if that makes any sense to you you have a big problem
If that makes any sense to you, you have a big problem

Concurrent Object Oriented Programming

Susmit Bagchi, NTNU

free your mind
Free Your Mind

To understand concurrent programming it is useful to first examine sequential programming and the (often hidden)assumptions behind it.

Languages such as Fortran,C/C ++,and Pascal are influenced by the underlying system architecture,which is typically a uniprocessor machine with a von Neumannarchitecture:

A single CPU connected to RAM and i/o devices via a bus;

Instructions and data are shared in RAM;

Processor activity consists of fetch-execute cycles;

One instruction is executed per cycle (ignoring such issues as pipelining and

superscalar architectures).

Susmit Bagchi, NTNU

contd
Contd..

This means that code is,essentially,written in the order we expect the machine to execute it. This defines a total orderingon the set of instructions:

{p 1,p 2,...,p L,q 1,q 2,...,q M,r 1,r 2,...,r N}

If we choose any two instructions from this set,then we can always rank them according to their execution order.

*Two characteristics of sequential programming*

1.The textual order of statements specifies their order of execution

2.Successive statements must be executed without any temporal overlap

Neither of these applies to concurrent programming.

Susmit Bagchi, NTNU

concurrent programming
CONCURRENT PROGRAMMING

Definition:

Operations in the source text are concurrent if they could be, but need not be, executed in parallel. Operations that occur one after the other, ordered in time, are said to be sequential.

The fundamental concept of concurrent programming is

-the notion of a process, which corresponds to a sequential

computation, with its own thread of control.

-the threadof a sequential computation is the sequence of

program points that are reached as control flows through the

source text of the program.

Susmit Bagchi, NTNU

concurrent programming languages
Concurrent programming languages
  • Specific language designs
  • **Actors (Hewitt, Guha)
  • **ABCL (Tokoro, Yonezawa)
  • **POOL (America, et al.)
  • **Obliq (Cardelli)
  • Semantic frameworks, e.g., actor semantics
  • Extensions to C++, e.g., COOL
  • Process calculus approaches (Pierce, etc.)

Susmit Bagchi, NTNU

interactions between processes
INTERACTIONS BETWEEN PROCESSES

Communication:involves the exchange of data between processes, either by an

explicit message passing or through the values of shared

variables.

Communication types: SYNC. and ASYNC.

Communication model: Communication I/O through channels

Synchronization::relates the thread of one process with that of another.

Interactions between processes can also be visualized in terms of

competitionandcooperationbetween processes.

Synchronization constructs:Semaphore, Monitors.

Susmit Bagchi, NTNU

concurrent programming model
Concurrent programming model

In order to model concurrency we allow process composition, P1 | P2.

Intuitively, this means that processes P1 and P2 execute concurrently. Such concurrent processes can interact in a synchronous fashion when one process wants to perform an input action and another process wants to per-form a matching output action.

Formally:

P ||Q  e: (P Q ) and  (Q P ).

Thus we have a partial ordering: given any two instructions from P or Q ,we may or may not be able to rank them according to their execution order.

HOW MANY PARTIAL ORDER SEQUENCES POSSIBLE?

ALL SEQUENCES ARE EXECUTABLE?

Susmit Bagchi, NTNU

programming model contd
Programming model contd..

Discussion on Concurrent programming constructs:

# Ordering : <{p},{q}, {r}> ; Poset C = {<p>, <q>, <r>}

# Combinatorial form (C)

# Alphabet X ={x, x, x’, x’’, ……..x’n}

# Terminal function, t:PT; T={S,F}

# Process state transition predicate [x x’ …. (x’n OR t(x))]

# Cyclic process

Susmit Bagchi, NTNU

characteristics of concurrent programming
Characteristics of concurrent programming

Two characteristics of concurrent programming:

If two operations are concurrent with one another then

1.The textual order of statements does not specify their order of execution

2.The operations are permitted (but not obliged)to overlap in time

Susmit Bagchi, NTNU

formal definition alternate form
Formal definition (alternate form)

As a very simple example, consider two processes A and B plugged together in the following way. A performs input action a and then wants to perform output action b, returning to state A. Process B performs an input action b followed by an output action c, returning to state B upon completion. Hence, they are defined as,

A = a.bˆ.A<a,b>

B= b.cˆ.B<b,c>

We assume we start with A and B operating concurrently, that is, in state A | B. Now we can have the following sequence of transitions:

a(a.bˆ.A| b.cˆ.B)A| cˆ.B A|B

Susmit Bagchi, NTNU

concurrent process expression

A] Prefixes: P,Q, R ::= 0 (inert process)

x(y).P (input prefix)

xˆ.y.P (output prefix)

P|Q (parallel composition)

(νx)P (restriction)

!P (replication)

B] The (Abelian) monoid properties:

1) P|Q  Q|P ---Commutativity of parallel composition

2) (P|Q)|R  P|(Q|R) --- Associativity of parallel composition

3) P|0  P

Concurrent process expression

Susmit Bagchi, NTNU

concurrent process expression contd
Concurrent process expression contd….

C] The scope extension property:

((νx)P)|Q  (νx)(P|Q) if x FV(P) ((νx) is non-distributive)

D] Replication/ Creation:

!P  (P|n)|!P

Susmit Bagchi, NTNU

concurrent object oriented programming languages
Concurrent Object Oriented Programming Languages
  • Preliminaries:
  • Objects are completely “encapsulated”.
  • Objects communicate via “message passing” (OR shared memory).
  • An object may enquire the “internal local state” of another object by
  • sending a “message” requesting to execute some “method”.
  • Advantage of “message passing” over “shared memory”:
  • “message passing” separates the two objects/processes completely, but

not the “shared memory” construct.

”shared memory” system needs to take care of shared variables by

synchronized data structure access---a bit complicated.

Susmit Bagchi, NTNU

why do we need concurrent oo language
Why do we need concurrent OO language?
  • Because,
  • Real world is concurrent (and distributed).
  • Performance gain in (due to concurrency)

 resource utilization

execution time

  • Fault tolerance by replicating

data

method

Susmit Bagchi, NTNU

object oriented concurrency issues

Interaction primitives

Synchronous and asynchronous model

 Object granularity

bias that language offers toward size of object

ACTOR offers fine-grain/ SmallTalk offers coarse grain

 Encapsulation

case SmallTalk: class variablemultiple instances 

concurrent update (mutex??)

Opportunity for “interference” in concurrent system

  • Class consistency (arises from object migration and potential for

independent redefinition/modification of class definitions)

OBJECT ORIENTED CONCURRENCY ISSUES

Susmit Bagchi, NTNU

actor model
ACTOR model
  • Actors originated through Carl Hewitt work on the artificial intelligence system Planner in the early 1970’s.
  • Actor approach was formulated around three main design objectives:
  • Shared, mutable data. The actor model is designed to deal with shared resources that may change state. An example is a bank account whose balance may change.
  • Reconfigurability. New objects may be created and it is possible to communicate with new objects after they are created.
  • Inherent concurrency. It should be possible to understand the "inherent concurrency" of a program by examining it.
  • ** The phrase "inherent concurrency" refers to the number of activities that could be carried out in parallel if there were an unbounded number of processes available.

Susmit Bagchi, NTNU

basic ideas in the actor model
BASIC IDEAS IN THE ACTOR MODEL
  • DEFINITION: An actor is an object that carries out its actions in response to communications it receives. Actors support large-scale concurrent symbolic computation.
  • *There are three basic actions that an actor may perform*
  • Send communication to itself or other actors
  • Create new actors
  • Specify a replacement behavior, which is essentially another actor that takes the place of the actor that creates it, for the purpose of responding to certain communications.

Susmit Bagchi, NTNU

important points to remember
*Important points to remember*
  • Each actor receives a linearly ordered sequence of communications.
  • There is no assignment to local variables in the basic actor model.
  • One execution of an actor script is an atomic computation.
  • An important part of the model is the mail system, which routes and buffers communication between actors. Every communication must be sent to a mail address and an actor may communicate with any actor if it knows its mail address.

Susmit Bagchi, NTNU

general properties of actor
General properties of ACTOR
  • The Actor model is asynchronous, with no global clock.
  • Communication is
  • explicit, through mail addresses, without shared variables,
  •  buffered and asynchronous.
  •  Weak fairness is assumed, in the following forms:
  • Every message that is sent is eventually delivered. (However the notion of "deliver" is subtle, because an actor may or may not be prepared to process a message at a given time. More discussion below.)
  • Every computation eventually progresses, i.e., each process is eventually scheduled and allowed to perform part of its computation.

Susmit Bagchi, NTNU

actor characterization
ACTOR characterization

All actors are characterized by:

¶ identity (never changes once an actor created)

¶ current behaviour (indicates actor’s action on next message)

Immutable actor: Actor having same “action behaviour” throughout its life time.

Actor Classes:

 Primitive actor

-corresponds to atomic types such as characters

-primitive actor are sent directly in messages

 Non-primitive actor

-mail-address represents actor identity

-current behaviouris composed of a set of instance

variables or local state of the actor

Susmit Bagchi, NTNU

actor anatomy
ACTOR anatomy

Some internal organs of an actor

(defBehaviour simple-check-acc [balance]

(script

[[:deposit amount customer]

(become check-acc[(sendbalance[+amount] ) ] )

(send customer [:deposited amount] ) ]

[[:withdraw amount customer]

(become check-acc[(sendbalance [-amount] ) ] )

(send customer [:withdraw amount] ) ]

[[:balance customer]

(send customer [: balance balance] ) ] ) )

**Anatomical decease: Actor model does not have any form of code sharing as part of model.

Susmit Bagchi, NTNU

actor is too old abcl 1 is charming

ABCL/1 childhood: ABCL/1 has evolved from Actor but,

more pragmatic; adopts more eclectic view toward object coexistence

Object in ABCL/1: The object and its behaviour is specified entirely by its script, which is a collection of message patterns and associated methods.

Message passing in ABCL/1: Asynchronous and point to point.

Message types in ABCL/1:

-past (send message and resume activity)

-now (send message and wait for response)

-future (send message, mention future action and resume

activity; something like “future-RPC”)

ACTOR is too old; ABCL/1 is charming!

Susmit Bagchi, NTNU

abcl 1 is attractive

Message priorities:

-no such message priority in ACTOR model----(a distinction!)

-two types of priorities in ABCL/1(express_messageORordinary_message)

Action set:

-reception of express_message will preempt ordinary_message processing

-when express_message processing is over, resumes from preemption point

Message queues and Object states:

-two message queues per object (express_message_QORordinary_message_Q)

-three object states:

*dormant (currently idle, will do something on message arrival)

*active (currently processing a message, executing a method)

*waiting (while processing a message is sent, waiting for reply)

ABCL/1 is attractive!!

Susmit Bagchi, NTNU

matters to think
MATTERS TO THINK

Some major research issues:

$$ HOW CAN YOU EXTEND THE CONCEPT OF “INHERITANCE” TO

CURRENT SETTING?

$$ HOW ACTOR WILL ACHIEVE CODE SHARING?

$$ SmallTalk-80 TRIED TO ACHIEVE “INHERITANCE”, BUT HOW TO COPE

WITH RESULTING “INCOMPLETE ENCAPSULATION”?

Susmit Bagchi, NTNU
