    In current document,

    With non-adaptive precoding, the precoder W is predefined and selected from the base codebook or its subset. The changes of the precoder W are [TBD].

    There are two candidates: N1 or N2

    In 16m, there are three types of permutation

    DRU: diversity mode (MFM 0)

    PRU based CRU: diversity mode (MFM 1)

    Subband based CRU: diversity mode (MFM 3)

    In this contribution, we show which precoder cycling duration is proper for all of these permutation

    All of simulation conditions can be found in C80216m-09/0385

    Overview


    Diversity mode dru mfm 0 sfbc with precoder mm 0 l.jpg
    Diversity mode, DRU (MFM 0)SFBC with precoder (MM 0)


    Diversity mode pru based cru mfm 1 sfbc with precoder mm 0 l.jpg
    Diversity mode, PRU based CRU (MFM 1)SFBC with precoder (MM 0)


    Diversity mode dru mfm 0 sm with precoder mm 1 l.jpg
    Diversity mode, DRU (MFM 0)SM with precoder (MM 1)



    Link adaptation mode subband based cru mfm 3 rank 1 precoder and sm with precoder ra mm 1 l.jpg
    Link adaptation mode, Subband based CRU (MFM 3)rank-1 precoder and SM with precoder (RA) (MM 1)


    Discussion 1 2 l.jpg
    Discussion 1/2

    • Problem of logical index cycling

      • In DRU, pilots will be shared by different LRUs

        • The pilot can’t be precoded with logical index cycling  pilot overhead reduction gain is disappeared

        • If we use same precoder for PRU, logical index precoding will be end up very small number of precoder cycling  reduce diversity gain

    • Problem of N2 cycling

      • Miniband will be used for link adaptation mode (MFM 3) as well as diversity mode (MFM 1)

        • In link adaptation mode (MFM 3), subband CQI will be used for scheduling miniband  N2 cycling has CQI mismatch due to different precoders are allocated to different miniband within a subband

    • Problem of time domain cycling

      • In link adaptation mode (MFM 3), different precoder for different subframe will reduce performance as same reason as N2 cycling

      • MS will be allocated to one subframe or two subframe  CQI mismatch or Feedback overhead increase


    Discussion 2 2 l.jpg
    Discussion 2/2

    • In diversity mode, the performance of N1 cycling and N2 cycling is almost same

    • In link adaptation mode, N1 cycling outperforms N2 cycling

    • In subband CRU, multiple PRU (N1) channel estimation can be done with N1 granularity

    • Remedy: Propose to select N1 cycling (Modify texts in C802.16m-09/0513 – proposed text of MIMO for the IEEE 802.16m amendment)

      • (In recommended text proposal #5)

        With non-adaptive precoding, the precoder W is predefined and selected from the base codebook or its subset. The changes of the precoder W are [TBD], and it changes every N1 contiguous PRUs.

      • (In recommended text proposal #6)

        With non-adaptive precoding, the precoder W is predefined and selected from the base codebook or its subset. The changes of the precoder W is [TBD], and it changes every N1 contiguous PRUs.
