understanding integrated authentication in iis

Understanding Integrated Authentication in IIS

Chris Adams

IIS Supportability Lead

Microsoft Corp.

agenda
Agenda
  • Introduction to Integrated Authentication
  • Dynamics of NTLM Authentication
  • Dynamics of Negotiate Authentication
    • Demonstration One
  • Best Practices for Integrated Authentication
  • References
introduction to integrated authentication
Introduction to Integrated Authentication
  • Introduced in Windows 2000
  • Commonly referred to as “Windows Integrated Authentication”
  • Secure: It is considered secure because it does not transmit password “on the wire”
  • Internet Explorer preferred –
    • IF Basic and Integrated are both enabled, IE will use Integrated for security reasons
introduction let s review
Introduction: Let’s review…
  • How authentication works in IIS
  • Request enters server core
  • Server core forwards to
  • anonymous provider. IIS builds
  • path (w3svc/1/root) and verifies
  • if anonymous is enabled.
  • Yes: Provide path and Anon.
  • users token to authorization
  • manager
  • No: IIS passes the path to each
  • provider to determine if
  • path has that provider enabled.
  • Each provider that is enabled returns to
  • Server core the appropriate header.

Anonymous

Server

Core

Basic

Kerberos

NTLM

Digest

Passport

introduction
Introduction…

Negotiate

NTLM

Kerberos

introduction to integrated authentication6
Introduction to Integrated Authentication

Platform information for Windows Integrated

Windows NT 4:

  • Supports only NTLM (Not known as Windows Integrated)

Windows 2000:

  • Supports Negotiate and NTLM

Windows 2003:

  • Supports Negotiate and NTLM
introduction to integrated authentication8
Introduction to Integrated Authentication
  • How the appropriate integrated authentication is determined?

NTAuthenticationProviders

AuthNTLM

Yes

NO

401.3

Access

Denied

Negotiate

NTLM

dynamics of ntlm
Dynamics of NTLM
  • Connection Oriented
    • Same Connection always used per request
    • HTTP Keep-Alives Required
  • Understanding Auth Dialog Boxes
    • NTLM, by default, doesn’t prompt
    • NTLM may prompt if original request fails with 401.1
  • NTLM’s use of Domain\Username\Password
    • Domain and Username are always shared over the wire between client and server
    • Password is never – Always uses Hash of password
    • Authentication Header includes:
      • Domain\Username\HashedPassword
dynamics of ntlm security
Dynamics of NTLM: Security
  • Why is NTLM authentication secure?
    • Hash Algorithm of password is unknown when hackers monitor the HTTP requests on the wire
    • If connections are broke, manipulated (by proxies), then NTLM fails
ntlm @ work
NTLM @ Work…

Client Requests: One Connection

Get /Default.HTM

1

3

Get /Default.HTM w/ AuthNTLM

Get /Default.HTM w/ AuthNTLM Hashed

5

Server Responses: Same Connection

401 – Access Denied

2

401 – WWW Auth: NTLM

4

200 - OK

6

dynamics of ntlm12
Dynamics of NTLM
  • NTLM at work… (previous slide)
    • IE Client requests a IIS resource (Anon)
    • IIS returns 401 with WWWAuthenticate Header saying NTLM
    • IE submits new request for a IIS resource with NTLM Authentication header (username)
    • IIS uses NT Authentication Header to build secret key and sends 401 with key back to client
    • IE submits new request for a IIS resource with NTLM Authentication header (username\password\hash of password)
    • IIS checks username\password\hash and matches, return 200 OK –or- 401.1 Login failed (IE prompts)
dynamics of negotiate
Dynamics of Negotiate
  • Why create another authentication protocol?
    • NTLM limitations
      • NTLM Tokens cannot be delegated
      • NTLM is proprietary and only supported by Windows platform
  • Is Negotiate a new protocol?
    • No, it is just a wrapper that allows either Kerberos or NTLM authentication based on client request
dynamics of negotiate14
Dynamics of Negotiate

Key Terms of Negotiate

  • Client: Internet Explorer
  • Server: IIS Server that is member of Active Directory Domain
  • Active Directory:
    • Key Distribution Center (KDC) for all clients
    • Ticket Granting Service: Issues all tickets (aka tokens)
dynamics of negotiate15
Dynamics of Negotiate

IIS Server

Active

Directory

(KDC)

The IIS server is

started and when the

server authenticates to

domain (aka KDC) it

receives it ticket.

Ticket Granting Services

dynamics of negotiate16
Dynamics of Negotiate

Active

Directory

(KDC)

Registered ServicePrincipalNames for CN=CA-WEBCAST-IIS,OU=Domain Controllers,DC=

ca-webcast,DC=local:

GC/ca-webcast-iis.ca-webcast.local/ca-webcast.local

HOST/ca-webcast-iis.ca-webcast.local/CA-WEBCAST

HOST/CA-WEBCAST-IIS

HOST/ca-webcast-iis.ca-webcast.local

HOST/ca-webcast-iis.ca-webcast.local/ca-webcast.local

E3514235-4B06-11D1-AB04-00C04FC2DCD2/84bbfa08-5854-4729-80aa-56117bc4ecb6/ca

-webcast.local

ldap/84bbfa08-5854-4729-80aa-56117bc4ecb6._msdcs.ca-webcast.local

ldap/ca-webcast-iis.ca-webcast.local/CA-WEBCAST

ldap/CA-WEBCAST-IIS

ldap/ca-webcast-iis.ca-webcast.local

ldap/ca-webcast-iis.ca-webcast.local/ca-webcast.local

NtFrs-88f5d2bd-b646-11d2-a6d3-00c04fc9b232/ca-webcast-iis.ca-webcast.local

Setspn %computername%

negotiate @ work
Negotiate @ Work…

Client Requests: One Connection

Initial Client request for IIS resource anonymously

KDC (Active Directory)

1

The Server esponse is 401 – WWWAuth Header for Negotiate

3

2

4

I need a ticket for

The following service

(aka HTTP\HOST)

3

6

If Service located in KDC, Secret Key shared with Client

Shared

4

5

IIS Server

2

Using key provided, Client creates hash (key) and sends IIS

5

1

IIS uses secret key and verifies that password matches

6

slide18

Demonstration OneConfiguring a Process to use a Domain Accountand KerberosThe purpose of this demonstration is to show how a worker process identity set on a application pool affects authentication when the authenticated user uses the Negotiate protocol and Kerberos

references
References
  • IIS 6 Help Documentation
    • http://www.microsoft.com/technet/treeview/default.asp?url=/technet/prodtechnol/windowsserver2003/proddocs/standard/sec_auth_intwinauth.aspIIS 6 Deployment Guide
  • Load Balancing and Kerberos
    • http://www.microsoft.com/technet/treeview/default.asp?url=/technet/prodtechnol/windowsserver2003/maintain/security/nlbsecbp.asp
