  1. The various ventilation options for poultry houses

  2. Index • About Ventilation system • About Fan EM 50 and its advantages • What is Cooling (Humidity) Pads? • What is 36" Fan?

  3. https://dhumal.com/new-design/ventilation

  4. Ventilation • The damages of extreme heat can be devastating. Heat stress causes extreme discomfort to the birds and high temperatures can limit bird growth. • Evaporative cooling is a very effective way to reduce heat stress and can drop the temperature inside the poultry house by 7 to 8 degrees Celsius. • This can often translate into the difference between mortality and livability.

  5. Fan EM 50 • The Shutter is traditionally the weak point in Conventional fans. • But in this fan shutter the system which utilizes centrifugal energy generated by propeller to open the shutter has the following advantages : • Counter weights are not required. • Shutters are always fully opened when fan is operating and are not affected by wind or dust accumulations. • Shutters will not stick or hang if they are not periodically cleaned.

  6. Shutters are tightly closed when fan is not operating. • Because shutters are fully opened when the fan is operating shutter pressure drop is minimized. • Shutter waving never occurs. • Shutters are in galvanized steel, which is much stronger than ordinary aluminium shutter fan

  7. Cooling (Humidity) Pads • When air is moved by a ventilation, system goes through a wet cooling pad, the air humidity increases. • The energy that is lost in the evaporation of the water results in reduction of air temperature. • Evaporative cooling is a natural process and is used throughout the world for following reasons :

  8. High Temperature Reduction • Low Energy Usage • Low Purchasing and Installation Cost • Good performance even in areas where water quality is poor • Low maintenance cost

  9. 36" Fan • Air cooling fans are used for maintaining good air circulation and temperature in poultry farms. • Our 36” air circulating fans can be used for various applications, like poultry farms, industrial buildings etc., • providing high efficiency. These fans are available in both single phase and three phase motor option. • In order to get an aerodynamic air flow, this fan is designed with a wide inlet and outlet opening and aerodynamic blade shape to cut the air at inlet and spread it evenly all over the flow area. • A high grade quality material and latest technology is used in manufacturing these air circulating fans. • Fan hanging option available, with adjustable angle of fan to get the air flow as per requirement

  10. Advantages • Quick and easy to install. • Low running cost and Low noise operation. • Statically and dynamically balanced body, resulting in low vibration and good stability of fan. • Considering the poultry use, these fans have been designed and made to sustain in dusty and moist environment in the poultry house. • Running on as low as 1/2 HP (370 W) motor with 960 rpm, which can reach the air at a distance of about 50 feet. • It controls the mortality rate during the months of summer • Wire guard safety provided on both side of fan, and designed to restrict the entry of big rats into the fan resulting in no damage of fan rotating parts. • These air circulating fans have non-corrosive housing and based on advanced working principle. • Fan is portable and can be made to stand even on rough surfaces. • Ensures high performance and longer service life.

  11. For more details • https://dhumal.com/
