Presentation Transcript
security of number theoretic public key cryptosystems against random attack

Security of Number Theoretic Public Key Cryptosystems against Random Attack

Paper by: Rob Blakley and G.R. Blakley

Presentation by: Jason Bourg

historical aspect
Historical Aspect
  • Paper written in 1978
  • Then
    • 0 < log(p) < 19,937
    • 4.3 x 106001
  • Now
    • 0 < log(p) < 13,466,917
    • 2144000 = 2.0 x 1043348
overview
Overview
  • Introduction
  • The RSA number theoretic method
  • The background in modular arithmetic
  • Coding moduli which are products of distinct safe primes
  • Complementarity properties of safe primes
overview4
Overview
  • The directorate and the message receiver in an RSA public key cryptosystem
  • The cryptanalyst and the sender in an RSA public key cryptosystem
  • Summary
1 introduction
1. Introduction

Public Key Cryptosystems

  • Concentrate on RSA
  • Goal of receiver:
    • Produce lists (c, d, m) of three positive integers where xcd = x mod(m) holds for every integer x
square free m please
Square Free m Please
  • c and d > 1 exist if and only if m is square free
  • What is square free?
    • A positive integer m is square free if and only if it is the product of distinct primes belonging to some finite set T of primes.
2 the rsa number theoretic method
2. The RSA number theoretic method
  • Same stuff we talked about in class
3 the background in modular arithmetic
3. The background in modular arithmetic
  • Let Y be a finite set of pairwise relatively prime positive integers. Let m be the product of the members of Y. Then cyc[x,m] = LCM {cyc[x,y] | y € Y}
    • 9 lemma’s
    • 6 theorem’s
    • 3 corollary’s
4 coding moduli which are products of distinct safe primes
4. Coding moduli which are products of distinct safe primes
  • p – 1 and q – 1 should have large prime factors
  • Safe primes
    • p is safe if there is an odd prime a such that 2a + 1 = p
  • More bad math
    • 2 lemma’s
    • 5 theorem’s
    • 2 corollary’s
5 complementarity properties of safe primes
5. Complementarity properties of safe primes
  • Suppose p and q are safe primes whose product is m
  • Find one nontrivial pair x, e such that

xe = x mod(m) can factor m

  • If x is small then e must be large, and conversely
6 the directorate and the message receiver in an rsa public cryptosystem
6. The directorate and the message receiver in an RSA public cryptosystem
  • If the directorate chooses a width w > 2
  • It allows every message receiver N to pick primes p(N) and q(N) at random such that

q < log(p(N)) < g + 1 < g + w / 2 < g + w < log(q(N)) < g + 3w / 2

6 cont
6. cont.
  • This guarantees that

2g < 2g + w < log(p(N)q(N)) < 2g + 2w

and

2p(N) < q(N)

  • Whence random search for factors of m = p(N)q(N) new sqrt(m) becomes expensive if g gets large
6 cont13
6. cont.
  • Assuming w > 2 the directorate will
  • Choose at random an odd positive integer a such that g – 1 < log(a) < g + w / 2 – 1
  • Form
    • GCD (r ,a) and GCD (r, 2a+1) for every prime r <= u.
    • GCD (a, (u-1)/2)

If either of these numbers is unequal to 1, forget a and return to step 1

6 cont14
6. cont.
  • Test whether a and 2a+1 are both prime to all intents and purposes. If either is demonstrably composite, forget a and return to step 1.
  • Choose at random an off positive integer b such that:

g + w – 1 < log(b) < g + 3w / 2 - 1

6 cont15
6. cont.
  • Form
    • GCD{r,b} and GCD{r,2b+1} for every prime r <= u.
    • GCD{b, (u-1) / 2}

If any of these numbers is unequal to 1, forget b and return to step 4.

  • Test whether b and 2b+1 are both prime to all intents and purposes. If either is demonstrably composite, forget b and return to step 4.
6 cont16
6. cont.
  • Form
    • GCD{a,b}
    • GCD{a, 2b+1}
    • GCD{2a+1,b}
    • GCD{2a+1, 2b+1}

If any of these numbers is unequal to 1, forget a and b and return to step 1.

6 cont17
6. cont.
  • Solve the six pairs of simultaneous linear congruences
    • A  0 mod(2a + 1) and A  1 mod(2b + 1)
    • B  1 mod(2a + 1) and B  0 mod(2b + 1)
    • C  0 mod(2a + 1) and C  -1 mod(2b + 1)
    • D  -1 mod(2a + 1) and D  0 mod(2b + 1)
    • E  1 mod(2a + 1) and E  -1 mod(2b + 1)
    • F  -1 mod(2a + 1) and F  1 mod(2b + 1)
6 cont18
6. cont.
  • cont.
    • Examine the Hollerith character typescripts which correspond to A, B, C, D, E, and F.
    • If all six of these typescripts are hopeless gibberish, go on to step 9. Otherwise forget a and b and go back to step 1.
6 cont19
6. cont.
  • Let
    • p(N) = 2a + 1
    • q(N) = 2b + 1
    • m(N) = p(N)q(N) = (2a + 1)(2b + 1)
    • a(p(N)) = a
    • a(q(N)) = b
    • v = 2ab
6 cont20
6. cont.
  • Comments on Step 9
    • The receiver N now knows that m(N) is square free if both p(N) and q(N) are square free.
    • The receiver believes that the integers a(p(N)), a(q(N)), p(N), q(N) are all primes.
      • This belief need not be correct.
6 cont21
6. cont.
  • Solve the linear congruence ud  1 mod(v) for d.
    • Call its smallest positive integer solution d(N)
  • Send the list (N, m(N)) to the directorate for inclusion as a listing in the directory.
  • Keep p(N), q(N), and d(N) secret.
7 the cryptanalyst and the sender in an rsa public key cryptosystem
7. The cryptanalyst and the sender in an RSA public key cryptosystem.
  • Eve needs to factor m….hard.
  • Same as in class, nice and secure.
8 summary
8. Summary
  • RSA is strong because it is hard to factor m.
    • Essential you pick your numbers correctly.
  • These guys must have known what they were talking about since RSA is still strong today.

Questions?
