  • An electronic portable device, based on the MSP430 microcontroller, that helps the professor take the class attendance automatically.

  • Validates the student identity avoiding any type of fraud.

  • Ease of use for both, student and professor.

Sponsored by


Dca block diagram l.jpg
DCA Block Diagram

Sponsored by


System components l.jpg
SystemComponents

  • MSP430F149 microcontroller

    • Ultra-low power

    • 64KB flash memory

    • Serial connection

    • Other peripherals

  • USBMOD3 Module

    • UART to USB conversion

    • Self-powered mode

  • Sponsored by


    System components7 l.jpg
    SystemComponents

    • FPC1010 Area Sensor

    • FPC2000 Fingerprint Processor

      • Fast, easy and secure

      • Fingerprint recognition eliminates

        the need for magnetic cards

        or pin numbers.

      • Fingerprints are a unique

        and precise ID.

    Sponsored by


    System components8 l.jpg
    SystemComponents

    • 1 MB Flash Memory

    • Lithium Battery Charging Controller

    • LCD display

    • Keypad

    Sponsored by


    Design features l.jpg
    Design Features

    • Handheld device

    • PC software to program the device, upload, and download attendance data.

    • Automatic generation of attendance reports

    • Flash memory will be used to store the class sections and student information.

    Sponsored by


    Design features10 l.jpg
    Design Features

    • DCA Simple User Interface

      • An LCD and Keypad will provide the professor with an easy user interface program.

      • The system will verify the professors ID for operation of the device.

      • Password protected system

    Sponsored by


    Design features11 l.jpg
    Design Features

    • PC Simple User Interface

      • USB interface with the PC.

      • The professor will be able to generate class attendance reports as well as changing the system information.

    Sponsored by


    Fingerprint brief operation l.jpg
    Fingerprint Brief Operation

    Enroll fingerprints

    Student presses fingerprint.

    FPC2000 processor retrieves the image and builds a template for it.

    The microcontroller downloads

    the fingerprint template and

    stores it in an internal data base.

    TemplatesDB

    Verify fingerprints

    Student presses fingerprint.

    FPC2000 processor retrieves

    the image and builds a template

    for it. It compares this template

    against uploaded candidates.

    The microcontroller uploads to the

    FPC2000 the fingerprint templates to

    be compared against the new template.

    TemplatesDB
