structured cobol programming
Structured COBOL Programming

10th edition

John Wiley & Sons, Inc.

Nancy Stern

Hofstra University

Robert A. Stern

Nassau Community College

James P. Ley

University of Wisconsin-Stout

PowerPoint Winifred J. Rex

Presentation Bowling Green State University

an introduction to structured program design in cobol

An Introduction to Structured Program Design in COBOL

Please note that the original slides will be modified in a number

of places by your professor.

These changes are for pedagogical reasons.

Chapter 1

chapter objectives
Chapter Objectives

To familiarize you with

  • Why COBOL is a popular business-oriented language.
  • Programming practices and techniques
  • History of COBOL
  • Use of the current ANSI standard versions of COBOL
  • Four divisions of a COBOL program
chapter contents
Chapter Contents
  • Computer Programming: An Overview
  • Applications Program Development Process
  • Nature of COBOL
  • History of COBOL and the ANS Versions
  • Techniques for Improving Program Design
  • Sample Programs
  • Entering and Running a COBOL Program on Your Computer
computer program
Computer Program
  • A set of instructions that enables computer to process data
  • Also called software
  • Two types of computer programs
    • Operating system programs - control overall operations of computer
      • Oftentimes called System Software
    • Applications programs - perform tasks required by users
      • Often called Applications Software Us.
applications programs
Applications Programs
  • Written by applications programmer
  • May provide quick solution to one-time problem
    • Displaying average grade for set of exam scores
  • Or may be run on regularly scheduled basis
    • Program to print student transcripts each semester
    • Program to generate a Payroll
    • Program to generate and print an Inventory Listing
application programs customized
Application Programs - Customized
  • Written for specific users like doctors, car dealerships
  • Necessary if user has special requirements
applications package general usage
Applications Package – General Usage
  • Written for general user who needs program to perform standard tasks
  • Standard tasks include budgeting, scheduling payroll, etc.
  • Cheaper, easier than writing customized program
program languages
Program Languages

Machine language

  • Only language computer understands
  • All programs executed on computer must be in machine language
  • Machine language programs difficult to write
  • Written in binary, such as:
    • 0001101001010100 (actual instruction)
    • 010110101000000011000100 (actual instruction in binary)
assembler languages
Assembler Languages
  • Level ‘higher’ than Machine Language.
  • Use mnemonic codes rather than pure binary digits, such as:

L R5,X

AR R5,R4

ST R5,SUM

  • Each of these instructions translates (normally one-to-one) into a machine language statement (that is, binary…)
program languages11
Program Languages

Symbolic language (like COBOL)

  • Called Higher-Level Languages
  • English-like languages used to write programs
  • Easier than writing programs in machine language or assembly languages.
  • Must be translated or compiled into machine language to run on computer
program development process
Program Development Process
  • Determine Program Specifications – the “Whats”
  • Design Program Using Program Planning Tools – the “Hows.”
  • Code and Enter Program (using some editor)
  • Compile Program Implementation
  • Test Program
  • Document Program
1 program specifications
1. Program Specifications
  • Systems analysts, users and programmers develop specifications
  • Specifications include:
    • Description of input and output data
    • Description of what the program must do to the input to convert it to the output - that is, WHAT the program is to do.
      • They may provide formulas, constraints on data, conditions, etc. etc. BUT (again, notHow the developers accomplish this!)
    • In a perfect world, Systems Analysts specify the ‘requirements’ needed. (doesn’t always work this way.)
1 program specifications14
1. Program Specifications

Record layout forms describe format of input and output data

  • Data names of each data item in record
  • Location of each data item in record
  • Size of each data item
  • Number of decimal positions (for numeric data items)
  • Please note that exactly WHO does this may vary depending on the expertise of the systems analysts, developers, etc. But these are part of the Specifications.
1 program specifications15
1. Program Specifications

Printer spacing charts describe

  • Spacing of outputs (see pp 6-7)
    • hard copy reports
    • screen layouts, etc.
  • Layout of printed output
  • Heading, detail, total lines
  • Error messages and locations…
2 design the program
2. Design the Program

Program planning tools used to map out structure and logic of program

Once specifications are captured (discuss!), design takes place.

Two real kinds of design:

  • Architectural design (high level, parts; components, blocks of functionality; relationships among these blocks, and
  • Detail design – the logic inside each block, part, component, etc.
2 design the program17
2. Design the Program
  • Different tools may be used to capture the preliminary (architectural) design as well as the detail (logic; algorithms) design.
  • Architectural Design:
    • For many traditional systems, we may use Data Flow Diagrams; Structure Charts, System Flow Charts, and similar technologies
  • For Detail design:
    • Most practitioners use flowcharts, pseudocode, HIPO, or other techniques to capture the module logic.
slide18
Architectural design: Book suggests Hierarchy charts show relationships among sections of program.
    • We will use these and call them Structure Charts.
  • Book cites for Detail Design:
    • Flowcharts use block diagrams to represent logic – a graphical model, and
    • Pseudo-code uses English-like statements
      • This one is preferred but some hang on to the flowchart. In some cases, it ‘is’ clearer, though.
3 code and enter program
3. Code and Enter Program
  • Programmer writes and enters program into computer
  • Program written in symbolic language (like COBOL)
  • Called source program
4 compile source program
4. Compile Source Program

Compiler is program that

  • Checks source program for rule violations
  • Translates source program into object program
  • (See p. 8 for System Flow Chart. Know this.)

Source program in symbolic language

Translated by compiler

Object program in machine language

5 test program
5. Test Program
  • Test or debug program to ensure it contains no errors
  • Check for two types of errors
    • Compile-Time Errors
    • Execution Errors
compile time errors
Compile-Time Errors
  • Errors detected by compiler during translation from COBOL to machine language
  • Detects violations of programming rules
    • Misspelled reserved words
    • Missing punctuation
    • Errors in use of the programming language
  • Also called syntax errors
execution errors
Execution Errors
  • Detected when program is run
  • Logic error causes incorrect output
    • Sequence of instructions incorrect
    • Wrong instruction coded
  • Run-time error if computer cannot execute instruction
    • Attempt to divide by zero
    • Attempt to read a file that cannot be found
debugging techniques
Debugging Techniques
  • Desk checking
    • always do this. Can be costly to omit.
  • Correcting syntax errors
    • Correct syntax errors and resubmit
  • Program walkthroughs
    • Sometimes done in teams; good approach
    • Can be done prior to submitting for compilation.
  • Executing the program
    •  Just because a program runs to EOJ, does NOT mean that program was successful!!
6 document the program
6. Document the Program
  • Documentation - formal set of procedures and instructions to specify how to use program
  • Written for
    • Those working with output
    • Computer operators who run program
    • Maintenance programmers who make modifications to program
    • In some circles called: program maintenance manual, operators manual, users manual, etc…
nature of cobol
Nature of COBOL
  • Business-oriented language
    • Great for business data processing
    • Large volumes of data
    • Great for data manipulation
      • No language is better for transaction processing or data manipulation than COBOL
      • Has other major deficiencies, but not these.
  • Standard language
  • English-like language
    • Multiply hours-worked by rate giving salary
  • Relatively easy to understand
history of cobol
History of COBOL
  • Developed in 1959 as standard language to meet needs of business
  • Committee to develop language convened by Department of Defense
  • Included representatives from academia, business, computer manufacturers
standard versions of cobol
1960s

1968

1974

1985

wide variations in COBOL compilers

first COBOL standard set by American National Standards Institute (ANSI)

second ANSI standard to make COBOL more efficient, standardized

this ANSI standard incorporated structured programming techniques

Standard Versions of COBOL
current and future standards
Current and Future Standards
  •  1985 currently the most widely used
  • Sometimes called COBOL 2.
  • 2002+ is next standard
    • Approval expected in 2002
    • Information on 2002+ COBOL standard at http://www.ansi.org
future of cobol
Future of COBOL

Likely to remain important language

  • Unlike academic environment, most programs are developed to be used for many years to realize a ROI. This implies the need to maintenance as requirements change and errors are discovered.
  • Older COBOL programs need to be updated
  • Still used by many for new program development
use of cobol
Use of COBOL
  • About 200 billion lines of COBOL source code in use
  • 5 billion new lines added each year
  • Used by 42.7% of application programmers in medium to large U.S. companies
  • $200 million in expected revenues for 2001
year 2000 problem y2k
Year 2000 Problem (Y2K)
  • Year stored as two digits in older programs to save space
  • 19 assumed as valid prefix for all years
    • 95 represented year 1995
  • Invalid as prefix for years 2000 and beyond
    • 00 could mean 1900 or 2000
year 2000 problem y2k33
Year 2000 Problem (Y2K)

Many calculations with dates incorrect starting in 2000

  • To find your age if you were born in 1970

Subtract 70 from 95 (95 - 70 = 25)

  • Calculation incorrect for year 2000 and beyond

00 - 70 = -70 when age should be 30

year 2000 problem y2k34
Year 2000 Problem (Y2K)

To correct problem

  • Billions of lines of code, many written in COBOL needed to be examined
  • Code changed to use four digits for year
  • Age, other calculations now correct

1995 - 1970 = 25

2000 - 1970 = 30

improving program design
Improving Program Design

Two techniques used to develop programs that are easier to understand, test, debug and modify

  • Structured Programming
  • Top-Down Programming
structured programming
Structured Programming
  • Eliminates use of GO TO statements
    • Allowed skipping to different sections of program without returning to starting point
    • Advocated the use of simple program constructs:
      • sequence
      • selection
      • iteration plus two extensions (later)
  • Program logic easier to follow with "GO-TO-less" programming
structured programming37
Structured Programming

Program divided into paragraphs

  • Main paragraph or modulecontrols logic flow using PERFORM statements
    • Sometime called a ‘driver’ module…
  • Main module "performs" other modules when instructions in that module required
    • Control transferred to a different paragraph and, upon completion of the instructions in that paragraph, control returns to the main paragraph.
  • Each module can be written and tested independently of others
top down programming
Top-Down Programming
  • Another technique to make programs easier to understand, test, debug and modify
  • Develop program like term paper
    • Develop outline first
    • Add details for each of main steps
    • Add further refinement for more complex steps
top down programming39
Top-Down Programming

For COBOL program

  • Code main modules or routines first
  • Code intermediate modules next
  • Details deferred to minor modules and coded last
  • We will use this technique a lot later on. We may refer to this technique as ‘drivers’ and ‘stubs.’
    • This is an outstanding approach to developing larger programs…
