2010 FREE RESPONSE QUESTION 6 Velocity and Acceleration

2010 FREE RESPONSE QUESTION 6 Velocity and Acceleration. Prepared by: Etjen Vincani. Two particles move along the x-axis, for 0<t<6, the position of Particle P at time t is given by P(t)=2cos(Pi/4t) while the position of Particle R at time t is given by R(t)=t^3-6t^2+9t+3.

adelie
Download Presentation

2010 FREE RESPONSE QUESTION 6 Velocity and Acceleration

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. 2010 FREE RESPONSE QUESTION 6Velocity and Acceleration Prepared by: Etjen Vincani

  2. Two particles move along the x-axis, for 0<t<6, the position of Particle P at time t is given by P(t)=2cos(Pi/4t) while the position of Particle R at time t is given by R(t)=t^3-6t^2+9t+3 A) For 0<t<6, find all times t to which particle R is moving to the Right B) For 0<t<6, find all times t during which the particles travel in opposite directions C) Find the acceleration of particle P at time t = 3. Is particle P speeding up, slowing down, or doing neither at time t = 3 ? Explain your reasoning. D) Write, but do not evaluate, an expression for the average distance between the two particles on the interval 1<t<3

  3. How do you determine Velocity Velocity = the first derivative of the position function HOW DO YOU DETERMINE ACCELERATION? Acceleration is the derivative of Velocity or the second derivative of Acceleration

  4. A) For 0<t<6, find all times t to which particle R is moving to the Right Particle R will move to the right when r´(t) is greater then 0. Thus the particle will be moving to the right when 3t2 -12t+9 >0. If you factor this you get (t-3)(t-1) >0 Thus the Particle will be moving to the right in the interval 0≤t<1 and 3<t≤6 WARNING PLEASE MAKE SURE NEVER TO---

  5. B) For 0<t<6, find all times t during which the particles travel in opposite directions • The particles are traveling in opposite directions when the derivatives of p(t) and r(t) have opposite signs or when the product of the two derivatives is less then 0. • P’(t) R’(t)= -π/2· 3(t-1)(t-3) sin(πt/4)<0 • (t-1)(t-3) sin(πt/4)<0 • T=1 and T=3 • Thus the particles move in opposite directions when 0<t<1 and when 3<t<4 • Or you can simply graph the derivatives as Shown and analyze the graph

  6. C) Find the acceleration of particle P at time t = 3. Is particle P speeding up, slowing down, or doing neither at time t = 3 ? Explain your reasoning. Since P“(t)= -π2/4cos •(π/4t) the acceleration at t=3 will be P“(3) = -π2/4 •(-√2/2) >0 Thus because the acceleration is positive the velocity is increasing when t=3 In addition using your calculator you can use the derivative feature as shown to get your result which is 1.37, a positive number which proves the velocity is increasing.

  7. D) Write, but do not evaluate, an expression for the average distance between the two particles on the interval 1<t<3 • The distance between the particles is |p(t)-r(t)| so the average distance on the interval 1<t<3 is 1/2∫ |p(t)-r(t)| dt

  8. THE END CITATIONS http://home.roadrunner.com/~askmrcalculus/index.html http://www.slideshare.net/canadagirl28/meghans-calculus-powerpoint
