DIGITAL RESEARCH MICROSCOPE BXL LCD 1

1. Since 1954 DIGITAL RESEARCH MICROSCOPE ® BXLi LCD BXL LCD

2. DIGITAL RESEARCH MICROSCOPE ® BXL LCD Technical Specifications : o o  Observation head  Camera and LCD display : inclined at 45 rotatable at 360 . : 5 inch LCD screen. Built-in digital camera with RCA, S-Video & USB- 2 output with 5MP Resolution. Internal media card reader/writer. ring on ocular tube. Adjustable 55-75mm. KEOWA WIDE FIELD WF10x/18mm(PAIRED) with eyeguards KEOWA MJ Series Semi-Plan Achromatic Objectives, anti-fungus treated 4x, 10x, 40x (S L), 100x (S L) oil immersion. Dust proof Quadruple nosepiece revolves on ball bearing with rubber grip and positive click stop. Double layer Mechanical stage size 120mm X 140mm having low positioned co-axial controls on ball bearing with ne vernier graduat io n . S t a g e f o c u s i n g l o c k . C r o s s movement 60mm X 80mm.  Diopter adjustment  Interpupillary distance:  Eypiece  Objective : : :  Nosepiece :  Mechanical Stage :  Tension Adjustment Ring : On right side provides a soft and sophisticated touch to the microscope. Focusable Abbe Condenser centerable NA 1.25 with rack & pinion, aspheric lens, swing out lter holder, Iris Diaphragm with BLUE lter. Built-in-base illumination system with 6V 20W bulb or 3W LED lamp with intensity controlled unit. Universal power supply (AC input 100V-240V, 50/60 Hz) ISO 9001, CE approved. Complete in a STYROFOAM molded box with dust cover, and other accessories. 3 years  Condenser :  Illumination :  Power Supply :  Accessories :  Warranty : The Western Electric & Scientific Works Near B.D. Higher Secondary School, Ambala Cantt-133001 India Distributor/Dealer: 1 :2 0 0 1 5 0 9 Tel : (91) 171 4002952 Ph. : (91) 94664 09560 Emai l: info@weswoxindia.com Weswoxindia.com With a policy of continuous development, WESWOX reserves the right to change design and specifications without prior notice.
