non photorealistic rendering cs 446 real time rendering game technology

Non-Photorealistic Rendering CS 446: Real-Time Rendering & Game Technology

David Luebke

University of Virginia

slide2
Demo
  • Today: Sean Arietta, Super Mario Sunshine
  • Thursday: Greg Tylka

Real-Time Rendering

assignments
Assignments
  • Assn 4 description due tonight at midnight
    • Remember to post these on forum, not send by e-mail
    • Assn 4 due Mar 31, integrated demo Mar 23

Real-Time Rendering

non photorealistic rendering
Non-Photorealistic Rendering

“Using a term like ‘nonlinear science’ is like referring to the bulk of zoology as ‘the study of nonelephant animals’”

  • Photorealism: age-old goal of graphics
  • Non-photorealistic rendering
    • Broadly, techniques for rendering that don’t strive for realism, but style, expressiveness, abstraction, uncertainty, etc
    • A terrible term that we may be stuck with
      • Better terms: stylized rendering, artistic rendering, abstract rendering, comprehensible rendering, etc.

Real-Time Rendering

stylized rendering
Stylized Rendering
  • NPR usually used to refer to graphics techniques that emulate a particular artistic style or medium
    • Impressionistic painting
    • Pen-and-ink (cross hatching, outlining, etc)
    • Colored-pencil, copperplate engraving, you name it
    • Cartoon drawing

Real-Time Rendering

toon shading
Toon shading
  • Toon shading is the term that we use to refer to cartoon-like rendering effects
  • Tendencies in cartoon/comic style:
    • Simple, flat shading (cel shading)
      • Two-tone (light/shadow) or three-tone (light/shadow/highlight)
    • Edge highlighting
      • Boundary (border edge)
      • Crease (hard edge)
      • Material edge
      • Silhouette edge

Real-Time Rendering

toon shading7
Toon Shading
  • Cel shading
    • Threshold the lighting equation
      • Ex: the Cg program we looked at
      • Diffuse below 0.5 ? dark color : light color
      • Specular above 0.5 ? hilight color : diffuse color
      • If no pixel shaders, can use N ● L to look up a 1-D texture containing the shaded colors
    • In general, can think of these procedures as remapping the traditional lighting equation elements (tone mapping)

Real-Time Rendering

silhouette rendering
Silhouette Rendering
  • Boundary (border edge)
    • Not shared by two polygons
    • E.g. the edge of a sheet of paper
    • Solid models usually have no boundaries
  • Crease (hard edge)
    • Shared by two polygons at a dihedral angle greater than some threshold (often 60°)
    • Or a vertex with two normals/two colocated vertices
    • Ridge or valley edges

Real-Time Rendering

silhouette rendering9
Silhouette Rendering
  • Material edge
    • Triangles sharing edge have different materials/texture maps/etc
    • Or just an edge that the artist wants to emphasize
  • Silhouette edge
    • Triangles sharing edge face different directions (towards/away from viewer)
    • Lots of techniques to find at runtime!

Real-Time Rendering

finding rendering silhouette edges
Finding/Rendering Silhouette Edges
  • Surface angle silhouetting
    • Again, like the Cg program we looked at
    • Calculate N●V, if below threshold  draw black
    • Problem: depends on surface curvature (see Fig 7.5)

Real-Time Rendering

procedural geometry silhouetting
Procedural Geometry Silhouetting
  • Idea: render the geometry in such a way that the silhouettes “fall out”
  • Ex:
    • Draw frontfacing polygons
    • Draw backfacing polygons
      • But draw them in thick (2-pixel) wireframe
      • Or draw them in wireframe, z-biased forward a bit
      • Or “fatten” them
      • Or displace them along their normals (“halo” effect)

Real-Time Rendering

results
Results

Wireframe Translation Fattening

40 fps 50 fps 11.5 fps

Original Venus model : 5672 triangles, 66 fps

Real-Time Rendering

image processing silhouetting
Image Processing Silhouetting
  • Idea: analyze the image after it’s rendered, and extract silhouettes (like edge detection)
  • Can help by rendering e.g. depth image, object-ID image, normal image
  • Perfect for fragment program!

Real-Time Rendering

silhouette edge detection
Silhouette Edge Detection
  • Idea: find silhouette edges geometrically and render them explicitly
    • Hierarchy of normal cones
    • Lots of other interesting geometric approaches
  • Most work, but gives the most flexibility in how silhouettes are drawn

Real-Time Rendering

recap edge highlighting
Recap: Edge Highlighting
  • Toon shading (and other NPR techniques based on drawing) requires drawing/highlighting some edges:
    • Silhouette edges
    • Mesh boundaries (always on silhouette)
    • Creases (ridge and valley)
    • Material boundaries
  • Find first at run-time, precalculate the others (unless object is deformable)

Real-Time Rendering

recap silhouette edges
Recap: Silhouette Edges
  • Surface angle silhouetting
    • Calc N●V, if below threshold  draw black
      • Best as a per-pixel routine
      • The Cg program we looked at
      • Options: spheremap, or use a mip-map with top-level textures dark
    • Pros:
      • Uses the texture hardware  fast
      • Can antialias the resulting lines
    • Cons:
      • Line width depends on curvature
      • Doesn’t work for some models (e.g., a cube)

Real-Time Rendering

recap silhouette edges17
Recap: Silhouette Edges
  • Procedural Geometry Silhouetting
    • Idea: render geometry such that the silhouettes “fall out”, e.g.:
      • Draw frontfacing polygons
      • Draw backfacing polygons
        • But draw them in (possibly thick) wireframe
        • Or draw them z-biased forward a bit
        • Or “fatten” them
        • Or displace them along their normals (“halo” effect)
          • Flip normals
          • Amount of displacement varies w/ distance (why?)
          • Perfect task for vertex shader!
    • Pros: relatively robust, doesn’t need connectivity info
    • Cons: Wastes some fill & some polys, needs antialiasing
recap silhouette edges18
Recap: Silhouette Edges
  • Silhouette Edge Detection
    • Idea: find silhouette edges geometrically on the CPU and render them explicitly
      • Brute force: test every edge to see if its adjoining polygons face opposite directions in eye space
        • Can speed this up with hierarchy or randomized coherent search
      • Most work, but gives most flexibility in how silhouettes drawn
    • GPU variant:
      • Draw degenerate quadrilateral at each edge
      • “Fatten” quad into a “fin” when edge is on silhouette
        • Fin thickness based on distance to eyepoint
        • Vertex shader & replicated vertices today  geometry shader!
highlighting ridge edges
Highlighting Ridge Edges
  • Clever related technique by Raskar:
    • Add “fins” to every edge at dihedral angle
    • Size fins according to distance to viewer
    • Again, perfect for vertex shader, geometry shader
  • Similar but more complicated technique for highlighting valley edges

Real-Time Rendering

drawing lines outlining polygons
Drawing Lines:Outlining Polygons
  • Surprisingly hard to draw polys as filled outlines
    • Problem: depth buffer values of edge & polys same
    • 2-pass technique: draw polys, then draw edges
      • Z-bias edges forward or polygons back (glPolygonOffset)
      • Works okay, but has occasional problems
    • 3-pass technique:
      • Render filled polygon
        • Disable depth buffer writes (leave depth test on)
        • Enable color buffer writes
      • Render polygon edges polygon
        • Normal depth & color buffering
      • Render filled polygon again
        • Enable depth buffer writes
        • Disable color buffer writes

Real-Time Rendering

drawing lines hidden line rendering
Drawing Lines:Hidden-Line Rendering
  • Hidden-line vs. obscured line vs halos
    • Hidden-line
      • Draw polygons to depth buffer (not color buffer)
      • Draw edges using previous technique
    • Obscured (light, dotted, dashed) line
      • Draw all edges in obscured style
      • Draw polygons to depth buffer (not color buffer)
      • Draw edges using previous technique
    • Haloed line
      • Draw all edges as thick background-color lines
      • Draw edges using biasing, foreground-color

Real-Time Rendering

other styles
Other Styles
  • Impressionistic or “painterly” rendering:
    • Sprinkle particles on object surface
    • Draw particles as brushstrokes
    • Can render images to encode normals, surface curvature, depth, color/tone info

Real-Time Rendering

painterly rendering
Painterly Rendering
  • More info if time permits…

Real-Time Rendering

other styles24
Other Styles
  • Hatching:
    • Store different cross-hatch patterns representing different tones as textures
    • Clever ways to use texture hardware to blend between tones at run-time
  • More info if time permits…

Real-Time Rendering

other styles25
Other Styles
  • “Graftals” are a general term used for strokes, decals, little bits of geometry
  • Dynamic placement of graftals to achieve certain effects/styles:
other styles26
Other Styles
  • Technical Illustration

Real-Time Rendering

generalizing npr
Generalizing NPR
  • Recent work by researchers in NPR attempts to generalize many of these concepts:

Coherent Stylized SilhouettesKalnins, Davidson, Markosian, Finkelstein

generalizing npr28
Generalizing NPR
  • Recent work by researchers in NPR attempts to generalize many of these concepts:

Suggestive ContoursDeCarlo, Finkelstein, Reinkiewicz, Santella

gallery of npr images
Gallery of NPR images
  • Technical Illustration
  • Coherent Stylized Silhouettes
  • Suggestive Contours
  • SIGGRAPH papers…
  • NPAR
