Exchange Deployment Planning Services

Ideal audience for this workshopMessaging SMENetwork SMESecurity SME. Exchange 2010 High Availability. Exchange 2010 High Availability. During this session focus on the following :How will we leverage this functionality in our organization?What availability and service level requirements do we

alair
Download Presentation

Exchange Deployment Planning Services

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


    1. Exchange Deployment Planning Services Key Message The goal of this presentation is to provide the audience with a basic understanding of Exchange 2010 High Availability, updated with SP1Key Message The goal of this presentation is to provide the audience with a basic understanding of Exchange 2010 High Availability, updated with SP1

    2. Exchange 2010 High Availability Slide Objective: To show the ideal audience for this module. Instructor Notes: This is the recommended audience for the module. Do not be overly concerned if the group does not match the ideal audience. During your time onsite you can have conversations with different resources to get questions answered. Slide Objective: To show the ideal audience for this module. Instructor Notes: This is the recommended audience for the module. Do not be overly concerned if the group does not match the ideal audience. During your time onsite you can have conversations with different resources to get questions answered.

    3. Exchange 2010 High Availability Slide Objective: To show the audience what to focus on during the module. Instructor Notes: Exchange 2010 high availability encompass many subjects. Ask the audience to think about how their organization manages each aspect of the availability story and how Exchange 2010 could assist in their requirements. Slide Objective: To show the audience what to focus on during the module. Instructor Notes: Exchange 2010 high availability encompass many subjects. Ask the audience to think about how their organization manages each aspect of the availability story and how Exchange 2010 could assist in their requirements.

    4. Agenda Slide Objective: To explain the overall goals of the Exchange 2010 High Availability Instructor Notes: Slide Objective: To explain the overall goals of the Exchange 2010 High Availability Instructor Notes:

    5. Exchange Server 2007 Single Copy Clustering SCC out-of-box provides little high availability value On Store failure, SCC restarts store on the same machine; no CMS failover SCC does not automatically recover from storage failures SCC does not protect your data, your most valuable asset SCC does not protect against site failures SCC redundant network is not leveraged by CMS Conclusion SCC only provides protection from server hardware failures and bluescreens, the relatively easy components to recover Supports rolling upgrades without losing redundancy

    6. Exchange Server 2007 Continuous Replication Slide Objective: Discuss Continuous Replication. Instructor Notes: Basic steps: Create a target database by seeding the destination with a copy of the source database (this can be accomplished via several ways – log record, streaming copy of database to passive, or offline copy). Monitor for new logs in the source log directory for copying by subscribing to Windows file system notification events. Copy any new log files to the destination inspection log directory using SMB. Inspect the copied log files. Upon successful inspection, move the copied log file to the storage group copy’s log path and replay the copied log into the copy of the database. Slide Objective: Discuss Continuous Replication. Instructor Notes: Basic steps: Create a target database by seeding the destination with a copy of the source database (this can be accomplished via several ways – log record, streaming copy of database to passive, or offline copy). Monitor for new logs in the source log directory for copying by subscribing to Windows file system notification events. Copy any new log files to the destination inspection log directory using SMB. Inspect the copied log files. Upon successful inspection, move the copied log file to the storage group copy’s log path and replay the copied log into the copy of the database.

    7. Exchange Server 2007 HA Solution (CCR + SCR) Slide Objective: Discuss the Exchange Server 2007 HA/SR solution. Instructor Notes: Key things to call out CMS cannot co-exist with other roles Clustered Exchange requires both Exchange and Windows Failover Clustering knowledge. Failovers occur at the server level. Site resilience is outside of clustering and therefore, requires manual activation. Slide Objective: Discuss the Exchange Server 2007 HA/SR solution. Instructor Notes: Key things to call out CMS cannot co-exist with other roles Clustered Exchange requires both Exchange and Windows Failover Clustering knowledge. Failovers occur at the server level. Site resilience is outside of clustering and therefore, requires manual activation.

    8. Exchange 2010 High Availability Goals Reduce complexity Reduce cost Native solution - no single point of failure Improve recovery times Support larger mailboxes Support large scale deployments Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    9. Slide Objective: Discuss Exchange 2010 high availability architecture.   Instructor Notes: NOTE: “You can't replicate outside the DAG.” (key difference from SCR)   Here is Harv’s current Exchange environment.   There are 5 servers <click> in the main datacenter that host mailboxes. These mailbox servers are grouped to provide automatic failover. Each mailbox database has 3 instances, which we’ll refer to as copies, <click> placed on separate servers to provide redundancy. At any given time, only one of the three database copies is active <click> and accessible to clients.   The Front-End Server <click> manages all communications between clients and databases. Outlook clients no longer connect directly to mailbox servers, as they did in previous versions of Exchange.   When a client such as Outlook connects <click> to Exchange, it first contacts the Front-End Server.   The Front-End Server determines <click> where the user’s active database is located, and forwards the request <click> to the appropriate server.   When the client sends an e-mail <click>, the active database is updated. Then, through log shipping <click>, the other 2 passive copies of the database are updated.   Let’s say that a disk fails <click>, affecting one of the databases on Mailbox Server 2. In previous versions of Exchange, the administrator would need to failover all the databases on Mailbox Server 2 to recover from this failure, or else restore the Database 2 from a tape backup. However, Exchange’s new architecture supports database-level failover, so Database 2 automatically fails over to Mailbox Server 1 <click> without affecting the other databases.   The Outlook client, having lost its connection to the database, automatically contacts <click> the Front-End Server to reconnect.   The Front-End Server determines which mailbox server has the active copy of the users’ database. It connects <click> the client to Mailbox Server 1.   When new mail is sent <click>, the active database on Mailbox Server 1 is updated. The second copy of the database <click> is also updated through log shipping. The end user is unaware that anything has happened, and Harv can replace the failed disk drive at his leisure.   The administrator can set up any number of copies per database to meet the Service Level Agreements for his users. For a special category of users, Harv keeps a 4th database copy on a mail server in a geographically remote location <click>. This server is located in a different Active Directory site, but is kept up-to-date over the Wide Area Network using the same replication technology as the other servers. If a hurricane, earthquake, or other catastrophe should shut down the main datacenter, this remote server can be manually activated and readied for client access in about 15 minutes.   Note: If a focus group participant asks “How is this different from Microsoft Clustering Services?,” here’s the answer: “The product team is taking technology from Microsoft Clustering Services and integrate it natively into Exchange Server (no separate management tools required). Would you find value in that? Why or why not?”  Slide Objective: Discuss Exchange 2010 high availability architecture.   Instructor Notes: NOTE: “You can't replicate outside the DAG.” (key difference from SCR)   Here is Harv’s current Exchange environment.   There are 5 servers <click> in the main datacenter that host mailboxes. These mailbox servers are grouped to provide automatic failover. Each mailbox database has 3 instances, which we’ll refer to as copies, <click> placed on separate servers to provide redundancy. At any given time, only one of the three database copies is active <click> and accessible to clients.   The Front-End Server <click> manages all communications between clients and databases. Outlook clients no longer connect directly to mailbox servers, as they did in previous versions of Exchange.   When a client such as Outlook connects <click> to Exchange, it first contacts the Front-End Server.   The Front-End Server determines <click> where the user’s active database is located, and forwards the request <click> to the appropriate server.   When the client sends an e-mail <click>, the active database is updated. Then, through log shipping <click>, the other 2 passive copies of the database are updated.   Let’s say that a disk fails <click>, affecting one of the databases on Mailbox Server 2. In previous versions of Exchange, the administrator would need to failover all the databases on Mailbox Server 2 to recover from this failure, or else restore the Database 2 from a tape backup. However, Exchange’s new architecture supports database-level failover, so Database 2 automatically fails over to Mailbox Server 1 <click> without affecting the other databases.   The Outlook client, having lost its connection to the database, automatically contacts <click> the Front-End Server to reconnect.   The Front-End Server determines which mailbox server has the active copy of the users’ database. It connects <click> the client to Mailbox Server 1.   When new mail is sent <click>, the active database on Mailbox Server 1 is updated. The second copy of the database <click> is also updated through log shipping. The end user is unaware that anything has happened, and Harv can replace the failed disk drive at his leisure.   The administrator can set up any number of copies per database to meet the Service Level Agreements for his users. For a special category of users, Harv keeps a 4th database copy on a mail server in a geographically remote location <click>. This server is located in a different Active Directory site, but is kept up-to-date over the Wide Area Network using the same replication technology as the other servers. If a hurricane, earthquake, or other catastrophe should shut down the main datacenter, this remote server can be manually activated and readied for client access in about 15 minutes.   Note: If a focus group participant asks “How is this different from Microsoft Clustering Services?,” here’s the answer: “The product team is taking technology from Microsoft Clustering Services and integrate it natively into Exchange Server (no separate management tools required). Would you find value in that? Why or why not?”

    10. Exchange 2010 High Availability Fundamentals Database Availability Group Server Database Database Copy Active Manager RPC Client Access service Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    11. Exchange 2010 High Availability Fundamentals Database Availability Group A group of up to 16 servers hosting a set of replicated databases Wraps a Windows Failover Cluster Manages servers’ membership in the group Heartbeats servers, quorum, cluster database Defines the boundary of database replication Defines the boundary of failover/switchover (*over) Defines boundary for DAG’s Active Manager Slide Objective:   Instructor Notes: Defines properties applicable to the DAG or all servers, e.g.: File Share Witness List of servers Network compression Network Encryption   Supports multiple networks   Slide Objective:   Instructor Notes: Defines properties applicable to the DAG or all servers, e.g.: File Share Witness List of servers Network compression Network Encryption   Supports multiple networks

    12. Exchange 2010 High Availability Fundamentals Server Unit of membership for a DAG Hosts the active and passive copies of multiple mailbox databases Executes Information Store, CI, Assistants, etc., services on active mailbox database copies Executes replication services on passive mailbox database copies Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    13. Exchange 2010 High Availability Fundamentals Server (Continued) Provides connection point between Information Store and RPC Client Access Very few server-level properties relevant to HA Server’s Database Availability Group Server’s Activation Policy Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    14. Exchange 2010 High Availability Fundamentals Mailbox Database Unit of *over A database has 1 active copy – active copy can be mounted or dismounted Maximum # of passive copies == # servers in DAG – 1 Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    15. Exchange 2010 High Availability Fundamentals Mailbox Database (Continued) ~30 seconds database *overs Server failover/switchover involves moving all active databases to one or more other servers Database names are unique across a forest Defines properties relevant at the database level GUID: a Database’s unique ID EdbFilePath: path at which copies are located Servers: list of servers hosting copies Slide Objective:   Instructor Notes: Many customers have described their naming schemes that make this transition relatively straightforward. For example, a name might include acronyms for the forest, AD site(s), DAGs, physical racks, disk slots, etc.Slide Objective:   Instructor Notes: Many customers have described their naming schemes that make this transition relatively straightforward. For example, a name might include acronyms for the forest, AD site(s), DAGs, physical racks, disk slots, etc.

    16. Exchange 2010 High Availability Fundamentals Active/Passive vs. Source/Target Availability Terms Active: Selected to provide email services to clients Passive: Available to provide email services to clients if active fails Replication Terms Source: Provides data for copying to a separate location Target: Receives data from the source Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    17. Exchange 2010 High Availability Fundamentals Mailbox Database Copy Scope of replication A copy is either source or target of replication at any given time A copy is either active or passive at any given time Only 1 copy of each database in a DAG is active at a time A server may not host >1 copy of a any database Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    18. Exchange 2010 High Availability Fundamentals Mailbox Database Copy Defines properties applicable to an individual database copy Copy status: Healthy, Initializing, Failed, Mounted, Dismounted, Disconnected, Suspended, FailedandSuspended, Resynchronizing, Seeding CopyQueueLength ReplayQueueLength Slide Objective:   Instructor Notes: System tracks health of each copy Active definition of health – Is Information Store capable of providing email service against it? Passive definition of health – Is Replication Service able to copy and inspect logs and have them replayed into the passive copy?Slide Objective:   Instructor Notes: System tracks health of each copy Active definition of health – Is Information Store capable of providing email service against it? Passive definition of health – Is Replication Service able to copy and inspect logs and have them replayed into the passive copy?

    19. Exchange-aware resource manager (high availability’s brain) Runs on every server in the DAG Manages which copies should be active and which should be passive Definitive source of information on where a database is active or mounted Provides this information to other Exchange components (e.g., RPC Client Access and Hub Transport) Information stored in cluster database Exchange 2010 High Availability Fundamentals Active Manager Slide Objective:   Instructor Notes: Active Directory is primary source for configuration information Active Manager is primary source for changeable state information such as active and mounted   In Exchange 2010, the Microsoft Exchange Replication service periodically monitors the health of all mounted databases. In addition, it also monitors ESE for any I/O errors or failures. When the service detects a failure, it notifies Active Manager. Active Manager then determines which database copy should be mounted and what it required to mount that database. In addition, tracks the active copy of a mailbox database (based on the last mounted copy of the database) and provides the tracking results information to the RPC Client Access component on the Client Access server to which the client is connected. When an administrator makes a database copy the active mailbox database, this process is known as a switchover. When a failure affecting a database occurs and a new database becomes the active copy, this process is known as a failover. This process also refers to a server failure in which one or more servers bring online the databases previously online on the failed server. When either a switchover or failover occurs, other Exchange 2010 server roles become aware of the switchover almost immediately and will redirect client and messaging traffic to the new active database.   For example, if an active database in a DAG fails because of an underlying storage failure, Active Manager will automatically recover by failing over to a database copy on another Mailbox server in the DAG. In the event the database is outside the automatic mount criteria and cannot be automatically mounted, an administrator can manually perform a database failover.   PAM: The Active Manager in the DAG decides which copies will be active and passive. It moves to other servers if the server hosting it is no longer able to. You need to move the PAM if you take a server offline for maintenance or upgrade.   SAM: Provides information on which server hosts the active copy of a mailbox database to other components of Exchange, e.g., RPC Client Access Service or HUB Transport. Slide Objective:   Instructor Notes: Active Directory is primary source for configuration information Active Manager is primary source for changeable state information such as active and mounted   In Exchange 2010, the Microsoft Exchange Replication service periodically monitors the health of all mounted databases. In addition, it also monitors ESE for any I/O errors or failures. When the service detects a failure, it notifies Active Manager. Active Manager then determines which database copy should be mounted and what it required to mount that database. In addition, tracks the active copy of a mailbox database (based on the last mounted copy of the database) and provides the tracking results information to the RPC Client Access component on the Client Access server to which the client is connected. When an administrator makes a database copy the active mailbox database, this process is known as a switchover. When a failure affecting a database occurs and a new database becomes the active copy, this process is known as a failover. This process also refers to a server failure in which one or more servers bring online the databases previously online on the failed server. When either a switchover or failover occurs, other Exchange 2010 server roles become aware of the switchover almost immediately and will redirect client and messaging traffic to the new active database.   For example, if an active database in a DAG fails because of an underlying storage failure, Active Manager will automatically recover by failing over to a database copy on another Mailbox server in the DAG. In the event the database is outside the automatic mount criteria and cannot be automatically mounted, an administrator can manually perform a database failover.   PAM: The Active Manager in the DAG decides which copies will be active and passive. It moves to other servers if the server hosting it is no longer able to. You need to move the PAM if you take a server offline for maintenance or upgrade.   SAM: Provides information on which server hosts the active copy of a mailbox database to other components of Exchange, e.g., RPC Client Access Service or HUB Transport.

    20. Active Directory is still primary source for configuration info Active Manager is primary source for changeable state information (such as active and mounted) Replication service monitors health of all mounted databases, and monitors ESE for I/O errors or failure Exchange 2010 High Availability Fundamentals Active Manager Slide Objective:   Instructor Notes: Active Directory is primary source for configuration information Active Manager is primary source for changeable state information such as active and mounted   In Exchange 2010, the Microsoft Exchange Replication service periodically monitors the health of all mounted databases. In addition, it also monitors ESE for any I/O errors or failures. When the service detects a failure, it notifies Active Manager. Active Manager then determines which database copy should be mounted and what it required to mount that database. In addition, tracks the active copy of a mailbox database (based on the last mounted copy of the database) and provides the tracking results information to the RPC Client Access component on the Client Access server to which the client is connected. When an administrator makes a database copy the active mailbox database, this process is known as a switchover. When a failure affecting a database occurs and a new database becomes the active copy, this process is known as a failover. This process also refers to a server failure in which one or more servers bring online the databases previously online on the failed server. When either a switchover or failover occurs, other Exchange 2010 server roles become aware of the switchover almost immediately and will redirect client and messaging traffic to the new active database.   For example, if an active database in a DAG fails because of an underlying storage failure, Active Manager will automatically recover by failing over to a database copy on another Mailbox server in the DAG. In the event the database is outside the automatic mount criteria and cannot be automatically mounted, an administrator can manually perform a database failover.   PAM: The Active Manager in the DAG decides which copies will be active and passive. It moves to other servers if the server hosting it is no longer able to. You need to move the PAM if you take a server offline for maintenance or upgrade.   SAM: Provides information on which server hosts the active copy of a mailbox database to other components of Exchange, e.g., RPC Client Access Service or HUB Transport.Slide Objective:   Instructor Notes: Active Directory is primary source for configuration information Active Manager is primary source for changeable state information such as active and mounted   In Exchange 2010, the Microsoft Exchange Replication service periodically monitors the health of all mounted databases. In addition, it also monitors ESE for any I/O errors or failures. When the service detects a failure, it notifies Active Manager. Active Manager then determines which database copy should be mounted and what it required to mount that database. In addition, tracks the active copy of a mailbox database (based on the last mounted copy of the database) and provides the tracking results information to the RPC Client Access component on the Client Access server to which the client is connected. When an administrator makes a database copy the active mailbox database, this process is known as a switchover. When a failure affecting a database occurs and a new database becomes the active copy, this process is known as a failover. This process also refers to a server failure in which one or more servers bring online the databases previously online on the failed server. When either a switchover or failover occurs, other Exchange 2010 server roles become aware of the switchover almost immediately and will redirect client and messaging traffic to the new active database.   For example, if an active database in a DAG fails because of an underlying storage failure, Active Manager will automatically recover by failing over to a database copy on another Mailbox server in the DAG. In the event the database is outside the automatic mount criteria and cannot be automatically mounted, an administrator can manually perform a database failover.   PAM: The Active Manager in the DAG decides which copies will be active and passive. It moves to other servers if the server hosting it is no longer able to. You need to move the PAM if you take a server offline for maintenance or upgrade.   SAM: Provides information on which server hosts the active copy of a mailbox database to other components of Exchange, e.g., RPC Client Access Service or HUB Transport.

    21. Exchange 2010 High Availability Fundamentals Continuous Replication Continuous replication has the following basic steps: Database copy seeding of target Log copying from source to target Log inspection at target Log replay into database copy Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    22. Exchange 2010 High Availability Fundamentals Database Seeding There are several ways to seed the target instance: Automatic Seeding Update-MailboxDatabaseCopy cmdlet Can be performed from active or passive copies Manually copy the database Backup and restore (VSS) Slide Objective:   Instructor Notes: Now that we have a basic understanding of the core components that are involved, we can discuss how log shipping works. Before log files can be shipped to a passive copy, the active database copy must first be seeded. This can be accomplished in a few ways.   Automatic seeding: An automatic seed produces a copy of a database in the target location. Automatic seeding requires that all log files, including the very first log file created by the database (it contains the database creation log record), be available on the source. Automatic seeding only occurs during the creation of a new server or creation of a new database (or if the first log still exists, i.e. log truncation hasn’t occurred). Seeding using the Update-MailboxDatabaseCopy cmdlet: You can use the Update-MailboxDatabaseCopy cmdlet in the Exchange Management Shell to seed a database copy. Manually copying the offline database: This process dismounts the database and copies the database file to the same location on the passive node. If you use this method, there will be an interruption in service because the procedure requires you to dismount the database. The second option utilizes the streaming copy backup API to copy the database from the active location to the target location. Slide Objective:   Instructor Notes: Now that we have a basic understanding of the core components that are involved, we can discuss how log shipping works. Before log files can be shipped to a passive copy, the active database copy must first be seeded. This can be accomplished in a few ways.   Automatic seeding: An automatic seed produces a copy of a database in the target location. Automatic seeding requires that all log files, including the very first log file created by the database (it contains the database creation log record), be available on the source. Automatic seeding only occurs during the creation of a new server or creation of a new database (or if the first log still exists, i.e. log truncation hasn’t occurred). Seeding using the Update-MailboxDatabaseCopy cmdlet: You can use the Update-MailboxDatabaseCopy cmdlet in the Exchange Management Shell to seed a database copy. Manually copying the offline database: This process dismounts the database and copies the database file to the same location on the passive node. If you use this method, there will be an interruption in service because the procedure requires you to dismount the database. The second option utilizes the streaming copy backup API to copy the database from the active location to the target location.

    23. Exchange 2010 High Availability Fundamentals Log Shipping Log shipping in Exchange 2010 leverages TCP sockets Supports encryption and compression Administrator can set TCP port to be used Replication service on target notifies the active instance the next log file it expects Based on last log file which it inspected Replication service on source responds by sending the required log file(s) Copied log files are placed in the target’s Inspector directory Slide Objective:   Instructor Notes: Exchange Server 2007 utilized SMB and Windows file system notifications to get logs. Exchange 2010 utilizes TCP sockets and notifications to the source about which logs are required on the target.Slide Objective:   Instructor Notes: Exchange Server 2007 utilized SMB and Windows file system notifications to get logs. Exchange 2010 utilizes TCP sockets and notifications to the source about which logs are required on the target.

    24. Exchange 2010 High Availability Fundamentals Log Inspection The following actions are performed to verify the log file before replay: Physical integrity inspection Header inspection Move any Exx.log files to ExxOutofDate folder that exist on target if it was previously a source If inspection fails, the file will be recopied and inspected (up to 3 times) If the log file passes inspection it is moved into the database copy’s log directory Slide Objective:   Instructor Notes: The following actions are performed by LogInspector:   Physical integrity inspection: This validation utilizes ESEUTIL /K against the log file and validates that the checksum recorded in the log file matches the checksum generated in memory.   Header inspection: The Replication service validates the following aspects of the log file’s header:   The generation is not higher than the highest generation recorded for the database in question. The generation recorded in the log header matches the generation recorded in the log filename. The log file signature recorded in the log header matches that of the log file.   Removal of Exx.log: Before the inspected log file can be moved into the log folder, the Replication service needs to remove any Exx.log files. These log files are placed into another sub-directory of the log directory, the ExxOutofDate directory. An Exx.log file would only exist on the target if it was previously running as a source. The Exx.log file needs to be removed before log replay occurs because it will contain old data which has been superseded by a full log file with the same generation. If the closed log file is not a superset of the existing Exx.log file, then we will have to perform an incremental or full reseed.Slide Objective:   Instructor Notes: The following actions are performed by LogInspector:   Physical integrity inspection: This validation utilizes ESEUTIL /K against the log file and validates that the checksum recorded in the log file matches the checksum generated in memory.   Header inspection: The Replication service validates the following aspects of the log file’s header:   The generation is not higher than the highest generation recorded for the database in question. The generation recorded in the log header matches the generation recorded in the log filename. The log file signature recorded in the log header matches that of the log file.   Removal of Exx.log: Before the inspected log file can be moved into the log folder, the Replication service needs to remove any Exx.log files. These log files are placed into another sub-directory of the log directory, the ExxOutofDate directory. An Exx.log file would only exist on the target if it was previously running as a source. The Exx.log file needs to be removed before log replay occurs because it will contain old data which has been superseded by a full log file with the same generation. If the closed log file is not a superset of the existing Exx.log file, then we will have to perform an incremental or full reseed.

    25. Exchange 2010 High Availability Fundamentals Log Replay Log replay has moved to Information Store The following validation tests are performed prior to log replay: Recalculate the required log generations by inspecting the database header Determine the highest generation that is present in the log directory to ensure that a log file exists Compare the highest log generation that is present in the directory to the highest log file that is required Make sure the logs form the correct sequence Query the checkpoint file, if one exists Replay the log file using a special recovery mode (undo phase is skipped) Slide Objective:   Instructor Notes: Log Replay After the log files have been inspected, they are placed within the log directory so that they can be replayed in the database copy. Before the Replication service replays the log files, it performs a series of validation tests.   It recalculates the required log generations necessary for log replay to be successful. This check determines the highest and lowest log generations required by inspecting the database header. The database header contains a log signature and this will be compared with the log file’s signature to ensure they match. The database header will report one of two conditions: Either the database is in a consistent state (Clean Shutdown) or an inconsistent state (Dirty Shutdown). If the database is consistent, then the next log file to be committed log position (LGPOS) will be used to derive the lowest and highest required log generations. If the database is in an inconsistent state, then the “Required Log” stamp defines the lowest and highest required generations. In addition, the backup information that is stored in the database header is reviewed to determine the last generation that was backed up.   It determines the highest generation that is present in the log directory to ensure that a log file exists. If there are no log files, then replay cannot continue. Compare the highest log generation that is present in the directory to the highest log file that is required. As long as the highest log generation that is present is equal to or higher than the highest required log generation, replay can continue. Make sure the logs form the correct sequence. Checking all the log files in the directory is a slow process, so only the required log files are validated. This is done to determine if recovery will fail immediately (the assumption being that if recovery fails on generation N, the database header will require generation N-1). In addition to validating that all the required log files are available, the following additional validation steps are performed: Ensures the generation of a log file matches the sequence expectation. Ensures the log file's signature is correct. Ensures the creation time of the log file forms a sequence with previous log files.   Query the checkpoint file, if one exists.   If the checkpoint file is too advanced by defining a generation that is higher than the lowest generation required, then the checkpoint file will be deleted. If the checkpoint is too far behind and points to a non-existent file, then the checkpoint file will be deleted.   Once these validation checks have been completed, the Replication service will replay the log iteration. This is actually a special recovery mode, which is different from the replay performed by ESEUTIL /R. For more information, see Eseutil /R Recovery Mode. Typically when ESEUTIL /R is executed, it replays all available log files including the Exx.log file, thus ensuring all transactions are either committed to the database or rolled back. However, since in continuous replication the replication engine is always one log file behind (the active Exx.log file), the undo phase of recovery (where uncommitted transactions are rolled back) is skipped to ensure database divergence does not occur.   After the log file is replayed, the following additional steps are performed. Validate that the required generations in the database header were updated. There are certain situations in which the database header will not get updated after a log replay event. This occurs when the log file that was replayed only contains termination and initialization records. In this scenario, however, the database should be in a consistent state. Execute the LogTruncater phase to remove any unnecessary logs from the passive and the active path. This call reads the database header for full and incremental backup information, so replays are blocked for this duration. Slide Objective:   Instructor Notes: Log Replay After the log files have been inspected, they are placed within the log directory so that they can be replayed in the database copy. Before the Replication service replays the log files, it performs a series of validation tests.   It recalculates the required log generations necessary for log replay to be successful. This check determines the highest and lowest log generations required by inspecting the database header. The database header contains a log signature and this will be compared with the log file’s signature to ensure they match. The database header will report one of two conditions: Either the database is in a consistent state (Clean Shutdown) or an inconsistent state (Dirty Shutdown). If the database is consistent, then the next log file to be committed log position (LGPOS) will be used to derive the lowest and highest required log generations. If the database is in an inconsistent state, then the “Required Log” stamp defines the lowest and highest required generations. In addition, the backup information that is stored in the database header is reviewed to determine the last generation that was backed up.   It determines the highest generation that is present in the log directory to ensure that a log file exists. If there are no log files, then replay cannot continue. Compare the highest log generation that is present in the directory to the highest log file that is required. As long as the highest log generation that is present is equal to or higher than the highest required log generation, replay can continue. Make sure the logs form the correct sequence. Checking all the log files in the directory is a slow process, so only the required log files are validated. This is done to determine if recovery will fail immediately (the assumption being that if recovery fails on generation N, the database header will require generation N-1). In addition to validating that all the required log files are available, the following additional validation steps are performed: Ensures the generation of a log file matches the sequence expectation. Ensures the log file's signature is correct. Ensures the creation time of the log file forms a sequence with previous log files.   Query the checkpoint file, if one exists.   If the checkpoint file is too advanced by defining a generation that is higher than the lowest generation required, then the checkpoint file will be deleted. If the checkpoint is too far behind and points to a non-existent file, then the checkpoint file will be deleted.   Once these validation checks have been completed, the Replication service will replay the log iteration. This is actually a special recovery mode, which is different from the replay performed by ESEUTIL /R. For more information, see Eseutil /R Recovery Mode. Typically when ESEUTIL /R is executed, it replays all available log files including the Exx.log file, thus ensuring all transactions are either committed to the database or rolled back. However, since in continuous replication the replication engine is always one log file behind (the active Exx.log file), the undo phase of recovery (where uncommitted transactions are rolled back) is skipped to ensure database divergence does not occur.   After the log file is replayed, the following additional steps are performed. Validate that the required generations in the database header were updated. There are certain situations in which the database header will not get updated after a log replay event. This occurs when the log file that was replayed only contains termination and initialization records. In this scenario, however, the database should be in a consistent state. Execute the LogTruncater phase to remove any unnecessary logs from the passive and the active path. This call reads the database header for full and incremental backup information, so replays are blocked for this duration.

    26. Exchange 2010 High Availability Fundamentals Lossy Failure Process In the event of failure, the following steps will occur for the failed database: Active Manager will determine the best copy to activate The Replication service on the target server will attempt to copy missing log files from the source - ACLL If successful, then the database will mount with zero data loss If unsuccessful (lossy failure), then the database will mount based on the AutoDatabaseMountDial setting The mounted database will generate new log files (using the same log generation sequence) Transport Dumpster requests will be initiated for the mounted database to recover lost messages When original server or database recovers, it will run through divergence detection and perform an incremental reseed or require a full reseed Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    27. Exchange 2010 High Availability Fundamentals Backups Streaming backup APIs for public use have been cut, must use VSS for backups Backup from any copy of the database/logs Always choose Passive (or Active) copy Backup an entire server Designate a dedicated backup server for a given database Restore from any of these backups scenarios Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    28. Multiple Database Copies Enable New Scenarios Exchange 2010 HA E-mail archive Extended/protected dumpster retention Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    29. Mailbox Database Copies Create up to 16 copies of each mailbox database Each mailbox database must have a unique name within Organization Mailbox database objects are global configuration objects All mailbox database copies use the same GUID No longer connected to specific Mailbox servers

    30. Mailbox Database Copies Each DAG member can host only one copy of a given mailbox database Database path and log folder path for copy must be identical on all members Copies have settable properties Activation Preference RTM: Used as second sort key during best copy selection SP1: Used for distributing active databases; used as primary sorting key when using Lossless mount dial Replay Lag and Truncation Lag Using these features affects your storage design

    31. Lagged Database Copies A lagged copy is a passive database copy with a replay lag time greater than 0 Lagged copies are only for point-in-time protection, but they are not a replacement for point-in-time backups Logical corruption and/or mailbox deletion prevention scenarios Provide a maximum of 14 days protection When should you deploy a lagged copy? Useful only to mitigate a risk May not be needed if deploying a backup solution (e.g., DPM 2010) Lagged copies are not HA database copies Lagged copies should never be automatically activated by system Steps for manual activation documented at http://technet.microsoft.com/en-us/library/dd979786.aspx Lagged copies affect your storage design

    32. DAG Design Two Failure Models Design for all database copies activated Design for the worst case - server architecture handles 100 percent of all hosted database copies becoming active Design for targeted failure scenarios Design server architecture to handle the active mailbox load during the worst failure case you plan to handle 1 member failure requires 2 or more HA copies and 2 or more servers 2 member failure requires 3 or more HA copies and 4 or more servers Requires Set-MailboxServer <Server> -MaximumActiveDatabases <Number>

    33. DAG Design It’s all in the layout Consider this scenario 8 servers, 40 databases with 2 copies

    34. DAG Design It’s all in the layout If I have a single server failure Life is good

    35. DAG Design It’s all in the layout If I have a double server failure Life could be good…

    36. DAG Design It’s all in the layout If I have a double server failure Life could be bad…

    37. DAG Design It’s all in the layout Now let’s consider this scenario 4 servers, 12 databases with 3 copies With a single server failure: With a double server failure:

    38. Deep Dive on Exchange 2010 High Availability Basics Quorum Witness DAG Lifecycle DAG Networks Please Note, the delivery consultant should select the appropriate deep dive topics for presentation based on customer situation and one’s own technical depth. Please Note, the delivery consultant should select the appropriate deep dive topics for presentation based on customer situation and one’s own technical depth.

    39. Quorum

    40. Quorum Used to ensure that only one subset of members is functioning at one time A majority of members must be active and have communications with each other Represents a shared view of members (voters and some resources) Dual Usage Data shared between the voters representing configuration, etc. Number of voters required for the solution to stay running (majority); quorum is a consensus of voters When a majority of voters can communicate with each other, the cluster has quorum When a majority of voters cannot communicate with each other, the cluster does not have quorum

    41. Quorum Quorum is not only necessary for cluster functions, but it is also necessary for DAG functions In order for a DAG member to mount and activate databases, it must participate in quorum Exchange 2010 uses only two of the four available cluster quorum models Node Majority (DAGs with an odd number of members) Node and File Share Majority (DAGs with an even number of members) Quorum = (N/2) + 1 (whole numbers only) 6 members: (6/2) + 1 = 4 votes for quorum (can lose 3 voters) 9 members: (9/2) + 1 = 5 votes for quorum (can lose 4 voters) 13 members: (13/2) + 1 = 7 votes for quorum (can lose 6 voters) 15 members: (15/2) + 1 = 8 votes for quorum (can lose 7 voters) N = number of nodes in clusterN = number of nodes in cluster

    42. Witness and Witness Server

    43. Witness A witness is a share on a server that is external to the DAG that participates in quorum by providing a weighted vote for the DAG member that has a lock on the witness.log file Used only by DAGs that have an even number of members Witness server does not maintain a full copy of quorum data and is not a member of the DAG or cluster

    44. Witness Represented by File Share Witness resource File share witness cluster resource, directory, and share automatically created and removed as needed Uses Cluster IsAlive check for availability If witness is not available, cluster core resources are failed and moved to another DAG member If other DAG member does not bring witness resource online, the resource will remain in a Failed state, with restart attempts every 60 minutes See http://support.microsoft.com/kb/978790 for details on this behavior

    45. Witness If in a Failed state and needed for quorum, cluster will try to online File Share Witness resource once If witness cannot be restarted, it is considered failed and quorum is lost If witness can be restarted, it is considered successful and quorum is maintained An SMB lock is placed on witness.log Node PAXOS information is incremented and the updated PAXOS tag is written to witness.log If in an Offline state and needed for quorum, cluster will not try to restart – quorum lost

    46. Witness When witness is no longer needed to maintain quorum, lock on witness.log is released Any member that locks the witness, retains the weighted vote (“locking node”) Members in contact with locking node are in majority and maintain quorum Members not in contact with locking node are in minority and lose quorum

    47. Witness Server No pre-configuration typically necessary Exchange Trusted Subsystem must be member of local Administrators group on Witness Server if Witness Server is not running Exchange 2010 Cannot be a member of the DAG (present or future) Must be in the same Active Directory forest as DAG

    48. Witness Server Can be Windows Server 2003 or later File and Printer Sharing for Microsoft Networks must be enabled Replicating witness directory/share with DFS not supported Not necessary to cluster Witness Server If you do cluster witness server, you must use Windows 2008 Single witness server can be used for multiple DAGs Each DAG requires its own unique Witness Directory/Share

    49. Database Availability Group Lifecycle

    50. Database Availability Group Lifecycle Create a DAG New-DatabaseAvailabilityGroup -Name DAG1 –WitnessServer EXHUB1 -WitnessDirectory C:\DAG1FSW -DatabaseAvailabilityGroupIpAddresses 10.0.0.8 New-DatabaseAvailabilityGroup -Name DAG2 -DatabaseAvailabilityGroupIpAddresses 10.0.0.8,192.168.0.8 Add Mailbox Servers to DAG Add-DatabaseAvailabilityGroupServer -Identity DAG1 -MailboxServer EXMBX1 Add-DatabaseAvailabilityGroupServer -Identity DAG1 -MailboxServer EXMBX2 Add a Mailbox Database Copy Add-MailboxDatabaseCopy -Identity DB1 -MailboxServer EXMBX2

    51. Database Availability Group Lifecycle DAG is created initially as empty object in Active Directory Continuous replication or 3rd party replication using Third Party Replication mode Once changed to Third Party Replication mode, the DAG cannot be changed back DAG is given a unique name and configured for IP addresses (or configured to use DHCP)

    52. Database Availability Group Lifecycle When the first Mailbox server is added to a DAG A failover cluster is formed with the name of DAG using Node Majority quorum The server is added to the DAG object in Active Directory A cluster name object (CNO) for the DAG is created in default Computers container using the security context of the Replication service The Name and IP address of the DAG is registered in DNS The cluster database for the DAG is updated with info about local databases

    53. Database Availability Group Lifecycle When second and subsequent Mailbox server is added to a DAG The server is joined to cluster for the DAG The quorum model is automatically adjusted The server is added to the DAG object in Active Directory The cluster database for the DAG is updated with info about local databases

    54. Database Availability Group Lifecycle After servers have been added to a DAG Configure the DAG Network encryption Network compression Replication port Configure DAG networks Network subnets Collapse DAG networks in single network with multiple subnets Enable/disable MAPI traffic/replication Block network heartbeat cross-talk (Server1\MAPI !<-> Server2\Repl)

    55. Database Availability Group Lifecycle After servers have been added to a DAG Configure DAG member properties Automatic database mount dial BestAvailability, GoodAvailability, Lossless, custom value Database copy automatic activation policy Blocked, IntrasiteOnly, Unrestricted Maximum active databases Create mailbox database copies Seeding is performed automatically, but you have options Monitor health and status of database copies and perform switchovers as needed

    56. Database Availability Group Lifecycle Before you can remove a server from a DAG, you must first remove all replicated databases from the server When a server is removed from a DAG: The server is evicted from the cluster The cluster quorum is adjusted The server is removed from the DAG object in Active Directory Before you can remove a DAG, you must first remove all servers from the DAG

    57. DAG Networks

    58. DAG Networks A DAG network is a collection of subnets All DAGs must have: Exactly one MAPI network MAPI network connects DAG members to network resources (Active Directory, other Exchange servers, etc.) Zero or more Replication networks Separate network on separate subnet(s) Used for/by continuous replication only LRU determines which replication network to use when multiple replication networks are configured

    59. DAG Networks Initially created DAG networks based on enumeration of cluster networks Cluster enumeration based on subnet One cluster network is created for each subnet

    60. DAG Networks

    61. DAG Networks

    62. DAG Networks To collapse subnets into two DAG networks and disable replication for the MAPI network:

    63. DAG Networks To collapse subnets into two DAG networks and disable replication for the MAPI network:

    64. DAG Networks Automatic network detection occurs only when members added to DAG If networks are added after member is added, you must perform discovery Set-DatabaseAvailabilityGroup -DiscoverNetworks DAG network configuration persisted in cluster registry HKLM\Cluster\Exchange\DAG Network DAG networks include built-in encryption and compression Encryption: Kerberos SSP EncryptMessage/DecryptMessage APIs Compression: Microsoft XPRESS, based on LZ77 algorithm DAGs use a single TCP port for replication and seeding Default is TCP port 64327 If you change the port and you use Windows Firewall, you must manually change firewall rules MSIT sees 30% compression, but percentage will vary based on message profileMSIT sees 30% compression, but percentage will vary based on message profile

    65. Deeper Dive on Exchange 2010 High Availability Advanced Features Active Manager Best Copy Selection Datacenter Activation Coordination Mode

    66. Active Manager

    67. Active Manager Exchange component that manages *overs Runs on every server in the DAG Selects best available copy on failovers Is the definitive source of information on where a database is active Stores this information in cluster database Provides this information to other Exchange components (e.g., RPC Client Access and Hub Transport)

    68. Active Manager Active Manager roles Standalone Active Manager Primary Active Manager (PAM) Standby Active Manager (SAM) Active Manager client runs on CAS and Hub

    69. Active Manager Transition of role state logged into Microsoft-Exchange-HighAvailability/Operational event log (Crimson Channel)

    70. Active Manager Primary Active Manager (PAM) Runs on the node that owns the cluster core resources (cluster group) Gets topology change notifications Reacts to server failures Selects the best database copy on *overs Detects failures of local Information Store and local databases

    71. Active Manager Standby Active Manager (SAM) Runs on every other node in the DAG Detects failures of local Information Store and local databases Reacts to failures by asking PAM to initiate a failover Responds to queries from CAS/Hub about which server hosts the active copy Both roles are necessary for automatic recovery If the Replication service is stopped, automatic recovery will not happen

    72. Best Copy Selection

    73. Best Copy Selection Process of finding the best copy to activate for an individual database given a list of status results of potential copies for activation Active Manager selects the “best” copy to become the new active copy when the existing active copy fails

    74. Best Copy Selection – RTM Sorts copies by copy queue length to minimize data loss, using activation preference as a secondary sorting key if necessary Selects from sorted listed based on which set of criteria met by each copy Attempt Copy Last Logs (ACLL) runs and attempts to copy missing log files from previous active copy

    75. Best Copy Selection – SP1 Sorts copies by activation preference when auto database mount dial is set to Lossless Otherwise, sorts copies based on copy queue length, with activation preference used a secondary sorting key if necessary Selects from sorted listed based on which set of criteria met by each copy Attempt Copy Last Logs (ACLL) runs and attempts to copy missing log files from previous active copy This was checked into build 213.This was checked into build 213.

    76. Best Copy Selection Is database mountable? Is copy queue length <= AutoDatabaseMountDial? If Yes, database is marked as current active and mount request is issued If not, next best database tried (if one is available) During best copy selection, any servers that are unreachable or “activation blocked” are ignored

    77. Best Copy Selection

    78. Best Copy Selection – RTM Four copies of DB1 DB1 currently active on Server1

    79. Best Copy Selection – RTM Sort list of available copies based by Copy Queue Length (using Activation Preference as secondary sort key if necessary): Server3\DB1 Server2\DB1 Server4\DB1

    80. Best Copy Selection – RTM Only two copies meet first set of criteria for activation (CQL< 10; RQL< 50; CI=Healthy): Server3\DB1 Server2\DB1 Server4\DB1 Highlight criteriaHighlight criteria

    81. Best Copy Selection – SP1 Four copies of DB1 DB1 currently active on Server1 Auto database mount dial set to Lossless

    82. Best Copy Selection – SP1 Sort list of available copies based by Activation Preference: Server2\DB1 Server3\DB1 Server4\DB1

    83. Best Copy Selection – SP1 Sort list of available copies based by Activation Preference: Server2\DB1 Server3\DB1 Server4\DB1 Highlight criteriaHighlight criteria

    84. Best Copy Selection After Active Manager determines the best copy to activate The Replication service on the target server attempts to copy missing log files from the source (ACLL) If successful, then the database will mount with zero data loss If unsuccessful (lossy failure), then the database will mount based on the AutoDatabaseMountDial setting If data loss is outside of dial setting, next copy will be tried

    85. Best Copy Selection After Active Manager determines the best copy to activate The mounted database will generate new log files (using the same log generation sequence) Transport Dumpster requests will be initiated for the mounted database to recover lost messages When original server or database recovers, it will run through divergence detection and either perform an incremental resync or require a full reseed

    86. Datacenter Activation Coordination Mode

    87. Datacenter Activation Coordination Mode DAC mode is a property of a DAG Acts as an application-level form of quorum Designed to prevent multiple copies of same database mounting on different members due to loss of network

    88. Datacenter Activation Coordination Mode RTM: DAC Mode is only for DAGs with three or more members that are extended to two Active Directory sites Don’t enable for two-member DAGs where each member is in different AD site or DAGs where all members are in the same AD site DAC Mode also enables use of Site Resilience tasks Stop-DatabaseAvailabilityGroup Restore-DatabaseAvailabilityGroup Start-DatabaseAvailabilityGroup SP1: DAC Mode can be enabled for all DAGs

    89. Datacenter Activation Coordination Mode Uses Datacenter Activation Coordination Protocol (DACP), which is a bit in memory set to either: 0 = can’t mount 1 = can mount

    90. Datacenter Activation Coordination Mode Active Manager startup sequence DACP is set to 0 DAG member communicates with other DAG members it can reach to determine the current value for their DACP bits If the starting DAG member can communicate with all other members, DACP bit switches to 1 If other DACP bits are set to 0, starting DAG member DACP bit remains at 0 If another DACP bit is set to 1, starting DAG member DACP bit switches to 1

    91. Improvements in Service Pack 1 Replication and Copy Management enhancements in SP1

    92. Improvements in Service Pack 1 Continuous replication changes Enhanced to reduce data loss Eliminates log drive as single point of failure Automatically switches between modes: File mode (original, log file shipping) Block mode (enhanced log block shipping) Switching process: Initial mode is file mode Block mode triggered when target needs Exx.log file (e.g., copy queue length = 0) All healthy passives processed in parallel File mode triggered when block mode falls too far behind (e.g., copy queue length > 0)

    93. Improvements in Service Pack 1

    94. Improvements in Service Pack 1 SP1 introduces RedistributeActiveDatabases.ps1 script (keep database copies balanced across DAG members) Moves databases to the most preferred copy If cross-site, tries to balance between sites Targetless admin switchover altered for stronger activation preference affinity First pass of best copy selection sorted by activation preference; not copy queue length This basically trades off even distribution of copies for a longer activation time. So you might pick a copy with more logs to play, but it will provide you with better distribution of databases

    95. Improvements in Service Pack 1 *over Performance Improvements In RTM, a *over immediately terminated replay on copy that was becoming active, and mount operation did necessary log recovery In SP1, a *over drives database to clean shutdown by playing all logs on passive copy, and no recovery required on new active

    96. Improvements in Service Pack 1 DAG Maintenance Scripts StartDAGServerMaintenance.ps1 It runs Suspend-MailboxDatabaseCopy for each database copy hosted on the DAG member It pauses the node in the cluster, which prevents it from being and becoming the PAM It sets the DatabaseCopyAutoActivationPolicy parameter on the DAG member to Blocked It moves all active databases currently hosted on the DAG member to other DAG members If the DAG member currently owns the default cluster group, it moves the default cluster group (and therefore the PAM role) to another DAG member

    97. Improvements in Service Pack 1 DAG Maintenance Scripts StopDAGServerMaintenance.ps1 It run Resume-MailboxDatabaseCopy for each database copy hosted on the DAG member It resumes the node in the cluster, which it enables full cluster functionality for the DAG member It sets the DatabaseCopyAutoActivationPolicy parameter on the DAG member to Unrestricted

    98. Improvements in Service Pack 1 CollectOverMetrics.ps1 and CollectReplicationMetrics.ps1 rewritten

    99. Improvements in Service Pack 1 Exchange Management Console enhancements in SP1 Manage DAG IP addresses Manage witness server/directory and alternate witness server/directory

    100. Switchovers and Failovers (*overs)

    101. Exchange 2010 *Overs Within a datacenter Database *over Server *over Between datacenters Single database *over Server *over Datacenter switchover Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    102. Single Database Cross-Datacenter *Over Database mounted in another datacenter and another Active Directory site Serviced by “new” Hub Transport servers “Different OwningServer” – for routing Transport dumpster re-delivery now from both Active Directory sites Serviced by “new” CAS “Different CAS URL” – for protocol access Outlook Web App now re-directs connection to second CAS farm Other protocols proxy or redirect (varies) Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    103. Datacenter Switchover Customers can evolve to site resilience Standalone ? local redundancy ? site resilience Consider name space design at first deployment Keep extending the DAG! Monitoring and many other concepts/skills just re-applied Normal administration remains unchanged Disaster recovery not HA event Slide Objective: Instructor Notes: Slide Objective: Instructor Notes:

    104. Site Resilience

    105. Agenda Understand the steps required to build and activate a standby site for Exchange 2010 Site Resilience Overview Site Resilience Models Planning and Design Site activation steps Client Behavior

    106. Site Resilience Drivers Business requirements drive site resilience When a risk assessment reveals a high-impact threat to meeting SLAs for data loss and loss of availability Site resilience required to mitigate the risk Business requirements dictate low recovery point objective (RPO) and recovery time objective (RTO)

    107. Site Resilience Overview Ensuring business continuity brings expense and complexity A site switchover is a coordinated effort with many stakeholders that requires practice to ensure the real event is handled well Exchange 2010 reduces cost and complexity Low-impact testing can be performed with cross-site single database switchover

    108. Exchange 2007 Site resilience choices CCR+SCR and /recoverCMS SCC+SCR and /recoverCMS CCR stretched across datacenters SCR and database portability SCR and /m:RecoverServer SCC stretched across datacenters with synchronous replication

    109. Exchange 2010 makes it simpler Database Availability Group (DAG) with members in different datacenters/sites Supports automatic and manual cross-site database switchovers and failovers (*overs) No stretched Active Directory site No special networking needed No /recoverCMS

    110. Suitability of site resilience solutions

    111. Site Resilience Models Voter Placement and Infrastructure Design

    112. Infrastructure Design There are two key models you have to take into account when designing site resilient solutions Datacenter / Namespace Model User Distribution Model When planning for site resilience, each datacenter is considered active Exchange Server 2010 site resilience requires active CAS, HUB, and UM in standby datacenter Services used by databases mounted in standby datacenter after single database *over

    113. Infrastructure Design User Distribution Models The locality of the users will ultimately determine your site resilience architecture Are users primarily located in one datacenter? Are users located in multiple datacenters? Is there a requirement to maintain user population in a particular datacenter? Active/Passive user distribution model Database copies deployed in the secondary datacenter, but no active mailboxes are hosted there Active/Active user distribution model User population dispersed across both datacenters with each datacenter being the primary datacenter for its specific user population

    114. Infrastructure Design Client Access Arrays 1 CAS array per AD site Multiple DAGs within an AD site can use the same CAS array FQDN of the CAS array needs to resolve to a load-balanced virtual IP address in DNS, but only in internal DNS You need a load balancer for CAS array, as well Set the databases in the AD site to utilize CAS array via Set-MailboxDatabase -RPCClientAccessServer property By default, new databases will have the RPCClientAccessServer value set on creation If database was created prior to creating CAS array, then it is set to random CAS FQDN (or local machine if role co-location) If database is created after creating CAS array, then it is set to the CAS array FQDN

    115. Voter Placement Majority of voters should be deployed in primary datacenter Primary = datacenter with majority of user population If user population is spread across datacenters, deploy multiple DAGs to prevent WAN outage from taking one datacenter offline

    116. Voter Placement

    117. Site Resilience Namespace, Network and Certificate Planning

    118. Each datacenter is considered active and needs their own namespaces Each datacenter needs the following namespaces OWA/OA/EWS/EAS namespace POP/IMAP namespace RPC Client Access namespace SMTP namespace In addition, one of the datacenters will maintain the Autodiscover namespace Planning for site resilience Namespaces

    119. Best Practice: Use Split DNS for Exchange hostnames used by clients Goal: minimize number of hostnames mail.contoso.com for Exchange connectivity on intranet and Internet mail.contoso.com has different IP addresses in intranet/Internet DNS Important – before moving down this path, be sure to map out all host names (outside of Exchange) that you want to create in the internal zone Planning for site resilience Namespaces

    120. Planning for site resilience Namespaces

    121. Design High Availability for Dependencies Active Directory Network services (DNS, TCP/IP, etc.) Telephony services (Unified Messaging) Backup services Network services Infrastructure (power, cooling, etc.) Planning for site resilience Network

    122. Latency Must have less than 250 ms round trip Network cross-talk must be blocked Router ACLs should be used to block traffic between MAPI and replication networks If DHCP is used for the replication network, DHCP can be used to deploy static routes Lower TTL for all Exchange records to 5 minutes OWA/EAS/EWS/OA, IMAP/POP, SMTP, RPCCAS Both internal and external DNS zone Planning for site resilience Network

    123. Planning for site resilience Certificates

    124. Planning for site resilience Certificates Best practice: minimize the number of certificates 1 certificate for all CAS servers + reverse proxy + Edge/Hub Use Subject Alternative Name (SAN) certificate which can cover multiple hostnames 1 additional certificate if using OCS OCS requires certificates with <=1024 bit keys and the server name in the certificate principal name If leveraging a certificate per datacenter, ensure the Certificate Principal Name is the same on all certificates Outlook Anywhere won’t connect if the Principal Name on the certificate does not match the value configured in msstd: (default matches OA RPC End Point) Set-OutlookProvider EXPR -CertPrincipalName msstd:mail.contoso.com

    125. Datacenter Switchover Switchover Tasks

    126. Datacenter Switchover Process Failure occurs Activation decision Terminate partially running primary datacenter Activate secondary datacenter Validate prerequisites Activate mailbox servers Activate other roles (in parallel with previous step) Service is restored

    127. Datacenter Switchovers Primary site fails Stop-DatabaseAvailabilityGroup <DAGName> –ActiveDirectorySite <PSiteName> –ConfigurationOnly (run this in both datacenters) Stop-Service clussvc Restore-DatabaseAvailabilityGroup <DAGName> –ActiveDirectorySite <SSiteName> Databases mount (assuming no activation blocks) Adjust DNS records for SMTP and HTTPS -ConfigurationOnly is used only when you have a partial datacenter outage, where all Exchange is down, but AD is still up and running.-ConfigurationOnly is used only when you have a partial datacenter outage, where all Exchange is down, but AD is still up and running.

    128. Datacenter Switchover Tasks Stop-DatabaseAvailabilityGroup Adds failed servers to stopped list Removes servers from started list Restore-DatabaseAvailabilityGroup Force quorum Evict stopped nodes Start using alternate file share witness if necessary Start-DatabaseAvailabilityGroup Remove servers from stopped list Join servers to cluster Add joined servers to started list

    129. Client Experiences Typical Outlook Behavior All Outlook versions behave consistently in a single datacenter scenario Profile points to RPC Client Access Server array Profile is unchanged by failovers or loss of CAS All Outlook versions should behave consistently in a datacenter switchover scenario Primary datacenter Client Access Server DNS name is bound to IP address of standby datacenter’s Client Access Server Autodiscover continues to hand out primary datacenter CAS name as Outlook RPC endpoint Profile remains unchanged

    130. Client Experiences Outlook – Cross-Site DB Failover Experience Behavior is to perform a direct connect from the CAS array in the first datacenter to the mailbox hosting the active copy in the second datacenter You can only get a redirect to occur by changing the RPCClientAccessServer property on the database

    131. Client Experiences Other Clients Other client behavior varies based on protocol and scenario

    132. End of Exchange 2010 High Availability Module

    133. For More Information Exchange Server Tech Center http://technet.microsoft.com/en-us/exchange/default.aspx Planning services http://technet.microsoft.com/en-us/library/cc261834.aspx Microsoft IT Showcase Webcasts http://www.microsoft.com/howmicrosoftdoesitwebcasts Microsoft TechNet http://www.microsoft.com/technet/itshowcase
