Presentation Transcript
definition of gis
Definition of GIS
  • Stores geographic locations and attributes about the location.
  • Able to add information
  • Edit information
  • Examples terrain information, disease information, tree information
examples of gis
Examples of GIS
  • Google Earth
  • Google Maps
  • CGIS – First Computerized GIS
  • ArcGIS-Current commercial GIS
  • Wikimapia
history of gis
History of GIS
  • First were cave paintings showing where animals where located
  • First known analytic use was cholera outbreak in London in 1854 when Dr. John Snow used a map to figure out how to stop the outbreak
demos
Demos
  • Google Maps
  • Wikimapia
google code
Google code
  • Need key and a domain to embed in web site
  • Uses Javascript
sample code
Sample Code
  • <script src="http://maps.google.com/maps?file=api&amp;v=2.x&amp;key=key" type="text/javascript"></script>
  • <script type="text/javascript">
  • var map = null;
  • vargeocoder = null;
  • function initialize() {
  • if (GBrowserIsCompatible()) {
  • map = new GMap2(document.getElementById("map_canvas"));
  • map.setCenter(new GLatLng(37.4419, -122.1419), 13);
  • }
  • }
  • </script>
more code
More Code
  • <body onload="initialize()" onunload="GUnload()">
  • <form id="form1" runat="server">
  • <div>
  • <asp:TextBox ID="TextBox1" runat="server"></asp:TextBox>
  • <asp:Button ID="Button1"
  • runat="server" Text="Button"
  • onclientclick="showAddress();return false"
  • UseSubmitBehavior="True" />
  • </div>
  • <br />
  • <div id="map_canvas" style="width:300px; height:500px"></div>
  • </form>
  • </body>
geolocating
Geolocating
  • function showAddress() {
  • geocoder = new GClientGeocoder();
  • var address=document.forms[0].TextBox1.value;
  • if (geocoder) {
  • geocoder.getLatLng(
  • address,
  • function(point) {
  • if (!point) {
  • alert(address + " not found");
  • } else {
  • map.setCenter(point, 13);
  • var marker = new GMarker(point);
  • map.addOverlay(marker);
  • marker.openInfoWindowHtml(address);
  • }
  • }
wikimapia
Wikimapia

wikimapiaRequestStr = "http://api.wikimapia.org/?function=box&bbox=" + LonMin.Text + "," + LatMin.Text + "," + LonMax.Text + "," + LatMax.Text + "&key=key”

The key can be gotten at wikimapia.org/api

Returns XML with places in the box

Can return other formats like JSON, KML and also gzip it.

xml format
XML format

<code class="xml"> <?xml version="1.0" encoding="utf-8"?> <?access-control allow="*"?> <folder language="en" version="1.0"> <!-- places folder, language and version --> <place id="22139">

<name>Golden Gate National Recreation Area: Land's End</name>

<url>http://wikimapia.org/22139/</url> <!-- original url -->

<location> <lon>-122.4997044</lon> <lat>37.7887088</lat> <north>37.788878</north> <south>37.78681</south> <east>-122.494082</east> <west>-122.508352</west> </location>

<polygon> <point x="-122.5077081" y="37.7867756"/> <!-- points of polygon x - longitude, y - latitude --> <point x="-122.494082" y="37.78681"/> <point x="-122.4945974" y="37.7880983"/> <point x="-122.496593" y="37.7874539"/> <point x="-122.4973226" y="37.7875896"/> <point x="-122.4997044" y="37.7887088"/> <point x="-122.5002408" y="37.7885053"/> <point x="-122.5024295" y="37.788234"/> <point x="-122.5035238" y="37.7880305"/> <point x="-122.5060344" y="37.7882001"/> <point x="-122.5071502" y="37.7875048"/> <point x="-122.5071502" y="37.7875048"/> <point x="-122.5077081" y="37.7867756"/> </polygon> </place>

xml parser in c
XML Parser in C#
  • XmlReader wikiReader = XmlReader.Create(wikimapiaStream);
  • while(wikiReader.Read()) {
  • if (wikiReader.IsStartElement()){
  • if (wikiReader.IsEmptyElement) {
  • name = wikiReader.Name;
  • }
  • else{
  • name = wikiReader.Name;
  • wikiReader.Read();
  • if (wikiReader.IsStartElement() {
  • name = wikiReader.Name;
  • }
  • content = wikiReader.ReadString();
  • if (name == "name"){
  • ListBox1.Items.Add(new ListItem(content));
  • }
other capabilities of wikimapia
Other Capabilities of Wikimapia
  • Can Search
  • Can request URL for a place; need place id gotten from Box
can be used with google maps and google world
Can be used with Google Maps and Google World
  • THE KML format is used by Google Earth
  • The KMZ format which is KML zipped can be used by Google Maps to add information about the area like Google Earth.
spatial databases
Spatial Databases
  • Can add points, lines, and polygons to the database in SQLServer and MySql
  • I will talk about MySql but these are standards that have been implemented so should work for other databases.
spatial types
Spatial Types

Point- POINT(12.5 13.1)

LineString- LINESTRING( 0 0, 0.5 0.4, 20.1 20.5)

Polygon- POLYGON( ………………………..)

MULTIPOINT holds many points

MULTILINESTRING holds many line strings

GEOMETRY can hold any type

use of types
Use of types
  • Create Table PointsAndLines (pt POINT,Line LINESTRING);
  • Insert Into PointsAndLines

Values (GeomFromText(‘(POINT(1 1)’)),…);

  • Select AsText(pt) From PointsAndLines.
references
References
  • Wikipedia-GIS
  • Wikimapia.org/api
  • code.google.com/apis/maps
  • dev.mysql.com
