a simple problem
A Simple Problem
  • grades, grades, grades*…
  • You would love to have a quiz average of 80 points (or better) in the QTM1300 course by the end of the semester.
  • Your quiz scores on the first eight quizzes are given in the table below.
  • What scores do you need to earn on the 9th and 10th final quizzes in order to meet your goal average of 80 points? * from FCL Excel Notes by Joyce Gordon, Babson College, 1998.
formulate the problem

Quiz Average

90 + 88 + 78 + 68 + 84 + 82 + 66 + 74 + x + y = 80

10

Formulate the Problem
  • obtain equation to be solved

You are looking for

x = score on 9th quiz (0 x 100)

y = score on 10th quiz (0 y 100)

so that

NOTE: When using Excel Solver to solve an equation make sure the right-hand side is a constant.

preparing the worksheet for solver
Preparing the Worksheet for Solver
  • start with a blank sheet
preparing the worksheet for solver5
Preparing the Worksheet for Solver
  • enter labels and constants

Enter labels in cells A1:A13 and B1

preparing the worksheet for solver6
Preparing the Worksheet for Solver
  • enter labels and constants

NOTE: These labels are not essential for the use of Solver

preparing the worksheet for solver7

Remember…

  • Quiz
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • Score
  • 90
  • 88
  • 78
  • 68
  • 84
  • 82
  • 66
  • 74
Preparing the Worksheet for Solver
  • enter labels and constants

Enter constants in cells B2:B9

preparing the worksheet for solver8

Remember…

90 + 88 + 78 + 68 + 84 + 82 + 66 + 74 + x + y = 80

10

x

y

Preparing the Worksheet for Solver
  • enter formula

Variable values in cells B10 and B11

Left-hand side of equation in cell B13

NOTE: These cells will be colored to indicate that they are essential for Solver

preparing the worksheet for solver9

Remember…

90 + 88 + 78 + 68 + 84 + 82 + 66 + 74 + x + y = 80

10

Preparing the Worksheet for Solver
  • enter formula

Click on cell B13

preparing the worksheet for solver10

Remember…

90 + 88 + 78 + 68 + 84 + 82 + 66 + 74 + x + y = 80

10

Preparing the Worksheet for Solver
  • enter formula

Type in =AVERAGE(

preparing the worksheet for solver11

Remember…

90 + 88 + 78 + 68 + 84 + 82 + 66 + 74 + x + y = 80

10

Preparing the Worksheet for Solver
  • enter formula

Highlight cells B2:B11

preparing the worksheet for solver12

Remember…

90 + 88 + 78 + 68 + 84 + 82 + 66 + 74 + x + y = 80

10

Preparing the Worksheet for Solver
  • enter formula

Type in ) and hit Enter

preparing the worksheet for solver13
Preparing the Worksheet for Solver
  • enter formula

NOTE: Alternative formula for cell B13: =(B2+ B3+ B4+ B5+ B6+ B7+ B8+ B9+ B10+ B11)/10

preparing the worksheet for solver14
Preparing the Worksheet for Solver
  • enter formula

NOTE: The function AVERAGE entered in cell B13 returns the average of the values in cells B2:B11; blank cells are ignored

using solver
Using Solver
  • invoke Solver

Click on Tools

using solver16
Using Solver
  • invoke Solver

Click on Solver

using solver17
Using Solver
  • invoke Solver
using solver18

NOTE: The cell displayed in the Set Target Cell: box must contain the formula for the left-hand side of the equation (cell B13)

Using Solver
  • complete the Solver Parameters dialog box

Click on cell B13

using solver19

Check the Value of: circle

Using Solver
  • complete the Solver Parameters dialog box
using solver20

Click on the Value of: box

Using Solver
  • complete the Solver Parameters dialog box

NOTE: The value displayed in the Value of: box must be the constant on the right-hand side of the equation (80)

using solver21
Using Solver
  • complete the Solver Parameters dialog box

Type in 80

NOTE: The value displayed in the Value of: box must be the constant on the right-hand side of the equation (80)

using solver22

Click on the By Changing Cells: box

Using Solver
  • complete the Solver Parameters dialog box
using solver23
Using Solver
  • complete the Solver Parameters dialog box

Highlight cells B10:B11

NOTE: The cells displayed in the By Changing Cells: box must be the cells containing variable values (cells B10:B11)

using solver24

Click on Add

Using Solver
  • complete the Solver Parameters dialog box

NOTE: The Subject to the Constraints: box must contain the constraints on the variable values (x,y 100)

using solver25

Click on the Cell Reference: box

Using Solver
  • complete the Solver Parameters dialog box

Highlight cells B10:B11

NOTE: The Subject to the Constraints: box must contain the constraints on the variable values (x,y 100)

using solver26

Make sure <= is displayed

Using Solver
  • complete the Solver Parameters dialog box

NOTE: The Subject to the Constraints: box must contain the constraints on the variable values (x,y 100)

using solver27

Click on the Constraint: box and type in 100

Using Solver
  • complete the Solver Parameters dialog box

NOTE: The Subject to the Constraints: box must contain the constraints on the variable values (x,y 100)

using solver28

Click on OK

Using Solver
  • complete the Solver Parameters dialog box

NOTE: The Subject to the Constraints: box must contain the constraints on the variable values (x,y 100)

using solver30

Check the Assume Linear Model and the Assume Non-Negative boxes

Using Solver
  • set the Options

NOTE: The equation (in the Target Cell B13) is linear on the non-negative variables (x in B10 and y in B11)

using solver31

Accept the remaining default options by clicking on OK

Using Solver
  • set the Options

NOTE: The equation (in the Target CellB13) is linear on the non-negative variables (x in B10 and y in B11)

using solver33
Using Solver
  • read solution

You need to earn a score of 100 on the 9th quiz and 70 on the 10th quiz to meet your goal average of 80 points.

using solver35

You need algebra!

Using Solver
  • a final comment

COMPLETESOLUTION

You need to earn a score of

x on the 9th quiz,

where 70  x  100, and

170 – x on the 10th quiz

to meet your goal average of 80 points.

NOTE:Excel Solver might not find all possible solutions
