slide1

Downtown Vancouver Transportation and Emergency Management System (DVTEMS)

PTV Vision User‘s Group Meeting

Karen Giese

Kean Lew

outline
Outline
  • Project Background
  • Custom Interactions
  • Model Demonstration
what is dvtems
What is DVTEMS?

Planning level travel demand model

Focus on pedestrian route choice

Based on the VISUM platform

Custom pedestrian & pedestrian-vehicle interactions

Communication through visual platform

Quantitative analysis

dynamic assignment
Dynamic Assignment

DVTEMS Uses Dynamic Assignment (DUE)

Key Benefits

  • Accounts for Capacity Constraints
  • Models Proper Interaction of Real Flows
  • Models Impacts of Short-Term Measures
  • Accounts for Special Event Temporal Characteristics
custom interactions
Custom Interactions
  • Two-way Pedestrian Capacity
      • Allows Pedestrians to Utilize Both Sidewalks Along Street
  • Vehicle-Pedestrian Interaction at Intersections
      • Uses Actual Crosswalk Flows from Assignment
  • Pedestrian Inundation
      • Pedestrians Encroach on Vehicle Space
      • Vehicle Capacity Decreased
      • User-defined Parameters
two way sidewalk capacity9

Capacity 1 = Capacity North Sidewalk + Capacity South Sidewalk

Capacity 2 = Capacity North Sidewalk + Capacity South Sidewalk

Two-Way Sidewalk Capacity

Iteration 1

two way sidewalk capacity10

Capacity 1 = Volume Westbound / Volume Both Dir * Two Way Capacity

Capacity 2 = Volume Eastbound / Volume Both Dir * Two Way Capacity

Two-Way Sidewalk Capacity

Until Converges

Iteration 2 onwards

pedestrian inundation
Pedestrian Inundation

Pedestrian Encroachment on Vehicle Lane(s)

  • Parameters to be User-Defined (On or Off):
      • Inundation Allowed (Global Setting)
      • Pedestrian Link Inverse Density Threshold for Inundation (Global Setting)
      • On-Street Parking Allowed (Link Setting)
      • Pedestrian Allowed On Road (Link Setting)
pedestrian inundation13
Pedestrian Inundation

Link Density < Inundation Threshold

Link Density > Inundation Threshold

Link Inverse Density > Inundation Threshold

pedestrian inundation14
Pedestrian Inundation

Link Inverse Density > Inundation Threshold

Capacity Required by Inundation

pedestrian inundation15

ped volume

Pedestrian Inundation

Link Inverse Density > Inundation Threshold

pedestrian inundation16
Pedestrian Inundation

Link Inverse Density > Inundation Threshold

Car Capacity = f (inundation capacity required)

output
Output
  • Volume by Time Interval and Mode
  • Pedestrian Density by Time Interval
  • Pedestrian Level of Service by Time Interval
  • Inundation Occurrence (Link Density > threshold and parameters allow for inundation)
  • Travel Times To/From Stadium by Mode
example scenario results volumes density los over time
Example Scenario Results: Volumes, Density, LOS Over Time

Event 1 Start: 19:00

Pre-Event 2 Start: 18:50

Event 2 Start: 21:00

18:45

example scenario results volumes density los over time19
Example Scenario Results: Volumes, Density, LOS Over Time

Event 1 End: 21:30

Event 2 End: 23:00

23:30

slide21

www.ptvamerica.com

Questions and Discussion

Thank you for your attention.
