1. www.dusuniot.com DSOM-040R Rockchip RK3588 System on Module DSOM-040R RK3588 SoM features a 64-bit octa-core Cortex A76/A55, it intergrates a 6TOPS NPU. It supports powerful hardware decoding capabilities，ensuring stable and reliable product support that scales effectively across diverse AI application scenarios. ? CPU: Rochchip RK3588 Quad-Core A76 +Quad-Core A55 Main Frequency 2.4GHz? ? RAM: 4GB/ 8GB/ 16GB 64bit LPDDR4/ LPDDR4x? ? OS: Debian11, Android 12.0, Ubuntu (Desktop / Server), Buildroot, RTLinux kernel, Android 12.0 Specification Get A Quote Product Details Hardware Overview Application High-Performance RK3588 System on Module for AIoT The DSOM-040R System on Module uses the Rockhcip RK3588 octa-core 64-bit low-power processor (quad core Cortex-A76 and quad core Cortex-A55), using the advanced 8nm lithography process, with a maximum frequency of up to 2.2GHz. It integrates a 6TOPS NPU and a high-performance quad-core Mali-G610 MP4 GPU, supporting 8K ultra HD display, quad-screen independent display, and powerful hardware decoding capabilities. It is equipped with rich high-speed data communication interfaces and functional interfaces, providing robust, reliable, and highly expandable product support for various AI application scenarios. RK3588
 octa-core CPU 6 Tops
 NPU 4~16GB RAM (optional)
 16~128GB eMMC (optional) SODIMM 314 Pin
 standard interface 8K HD Video
 decoding Rich peripheral
 interface Industrial standard
 -20~85℃ Debian11, Android 12.0, Ubuntu (Desktop / Server), Buildroot, RTLinux kernel Rockchip New-Gen Powerful Octa-core Processor RK3588 Adopt RK3588 octa-core 64bit flagship processor It has a quad-core Cortex-A76 and quad-core Cortex-A55 architecture, with the Cortex-A76 cores running at up to 2.4GHz and the Cortex-A55 cores running at up to 1.8GHz. Support6Topscomputingpower It integrates an ARM Mali-G610 MP4 quad-core GPU, a 6TOPS NPU (Neural Processing Unit), and a dedicated NEON coprocessor, providing powerful performance support. TheplatformsupportsanAMPsystemarchitecturewithacombinationofLinux,RTOS,andBare-metal. One or more cores can run Linux, while the other cores run RTOS or Bare-metal.One or more cores can run Linux, while the other cores run RTOS or Bare-metal. The operating system scheduling is completely isolated, enabling flexible resource partitioning. It also offers microsecond-level interrupt response latency (<5us), meeting the requirements of industrial applications for real-time performance and high stability. 6 TOPS NPU Computing Power for AIoT RK3588 System on Module can work collaboratively or independently, flexibly allocating computing power and avoiding redundancy, achieving a comprehensive computing power of up to 6 TOPS; Introducing INT4/INT8/INT16/FP16 mixed operations, enabling networkmodel conversion based on frameworks such as TensorFlow/MXNet/PyTorch/Caffe, with strong compatibility to meet the edge computing needs of the vast majority of terminal devices. NPU 6Tops Face Recognition AI Computing Power Introducing INT4/INT8/INT16/FP16 mixed Object Recognition operations, enabling network model conversion based on frameworks such as TensorFlow / MXNet / PyTorch / Caffe License Plate Recognition Action Recognition 8K Video Encoding/Decoding, High-Definition Quad-Ccreen Multi-Display The RK3588 SoM supports 8K ultra-high-definition video simultaneous encoding and decoding, supports multi-channel 8K video output and 4K video input, multiple display interfaces (2x HDMI 2.1, 2x DP1.4, 2x MIPI-DSI, BT.1120) can achieve quad-screen multi-display, supporting multi-screen splicing, synchronized display, and independent display, applicable to various high-definition multi-screen interactive display scenarios. Powerful Memory and Rich Interface Get AQuote Supporting Multiple OSs with Open System Architecture DSOM-040R RK3588 SoM supports Android 12.0, Ubuntu Desktop and Server, Debian 11, Buildroot, and RTLinux kernel. Based on the Linux systemkernel, the service layer can be deeply customized and developed, realizing remote device upgrades and management, greatly improving the convenience and efficiency of post-maintenance. Industrial-Grade Standards RK3588 SoM for Harsh Environments Through strict testing and production, the RK3588 SoM product’s reliability, safety, and stability in harsh environments are ensured. With built-in temperature control strategies, it can operate continuously 24/7, whether it’s -20°C extreme cold or 85°C high heat, meeting the needs of industrial-grade applications and suitable for various harsh working environments. Dusun Embedded Mainboard Solution SoMsSecondaryDevelopment EmbeddedMainboard ODM/EMS Providing a stable hardware platform that has been tested by the With decades of experience in AIoThardware design,Dusun IoT market to help partners shorten the productization cycle and quickly focuses on providingzero-to-one  embedded mainboard design  and complete product development. development services forAppliances,Electrical,and Electronics Manufacturers and software developercustomers. Requirements & Product Confirmation Validation of SoM Functionality Carrier Board Development &Guidance Design R & D Manufacturing Product Prototyping & Debugging Mass Production & Shipment Custom Embedded Mainboard System Block Diagram of DSOM-040 Industrial RK3588 SoM Parameters of DSOM-040R Industrial RK3588 System on Module Item Parameter Soc RockChip RK3588 CPU Eight core 64 bit (4 * Cortex-A76 + 4 * Cortex-A55), advanced 8nm technology, with a main frequency of up to 2.2GHz GPU ARM Mali-G610 MP4 quad core GPU, supports OpenGLES3.2/ OpenCL2.2/ Vulkan1.1, 450 GFLOPS NPU NPU has a computing power of up to 6 TOPS, supports INT4/ INT8/ INT16 mixed operations, and can achieve networkmodel conversion based on TensorFlow/ MXNet/ PyTorch/ Caffe and other frameworks ISP Integrated 48MP ISP with HDR&3DNR Encoding and decoding Video decoding: 8K@60fps H.265/ VP9/ AVS2 8K@30fps H.264 AVC/ MVC 4K@60fps AV11080P@60fps MPEG-2/-1/ VC-1/VP8
 Video encoding: 8K@30fps Encoding, supports H.265/H.264 RAM 4GB/ 8GB/ 16GB 64bit LPDDR4/ LPDDR4x FLASH 16GB/ 32GB/ 64GB/ 128GB eMMC Ethernet Integrated PCIe3.0/ 2*GMAC/ SDIO3.0/ USB3.0, expandable multi-gigabit Ethernet, WiFi6, Bluetooth, 5G/4GLTE Video output 2*HDMI2.1（ 8K@60fps or 4K@120fps Reused with eDP,
 2* MIPI-DSI（ 4K@60fps ）
 2* DP1.4（ 8K@30fps Reusable with USB 3.0),
 1*BT.1120（1080P@60fps ） Video input 1*HDMI-IN（ 4K@60fps ）, supports HDCP 2.3,
 2* MIPI CSI (4 Lane), 4 * MIPI CSI (2Lane), or 1* MIPI CSI (4 Lane)+2* MIPI CSI (2Lane)
 2* MIPI DC (4-channel DPHY v2.0 or 3-channel CPHYV1.1),
 1* DVP camera interface (up to 150MHz input data)
 Supports multi-channel 8K video output and 4K video input, with up to seven different displays Audio 2* 8-channel I2S,
 2*2-channel I2S,
 2* SPDIF,
 2* 8-channel PDM (supporting multiple MIC arrays),
 1* dual channel digital audio codec (16 bit DAC),
 1*VAD PCIe PCIe3.0 (2*2lanes,1* 4lanes,4 *1lanes), 3 * PCIE2.0 (1lanes ) SATA 3 * SATA3.0 Watchdog 1* Independent watchdog USB2.0 2* USB2.0 Host, 2* USB2.0 OTG USB3.0 3 * USB3.1(Gen1) UART 10 * UART I2C 9* I2C SPI 5 * SPI ADC 5 * ADC PWM 16 * PWM SDIO 1* SDIO OS Supports Android 12.0, Ubuntu desktop and server versions, Debian11, and Buildroot; Supports RTLinux kernel Specification Wide Range of Application Scenarios The RK3588 SoM has a wide range of application scenarios, which can be applied to smart cockpits, smart big screens, commercial displays, edge computing, IPCs, NVRs, high-end tablets, ARM PCs, AI cameras, AGV intelligent robots, and other terminals. RK3588AI Camera Embedded Mainboard RK3588 High-End AI Tablet Embedded Mainboard RK3588AGV/AMR Embedded Mainboard RK3588Industrial AI edge computing gateway Safety Monitoring AI Robot Edge Computing Industrial and Agricultural Terminal Equipment Large Screen Display Automotive Multi-Screen System ARM PC AIoT Intelligent Terminal Intelligent NVR One-stop Development for IoT Gateways, Industrial Motherboards & System on Modules. Turn IoT Device Development Process into Success. Developing Now
