Presentation Transcript
Fingerprinting and markers for floral crop improvement l.jpg
Fingerprinting and Markers for Floral Crop Improvement

James W. Moyer

Dept. of Plant Pathology

North Carolina State University, Raleigh, NC 27695

Introduction l.jpg

  • Floral industry has experienced significant growth

    • Industry production

    • Introduction of new products

      • Cultivars of existing crops

      • New species

  • Rapid expansion brings new issues

    • Breeder’s rights

    • Grower confidence in cultivar identity

    • Improved plant quality

      • Disease and insect resistance

      • Heat and drought tolerance

      • Longer shelf life

Dna fingerprinting and molecular markers l.jpg
DNA Fingerprinting and Molecular Markers

  • DNA fingerprinting is a useful tool in floral crop genetics

    • Cultivar identification

    • Maintenance of breeding lines

    • Protecting breeders’ rights

  • Molecular markers can facilitate the identification and introgression of genes for cultivar improvement

  • Methods for generating genetic markers include:

    • AFLP

    • SSR

    • Retrotransposons

Objectives l.jpg

  • Identify and prioritize commercially important crops

    • Survey the industry

  • Develop core tools for priority crops

    • Research available technologies

    • Select a method and develop a strategy

    • Generate polymorphisms useful for fingerprinting or other marker assisted breeding applications

  • Develop high-throughput technologies for efficient processing

Survey l.jpg

  • Prioritizing a list of crops according to:

    • Breeding effort: could support development and use of molecular tools

    • Competitiveness: would benefit from fingerprinting for patenting and monitoring of license agreements

  • Responses:

    • Highest priority crops are chrysanthemum, petunia, geranium, carnation, and New Guinea Impatiens

Crop values l.jpg
Crop Values

Value x $1000

Top ten:

Other high priority crops:

New Guinea Impatiens was 11th at 75,219,000

Carnation was 27th at 6,430,000

Aflp fingerprinting l.jpg
AFLP Fingerprinting

  • Used to generate molecular markers for fingerprinting without prior knowledge of the genome

  • Successful for poinsettia and NGI

    • Databases created for both crops

  • Progressed from manual radioactive techniques (above) to semi-automated fluorescent techniques (below)

  • F-AFLP utilized for genetic analysis in several plant species

    • Barley, wheat, and azalea

F aflp fingerprinting l.jpg
F-AFLP Fingerprinting

  • Advantages of fluorescent-based methods over traditional AFLP:

    • Fluorescent label replaces the radioactive label, making this procedure safer and less expensive

    • Scoring is more accurate and more reproducible

      • Better separation of fragments on the gel

      • Internal size standard present in every lane

    • Fragment scoring is based on a numerical representation of the fragment intensity

  • Compared to conventional 33P-labeled AFLP, this technique:

    • Increased the number of detectable fragments

    • Showed higher resolution of amplification products

    • Made scoring faster and more objective

Fingerprinting in poinsettia l.jpg
Fingerprinting in Poinsettia

  • Poinsettia database:

    • 117 cultivars

    • 41 AFLP fragments

  • Successfully distinguishes most cultivars

    • Multiple plants from representative cultivars used for validation studies

    • Plants from the same breeding family cluster together

    • Color sports cluster together as the same cultivar

Fingerprinting in ngi l.jpg
Fingerprinting in NGI

  • NGI database:

    • 168 cultivars

    • 95 AFLP fragments

  • Successfully distinguishes cultivars

    • Samples collected from multiple breeders

    • Duplicate samples used for validation studies

      • Always cluster together

    • Larger number of fragments used in order to account for genetic variation

Aflp fingerprinting11 l.jpg
AFLP Fingerprinting

  • Disadvantages:

    • Technology is patented

    • Many polymorphisms may be needed to distinguish closely related cultivars or cultivars with higher levels of genetic variation (40 – 80 fragments)

Microsatellites ssrs l.jpg
Microsatellites (SSRs)

  • Genetic markers used for genotype identification and marker-assisted breeding in a wide range of crops including:

    • Non-floral crops

      • Soybean, rice, apple, pine, mango, cotton

    • Floral crops

      • Chrysanthemum, Dianthus

  • Fewer high quality markers are needed to differentiate genotypes

  • System is patented but licensable, and could be used on a larger scale than AFLP technology

Ssr strategies l.jpg
SSR Strategies

  • Database mining

  • Library enrichment

  • Library screening

    • Hybridization

    • PCR

  • High throughput sequencing

Strategy 1 library screening and pcr l.jpg
Strategy 1: Library Screening and PCR

  • Genomic DNA from poinsettia was partially digested with a restriction enzyme to generate ~1200bp fragments

  • Fragments were ligated to a plasmid vector and transformed to make a library

  • The library was screened by PCR using primers complementary to the repetitive sequence with vector primers

  • PCR positive primers were sequenced and analyzed

Ssr results strategy 1 l.jpg
SSR Results: Strategy 1

  • Number of plates sequenced = 3

  • Number of repeats identified = 233

  • Number of polymorphic repeats = 1

  • Change strategies to cover more of the genome and identify more potential markers

Strategy 2 library sequencing l.jpg
Strategy 2: Library Sequencing

  • Partially digest genomic DNA to generate 1200bp fragments

  • Ligate fragments into a plasmid vector to create a library

  • Use high-throughput methods to sequence the library, and therefore more of the poinsettia genome

    • Plate has 96 wells: 700bp per well = 67200bp per plate

    • Literature indicates that one SSR will be present every 6000bp

    • Could theoretically identify 11 SSRs per sequencing plate

Ssr results strategy 2 l.jpg
SSR Results: Strategy 2

  • Number of repeats identified to date = 636

  • The larger repeat sequences will be analyzed for possible polymorphism

  • Additional colonies will be sequenced to identify additional microsatellites

Retrotransposons l.jpg

Typical Retrotransposon:



300 bp



















300 bp

300 bp

300 bp

300 bp


Identified in:

  • Poinsettia ( 11 cultivars)

  • Chrysanthemum (1 cultivar)

  • African violet ( 2 cultivars)

  • Petunia (1 cultivar)

Reverse Transcriptase Gene:

Retrotransposon analysis l.jpg

Eckespoint Pink Peppermint

Sonora Jingle Bells

Freedom Marble

Winter Rose

Freedom Jingle Bells

Eckespoint Jingle Bells


Pink African Violet

Peterstar Jingle Bells


Purple African Violet

Coral Davis Mum

Coral Davis Mum

Coral Davis Mum

Coral Davis Mum


Pink African Violet

Purple African Violet

Eckespoint Jingle Bells

Eckespoint Pink Peppermint

Peterstar Jingle Bells

Sonora Jingle Bells

Freedom Marble

Winter Rose

Retrotransposon Analysis

Summary l.jpg

  • Accomplishments

    • Fluorescent technologies were adapted for use with microsatellite markers

    • Input was collected from the industry and important crops were identified

    • Strategies for finding SSR markers were developed

      • Methods currently being tested and refined on poinsettia

      • Techniques will be applied to other floral crops

    • Designed strategies for locating retrotransposons

      • Tested in several crops

    • Implemented high-throughput methods

      • DNA extraction from cloning experiments

      • Examine possibility of multiplexing fluorescent SSR primers in future experiments
