measuring water velocity and streamflow in open water and under ice

Measuring Water Velocity and Streamflow in Open-water and Under Ice

John Fulton and Steve Robinson

U.S. Geological Survey

Joe Ostrowski

Middle Atlantic River Forecast Center

National Weather Service

Dapei Wang

Water Survey of Canada

overview
Overview
  • Evolution of Methods
    • Water Velocity
    • Streamflow
  • Open-water and Ice-cover Projects
    • Radar
    • Acoustics
  • The ‘Real Story’ Behind Your Ice Record
evolution of methods
Evolution of Methods

Current-meter methods

umax

Chapra (1997)

evolution of methods1
Evolution of Methods

Darcy, in Proc. Roy. Soc., A (1909)

  • Secondary and vertical flow components develop due to side-wall effects
  • umax may occur below the water surface

Therefore, we need an “alternative” velocity distribution equation

USGS (1904)

evolution of methods2
Evolution of Methods

Information Entropy(probability-based solution for characterizing the velocity distribution)

“y-axis” contains umax

evolution of methods3
Evolution of Methods

A significant amount of information can be derived from the maximum velocity

  • uavg = f (M) umax
  • Q = uavg A
  •  (M) is a measure of a streams “happy place” and does not change with
    • flow
    • velocity
    • stage
    • channel geometry
    • bed form and material
    • slope
    • alignment
nws proof of concept study
NWS Proof-of-Concept Study

Radar guns

“Actual” Stream Flow

Rating Curve

Current-meter method

ADCPs

nws proof of concept study open water
NWS Proof-of-Concept StudyOpen-water

Steps …

  • y-axis
  • f(M)
  • umax or uD
  • area
  • Q = uavg A = ( umax ) A

Yen (1998)

nws proof of concept study open water1
NWS Proof-of-Concept StudyOpen-water

Steps …

  • y-axis
  • f(M)
  • umax or uD
  • area
  • Q = uavg A = ( umax ) A

Yen (1998)

nws proof of concept study open water2
NWS Proof-of-Concept StudyOpen-water

Steps …

  • y-axis
  • f(M)
  • umax or uD
  • area
  • Q = uavg A = ( umax ) A

Chiu and others (2001)

nws proof of concept study open water3
NWS Proof-of-Concept StudyOpen-water

Steps …

  • y-axis
  • f(M)
  • umax or uD
  • area
  • Q = uavg A = ( umax ) A

Yen (1998)

nws proof of concept study open water4
NWS Proof-of-Concept StudyOpen-water

Steps …

  • y-axis
  • f(M)
  • umax or uD
  • area
  • Q = uavg A = ( umax ) A

Yen (1998)

nws proof of concept study open water5
NWS Proof-of-Concept StudyOpen-water

Open-waterChartiers Creek at Carnegie, PaDrainage area – 257 mi2Unregulated system

usurf velocity – ADV = 2.6 fps

usurf velocity – radar= 2.5 - 2.6 fps

Discharge methods

Current-meter = 210 cfs

Rating curve = 189 cfs

Entropy regress = 193 cfs

Entropy surf vel = 201 cfs

s.d. = 9 cfs

f = 0.58

nws proof of concept study open water6
NWS Proof-of-Concept StudyOpen-water

usurf velocity – ADV = 2.4 fps

usurf velocity – radar= 2.0 - 2.3 fps

Susquehanna River at Bloomsburg, PaDrainage area – 10,560 mi2Regulated system

Discharge methods

Current-meter = 10,800 cfs

ADCP = 10,130 cfs

Rating curve = 10,550 cfs

Entropy regress = 10,330 cfs

Entropy surf vel = 9,950 cfs

s.d. = 340 cfs

f = 0.78

nws proof of concept study open water7
NWS Proof-of-Concept StudyOpen-water

Open-waterBasin DAs – 260 to 24,100 mi2Regulated and non-regulated systems

slide17

NWS Proof-of-Concept StudyIce-cover

Steps …

  • y-axis and f(M) established during open water
  • umax along y-axis
  • area
  • Q = uavg A = ( umax ) A
nws proof of concept study ice cover
NWS Proof-of-Concept StudyIce-cover
  • Red River of the North at Grand Forks, ND (1984 to 2002)
  • Open water measurements
  • Ice measurements were collected by the North Dakota District on
    • 01/20/04
    • 02/05/04
    • 03/02/04
  • f = .596 computed for open-water used to calculate stream flow under ice cover

STA 84

Qact = 463 cfs

Qobs= 476 cfs

diff = 3%

Nolan, K.M. and Jacobson, Jake, Discharge measurements under ice cover, USGS WRIR 00-4257

nws proof of concept study1
NWS Proof-of-Concept Study

Future Efforts …

  • Partnering with the
    • NWS
    • SRBC
    • HIF
    • University of Washington
    • USGS, North Dakota District
    • Water Survey of Canada
  • Wind and precipitation influences
  • Flashy conditions
  • Ice conditions
  • Real-time areas
water survey of canada
Water Survey of Canada

Project Scope

  • Equipment
    • SonTek Argonaut-SW & SL
  • Open-channel flow and flow under ice
  • Flow velocity distribution (FVD) model
water survey of canada1
Water Survey of Canada
  • Vertical velocity distribution in open water
  • universal-velocity-distribution law
  • bed roughness parameter y0b to reflect effects of channel bed roughness
  • hydraulic parameterg to reflect effects of hydraulic gradient
slide22

Water Survey of Canada

  • Vertical velocity distribution under ice cover
  • ice roughness parameter y0i
  • for effects of bottom surface
  • of ice cover
  • approximated by a two-layer
  • scheme
  • lower layer - solely affected
  • by bed roughness
  • upper layer - solely affected
  • by ice roughness
slide23

Water Survey of Canada

  • ADVM SonTek Argonaut-SW @ Chateauguay River
  • Chateauguay River, QC, Canada
  • two SW installations, 400 m apart
  • SW data: Dec. 03 – May 04

Open flows & Flow under ice cover

  • upstream site:

flow depth 2-5 m

channel width ~ 85 m

ice cover 12/11/03 to 3/25/04 21:30

  • downstream site:

flow depth 2-4 m

channel width ~ 40 m

ice cover 1/9/04 9:45 to 3/4 12:00
