Presentation Transcript



occurrence in daily life
Occurrence in daily life

Acrylamide in fried or baked goods is produced by the reaction between asparagine and reducing sugars (fructose, glucose, etc.) or reactive carbonyls. Browning during baking, frying or deep-frying will produce acrylamide and over-cooking of foods will produce large amounts of acrylamide. Acrylamides can also be created during microwaving. Acrylamide cannot be created by boiling, and very few uncooked foods contain any detectable amounts.

Acrylamide in olives and prune juice comes through another process. It has been suggested that environmental pathways, such as the breakdown of the herbicide glyphosate (Roundup), are sources too.

Smoking is also a major acrylamide producer. Estimates for the proportion in the diet coming from the consumption of coffee range from twenty to forty percent.

health risks
Health Risks
  • Potential health risk There is evidence that exposure to large doses can cause damage to the male reproductive glands. Direct exposure to pure acrylamide by inhalation, skin absorption, or eye contact irritates the exposed mucous membranes, e.g. the nose, and can also cause sweating, urinary incontinence, nausea, myalgia, speech disorders, numbness, parasthesia, and weakened legs and hands. In addition, the acrylamide monomer is a potent neurotoxin, causing the disassembly or rearrangement of intermediate filaments (nerve damage). Ingested acrylamide is metabolised to a chemically reactive epoxide, glycidamide.
  • Cancer According to a 2005 review, acrylamide reliably produces various types of cancer in experimental mice and rats. However, studies in human populations have failed to produce consistent results, and it remains unclear whether this is due to a reduced risk in a natural setting or the methodological difficulties inherent in such studies. For example, it might be difficult to isolate the effects of acrylamide because it is so ubiquitous in western diets.

sds gel

Stacking Gel

4 % acrylamide

12% acrylamide

Resolving Gel

protein gel
Protein Gel

Protein Standard

216 kDa

132 kDa

78 kDa

45.7 kDa

32.5 kDa

18.4 kDa


gel only

  • Lanes:
  • 1Molecular Weight Markers
  • Supernatant
  • Pellet
  • Resin
  • Fraction 2
  • Fraction 1

Proteins are measured in kiloDaltons

1 amu = 1 Dalton

1,000 atomic mass units = 1 kiloDalton (kDa)

calculating protein size

Size of protein in kDa

mm from top of gel

3 216 kDa

6 132 kDa

9 78 kDa

18 45.7 kDa

22 32.5 kDa

30 18.4 kDa

Calculating Protein Size
calculating protein size13

Size of protein in kDa

mm from top of gel

3 216 kDa

6 132 kDa

9 78 kDa

18 45.7 kDa

22 32.5 kDa

30 18.4 kDa

Calculating Protein Size

Protein size

20 40 60 80 100 120

Use the graphed protein standard to calculate unknown protein sizes

10 20 30

mm from top of gel
