How Board Level Shields Reduce Device Weight & Size Without Compromising Perform

Board level shields play a crucial role in minimizing device weight and size while ensuring EMI protection. Modern designs and lightweight materials, such as metallized plastic, enable compact, high-performance solutions. Learn how these shields contribute to efficient circuit board layouts and reduce the need for bulky enclosures.

Jon84
Download Presentation

How Board Level Shields Reduce Device Weight & Size Without Compromising Perform

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. How SnapShot® Board Level Shields Minimize Size and Weight Introduction SnapShot® board-level shields from XGR Technologies offer the lightest weight EMI shielding available, enabling ultra-compact device designs without compromising performance. Weight Comparison Table Thickness (mm) Length Weight Decrease Width Height Weight Shield Type (g) (mm) (mm) (mm) SnapShot® 0.125 0.77 86% 100 40 40 3 Typical Frame & Lid 0.150 5.66 n/a When grams matter ... SnapShot Delivers Benefits of SnapShot® Board Level Shields Ultra-Lightweight Shielding Reduces the Need for Heavy Casings SnapShot® shields are up to 90% lighter than traditional frame-and-lid shields, thanks to their metalized engineered polymer construction. Eliminates the need for bulky enclosures, reducing overall weight while maintaining EMI protection. Minimal Impact on Device Size Optimized Board Space & Layout At only 0.125mm thick, SnapShot® shields add minimal height, making them ideal for compact electronics. Provides effective EMI shielding while allowing optimal use of PCB space by preventing crosstalk and interference. Material Innovation - Metalized Engineered Polyer Metalized Plastic • Conductive outer surface (Tin) •Non-conductive inner surface (PEI) + Polyetherimide + Tin Plating Attaches by “snapping” over Solder Spheres • Manual or automated with the use of installation tooling • Creates strong electromechanical connection Need the Lightest Board Level Shield? Contact can optimize your device’s weight, size, and performance. XGR Technologies today to learn how SnapShot®
