AODD pump and its industry application

Air-Operated Double-Diaphragm (AODD) pumps use compressed air as a power source to move fluids. A particular amount of pressure (measured in pounds per square inch) and air volume (measured in cubic feet per minute) are needed to operate an AODD pump. AODD pumps are capable of performing in most applications under the most challenging conditions. When in operation, there is air pressure on the entire surface of the diaphragm, which removes mechanical stress from the operation, keeping it in a balanced condition.

Idex2
Download Presentation

AODD pump and its industry application

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. AODD pump and its industry application

  2. Air-Operated Double-Diaphragm (AODD) pumps use compressed air as a power source to move fluids. A particular amount of pressure (measured in pounds per square inch) and air volume (measured in cubic feet per minute) are needed to operate an AODD pump. AODD pumps are capable of performing in most applications under the most challenging conditions. When in operation, there is air pressure on the entire surface of the diaphragm, which removes mechanical stress from the operation, keeping it in a balanced condition. As a result, the diaphragms in an AODD pump last longer as compared to mechanically operated pumps. The simplicity of the design of AODD pumps allows operators to find the correct pressures and flows for an optimised operation. Since AODD pumps are operated without electricity, there are no chances of sparks or electric shocks during operation. This makes AODD a safer pump alternative.

  3. Where is the AODD pump used? AODD pumps are used in various industries. They are very popular in the wastewater and sewage treatment industries. Because of their self-priming capabilities, AODD pumps are also a natural choice in industries where one needs to lift fluids from a lower level. At the same time, AODD pumps are also used in sectors where fluids are to be pumped over long distances.

  4. Advantages of AODD Pumps Long life: Since AODD pumps run on air pressure, there are only a few wet parts. The dry operation allows the pump to run for a long time without any significant wear and tear. Self-priming: Since AODD pumps are capable of evacuating air from the suction line and starting pumping without the need for any manual priming, they are considered reliable, especially when the operator has to work with a suction line that may contain gases or air. Can handle various kinds of fluids: AODD pumps can work with fluids of different densities and viscosities, such as solid-laden fluids, abrasive liquids, and corrosive chemicals.

  5. Adjustable flow rates: As mentioned above, AODD pumps allow users to adjust flow rates (between 19 and 1,100 litres per minute) and pressure by regulating the air pressure supplied to the pump. This feature comes in handy for industries that require operators to constantly change pressure and flow owing to, say, changes in the texture and density of fluids. Easy installation: Because of the simple design of two diaphragms that perform under compressed air and a minimum number of moving parts, AODD pumps are compact and easily portable. These pumps do not require a fixed power source, which adds to their flexibility. Safety: AODD pumps are designed to offer easy leak detection and containment. And if the diaphragm ruptures, the fluid is contained within the pump chamber, eliminating any risk of spilling.

  6. Versatility: AODD pumps can be customized based on the requirements of various operators. From clean water to harsh chemicals and sewage, they can be used with various kinds of fluids. It is to be noted here that the pump material is very important when it comes to operating different kinds of fluids. For example, while handling water, a metallic pump may react to strong acids, so a plastic pump would be a better idea.

  7. Industries that use AODD pumps include automotive, ceramics, chemicals, construction, marine, mining, oil and gas, paints and coatings, pulp and paper, and water treatment. However, choosing the right AODD manufacturers in a market full of suppliers can be really challenging for operators across industries. While making the decision, it's important to consider the reliability, lead time, maintenance package, after-sales service, and on-time delivery records of the suppliers.

  8. With a legacy dating back to 1965, Sandpiper has made a name for itself as a renowned supplier of superior, high-quality, robust, reliable air-operated double diaphragm pumps. As the top producer of submersible pumps in Ahmedabad, Sandpiper is committed to offering its customers not just the best fit based on their requirements but also top-notch after-sales service.

  9. Operating under the IDEX India wing, Sandpiper takes pride in offering multiple solutions from its comprehensive portfolio of value-driven products. Sandpiper AODD pumps are durable, self-operated, self-primed, and abrasion-resistant. They offer excellent solid holding capability, and they come with a non-stalling air valve guarantee. AODD pumps can be easily moved around as they are light in weight. At the same time, they are capable of handling very high pressure.

  10. AODD pumps are an alternative to centrifugal pumps and are used in a variety of industries. Here are some benefits of Sandpiper AODD pumps: • They can be submerged completely while maintaining safety protocols. • They do not require electricity and can be fully grounded. • They can be deadheaded safely without any pump or product damage. • They offer flow and pressure control without any complex or sophisticated parts or mechanisms.

  11. IDEX INDIA PVT LTD4th Floor, S 14Solitaire Corporate Park,Guru Hargovindji Rd,Chakala, Andheri (East),City : Mumbai 400 093,IndiaTel: 022-6643-5555 https://www.facebook.com/idexind/ https://www.linkedin.com/company/idex_india/ https://www.youtube.com/channel/UCKml3OtxrSl6GUxucDaWIOg
