AC-Flexure Test02-17-04 Updated03-02-04
AC-Flexure Test02-17-04 Updated03-02-04. Moment Load about E-W Axis-1. W into page. XY Stage. Box. S. N. 20 lbs +/-5%. George. Brace 2 Plcs. AO-Spool. Result of 20 lbs load: .005 inch flexure at point of application of load. Pivot Point. E. Moment Load about E-W Axis-2.
