Presentation Transcript
Slide1 l.jpg

State transitions in the epileptic brain

Stiliyan Kalitzin,

Epilepsy Institute of The Netherlands (SEIN)


Slide2 l.jpg

Central Didactic Question 1:

Why do epileptic seizures occur ?

This question is not about :

What are epileptic seizures ?

What causes epilepsy ? (neural loss, channel protein mutations, etc)

This question is about:

Autonomous transitions to epileptic type of activity and back


Slide3 l.jpg

  • Why is this question relevant for ISPWxx ?

  • Trial-and error “neuro-phenomenology” approach has its limits. To understand prediction, predictability and to be able to actually predict seizures we need to know how do they set on.

  • Even more so, to avoid, stop or contain the seizure onset we need to know what are we dealing with.

  • On a more “mundane” level, even the classical diagnostic challenge of finding the seizure onset site (SOS) can benefit from proper knowledge of the onset mechanism.

General Warning : all concepts that follow are (computer) model inspired.

Living brain is a system with nearly infinite number of degrees of freedom and of humongous complexity.


Slide4 l.jpg

  • Candidates:

  • Attractor deformation scenario, precipitated by

  • - plastic changes from sensory or other input

  • - fluctuating chemical (metabolic) compounds

  • B. Transitions in multi-stable (multi-attractor) systems

  • - sensory input

  • - stochastic fluctuations (thermal noise)

  • C. Intrinsic instability – intermittency

  • - no precipitating factor

Attractor: invariant, asymptotically stable manifold in the phase space of the system.

Irreducible (no sub-attractors)  connected


Slide5 l.jpg

seizure

Autonomous

normal

Fluctuations

(noise)

B. Multi-attractor scenario

Attractor1

Attractor2

Fluctuations

seizure

normal

Control

Parameter

Generic models for autonomous epileptic state transitions

A. Attractor deformation scenario

Attractor

Non-autonomous

Control

Parameter


Slide6 l.jpg

Complex non-linear models:

Autonomous seizure generation


Slide7 l.jpg

Example: complex Z^4 model with two deformation dimensions

Phase-space plot

HC slice, low Mg ictal data,

Hilbert-transform complex reconstruction

(courtesy: P. Carlen, H. Khosravaniand M. Derchansky)


Slide8 l.jpg

repulsor

attractor

Topological attractors in phase-spaces.

Analytic models and reconstructions

Fixed point

Method: relative critical point sets detecting vector-field ridges and convergence manifolds

Kalitzin, S. N., Staal J., ter Haar Romeny B., Viergever MA. (2001).

"A computational method for segmenting topological point-sets and application to image analysis."

Pattern Analysis and Machine Intelligence, IEEE Transactions on 23(5): 447-459.



Slide10 l.jpg

Bifurcation diagram

Input

distribution

Input

Normal activity - steady state

Paroxysmal activity - limit cycle

normal

and

paroxysmal

only

normal

only

paroxysmal

© SEIN, 2004

Medical Physics Department


Slide11 l.jpg

Extra bonus from modeling: Closed-loop seizure abortion as prescribed from model simulation in bi-stable system

Closed - loop seizure control

Counter - stimulus parameters

_

+

Suffczynski, P., Kalitzin S. & Lopes da Silva, F.H., Dynamics of non - convulsive epileptic phenomena modeled by a bistable neuronal network. Neuroscience 126(2) p. 467-484, 2004

Medical Physics Department


Slide12 l.jpg

Statistical validation of multi-attracor scenario prescribed from model simulation in bi-stable system

for ictal transitions in rats and humans


Slide13 l.jpg

Modeling distributions of ictal and interictal durations prescribed from model simulation in bi-stable system

Suffczynski S., Lopes da Silva FH., Parra J., Velis D., Bouwman B., Clementina M., van Rijn P., van Hese P., Boon P., Houman K., Derchansky M., Carlen P., Kalitzin S., (2006),

”Dynamics of epileptic phenomena determined from statistics of ictal transitions,” IEEE Trans Biomed Eng 53(3): 524-32.


Slide14 l.jpg

A+B combined scenario prescribed from model simulation in bi-stable system


Slide15 l.jpg

Multi-stability (multi-homeostatic system) prescribed from model simulation in bi-stable system

involving synaptic plasticity

Kalitzin, S., van Dijk BW, Spekreijse H. (2000).

"Self-organized dynamics in plastic neural networks: bistability and coherence."

Biol Cybern 83(2): 139-50.


Slide16 l.jpg

Ergodic prescribed from model simulation in bi-stable system

C. Intermittency in continuous deterministic systems

(dynamical billiards)


Slide18 l.jpg

Pre-ictal? prescribed from model simulation in bi-stable system

Alternative: Discrete intermittent systems

Elan L. Ohayon, Hon C. Kwan, W. McIntyre Burnham, Piotr Suffczynski, Stiliyan Kalitzin, Emergent Complex Patterns in Autonomous Distributed Systems: Mechanisms for Attention Recovery and Relation to Models of Clinical Epilepsy, IEEE SMC’2004 Conference Proceedings, October 10-13 2004 The Hague, p. 2066-2072


Slide19 l.jpg

The “EPI-TABLE” prescribed from model simulation in bi-stable system


Slide20 l.jpg

Central Didactic Question 2: prescribed from model simulation in bi-stable system

When do we know that we know more than nothing ?

This question is about:

Defining (weak) predictability

“Existence of a set of retrospective measurements such that a statistically significant association between the outcomes of these measurements and the time to the first seizure following these measurements can be demonstrated”.


Slide21 l.jpg

Statistical significance: prescribed from model simulation in bi-stable system

N surrogates obtained as random permutations of predictor’s values for the same times of measurement

Kalitzin, S. N., J. Parra, et al. (2007). "Quantification of unidirectional nonlinear associations between multidimensional signals." IEEE Trans Biomed Eng54(3): 454-61.

  • Predictability  association measure

  • Non-linear h2 association index – favors single mode distributions

  • Mutual information – weaker measure

seizure

Time to seizure


Slide22 l.jpg

Example of stochastic parameter random walk: prescribed from model simulation in bi-stable system

Weak but statistically significant predictability based on measuring the control parameter


Slide23 l.jpg

  • Few clouds on the prediction horizon prescribed from model simulation in bi-stable system

  • Brain is predominantly an open system, concepts such as “spontaneous activity” or “spontaneous seizures” are agnostic categories.

  • Brain is unlikely to be in a “thermal equilibrium” state. Noise fluctuations do not spread evenly over all degrees of freedom and therefore one cannot observe everything at all times.

  • Brain is seldom a stationary system, we need ample statistics in short times.

Our approach: active, stimulation based observation


Slide24 l.jpg

Stimulus sequence prescribed from model simulation in bi-stable system

Photosensitive epilepsy (PSE) is the most common form of human reflex epilepsy which offers a highly reproducible model to investigate whether the transition to an epileptic response may be detected

Objective: To quantify the dynamical state of the brain during stimulation prior to eventual photo paroxysmal response.

J. Parra, S. Kalitzin, , J Iriarte, W. Blanes, D. Velis, F. Lopes da Silva, Gamma band phase clustering and photosensitivity. Is there an underlying mechanism common to photosensitive epilepsy and visual perception? Brain 126, p. 1164-1172, 2003

10Hz photic stimulator

(20Hz, 15Hz, ..)

MEG/EEG

recording

Triggered response

Patient/Subject

rPCI

Question: can we predict an eventual discharge from features of the triggered response ?


Slide25 l.jpg

Observation: enhanced fast activity in the VEP prescribed from model simulation in bi-stable system


Slide26 l.jpg

Analysis: PCI prescribed from model simulation in bi-stable system


Slide27 l.jpg

No seizure prescribed from model simulation in bi-stable system

Seizure


Slide28 l.jpg

MEG study prescribed from model simulation in bi-stable system

rPCI statistics per subject


Slide29 l.jpg

rPCI in TLE seizure prediction prescribed from model simulation in bi-stable system


Slide30 l.jpg

Averaged rPCI performance for 3 patients, 5 contacts prescribed from model simulation in bi-stable system


Slide31 l.jpg

Localization of the Seizure Onset Sites (SOS). prescribed from model simulation in bi-stable system

Interictal (>24hrs before the leader seizure) rPCI (collective data from 6 patients, 18 contacts)


Slide32 l.jpg

Active paradigms of seizure anticipation: Computer model evidence for necessity of stimulation

Piotr Suffczynski, Stiliyan Kalitzin , Fernando Lopes da Silva, Jaime Parra, Demetrios Velis, Fabrice Wendling

Phisical Review E 78(5), 051917(9)

Computer modeling: powerful reconstructive tool

( deformation of bi-stable dynamics realistic model of TLE)

Almost any parameter change that affects the seizure thresholdwill have some measurable appearance. The question is: how universally this appearance is related to the seizure threshold?


Slide33 l.jpg

Seizure threshold and observables co-registration evidence for necessity of stimulation


Slide34 l.jpg

Different paths to seizure: different “risk estimators” evidence for necessity of stimulation

S0 (energy of the background signal)

Seizure threshold

Driving

rPCI


Slide35 l.jpg

Closed-loop stimulation: direct neuronal control (neuro-feedback)

Autonomous seizure generation  Automated seizure denial




Slide40 l.jpg

Reactive pulse control (neuro-feedback)

Phase-space “surgery”


Slide41 l.jpg

Peter Carlen (neuro-feedback)

Fernando Lopes da Silva

Piotr Suffczynski

Fabrice Wendling

Thank You !

Demetrios Velis

Elan Ohayon

Wouter Blanes

Frank van Engelen

Erik Kuitert

Jaime Parra

Stiliyan Kalitzin


Slide42 l.jpg

seizure (neuro-feedback)

normal

Attractor1

Attractor2

seizure

normal

“Aggregate” A+B+C scenario

deformation

Control

Parameter


Slide43 l.jpg

Stimulation scenarios: (neuro-feedback)

  • Provocative (reflex epilepsies)

  • “Non-provocative” (no adverse clinical reactions)

  • Curative – to subdue adverse clinical condition


Slide44 l.jpg

Stimulus sequence (neuro-feedback)

Provocative Photo Stimulation (Visual Sensitivity)

Photosensitive epilepsy (PSE) is the most common form of human reflex epilepsy which offers a highly reproducible model to investigate whether the transition to an epileptic response may be detected

Objective: To quantify the dynamical state of the brain during stimulation prior to eventual photo paroxysmal response.

J. Parra, S. Kalitzin, , J Iriarte, W. Blanes, D. Velis, F. Lopes da Silva, Gamma band phase clustering and photosensitivity. Is there an underlying mechanism common to photosensitive epilepsy and visual perception? Brain 126, p. 1164-1172, 2003

10Hz photic stimulator

(20Hz, 15Hz, ..)

MEG/EEG

recording

Triggered response

Patient/Subject

rPCI

Question: can we predict an eventual discharge from features of the triggered response ?



Slide46 l.jpg

Analysis: PCI (neuro-feedback)


Slide47 l.jpg

No rPCI (neuro-feedback)

Control

Quantification: Relative Phase Clustering Index (rPCI)

PCI

rPCI

Frequency


Slide48 l.jpg

rPCI per group of subjects (neuro-feedback)

MEG study


Slide49 l.jpg

86 PPR , 386 control samples (neuro-feedback)

AUC=91%

Mean rPCI values > 0.106, were > 85% sensitive and 80% specific.

MEG study



Slide51 l.jpg

Direct intracranial electrical stimulation (neuro-feedback) (allegedly) non-provocative

PTL


Slide52 l.jpg

Active observation: stimulation with “carrier frequency”

Phase clustering index (PCI)

Complex amplitudes

Repetitive stimulus

S. Kalitzin, J. Parra, D. Velis, F. Lopes da Silva, Enhancement of phase clustering in the EEG/MEG gamma frequency band anticipates transition to paroxysmal epileptiform

activity in epileptic patients with known visual sensitivity, IEEE-TBME, v.49, 11 p 1279-1286, 2002


Slide53 l.jpg

Extended definition based on q-norm, q>1

Higher q penalizes amplitude fluctuations;

q=2 is the magnitude squared coherence

(MSC) Dobie and Wilson (1994).

Extended definition based on response amplitude entropy

Penalizes singular

amplitude distributions

Simple example: perfect phase alignment


Slide54 l.jpg

Statistical significance of PCI

Random phase generation

Critical value of PCI (amplitude dependent !)

Corresponding to a significance level p
