slide1

Advanced Weather Interactive Processing System (AWIPS) Overview for System-of-SystemsWorkshopOctober 7, 2009

Ronla Henry & Steve Schotz

NWS – Office of Science and Technology

agenda
AGENDA
  • AWIPS Overview
    • Mission and Functions
    • Brief History
  • AWIPS II Technology Infusion Scope and Milestones
  • AWIPS II Architecture Overview
    • Major Software Components
    • Communications Interfaces
    • Standards and Formats
  • AWIPS II Extended Data Delivery Project Overview
awips overview functions mission awips is the critical link to the nws forecaster

NEXRAD

GOES/POES

Warnings

NCEPModels

Watches

Advisories

ASOS

Forecasts

Buoys,

River Gauges

AWIPS Overview - Functions/MissionAWIPS is the Critical Link to the NWS Forecaster

169 separate AWIPS systems at

137 geographical locations

AWIPS

Communications

AWIPS Workstations and

Servers

Service provided to

3066 US Counties

24 hrs/day,

365 days/yr.

~900 Workstations (total)

~1200 Servers (total)

awips a brief history
AWIPS ABrief History
  • The original prime contract for system development was awarded to PRC, Inc on December 29, 1992
    • To replace Automation of Field Operations and Services (AFOS)
    • PRC, Inc later acquired by Northrop Grumman IT (NGIT)
    • Commissioned - 2000
  • Operations phase of original contract expired on September 30, 2005
  • Re-compete contract awarded to Raytheon Technical Services (RTS) on August 17, 2005
    • Proposal included a high level plan to re-engineer AWIPS software into a Service Oriented Architecture (SOA), AWIPS II
awips ii technology infusion scope
AWIPS II Technology Infusion Scope

AWIPS II Technology Infusion (FY2005 – FY2015)

    • A long-term project which delivers a modern, robust software infrastructure that provides the foundation for future system level enhancements for the entire NWS enterprise
  • Phase 1: (FY2006-FY2011)
    • Migration of WFO/RFC AWIPS (AWIPS I) to a modern Service Oriented Architecture (SOA) infrastructure executed incrementally through a series of task orders
  • Phase II: (FY2009-FY2012) – AWIPS SOA Extension
    • Creation of a seamless weather enterprise spanning NWS operations
      • Migration of NAWIPS into the AWIPS ISOA
      • Delivery of thin client to support for the Weather Service Offices, Center Weather Support Units, Incident Meteorologists, (e.g., Fire Weather, backup support for RFCs and National Centers)
      • Integration of Weather Event Simulator)
      • CHPS Integration into AWIPS SOA
  • Phase III: (FY2009 – FY2015) – Enterprise Level Enhancements
      • Data delivery enhancements: “Smart push-smart pull”data access
      • Integrated visual collaboration
      • Information generation enhancements
      • Visualization enhancements
awips i to awips ii re architecture approach
AWIPS I to AWIPS IIRe-Architecture Approach
  • Perform “black-box” conversion
    • Preserve existing functionality, look and feel on top of new infrastructure
  • Thorough field validation and acceptance before deployment
  • No loss of functionality
    • Deployed system current with deployed AWIPS capability (i.e., OB9)
  • Use open source projects - No proprietary code
    • JAVA and open source projects enable AWIPS II to be platform and OS independent
  • Objective is to make AWIPS II available for collaborative development
awips ii reference architecture based on plug in extensible services
AWIPS-II: Reference ArchitectureBased on Plug In Extensible services

AWIPS-II Reference Architecture

Enterprise Service Bus (ESB) - Camel

<<Visualization Framework >>

CAVE

<<Service Framework >>

EDEX

Core Generic Services

Meta

Data

Data

Core Libraries

slide11

AMC4 Americom Commercial

Satellite

SBP

CSU/

DSU

GINI

CISCO

2514

DEMOD

SBP

CSU/

DSU

CISCO

2514

Application

Server

Data

Server

CISCO

4500

Data

Server

Application

Server

Work

Station

SBIG

CPID

CPIC

AS1A

DS1A

WK1B

WFO or RFC

CISCO

7000

DSIA

AWIPS Network

Control Facility

AWIPS Communications

Interfaces

Source of AWIPS Satellite Imagery

NOAAPort

Receive

System

DEMOD

SP1D

NESDIS

Non-Gov

Data Users

Comb

HPA

Mod

AWIPS Master Ground Station

Server

Source of AWIPS Model Data

Site AWIPS

System

AWIPS

WIDE AREA

NETWORK

(NOAANET)

SB1A

NCEP

NWSTG

NEXRAD

ASOS

CRS

RRS

LDAD

Other Gov, WMO, Academic, and

Private Industry Interfaces

awips ii primary standards formats
AWIPS II Primary Standards & Formats
  • Ingested Data Formats
    • GRIB1/GRIB2 – Gridded data
    • NetCDF3 – Support AWIPSI/II interoperability
    • BUFR – Observational Data, e.g., soundings
    • METAR, SHEF – Surface and hydrological data
    • GINI – Satellite Imagery
    • OPRG L3 – Radar Imagery
    • Text Messages – Text products
  • Data Store Formats
    • PostGres – Metadata and select data type store, e.g., text
    • HDF5 – Binary store for grids, imagery and select observations
  • Product Distribution
    • NetCDF3 – NDFD Grids
    • ASCII Text – Text products
awips ii extended data delivery overview
AWIPS II Extended Data Delivery Overview
  • Objective – Develop robust data delivery system within AWIPS II infrastructure that enables efficient access to high volume datasets
    • Address significant growth in data volumes, e.g., ensembles, GOES-R, NPOESS and mitigate impacts on SBN
  • High-Level requirements in common with NextGen
    • Data registry and discovery services
    • “Smart” push/pull technology
      • Sub-setting by user selectable space, time, and parameter
      • Complex retrievals, e.g., derived parameters, coordinate transformations, etc
    • Ad hoc and subscription services
    • Operationally robust – supports availability, latency and security requirements for operational users
  • Multi-Phase Implementation
    • IOC Focus – NWS data providers, e.g., NOMADS, MADIS, possibly with basic services only, discovery, sub-setting – Target FY12
