slide1
LEED for Municipalities:
  • An Overview and Guidelines for Implementation
slide2
Contents

Overview

    • Green Building
    • USGBC
    • LEED
    • Making the Business Case
    • Examples in the Industry

Case Study

    • City of Boulder Process
    • Funding and Allocation
    • Consultant Process
    • Recommendations
    • Next Steps

Tools and Resources

slide3

Environmental Impact of U.S. Buildings

  • 65.2% of total U.S. electricity consumption
  • > 36% of total U.S. primary energy use
  • 30% of total U.S. greenhouse gas emissions
  • 136 million tons of U.S. construction and demolition waste
  • 12% of potable water in the U.S.
  • 40% (3 billion tons annually) of raw materials use globally
slide4
Defining Green Design
  • Green
  • High Performance
  • Ecological
  • Sustainable
  • Whole System
  • Restorative
  • Regenerative
  • Elegant
  • Efficient
  • Resource Conservation
  • Cost Effective

Use the language which appeals to your audience

slide5

Benefits of Green Building

Economic

    • Reduce operating costs
    • Increase building valuation, occupancy, ROI
    • Productivity

Health and Safety

    • Enhance occupant comfort and health
    • Reduce liability

Community

    • Minimize strain on local infrastructures and improve quality of life

Environment

    • Reduce the impacts of natural resource consumption
slide6
U.S. Green Building Council
  • Non-profit organization based in Washington, DC
  • Membership by companies across building industry
  • Consensus driven
  • Goal of market transformation towards green building

“As a balanced, consensus coalition representing the entire building industry, the USGBC promotes the design, construction, and operation of buildings that are environmentally responsible, profitable, and healthy places to live and work.”

slide7

LEED Green Building Rating System

  • Leadership in Energy & Environmental Design (LEED)
  • Third Party Verification / Certification of Performance
  • Tool for Team / Building Integration
  • Checklist of Greening Strategies
  • Defines “Green” Building
  • Sets Quantifiable Targets and Goals
  • Tool for Benchmark and Comparison Across Buildings
slide8

Applying LEED

  • Checklist of Available Strategies / Points
  • Contains Prerequisites and Credits
  • Requires Team Wide Collaboration / Participation
  • Initiate (Register) During Design
  • Certify After Occupancy
slide9

LEED Products

  • New Construction (NC)
  • Existing Buildings (EB)
  • Commercial Interiors (CI)

Under Development

  • Core and Shell (CS)
  • Home (H)
  • Neighborhood Developments (ND)
slide10
LEED Application Guides
  • Under Development
  • Lodging
  • Campus
  • Retail
  • Healthcare
  • Laboratories
  • Schools

LEED was designed for commercial projects. These guides support application in other project types.

slide11

LEED Categories

SustainableSites (1 prerequisites / 14 points)

WaterEfficiency (0 prerequisites / 5 points)

EnergyandAtmosphere (3 prerequisites / 17 points)

MaterialsandResources (1 prerequisites / 13 points)

IndoorEnvironmentalQuality (2 prerequisites / 15 points)

slide12

LEED-NC Levels of Certification

Total Points = 69

Certification at Four Levels:

  • Certified (26- 32 points)
  • Silver (33-38 points)
  • Gold (39-51 points)
  • Platinum (52 + points)

Basic LEED Certification is designed to be one step above code, and ratchets up along side code and standard practice.

slide13

LEED Certification Process

  • Identify target points

(not every credit is appropriate for every project)

  • Register project with USGBC declaring intent to use LEED ($750-$3,000 fee based on size)
  • Identify responsible team members for each point

(this is an integrated effort)

  • Collect and submit documentation
  • Building Certification

($1,500-$7,500 fee based on size)

documenting leed compliance
Documenting LEED Compliance
  • Signed Letter Template declaring achievement
  • Supporting documentation in some cases, including calculations, plans, cut sheets, etc.
slide15
Cost of Green Building: Factors
  • Location
  • Baseline
  • Owner/ Team Values
  • Climate
  • Timing of Implementation
  • Building Size
  • Building Scope
  • How Much Does it Cost to Build Green… It Depends.
slide16
Cost of Green Building and LEED
  • Studies show a 0-3% average premium on total project costs for LEEDbuildings with <5 year payback
  • Costs are generally attributed to increased design time, modeling and commissioning
  • Studies show that costs associated with LEED are reduced / eliminated with team experience
  • From a life-cycle perspective (costs over time) green building and LEED are generally considered a good investment
slide17
RFP Language to Avoid Inflated Bid Costs
  • “Contractor shall….”
  • “…Deliver a finished work product that assists the owner in achieving a LEED Certification for the building”
  • NOT
  • “…Ensure that the building achieves LEED Certification”
slide18

Other Rating System Tools

  • EPA Energy Star Portfolio Manager
    • Addresses opportunities related to energy only
    • Limited to specific building types within existing database
  • GreenGlobes
    • On-line questionnaire
    • Linked to EPA Target Finder (with limited database)
    • 150 yes / no / NA questions in 7 category areas
    • Not consensus based
    • Not science based
slide19

LEED in the Marketplace

~ 5% of Commercial Buildings in U.S.

~ 250 Certified Projects (NC, EB and CI)

~ 2000 Registered Projects (NC, EB and CI)

USGBC is targeting a 25% market penetration with LEED

As of 5.05

slide22

LEED Users by State

Every State in the U.S. has LEED Registered Project(s)

leed nc users
LEED-NC Users

State

Municipal

  • California
  • Maryland
  • Massachusetts
  • New Jersey
  • New York
  • Oregon
  • Pennsylvania
  • Washington
  • Austin, TX
  • Boston, MA
  • Boulder, CO
  • Chicago, IL
  • Los Angeles, CA
  • Portland, OR
  • San Jose, CA
  • San Francisco, CA
  • Seattle, WA

*Not limited to these examples

slide24
LEED Application for Municipalities
  • Portland, OR
  • Requires that all city owned new construction projects meet LEED-NC Gold
  • Requires that all tenant improvements to city owned facilities meet LEED-CI Silver
  • Requires that all city operations and maintenance meet local guidelines which are designed to meet LEED-EB
  • Cook County, IL
  • All county projects must meet LEED certification including 8 LEED EAc1 Energy Optimization credits (50% cost reduction compared to ASHRAE)
slide25
LEED Application
  • Atlanta, GA
  • All city funded projects over 5k SF or
  • $2 million must meet LEED Silver. Exempt projects must complete LEED checklist.
  • Arlington, VA
  • All site plan applications must include a completed LEED scorecard and have a LEED-AP on the team
  • Projects that earn LEED Silver can develop at a higher density
  • All projects contribute to a green building fund which is refunded if project earns LEED certification
slide26
LEED Application
  • Calabasas, CA
  • All non-residential city and privately owned buildings between 500-5,000 SF must meet LEED Certified level
  • Building over 5,000 SF must meet LEED Silver
  • Frisco, TX
  • All non-single family residential developments must submit a LEED checklist completed by a LEED-AP and with a cost estimate for each point
  • Issaquah, WA
  • Developers intending to use LEED receive free consultation (provided by City) and are placed at head of permit review line
slide27
Application of Green Building Programs: Factors
  • City structure
  • City leadership
  • Funding
  • Departments
  • Education
  • Incentives
  • Cities have different frameworks and challenges to enable innovative and effective programs
slide28
Colorado’s Building Climate
  • No State adopted building and energy code
  • “Home rule” State
  • Supports voluntary compliance
  • Supports energy and resource efficiency
  • Supports early adopters
slide29

LEED Certified Projects in Colorado

  • CH2M Hill (3 buildings)
  • Belmar 2M3
  • Boulder Recreation Center
  • Boulder Community Hospital
  • Denver Place
  • Russell T. Tutt Science Center
  • U.S. Department of Transportation
  • Snowmass Golf Clubhouse
  • Aspen Sundeck
  • Colorado Springs Utilities Laboratory

Additionally there are over 35 registered projects

7.05

slide30
The Boulder Story: Background
  • Conscious History of Land Use Planning
  • Guiding Documents
  • Supporting Policies
  • Community Involvement
slide31
The Boulder Story:
  • City Departments and Funding
  • Invested departments
  • Interdepartmental partnerships
  • State funding
  • Departments’ funding allocation
  • Business process
  • Long-term budget process
slide32
The Boulder Story
  • LEED Consultant and Local Developerteam up
  • Cross-education (what is LEED? What isn’t LEED?)
  • Building and Land Use Code / LEED Comparison
    • Barriers
    • Local Climate/ Cultural Considerations
    • Implementation Considerations
  • Charrettes with City staff to review thoughts and findings along the way

How can we use LEED to inform Boulder codes and support better commercial building practices?

slide33
The Boulder Story: Evaluation
  • LEED / Green Building strategies were evaluated with
  • regards to:
  • Cost Impact
    • To the Builder
  • Environmental and Community Benefit
    • Overall
  • Implementation Difficulty
    • For the City
slide34
The Boulder Story: Requiring LEED?
  • Initiated process with goal of making code equivalent to LEED certified level
  • Difficult to codify enough LEED credits that all commercial buildings meet LEED (26 points)
  • Focused on eliminating barriers to pursuing LEED
  • Focused on meeting the intent of LEED with regards to the effectiveness of green building
slide35
The Boulder Story: Requiring LEED?
  • Showers in Boulder?
  • Require operable windows?
  • Reduced development footprint?
  • Required material and product specifications?
    • Paints?
    • Carpet?
    • Composite wood?
    • Recycled content?

LEED is not a code, it is an effective and integrated benchmarking tool. LEED can be used to frame opportunities for resource and cost effective building.

slide36
The Boulder Story: Code Recommendations
  • Require bike racks and carpool parking for 5% of occupants or 1 rack / 2,000 SF
  • Require light colored / shaded paving and roofing
  • Limit irrigation water availability / require xeriscaping
  • Eliminate barriers to waterless urinals and composting toilets
  • Require independent building commissioning > 10k SF
  • Require energy analysis > 20k SF
  • Require job site recycling
  • Require CO2 monitoring
  • Require air quality management plan/ implementation
  • *Not limited to these examples
slide37
The Boulder Story: Recommended Incentives
  • How to support building specific applications of effective green strategies?

Green Building Fund

      • All projects pay into fund - Refunded if certified

Valuation Exemption

      • Green products excepted from permit valuation

Density Bonus

      • Site density allowance bonuses for certification

Fast Track Review

      • LEED projects “move to the head of the line”

Energy Efficiency Certification

      • License private professionals to review and verify energy requirements, streamlining City process
slide38
The Boulder Story:

Challenges to Implementation

Department ownership & prioritization

Business process

Staff resources

Budget cycle

Staff education & training

Integration of existing process vs. new process

slide39
The Boulder Story: Next Steps
  • Internal City prioritization – Goal Committee
  • Stakeholder sessions to gather input, strengthen plan, & solicit recommendations
  • Stakeholder review of proposed changes
  • Internal City budget & funding
  • Internal City staff education / training
  • Workshops & fact sheets for public
  • Community educational events / training
slide40
Greening the City: Action Steps
  • Understand what it is costing to NOT build green
  • Examine zoning, permits, codes and procedures for barriers to building green
  • Set short and long term goals
  • Identify champions and track implementation
  • Integrate team upfront
  • Adopt standards
  • Identify and implement low hanging fruit
  • Provide incentives
  • Measure benefits
  • Ongoing education
slide41
www.usgbc.org/chapters/colorado
  • Learn about green building
  • Advocacy support
  • Gain recognition as a green professional
  • Local materials database
  • Guidelines for selecting green professionals
slide42
For more information contact:
  • Elizabeth Vasatka, City of Boulder
  • 303-441-1964 / Vasatkae@ci.boulder.co.us
  • Lauren Yarmuth Denner, DOMANI
  • 303-232-0193 / Lauren.denner@domani-llc.com
