Presentation Transcript
multi layer traffic engineering in ip over optical networks

Multi-Layer Traffic Engineering in IP over Optical Networks

October 20, 2004

Hung-Ying Tyan

Department of Electrical Engineering

National Sun Yat-sen University

outline
Outline
  • IP Network
  • Transport Network
  • Traffic Engineering
  • Some Observations
  • Multi-Layer Traffic Engineering
  • Our ML-TE Framework
  • Our ML-TE Algorithms
  • Evaluation
ip network
IP Network

CompanySchoolEnterprise

CompanySchoolEnterprise

Internet Service Providers (ISP)

Carriers

router

MAN, WAN

LAN

ip network4

OXC

OXC

OXC

OXC

OXC

OXC

OXC

IP Network

(Optical) Transport Network

ip network over otn

OXC

OXC

OXC

OXC

OXC

OXC

OXC

IP Network over OTN

Conceptual view

Data center

Actual

IP link = circuit

transport network
Transport Network
  • Evolved from traditional telecommunications networks
  • Good at long distance transmission of digital signal
  • Technologies
    • Synchronous Optical Network (SONET)
    • Wavelength Division Multiplexing (WDM)
    • Providing long-term circuits between end points
  • Separation from application networks
    • Network on network; “overlay network”
    • Business tiers: carriers vs ISPs
traffic engineering te
Traffic Engineering (TE)
  • Mechanisms to allocate network resources according to traffic demand
    • ISP: Make better use of resources ($$$)
  • Static: Network planning/provisioning/optimization
  • Dynamic:Resources allocation adapts to traffic change
dynamic te
Dynamic TE
  • Basic idea:Move traffic around to alleviate congestion
  • Why is it effective?
    • Data traffic can be bursty
    • Special events occur more frequently in data networks
observations
Observations
  • ISPs and carriers want to provide better service with less cost
  • Over-provisioning because of slow response to adding capacity and large variation in traffic demand
    • Utilization < 25%
  • Current dynamic TE is still limited
    • Only deal with congestion
large daily traffic variation
Large Daily Traffic Variation

OC-48 link between Dallas and Washington DC

more observations
More Observations
  • “Information Super Highway”?
  • Distribution channel of electronic information products
  • Electronic post office
technology advances
Technology Advances
  • Control Plane Technology
    • A separate network dedicated to resources control
    • Allows resources to be added or released quickly
  • Optical devices and equipments
    • Optical laser, receiver, filter etc
    • Wavelength conversion
    • Optical add-drop multiplexer (OADM)
    • Optical cross connect (OXC)
new te paradigm multi layer te

2

3

2

4

2

4

3

Peak Hours

Off-Peak Hours

New TE Paradigm – Multi-Layer TE
  • For ISP, IP links can be leased or released on demand
    • IP network topology can be changed on demand
    • Let IP network topology adapt to actual traffic demand
value proposition
Value proposition
  • For ISP
    • OPEX reduction
    • Simplified network planning
  • For Carrier
    • New applications/customers for Carrier Increased (overall) revenues
    • Improved resource efficiency More revenue from the same resources
network model

OXC

OXC

OXC

OXC

OXC

OXC

OXC

Network Model
  • Two-layer overlay
    • IP/MPLS network
    • Optical network
  • Assume that Optical TE is already available
our mlte framework

Input

  • -Traffic matrix
  • Physical topology
  • etc

Initial provisioning

Network monitoring

congestion

under-utilization

MPLS-TEHybrid path routing

Cost down?

no

yes

Activate

new IP links

Remove idle IP links

Our MLTE Framework
slide17

Network Monitoring & MPLS-TE

IP/MPLS Network

1

2

3

  • Monitor outgoing IP links
    • Detect congestion (if utilization > TH_high)
    • Detect underutilization ( if utilization < TH_low)
  • Select target LSPs and notify ingress nodes
  • Ingress node attempts to re-route LSPs
hybrid path routing
Hybrid Path Routing
  • Augmented topology information from optical layer: candidate links
  • Hybrid path consisting of
    • Existing IP links
    • Candidate links
  • Special cost functionfor both congestionand under-utilization

IP/MPLS Network

OXC

OXC

OXC

OXC

OXC

OXC

OXC

Optical fiber

Optical Network

hybrid path routing19
Hybrid Path Routing
  • Define Network_Cost = sum( Link_Costi ) Link_Costi = F(Link_Utilizationi) x real_link_costi
  • Algorithm:
    • Triggered by congested or under-utilized links
    • Dijkstra’s shortest path
    • d(link_costi)= F(expected_link_utilizationi) – F(link_utilizationi)
    • Granting a new route only if it decreases the real network cost

F

link_utilization

UH

north america model

LSP Demand

High

Low

0

8

16

Time (hr)

North America Model

OXC

Seattle

Boston

Chicago

OXC

Detroit

OXC

OXC

Denver

OXC

NYC

OXC

Cleveland

OXC

SF

DC

OXC

OXC

OXC

KansasCity

LA

OXC

Atlanta

OXC

OXC

Dallas

Miami

OXC

14 Nodes

24 Links (fiber)

193 LSPs

experiment results
Experiment Results
  • Simulation tool: J-Sim (www.j-sim.org)
  • North America Model
    • 14 nodes, 24 links, 193 LSPs
    • Average # of IP links ~ 21
    • # of IP links at peak demand = 33
    • Cost saving ~ 36% v.s. over-provisioning
    • Tradeoff between cost and number of LSP reroutes
research topics
Research Topics
  • ML-TE framework
  • TE operations
    • MPLS-TE procedure and Optical-TE
  • Topology transformation algorithm
  • Hybrid path routing algorithm
    • Suitable for both congestion and under-utilization
thank you
Thank you!

Question?
