  1. The Lesser-Known Highlights of Solar Charge Controller Go Power! www.gpelectric.com

  2. Solar Charge Controllers What are Solar Charge Controllers? Types of solar charge controllers Highlights of PWM charge controller What to Know Highlights of the MPPT charge controller

  3. What are Solar Charge Controllers? A Solar system allows customers to use solar off-grid, either full time or as a backup during the power outages. The solar charge controller manages the amount of energy being sent into the battery backup so that the energy doesn’t exceed its voltage capacity. As a result, it will extend the battery's life and avoid any further damage to it.

  4. Types of solar charge controllers PWM charge controller MPPT charge controller

  5. It is recommended for use in a smaller system where MPPT benefits are minimal. 1 Highlights of PWM charge controller It must use off-grid PV modules typically with VMP=17 to 18 volts for every 12v nominal battery voltage. 2 It operates at battery voltage to perform well in warm temperatures and even when the battery is almost full. 3

  6. The PV array voltage is higher than the battery voltage. 1 Highlights of the MPPT charge controller It operates above the battery voltage to provide you with a boost in cold temperature when the battery is low 2 It enables lower cost/grid-tie PV modules to decrease system cost. 3 overall PV

  7. To get more information regarding the solar charge controller, reach out to Go Power! today. Phone Number 1.866.247.6527 Email Address info@gpelectric.com Website www.gpelectric.com
