2. MEDICAL OXYGEN CONCENTRATOR AM-OC14 Medical Oxygen Concentrator is a highly efficient low power consumption equipment in which oxygen is produced within 3 minutes when the power is on and its purity is high up to 93%±3%. It is designed with internal modules and an integrated system of oxygen modules for an easy and fast installation of the equipment. Likewise, it is connected through an alarm system, a photosensitive LED display, a monitor to check the oxygen purity, etc., are required to operate the equipment easily. Features LED display, alarm system, oxygen purity monitor, power failure alarms High efficient, low power consumption design with integrated oxygen module system for easy installation Internally modularized and oxygen is produced with high purity Highly efficient Lithium molecule useful for 30,000 hours of operation HEAP high-efficient filter to ensure pure and sterile oxygen Noise is less than 49dB Oil-free patented compressor Lifetime 25000 hours Specifications Model AM-OC14 Flow Rate 5 L/min adjustable Purity 93%±3% Power Supply 220 V/50 Hz or 110 V/60 Hz Power Consumption 300 VA Noise 52 dB Compressor pure copper oil free compressor Molecular Sieve Z12 to 07 Filter HEAP high efficiency filter Alarm Power failure, Over-heat, Low O2 purity alarm Operation Environment Temperature: 5 0C to 40 0C Humidity≤80% Atmospheric pressure: 86 kPa to 106 kPa

3. MEDICAL OXYGEN CONCENTRATOR AM-OC14 Dimension 335x320x620 mm Packing Size 445x390x755 mm Net Weight 16.2 kgs Gross Weight 18.7 kgs ACCESSORIES Nasal Cannula Adult mask Humidifier bottle Oxygen tube Nebulizer cup(optional) Applications Use air as raw material, use molecular sieve to transform pressure attach process to produce oxygen with a concentration range of 90% to 96%.
