slide1

CERN Technical Training 2005

ELEC-2005Electronics in High Energy PhysicsSpring term: Integrated circuits and VLSI technology for physics

Basic Analog Design

Giovanni Anelli

15 March 2005

Part I

outline part i
Outline – Part I
  • The MOS transistor: quick summary
    • The MOS transistor
    • DC characteristics
    • Important formulas
  • Basic analog building blocks

Giovanni Anelli - CERN

the n mos transistor
The (N)-MOS transistor

y

z

x

DRAIN

GATE

SUBSTRATE

Transconductance

SOURCE

Giovanni Anelli - CERN

linear and saturation regions
Linear and Saturation regions

LINEAR REGION (Low VDS):Electrons (in light blue) are attracted to the SiO2 – Si Interface. A conductive channel is created between source and drain. We have a Voltage Controlled Resistor (VCR).

G

S

D

n+

n+

SATURATION REGION (High VDS):When the drain voltage is high enough the electrons near the drain are insufficiently attracted by the gate, and the channel is pinched off. We have a Voltage Controlled Current Source (VCCS).

G

S

D

n+

n+

Giovanni Anelli - CERN

voltage and current sources
Voltage and Current sources

RS

Vout

+

Voltage source. Ideal if RS = 0.

V

Iout

I

Current source. Ideal if RS = ∞.

RS

Giovanni Anelli - CERN

drain current vs drain voltage
Drain current vs Drain voltage

This is a real device measurement !

Output conductance

Saturation region (VCCS)

@ three different VGS

Linear region (VCR)

Giovanni Anelli - CERN

drain current vs gate voltage
Drain current vs Gate voltage

This is also a measurement, same device.

red

High field (vertical and longitudinal) effects

Linear region (green) and saturation region (red)

Subthreshold region

green

Giovanni Anelli - CERN

log i ds vs v gs
Log(IDS) vs VGS

Exactly same measurement as before, but semi log scale

red

green

WEAK INVERSION

THRESHOLD VOLTAGE

STRONG INVERSION

SUBTHRESHOLD SLOPE

LEAKAGE CURRENT

Giovanni Anelli - CERN

a few equations in saturation
A few equations in saturation

Weak Inversion

Strong Inversion

Giovanni Anelli - CERN

output conductance
Output conductance

IDS

ID’

DI

ID

Dashed lines:ideal behavior

DV

VD

VD’

VDS

G

S

D

n+

n+

DL

L

The non-zero output conductance is related to a phenomenon calledchannel length modulation

Giovanni Anelli - CERN

output conductance resistance
Output conductance / resistance

Drain-to-source current in saturation

Output conductance

Remember: l is proportional to 1/L

Output resistance

Giovanni Anelli - CERN

g m i d vs log i d w
gm / ID vs log (ID / W)

Weak Inversion (W.I.)

Strong Inversion (S.I.)

W.I.

M.I.

S.I.

Moderate Inversion (M.I.): No Equations

Giovanni Anelli - CERN

outline part i13
Outline – Part I
  • The MOS transistor: quick summary
  • Basic analog building blocks
    • Small-signal equivalent circuit
    • Common-Source Stage
    • Common-Gate Stage
    • Cascode Stage
    • Differential Pair
    • Current Mirrors
    • Differential Pair + Current Mirror

Giovanni Anelli - CERN

our first circuit
Our first circuit!

VDD

RD

VDS

VGS

For a small signal:

vds = -vgs*gm*RD

Giovanni Anelli - CERN

small signal equivalent circuit
Small-signal equivalent circuit

G

D

Valid only at very low frequencies

No bulk effect

S

This equation fixes the bias point

This equation defines the small signal behavior

Giovanni Anelli - CERN

small signal equivalent circuit16
Small-signal equivalent circuit

D

G

S

B

And we should also add the series resistances…

Giovanni Anelli - CERN

common source stage css
Common-Source Stage (CSS)

Small signal model in saturation

G

D

Vout

+

gmVin

Vin

RD

ro

S

VDD

DC characteristic

RD

Small signal gain

Vout

Vin

Small signal gain(with channel length modulation)

ro

The above results could also have been obtained directly from the small signal model

Giovanni Anelli - CERN

css simulation dc
CSS Simulation - DC

W = 100 mm

L = 0.5 mm

R = 100 W

The maximum small signal gain is only –1.8!!!

Giovanni Anelli - CERN

css simulation dc19
CSS Simulation - DC

Increasing the value of the load resistor to 1 kW we have

W = 100 mm

L = 0.5 mm

R = 1000 W

The maximum small signal gain is now –9.6.

Giovanni Anelli - CERN

css simulation small signal
CSS Simulation – Small Signal

R = 1000 W

gm = 9.6 mS

We inject at the input a sinusoid with frequency 1 kHz, peak to peak amplitude 1 mV AND dc offset = 0.9 V.

The DC offset is important to be in the right bias point.

The input voltage is converted in a current by the transistor and then in a voltage again by the resistor.

Giovanni Anelli - CERN

css with current source load
CSS with Current Source load

To increase the gain, we can use the output resistance of a transistor. T2 provides the DC current bias to T1, and has a high output impedance. The bias current is determined by Vb.

VDD

Small signal gain

Vb

T2

Vout

This solution gives a much higher gain than the other solutions and has a better DC output swing, since Vout_max = VDD – VDS2_sat and Vout_min = VDS1_sat.

Vin

T1

N.B. The DC output level here is not well defined, we will need a feedback loop.

Giovanni Anelli - CERN

diode connected transistor
Diode-connected transistor

Impedance seen looking into the source.

VDD

G, D

ro

gmVGS

gmbVBS

B

ix

S

+

ix

vx

+

vx

We have three resistances in parallel: 1/gm, 1/gmb and r0. This is true also if the gate is connected to a fixed potential which is not VDD.

Giovanni Anelli - CERN

common gate stage cgs
Common-Gate Stage (CGS)

In the Common-Source Stage the input signal is applied to the gate. We can also apply it to the source, obtaining what is called a Common-Gate Stage (CGS)

Not considering channel length modulation (r0) for the moment

VDD

RD

Vout

Vb

Vin

The gain is slightly higher than the one of a CSS, since we apply the signal to the source.

Giovanni Anelli - CERN

common gate stage cgs24
Common-Gate Stage (CGS)

Let’s now calculate the input impedance and the gain considering r0:

VDD

With the small-signal equivalent circuit we can easily obtain

RD

Vout

Vb

Vin

The input impedance of a CGS is relatively low, but this only if the load impedance (RD) is low.

Giovanni Anelli - CERN

cascode stage cascs
Cascode Stage (CascS)

r01

The “cascade” of a Common-Source Stage (V-I converter) and of a Common-Gate Stage is called a “Cascode”.

VDD

REMINDER

I

RD

Vout

R1

R2

T2

Vb

Vin

T1

The gain is practically the same as in the case of a Common-Source Stage.

Giovanni Anelli - CERN

cascode stage output resistance
Cascode Stage Output Resistance

One nice property of the cascode stage can be discovered looking at the resistance seen in the drain of T2.

Rout

With the small-signal equivalent circuit we can obtain

T2

Vb

Compared to a Common-Source Stage, the output impedance is “boosted” by a factor (gm2 + gmb2) r02.

Vin

T1

The disadvantage of the cascode configuration is that the minimum output voltage is now the sum of the saturation voltages of T1 and T2.It must therefore be used with care in low voltage circuits.

Giovanni Anelli - CERN

cascs with current source load
CascS with current source load

To fully profit from the high output impedance of the cascode stage, it seems natural to load it with a high impedance load, like a current source.

VDD

Vb1

T3

Vout

T2

Vb2

If r03 is not high enough, we can use the cascode principle to boost the output impedance of the current source as well.

N.B. Remember that the DC output level here is not well defined, and that we will need a feedback loop.

Vin

T1

Giovanni Anelli - CERN

single ended vs differential
Single-Ended vs Differential

A single-ended signal is defined as a signal measured with respect to a fixed potential (usually, ground).A differential signal is defined as a signal measured between two nodes which have equal and opposite signal excursions. The “center” level in differential signals is called the Common-Mode (CM) level.The most important advantage of differential signals over single-ended signals is the much higher immunity to “environmental” noise.As an example, let’s suppose to have a disturbance on the power supply.

VDD

VDD

RD

RD

RD

Vout_SE

Vout +

Vout -

Giovanni Anelli - CERN

single ended vs differential29
Single-Ended vs Differential

The Common-Mode disturbances disappear in the differential output.

Giovanni Anelli - CERN

differential pair dp
Differential Pair (DP)

Vin1

Vin,CM

Vin2

Vout2

Vout,CM

Vout1

t

VDD

RD

RD

Vout1

Vout2

Vin1

Vin2

ISS

The current source has a very important function, since it makes the sum of the currents in the two branches (I1 + I2= ISS) independent from the input common mode voltage.The output common mode voltage is then given by:

Giovanni Anelli - CERN

differential pair dp31
Differential Pair (DP)

Vout1 - Vout2

RD ISS

Vin1 - Vin2

- RD ISS

VDD

VDD

Vout2

Vout1

RD

RD

Vout1

Vout2

VDD - RD ISS

Vin1 - Vin2

Vin1

Vin2

ISS

N.B. The small signal gain is the slope of this plot

Giovanni Anelli - CERN

dp small signal gain
DP small signal gain

This circuit can be easily analyzed assuming that the point P is AC grounded. In this case, we have 2 Common-Source Stages!

VDD

RD

RD

Vout1

Vout2

Vin1

Vin2

T1

T2

P

Vb

T3

Giovanni Anelli - CERN

differential pair with mos loads
Differential Pair with MOS loads

To analyze the two circuits we can now make use of the half-circuit concept and profit from all the results obtained up to now.

VDD

VDD

T4

T4

T3

T3

Vb

Vb

Vout2

Vout1

Vout2

Vout1

Vin2

Vin2

Vin1

Vin1

T2

T2

T1

T1

ISS

ISS

Giovanni Anelli - CERN

cascode differential pair
Cascode Differential Pair

And, of course, the gain can be boosted using common-gate stages.

VDD

T8

T7

Vb3

Vb3

T6

T5

Vb2

Vb2

Cascode stages were used a lot in the past, when the supply voltages were relatively high (few volts).

In deep submicron technologies they are used with more care.

Vout1

Vout2

Vb1

Vb1

T4

T3

Vin1

Vin2

T2

T1

ISS

Giovanni Anelli - CERN

current mirror cm
Current mirror (CM)

We suppose that all the transistors have the same m, Cox and VT.l is the same if the transistors have the same L

VDD

IREF

I1

WRLR

W1L1

GND

To have an exact replica of the reference current, we have to make the transistor identical AND they must have the same VDS. When this is not possible, choosing long devices reduces the effect of l.Precise current ratios can be obtained playing with the ratio between the transistor widths (not the lengths!).

Giovanni Anelli - CERN

cascode current mirror ccm
Cascode current mirror (CCM)

VG3 must be fixed so that VD1 = VD2.

Making L1 = L2 and therefore having l1 = l2, we obtain that the current I3 practically does not depend on the voltage VD3. Of course, all the devices must be in saturation (the circuit is not suitable for low voltage applications).

I3

VDD

VD3

W3L3

IREF

VG3

VD1

VD2

W1L1

W2L2

GND

Important: L3 can be different from L1 and L2.

How do we fix VG3 so that VD1 = VD2 ?

Giovanni Anelli - CERN

cascode current mirror ccm37
Cascode current mirror (CCM)

VDD

Transistor 4 does the job here!

Transistors 1 & 2 decide the current ratio.

Transistors 3 & 4 fix the bias VD1 = VD2.

These results are valid even if transistors 3 & 4 suffer from body effect.

IREF

I3

VD3

W4L4

W3L3

VD1

VD2

W1L1

W2L2

GND

The problem of this current mirror is that VD3 > VDS3 + VGS2.

Giovanni Anelli - CERN

differential pair active cm
Differential Pair + Active CM

Current mirrors can also process a signal, and they can therefore be used as active elements. A differential pair with an active current mirror is also called a differential pair with active load. The current mirror here has also the important role to make a differential to single-end conversion!

VDD

Common Mode Analysis

T3

T4

Vout

T2

T1

Maximum output excursion

Vin

T5

Vb

Giovanni Anelli - CERN

differential pair active cm39
Differential Pair + Active CM

Let’s now calculate the small-signal behavior, neglecting the bulk effect for simplicity. The circuit is NOT symmetric, and therefore we can not use the half-circuit principle here. As a first approximation, we can consider the common sources of the input transistors as a virtual ground. The small-signal gain G can be seen as the product of the total transconductance of the stage and of the output resistance.

VDD

T3

T4

iout

+

Vout

T2

T1

ISS

Giovanni Anelli - CERN

slide40

CERN Technical Training 2005

ELEC-2005Electronics in High Energy PhysicsSpring term: Integrated circuits and VLSI technology for physics

Basic Analog Design

Giovanni Anelli

15 March 2005

Part I
