monthly operator reports for filtered surface water systems

Monthly Operator Reports for Filtered Surface Water Systems

Sustained Compliance Workshop - Anchorage, AK

September 23-24, 2010

Eric Burg

Kenai Peninsula & Southeast Alaska – Compliance & Monitoring Section

DEC Drinking Water Program

Eric.Burg@alaska.gov / (907) 262-5210 ext. 246

presentation outline
Presentation Outline
  • Introduction
  • Elements of an Operator Report & Reporting Requirements
  • Common Reporting Errors and Issues
  • Summary
introduction continued
Introduction Continued
  • Monthly Operator Reports serve several functions
      • Primary function is it provides a way to track effectiveness of the filtration and disinfection system.
      • Provides a record of daily operational readings.
      • A means of reporting to DEC that all regulatory requirements have been met.
introduction continued1
Introduction Continued
  • Different Types of Operator Reports
    • Conventional or Direct Filtration
      • 3 or more filters
      • Less than 3 filters
    • Alternate Filtration, Slow Sand, or Diatomaceous Earth
      • Standard report
      • Reduced Monitoring
introduction continued2
IntroductionContinued

System Information & Daily Readings

Combined Filter and Disinfection Performance

introduction continued3
IntroductionContinued

Continuous Monitoring Summary

CFE or IFE Turbidity Exceedance Report

presentation outline1
Presentation Outline
  • Introduction
  • Elements of an Operator Report & Reporting Requirements
  • Common Reporting Errors and Issues
  • Summary
elements of an operator report page 1 of operator report
Elements of an Operator ReportPage 1 of Operator Report

System Information and Daily Readings Page

  • System Information
    • Public Water System (PWS) Name
    • PWS ID #
    • Address
    • Phone #
  • Month & Year of report
  • Turbidity
  • Entry Point Chlorine
  • Filter
  • Fluoride
  • Operator Signature Line
elements of an operator report page 1 of operator report continued1
Elements of an Operator ReportPage 1 of Operator Report Continued
  • System Information
    • Public Water System (PWS) Name
    • PWS ID #
    • Address
    • Phone #
  • Month & Year of report
  • Turbidity
  • Entry Point Chlorine
  • Filter
  • Fluoride
  • Operator Signature Line
turbidity reporting requirements
Turbidity Reporting Requirements
  • Combined filter effluent (CFE) turbidity measurements
    • Taken after the point where all individual filter effluents combine.
    • Turbidity measurements are taken from grab samples or online turbidimeter recordings taken at four hour intervals.
    • Recorded on first page of operator report.
turbidity reporting requirements continued
Turbidity Reporting Requirements Continued
  • CFE turbidity requirements
    • 95% of all CFE turbidity measurements taken during the month must be less than or equal to:
      • 0.3 NTU for Conventional and Direct filtration plants
      • 1.49 NTU for Alternative, Slow Sand, & Diatomaceous Earth plants
turbidity reporting requirements continued1
Turbidity Reporting Requirements Continued
  • Maximum CFE Turbidity limits:
    • 1.49 NTU for Conventional and Direct plants
    • 5 NTU for Alternative, Slow Sand, & Diatomaceous Earth plants
  • Must notify DEC within 24 hours if maximum CFE limit is exceeded.
    • Document on Page 2 of operator report.
elements of an operator report page 1 of operator report continued2
Elements of an Operator ReportPage 1 of Operator Report Continued
  • System Information
    • Public Water System (PWS) Name
    • PWS ID #
    • Address
    • Phone #
  • Month & Year of report
  • Turbidity
  • Entry Point Chlorine
  • Filter
  • Fluoride
  • Operator Signature Line
entry point chlorine reporting requirements
Entry Point Chlorine Reporting Requirements
  • Residual readings collected daily at entry point to the distribution system
    • Sampling frequency is based on population #’s
      • 500 or fewer = 1 sample/day
      • 501 – 1,000 = 2 samples/day
      • 1,001 – 2,500 = 3 samples/day
      • 2,501 – 3,300 = 4 samples/day
      • 3,301 or greater and all other systems that monitor continuously
        • Must report lowest value each day
entry point chlorine reporting requirements continued
Entry Point Chlorine Reporting RequirementsContinued
  • Entry point chlorine residuals must be at least 0.2 mg/L at all times.
    • Some systems may have a higher entry point chlorine concentration requirement.
      • To meet contact time requirements.
        • Flow Characteristics
        • Turbidity levels
entry point chlorine reporting requirements continued1
Entry Point Chlorine Reporting RequirementsContinued
  • If entry point residual drops below 0.2 mg/L
    • Contact DEC soon as possible - no later than the end of the next business day.
    • Date and duration below 0.2 mg/L must be recorded on page 2 of the operator report (Entry Point Disinfection Performance Criteria).
    • DEC will review if treatment technique violation was generated.
        • If chlorine level is raised above 0.2 mg/L within 4 hours, no violation will be assessed.
elements of an operator report page 1 of operator report continued3
Elements of an Operator ReportPage 1 of Operator Report Continued
  • System Information
    • Public Water System (PWS) Name
    • PWS ID #
    • Address
    • Phone #
  • Month & Year of report
  • Turbidity
  • Entry Point Chlorine
  • Filter
  • Fluoride
  • Operator Signature Line
filter reporting requirements
Filter Reporting Requirements
  • Did you filter & produce water during the day?
    • Check “Yes” or “No”
elements of an operator report page 1 of operator report continued4
Elements of an Operator ReportPage 1 of Operator Report Continued
  • System Information
    • Public Water System (PWS) Name
    • PWS ID #
    • Address
    • Phone #
  • Month & Year of report
  • Turbidity
  • Entry Point Chlorine
  • Filter
  • Fluoride
  • Operator Signature Line
fluoride reporting requirements
Fluoride Reporting Requirements
  • Measured daily at the entry point to the distribution system.
  • Entry point fluoride residual must not exceed 2.0 mg/L.
  • Notify DEC within 24 hours if fluoride residual is equal to or greater than 2.0 mg/L.
fluoride reporting requirements continued
Fluoride Reporting RequirementsContinued
  • On the first day that the fluoride residual is > 2.0 mg/L, a confirmation sample must be collected and sent to a certified laboratory to verify field test results.
  • Public Notice requirements will be based upon certified laboratory sample results.
      • Circumstances may dictate otherwise.
elements of an operator report page 1 of operator report continued5
Elements of an Operator ReportPage 1 of Operator Report Continued
  • System Information
    • Public Water System (PWS) Name
    • PWS ID #
    • Address
    • Phone #
  • Month & Year of report
  • Turbidity
  • Entry Point Chlorine
  • Filter
  • Fluoride
  • Operator Signature Line
operator signature requirement
Operator Signature Requirement
  • Must be signed in accordance with 18 AAC 80.1900
    • The owner or operator shall certify by signature that the information and data contained in a report required to be filed under this chapter are true and correct to the best of the owner’s or operator’s knowledge.
elements of an operator report page 2 of operator report
Elements of an Operator ReportPage 2 of Operator Report

Combined Filter and Disinfection Performance Page

  • Combined Filter Performance Criteria
  • Entry Point Disinfection Performance Criteria
  • Distribution System Disinfection Residual Criteria
elements of an operator report page 2 of operator report continued
Elements of an Operator ReportPage 2 of Operator Report continued
  • Combined Filter Performance Criteria
  • Entry Point Disinfection Performance Criteria
  • Distribution System Disinfection Residual Criteria
elements of an operator report page 2 of operator report continued1
Elements of an Operator ReportPage 2 of Operator Report continued
  • Combined Filter Performance Criteria
  • Entry Point Disinfection Performance Criteria
  • Distribution System Disinfection Residual Criteria
elements of an operator report page 2 of operator report continued2
Elements of an Operator ReportPage 2 of Operator Report continued
  • Combined Filter Performance Criteria
  • Entry Point Disinfection Performance Criteria
  • Distribution System Disinfection Residual Criteria
elements of an operator report page 3 of operator report
Elements of an Operator ReportPage 3 of Operator Report

Continuous Monitoring Summary Page

  • Conventional and Direct Filtration systems only
      • Combined filter effluent monitoring – less than 3 filters
      • Individual filter effluent monitoring – 3 or more filters
presentation outline2
Presentation Outline
  • Introduction
  • Elements of an Operator Report & Reporting Requirements
  • Common Reporting Errors and Issues
  • Summary
common reporting errors and issues
Common Reporting Errors and Issues
  • Distribution chlorine residuals
      • Not collected at the same time and place as total coliform sample.
      • Not recorded on operator report.
      • Readings written on total coliform sample paper work may not always be reported to us by the lab.
    • Missed same time and place chlorine residual results in two violations
      • Distribution system residual requirement
      • Maximum Residual Disinfectant Residual (MRDL) requirement
common reporting errors and issues1
Common Reporting Errors and Issues
  • Late submittals
    • Reports due to DEC by the 10th of the following month.
      • Late reporting violation
  • Missing operator signature & date
    • Required by 18 AAC 80.1900.
      • Late reporting violation if amended report not received by 10th.
common reporting errors and issues2
Common Reporting Errors and Issues
  • Not submitting or filling out all the required pages
  • Not notifying DEC when required
      • Turbidity exceedances
      • Low entry point chlorine levels
  • Month & Year of report not recorded
common reporting errors and issues3
Common Reporting Errors and Issues
  • Illegible handwriting
  • Decimal point errors
presentation outline3
Presentation Outline
  • Introduction
  • Elements of an Operator Report & Reporting Requirements
  • Common Reporting Errors and Issues
  • Summary
summary
Summary
  • Operator reports are an important and useful tool to keep track of your system performance.
    • Turbidity readings
      • CFE’s for all system types.
      • IFE verification for Conventional & Direct systems.
    • Chlorine readings
      • Entry point
      • Distribution
    • Fluoride readings
    • Operational issues or anomalies
    • Satisfies regulatory reporting requirements
summary continued
Summary Continued

Where to Get Operator Report Forms?

  • On the web at:

http://dec.alaska.gov/eh/dw/publications/forms.html

  • From the DEC office that covers your system.
summary continued where to send your report
Summary ContinuedWhere to Send Your Report?

Anchorage Office

555 Cordova Street

Anchorage, AK 99501

Toll Free: 1-866-956-7656

Fax: 269-7650

DEC.DWData.Anchorage@alaska.gov

Fairbanks Office

610 University Avenue

Fairbanks, AK 99709-3643

Toll Free: 1-800-770-2137

Fax: 451-2188

DEC.DWData.Fairbanks@alaska.gov

Soldotna Office

43335 Kalifornsky Beach Rd., Suite 11

Soldotna, AK 99669-9792

Phone: (907) 262-5210

Fax: 262-2294

DEC.DWData.Kenai@alaska.gov

DEC.DWData.Juneau@alaska.gov

Wasilla Office

1700 E. Bogard Rd., Bldg. B Suite 103

Wasilla, AK 99654

Phone: (907) 376-1850

Fax: 376-2382

DEC.DWData.Wasilla@alaska.gov
