concurrency analysis platform and tools for finding c o ncurrency bugs

TL58

Concurrency Analysis Platform And Tools For Finding Concurrency Bugs

 Thomas Ball

Principal Researcher

Microsoft Corporation

 Madan Musuvathi

Researcher

Microsoft Corporation

 Shaz Qadeer

Senior Researcher

Microsoft Corporation

 Sebastian Burckhardt

Researcher

Microsoft Corporation

concurrency is hard
Concurrency Is HARD !
  • Rare thread interleavings can result in bugs
  • These bugs are hard to find, reproduce, and debug
    • Heisenbugs: Observing the bug can “fix” it !
  • A huge productivity problem
    • Developers and testers can spend weeks chasing a single Heisenbug
main takeaways
Main Takeaways
  • You can find and reproduce Heisenbugs
    • new automatic tool called CHESS
    • for Win32 and .NET
  • CHESS used extensively inside Microsoft
    • Parallel Computing Platform (PCP)
    • Singularity
    • Dryad/Cosmos
  • Releasing via DevLabs
why is concurrency hard
demo

Why Is Concurrency Hard?

 Madan Musuvathi

Researcher

Microsoft Corporation

concurrency analysis platform cap
Concurrency Analysis Platform (CAP)
  • Goal: Drive a program along an interleaving of choice
    • Interleaving decided by user or by a program/tool
  • Today: Controlling/observing concurrency is difficult
    • Manual and intrusive process
  • Enables lots of concurrency tools:
    • Test a program along a set of interleavings
    • Reproduce Heisenbugs
    • Program understanding / debugging
    • ...
taming concurrency
demo

Taming Concurrency

 Madan Musuvathi

Researcher

Microsoft Corporation

cap architecture
CAP Architecture

Coverage

Unmanaged

Program

Repro

Monitors

Memory

Model

bugs

Visualization

Debugging

Testing

Data

races

Windows

CAP

Managed

Program

  • Record the interleaving executed
  • Drive the program along an interleaving

.NET CLR

cap specifics
CAP Specifics
  • Ability to explore all interleavings
    • Need to understand complex concurrency APIs (Win32 and System.Threading)
    • Threads, threadpools, locks, semaphores, async I/O, APCs, timers, …
  • Does not introduce false behaviors
    • Any interleaving produced by CAP is possible on the real scheduler
overview
Overview
  • Concurrency Analysis Platform (CAP)
  • CHESS : find/reproduce Heisenbugs
    • Integration with Visual Studio
    • Demo on CCR Heisenbug
  • Future CAP tools
    • FeatherLite: Data-race detection
    • Sober: Memory-model bugs
chess find and reproduce heisenbugs
CHESS: Find And Reproduce Heisenbugs

Program

While(not done) {

TestScenario()

}

CHESS runs the scenario in a loop

CHESS

TestScenario() {

}

  • Every run takes a different interleaving
  • Every run is repeatable
  • Uses the CAP scheduler
  • To control and direct interleavings

CAP

Win32/.NET

  • Detect
  • Assertion violations
  • Deadlocks
  • Dataraces
  • Livelocks

Kernel:

Threads, Scheduler,

Synchronization Objects

chess challenge programs have lots of interleavings

Number of executions: nnk

Exponential in both n and k

For n=2, k = 100

> # of atoms in the universe

Limits scalability to large programs

CHESS challenge Programs have LOTS of interleavings

Thread 1

Thread n

x = 1;

x = k;

x = 1;

x= k;

k steps

each

n threads

Goal: Scale CHESS to large programs (large k)

preemption bounding
Preemption Bounding
  • Focus on executions with small number of preemptions
  • Unexpected preemptions cause bugs

Thread 1

Thread 2

x = 1;

if (p != 0) {

x = p->f;

}

x = 1;

if (p != 0) {

p = 0;

preemption

x = p->f;

}

non-preemption

managing astronomical number of interleavings

Number of interleavings: nnk

Interleavings with c preemptions

(n2k)c. nn

For n=2, k=100, c=2

< 1 million interleavings

Analysis techniques reduce this further

Managing Astronomical Number Of Interleavings

Thread 1

Thread n

x = 1;

x = k;

x = 1;

x= k;

k steps

each

n threads

chess in vsts
demo

CHESS In VSTS

 Thomas Ball

Principal Researcher

Microsoft Corporation

chess internal customers
CHESS Internal Customers
  • Parallel Computing Platform
    • PLINQ: Parallel LINQ
    • CDS: Concurrent Data Structures
    • STM: Software Transactional Memory
    • TPL: Task Parallel Library
    • ConcRT: Concurrency RunTime
    • CCR: Concurrency Coordination Runtime
  • Dryad/Cosmos
  • Singularity (Research OS from MSR)
    • CHESS can systematically test the boot and shutdown process
overview1
Overview
  • Concurrency Analysis Platform (CAP)
  • CHESS: Find/reproduce Heisenbugs
    • Integration with Visual Studio
    • Demo on CCR Heisenbug
  • Future CAP tools
    • FeatherLite: Data-race detection
    • Sober: Memory-model bugs
featherlite lightweight data race detection
FeatherLiteLightweight data-race detection
  • Data-races: Access to data with insufficient synchronization
  • Data-races are a common source of concurrency errors

Thread 1

Thread 2

EnterCS(cs)

if (p != 0) {

x = p->f;

}

LeaveCS(cs)

p = 0;

sampling to reduce overhead
Sampling To Reduce Overhead
  • Existing data-race detection tools have a large runtime overhead
    • More than 10X slowdown
    • Process every memory access
  • Intelligent sampling algorithms
    • Process < 5% of the memory accesses
  • Less than 30% runtime overhead
    • Existing tools > 1000% overhead
featherlite cap active data race detection
FeatherLite + CAP"Active" data-race detection
  • Programs have “benign” data-races
    • Do not result in program crashes
    • Example: Updating statistical counters without holding a lock
  • FeatherLite drives the program along the two outcomes of the data-race
sober tool for finding memory model errors
SoberTool for finding memory-model errors
  • Expert programmers use “lock-free” techniques
    • Use low-level synchronizations, volatile variables, …
    • For performance
  • Such programs are exposed to memory-model issues
    • Compiler can reorder instructions
    • Hardware can reorder/delay memory accesses
  • Result: Hard-to-find bugs that are hard-to-understand
sober quiz
Sober Quiz
  • Can both threads DoWork() at the same time?

// initial state

volatile bool flag1 = false;

volatile bool flag2 = false;

Thread 1

Thread 2

flag1 = true;

if( !flag2 )

DoWork();

flag2 = true;

if( !flag1 )

DoWork();

conclusion
Conclusion
  • Concurrency Analysis Platform (CAP) for controlling thread interleavings
    • Enables lots of concurrency tools
  • CHESS – Find and reproduce Heisenbugs
    • Don’t stress, use CHESS
    • Look for download on http://msdn.microsoft.com/devlabs/
  • Future CAP tools
    • FeatherLite: Lightweight data-race detection
    • Sober: Tool for finding memory-model bugs
evals recordings
Evals & Recordings

Please fill out your evaluation for this session at:

This session will be available as a recording at:

www.microsoftpdc.com

slide29
