible. Example: File To Delete:

Command Injection – Force web application to execute a command it shouldn’t be executing

Matt ‘ OR 1 = 1; --


usual web app security analysis
‘Usual’ web app security analysis
  • Several manual techniques are prevalent for web app security analysis
    • Source code audits by security professionals / white box analysis
    • Penetration testing / black box analysis
  • Shortcomings from manual techniques include
    • Time / cost associated with the investigation
    • Coverage / precision of the investigation
    • If investigation causes code changes, the changes may need to be re-audited

Need a less costly, more automated process for this type of auditing. Primary motivation for this paper.

static analysis in more detail
Static Analysis in more detail

Analyze the code without actually running the application

Use different algorithms to analyze the code to find errors. Wide range of complexity to the algorithms

If source code is not available, byte code can be used to perform the static analysis (technique used in this tool)

Basic premise is to give a static analysis tool something to look for (some type of pattern). If the tool finds a match, it will note the match. Simple Example: grep Complex Example: this tool

General Goals for static analysis – Soundness, Precision, Scalability

contributions of the paper
Contributions of the paper

Proposes a methodology and tool to detect a diverse set of common web application vulnerabilities.

Improve precision of tool by using fully context-sensitive pointer analysis (less false positives)

Deliver an actual implementation of the idea, built as an Eclipse Plug-in:

Validate the methodology against real web applications. Found real errors, with few false positives.

data as an attack vector tainted objects
Data as an attack vector – Tainted Objects
  • How does data propagate from data the user controls (user input) to data the application uses (e.g. SQL query)?
  • We can model this using tainted object propagation, which is composed into three segments:
    • Source Descriptors – How user-provided data can enter a web application
    • Sink Descriptors – Potentially unsafe ways that data can be used in a program (e.g. if the data is tainted)
    • Derivation Descriptors – How tainted objects can be manipulated, and still remain tainted in the application (e.g. what methods can be sent to a tainted object, or can use the tainted object as an argument to a method, to create another tainted object or keep the objected in a tainted state.

Tainted Object Propagation ~ Modeling object flow through an application

tainted object propagation descriptions
Tainted Object Propagation Descriptions

Source Descriptor Example

<HttpServletRequest.getParameter(String), -1, ε>

Sink Descriptor Example

<Connection.executeQuery(String), 1, ε>

Derivation Descriptor Examples

<StringBuffer.append(String), 1, ε, -1, ε>

<StringBuffer.toString(String), 0, ε, -1, ε >

Using the descriptors, you can theoretically find all sources and sinks in the code, and can understand when a sink uses a tainted source object that is still tainted after manipulation by derivation descriptor rules.

tainted object security violation
Tainted Object Security Violation
  • A Security Violation occurs when:
  • A source object is tainted (given the rules for source descriptors)
  • From this tainted source object, there are derivations performed in the code to produce another object that is tainted, or keep the current object in the tainted state (based on derivation descriptors)
  • The tainted object is used in a sink (based on the sink descriptors)
  • When the above steps occur, then user-controlled input is being used by the
  • application in a potentially vulnerable / exploitable way.
generating sources sinks and derivations
Generating Sources, Sinks, and Derivations

Generating the rules for sources, sinks, and derivations is a

manual process.

Without providing 100% coverage for all sources, sinks, and derivations, the

model is incomplete and can miss vulnerabilities!

For this tool, J2EE APIs were evaluated to generate sources and

sinks, and Java String manipulation libraries were evaluated to generate

derivation descriptors

What if something is missing? Definitely a possibility.

- This tool used some additional static analysis to pinpoint tainted sources that were never passed to a method listed in derivation descriptors. This found additional derivation descriptors.

Concern: What if the source is written to a File, and used later by the application? This ‘derivation’ cannot be covered through String manipulation

what about object references
What about object references?

To have sound static analysis, your tool needs to track what

object references (program variables) point to tainted objects

(on the heap)

In a naïve implementation, to maintain soundness, you could

end up with a very large number of potentially tainted object

references if you do not perform good points-to analysis.

Example: Are buf1 and buf2 both tainted? Is this a violation?

points to analysis
Points-to analysis
  • Solve the tainted object scalability problem using approximation with static
  • object names
  • Do not want to miss potential pointers to a tainted object, but at the same
  • time, if you do not do any bounding, end up with a huge number of
  • potentially tainted objects
  • Tool uses a context-sensitive Java points-to analysis developed by Whaley
  • and Lam
    • Uses Binary Decision Diagrams (BDDs) to represent points-to results for multiple execution contexts in a program

Not many technical details on the BDD method, but this essentially allows this tool to perform context-sensitive static analysis to reduce the set of objects that could be tainted.

NOTE: Exact points-to analysis is an undecidable problem. Need a conservative estimate that is still sound (doesn’t miss any tainted objects)

additional claims of novelty
Additional Claims Of Novelty

Sound and precise context-based points-to analysis, reducing

the tainted object space

Further reduction of tainted object space by introducing a

clever way to handle Container references – can identify / name

underlying structure of the Container, resulting in a further

reduced tainted object space.

Object naming for String manipulation methods. Introduced

logic to name Strings produced from String manipulation

methods to further reduce tainted object space.

programmatic representation of descriptions
Programmatic representation of descriptions

Source, Sink, and Derivation descriptions can be created using Program

Query Language (PQL)

PQL – Java-like language that can be used to describe a sequence of

dynamic events that involves variables referring to object instances

Two main PQL statements define the framework that is used to find security violations. User must then define source(), derived() and sink()

pql example sql injection
PQL Example – SQL Injection

Fairly simple to understand the definitions for source, sink, and derived.

evaluation experimental results
Evaluation / Experimental Results

Tested against 8 large open-source web applications

Created set of source, sink, and derivation descriptors (derivation focused

on String, StringBuffer, and StringTokenizer classes

Four combinations of testing (with/without context sensitivity, with/without

improved object naming)

Recorded a total of 41 potential security violations. 29 turned out to be

security errors, and 12 were false positives

More precise with both context sensitivity and improved naming enabled

(and actually faster execution time)

Found two errors in common library code (J2EE and hibernate)

Almost all errors were confirmed by the application developers, resulting in

code fixes.

errors discovered
Errors Discovered

Parameter manipulation to perform HTTP splitting was the most prevalent

attack vector

Browser re-direct attacks based on user-entered data (HTTP referrer field

was modified)

SQL injection vector in Hibernate library code

False Positives

All due to not defining an object naming rule correctly -StringWriter.toString()

Once this was added to the naming rules, there were no false positives


Input validation / control flow is not handled – If application

does some parameter validation – this tool will not take that

into account

Source / Sink / Derivation descriptions need to be manually

created and potentially updated – J2EE sources / sinks, and

String library descriptors cover a lot – are there more?

Need to manually tune the object naming rules so that you can

minimize false positives

Can you think of other paths not covered by the


Example - user input gets stored to a file, then read in later and used in a sink

other techniques used in practice
Other Techniques used in Practice

Penetration Testing – Black box and white box. Depending on

the effort, may only catch a small sample of security risks. Will

not identify parts of the system that remain untested

Runtime Monitoring – Pattern matching of HTTP requests at

runtime by a proxy. White list of good inputs and/or blacklist

of bad inputs. Protection against errors already manifested in


Protection at levels other than application (e.g. Oracle virtual

private databases to minimize amount of data available to



This paper proposes applying tainted object propagation

techniques to Java web applications, and presents a tool

implemented as an Eclipse plug-in

The proposed technique maintains static analysis soundness,

and increases scalability and precision with context-sensitive

pointer analysis and object naming.

Improved object naming by modifying naming for Containers

and Strings

Seems like a good tool requiring minimal manual integration

work to use as an additional mechanism to measure your web

application’s security

lapse tool

<source id="javax.servlet.ServletRequest.getParameterMap()">

<category>Parameter tampering</category>


<source id="javax.servlet.ServletRequest.getParameterNames()">

<category>Parameter tampering</category>


initial student feedback
Initial Student Feedback

Shortcomings - Weak Analysis(?), Manually creating PQL descriptors

Can we use this with other languages (.NET, ROR, *SPs)

Do people actually use PQL? (
